Heinner HWM-6120 User manual

Automatic washing-machine
Model: HWM-6120
EN Instruction manual
www.heinner.com
1/74

CONTENTS
CHAPTER-1: BEFORE USING THE APPLIANCE
• Correct Usage 4-5
• General warnings 6-7-8-9
• Safety warnings 10-11-12-13-14
•Packaging and Environment 15
• Savings Information 16
CHAPTER-2: OVERVIEW OF YOUR DEVICE
• General Appearance 17-18
• Specifications 19
CHAPTER-3: INSTALLATION
• Removing transportation safety screws 20-21
• Adjusting Adjustable Stays 22-23-24
• Electrical connection 25
• Water inlet hose connection 26-27
• Water discharge connection 28
CHAPTER-4: INTRODUCTION OF CONTROL PANEL 29
• Detergent drawer 30-31
• Programme knob 32
• Electronic display 33-34
CHAPTER-5: PRELIMINARY PREPARATION FOR LAUNDERING
•Separating laundries 35-36
• Putting laundries in the machine 37
• Adding detergent into machine 38
• Operating your machine 39-40-41
• Auxiliary Functions 42-43-44-45-46-47
• Child lock 48
• Cancelling programme 49
• Finishing programme 50
CHAPTER-6: PROGRAM TABLE 51-52-53-54-55-56-57-58
CHAPTER-7: MAINTENANCE AND CLEANING OF YOUR MACHINE WARNıNG 59
• Water inlet filters 60
• Pump filter 61-62
• Detergent drawer 63
CHAPTER-8: FLUSH STOPPER / BODY / DRUM 64
CHAPTER-9: TROUBLESHOOTING 65-66-67-68-69
CHAPTER-10: AUTOMATIC FAULT WARNINGS AND WHAT TO BE DONE 70
CHAPTER-11: PRACTICAL INFORMATION 71-72-73-74
•How to read the energy label and saving energy 75-76
•Disposal of your old machine 77
www.heinner.com
2/74

CHAPTER -1: BEFORE USING THE
APPLIANCE (CORRECT USAGE)
• Definitely read the user’s manual.
•Your machine is designed to be
used domestically. Commercial use will
cause your warranty to be cancelled.
•Keep your pets away from your machine
•Please check the packaging of your machine
before installation, and the outer surface after the package is opened. Do
not operate damaged machines or machines with opened package.
•Have your machine installed only by authorized service. Any interference to
your machine by anyone other than authorized services shall cause your
warranty to be void.
•The appliance is not intended for use by people (including children) with
reduced physical,
sensory or mental capabilities, or lack of experience and knowledge unless
they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
www.heinner.com
3/74

•Use your machine only for laundries that
have been specified as suitable for washing by the manufacturer.
• Before operating the washing machine,
remove the 4 transportation screws and rubber spacers from the back of the
machine. If the screws are not removed, it may cause heavy vibration, noise and
product malfunction, (voiding the guarantee).
•Your machine is not covered under warranty
for faults caused by any kind of external factors (pesticides, fire, etc.).
•Please do not throw away this user manual;
keep it for future reference. You or somebody else might need it in the future.
Note: Machinery specifications may vary depending on the product
purchased.
•The necessary ambient temperature for your
machine’s ideal operation is 15-25°.
•Frozen hoses can tear and explode. In regions
where temperature is below zero, ambient temperature might endanger the safe
operation of electronic card.
•Please ensure that the clothes you will place
in your machine do not contain any foreign substances (nail, needle, coins, lighter,
matches, clip etc.) in their pockets. These foreign substances can damage your
machine.
•Before starting to use your machine, you may
call the nearest authorized service and request free-of-charge help for installation,
operation and use of your machine.
•It is recommended to perform the first
washing operation in 90˚ Cotton programme and without laundry by inserting ½
scale of detergent in 2nd compartment of the detergent drawer.
www.heinner.com
4/74

•As detergent or softener exposed to air for a
long time may cause residues, put your detergent or softener in the detergent
drawer at the beginning of every washing.
•It is advised that you unplug your machine
and close the water inlet tap if you will not use your machine for a long time.
Also, leaving the door of your machine will prevent the formation of bad odors
due to humidity.
•Some water might be left in your machine
after the trials and tests conducted due to Quality Control procedures.
This will not damage your machine.
•Remember that packaging materials of your
machine may be dangerous for children. Keep the packaging materials in a
place where children cannot reach or dispose of them appropriately.
•Keep the small parts found in the document
part away from the reach of children and babies.
•Use pre-wash programs only for very dirty laundry.
www.heinner.com
5/74

•Never open the detergent compartment when the
appliance is running.
•In case of any breakdown, unplug the appliance
first and then turn the tap off. Do not attempt to
repair by yourself, always contact for authorized
service advice.
•The amount of laundry you put in
your washing machine should not exceed the maximum amount
indicated.
•Never force the door to open when the machine
is running.
•Washing floury clothes in your machine
damages the machine. Do not wash
floury clothes in your machine.
www.heinner.com
6/74

•Please adhere to detergent/fabric conditioner
manufacturers’ advice regarding the use of fabric conditioner or similar
products in your machine.
•Set up your machine in a place where its
door can be completely opened. (Do not set up your machine in places where its
door cannot be fully opened.)
•Set up your machine at locations that can
be fully ventilated and could have constant air circulation.
CHAPTER -1: BEFORE USING THE APPLIANCE
(SAFETY WARNINGS)
You must read these warnings. You can thus protect yourself and your
beloved ones against fatal injuries and risks.
DANGER OF GETTING BURNT!
Do not touch discharging hose and water during discharging as the
appliance may reach high temperatures when running.
www.heinner.com
7/74

DEATH RISK DUE TO ELECTRICAL CURRENT!
•Do not use multiple
receptacles or extension cord.
•Do not plug in damaged plug sockets.
•Never pull the cable when
unplugging always grip the plug itself.
•Do not plug-in or out the plug from the receptacle
with wet hands to prevent electrocution!
•Never touch the machine with wet hands or feet.
•Call the nearest authorized
service for a replacement if the power cord
malfunctions.
www.heinner.com
8/74

Flooding risk!
•Check whether the water runs fast or not
before placing the discharge hose on the sink.
•Take necessary measures to prevent the
slipping of your hose.
•The backfiring force of a hose that is not
placed appropriately can displace the hose. Prevent the stopper inside
your sink from blocking the sink hole.
www.heinner.com
9/74

Danger of Fire!
•Do not keep inflammable liquids near your machine.
•The sulphure content of paint removers might cause corrosion. For this
reason, never use paint-removing materials in your machine.
•Never use products that contain solvent material (like washing gas) in
your machine.
•Remove all the objects in the pockets of your laundries (needle,
paperclip, lighter, matches etc.) when placing them your machine.
Fire and Explosion risk may occur.
www.heinner.com
10/74

Fall and injury hazard!
•Do not climb on your machine. The upper table
of your machine may break and you might get injured.
•Tidy the hose, cable and packaging of your
machine during installation. You might trip over and fall.
•Do not turn your machine upside down, or on its side.
•Do not lift your machine by holding it from
extruding parts (detergent drawer, door). These parts might break and
cause you to get injured.
•There’s the risk of tripping and injury if the materials like hose and cables
are not properly stored after your machine is installed.
Machine must be carried by 2 people or more.
www.heinner.com
11/74

Child safety!
•Do not leave children unattended near the machine.
Children might lock themselves up into the machine and
death risk might occur.
•Door glass and surface might be extremely hot while
your machine
operates. Thus, especially touching the machine might
give damage to the
skins of children.
•Keep packaging material away from children.
•Poisoning might occur if the detergent and maintenance materials are
consumed, and eyes or the skin might be irritated if they come into contact with
the skin. Keep the cleaning materials away from the reach of children.
www.heinner.com
12/74

Removal of packaging materials Packaging materials protect your machine
from any damage that might occur during transportation. Packaging materials
are environment friendly as they are recyclable.
Recycling material provides both raw material savings and decreases waste
production.
Disposal of old machine
Electrical or electronical old devices might still contain salvagable
parts. So, never throw away your old devices that you do not use
into the waste.
Ensure that the parts of your old electronic or electrical devices are reused
by giving them to the gathering centres foreseen by related authorities.
Please ensure your old appliances are kept in an appropriate place for
the safety of children until they are taken outside the house.
Some important information to get more efficiency out of your
machine:
•The amount of laundry you put in your washing
machine should not exceed the maximum amount indicated.
•By this way, your machine shall run in saving mode.
•Not using the pre-wash feature for little and normal-dirty laundry shall save
electricity and water.
www.heinner.com
13/74

CHAPTER -2: OVERVIEW OF YOUR DEVICE GENERAL
APPEARANCE
Electronic display
Programme knob
Upper Tray
Detergent drawer
Container
Cover of pump filter
www.heinner.com
14/74

Transportation Safety Screw Water
Inlet Valve
Discharging Hose
Power Cable
Transportation Safety Screw
Transportation Safety Screw
Transportation Safety Screw
www.heinner.com
15/74

Operating voltage /
frequency (V/Hz) (220-240) V~/50Hz
Total current (A) 10
Water pressure Maximum: 1 Mpa Minimum : 0.1 Mpa
Total power (W) 2200
Maximum dry laundry
capacity (kg) 6
Spinning revolution
(rev / min) 1200
Programme number 15
Dimensions
(Height x Width x Depth) (mm) 845 x 597 x 527
www.heinner.com
16/74

CHAPTER -3: INSTALLATION REMOVING
TRANSPORTATION SAFETY SCREW
Before operating the washing machine,
remove the 4 transportation screws and
rubber spacers from the back of the
machine. If the screws are not
removed, it may cause heavy vibration,
noise and product malfunction, (voiding
the guarantee).
For this reason, transportation safety
screws shall be loosened by being
rotated in counter-clockwise using an
appropriate wrench.
www.heinner.com
17/74

Transportation screws shall be removed
by pulling out.
Fit the plastic transportation screw taps
delivered in accessories bag to the
palces where transportation screws have
been removed.
The transportation safety screws should
be stored to be used in case of
transportation.
NOTE: You should absolutely remove
the transportation screws of your
machine before the first usage.
Faults occurring in the machines
operated with transportation screw fitted
shall be out of scope of warranty.
www.heinner.com
18/74

Adjusting Adjustable Stays
•Do not install your machine on a carpet or such grounds
that would prevent the ventilation of its base.
•To ensure silent and vibration-free operation of your machine,
it should be deployed on a non-sliding and firm ground.
•You can adjust the balance of your machine through the stays.
•Loosen the plastic adjustment nut.
www.heinner.com
19/74

•Adjust the stays upward and downward by rotating them.
•After maintaining the balance, compress the plastic
adjustment nut upward again.
www.heinner.com
20/74
