Heliospectra MITRA MI65SF User manual
MITRA
Quick Set Up Guide
When unpacking the luminaire make sure to have a sturdy
surface to work on. Damage to the unit can occur if dropped.
Do not immerse the xture in water or clean the xture with a
high-pressure water jet or strong detergents.
Never operate the xture with the LED board directly on a
at surface (e.g. table) as this may damage the LED board.
A minimum distance of 0.2m/8in should be kept to other
objects.
The product is for indoor use only.
Always allow a free ow of air around the xture. A minimum
distance of 0.2m/8in should be kept to other objects. Blocked
airow might overheat and damage the xture.
This xture may only be serviced by a trained technician. In the
case of a suspected malfunction contact your distributor or
Heliospectra directly.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a similar
qualied person.
The luminaire should be positioned so that prolonged staring
into the luminaire at a distance closer than 1 meter/ 40 inches
is avoided.
Do not stare into the light source. LED grow lights may contain
potentially harmful light radiation. Please use UV blocking
eyewear when working in and around the illuminated area.
Only connect the xture to properly grounded mains that
complies with the voltage rating on the xture (see power
label).
Only operate the xture with an undamaged power cord,
power plug and electrical outlet.
Never unplug the xture by pulling on the power cord.
For proper performance of the unit the ambient air
temperature shall be no higher than 40° C.
Quand vous déballez le luminaire, assurez-vous d’avoir une
surface solide sur laquelle travailler. L’appareil peut être
endommagé si on le fait tomber.
N’immergez pas l’appareil dans l’eau et n’essayez pas de
le nettoyer avec un jet d’eau à haute pression ou avec des
produits détergents.
Ne pas mettre en marche le luminaire lorsque la platine LED
est posée à plat sur quelconque surface (par exemple : une
table), cela pourrait endommager la platine LED. Respectez
une distance minimum de 0,2 m/8 po entre l’appareil et les
autres objets.
Le produit ne s’utilise qu’en intérieur.
Assurez-vous qu’il y ait un minimum d’air autour de l’appareil.
Respectez une distance minimum de 0,2 m/8 po entre
l’appareil et les autres objets. Le blocage de la circulation de
l’air pourrait causer une surchauffe et endommager l’appareil.
Cet appareil ne peut être entretenu que par un technicien
expérimenté. Si vous avez un doute sur le bon fonctionnement
de celui-ci, contactez votre distributeur ou Heliospectra
directement.
La source de lumière contenue dans ce luminaire ne doit-être
remplacée que par le fabricant, ses agents de services ou une
personne également qualiée pour le faire.
Le luminaire doit être positionné de telle sorte qu’il soit
impossible de le xer longuement à une distance de un
mètre/40 pouces soit évité.
Ne pas regarder xement la source de lumière. Les éclairages
LED pourraient potentiellement contenir des radiations
lumineuses nocives. Portez des lunettes anti-rayons UV quand
vous travaillez sous ou à proximité de l’endroit éclairé.
Ne connectez l’appareil que sur une prise reliée à la terre et
dont la tension correspond à celui de l’appareil (voir l’étiquette
concernant la puissance).
L’appareil doit être uniquement mis en marche avec une prise,
un cordon électrique ou une prise secteur en bon état.
Ne jamais déconnecter l’appareil en tirant sur le cordon
électrique.
Pour une utilisation optimale de l’appareil, la température
ambiante ne doit pas dépasser 40 °C.
Precautions
Our product is an advanced and safe LED
xture. However, for proper operation and for
your safety, please read and follow the below
precautions:
Le produit est un appareil à LED moderne
et sûr. Néanmoins pour l’utiliser correctement
et en toute sécurité, veuillez lire les informa-
tions ci-dessous:
Version 8. Published 2022-04-26©2011–2022 by Heliospectra AB. All rights reserved.
MITRA linear has pre-mounted C-brackets (42mm/1.65in). MITRA
Square and MITRA Split have a series of holes in the side mounts
designed to t an eye-hook for mounting with chains or wires.
DRAWN
CHK'D
APPV'D
MFG
Q.A
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS
SURFACE FINISH:
TOLERANCES:
LINEAR:
ANGULAR:
FINISH:
DEBURR AND
BREAK SHARP
EDGES
NAME
SIGNATURE
DATE
MATERIAL:
DO NOT SCALE DRAWING
REVISION
TITLE:
DWG NO.
SCALE:4.5:1
SHEET 2 OF 2
A0
WEIGHT:
MITRA manual PSU closeup
MITRA PSU
Standard
A A
B B
C C
D D
E E
F F
G G
H H
J J
K K
L L
M M
N N
P P
R R
T T
24
24
23
23
22
22
21
21
20
20
19
19
18
18
17
17
16
16
15
15
14
14
13
13
12
12
11
11
10
10
9
9
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
The PSU casing off model MIPSU01
has pre-cut holes on the top and
back to allow you to t your chosen
hanging apparatus.
The PSU models MIPSU03 and
MIPSU04 have a backplate which is
prepared for mounting with chains.
1
2
3
Connect the lamps PSU connector to the PSUs
Lamp connector.
Connect the Dimming connector to the pre-
ferred dimming solution.
Connect the Power cable to the power mains.
Installation of the Luminaire needs to be conducted by a licensed electrician.
Luminaires must be installed with adequate surge protection according to the
IEEE 1100-2005 recommended practice or, in Europe, the IEC 62305 standard.
One-point
chain mounting.
Two-point
chain mounting.
MIPSU01 MIPSU03 & MIPSU04
NOTE. Heliospectras recommendation for installations using chain:
Welded chain with a diameter of 2-3 mm (1/16 - 1/8 in).
Working load limit: Minimum 4 times the total weight of the equipment.
Pre-cut mounting
holes
Electrical Installation
Mounting
Version 8. Published 2022-04-26©2011–2022 by Heliospectra AB. All rights reserved.
SQUARE
(MI65SF, MI65SV, MI65SB)
LINEAR
(MI65LF, MI65LV, MI65LB)
SPLIT
(MI65LFS, MI65LVS, MI65LBS)
Electrical
Voltage Range 200 - 480 VAC 200- 480 VAC 200 - 480 VAC
Frequency 50/60 Hz 50/60 Hz 50/60 Hz
Typical Power
Consumption 0-650 W 0-650 W 0-650 W
Physical
Weight 12 kg (26.5 lbs)
excl. power supply
13,5 kg (29.7 lbs)
excl. power supply
13,5 kg (29.7 lbs)
excl. power supply
Size
580 x 630 x 88 mm
22.8 x 24.8 x 3.5 in
(L x W x H)
1100 x 340 x 88 mm
43.3 x 13.4 x 3.5 in
(L x W x H)
1100 x 140 x 88 mm
43.3 x 5.5 x 3.5 in
(L x W x H)
Temperature Operating: -10-40°C (14-104 F)
Storage: -20-70°C (-4-158 F)
Operating: -10-40°C (14-104 F)
Storage: -20-70°C (-4-158 F)
Operating: -10-40°C (14-104 F)
Storage: -20-70°C (-4-158 F)
Heat Value
(BTU/h) Up to 2218 BTUs/hr Up to 2218 BTUs/hr Up to 2218 BTUs/hr
IP Rating IP67 IP67 IP67
Lifetime Q90 > 46 000 hrs Q90 > 46 000 hrs Q90 > 46 000 hrs
Controllable 0-10V Dimming 0-10V Dimming 0-10V Dimming
Cooling Passive - Convection cooled Passive - Convection cooled Passive - Convection cooled
Housing
Material
ABS plastic and Anodized
Aluminum
Diffuser : Highly transmissive
acrylic glass
ABS plastic and Anodized
Aluminum
Diffuser : Highly transmissive
acrylic glass
ABS plastic and Anodized
Aluminum
Diffuser : Highly transmissive
acrylic glass
Compliance CE, cETLus, and Damp Location CE, cETLus, and Damp Location CE, cETLus, and Damp Location
Hanging
Attachments Hole prole C-bracket Hole prole
Telephone
+46 31 40 67 10 (SWE) +1 (888) 942 GROW (US)
+1 (437) 922 6677(CAN) +81 (0) 90 1432 1993 (JP)
Email
Website
www.heliospectra.com
Heliospectra AB
Fiskhamnsgatan 2
SE-414 58 Göteborg
Sweden
For more information on our products, support articles and full product manuals, please
visit our support portal at support.heliospectra.com,
or scan the QR code to go straight there.
