Sky Light TINY RH User guide

SKYLIGHT
SKYLIGHT TINY RH/RV installation and safety manual EN
www.skylight.blue
SKYLIGHT
1/2
SL_TINY RH/RV_Instruction manual_EN_v1_0_20180617
1. Features
The SKYLIGHT TINY RH/RV lamps were designed for
vivariums equipped with a glass top. Lamps were designed for
terrariums with living plants. The spectrum of light emitted by
these lamps is suitable for the proper photosynthesis process,
making these products suitable for growing even the most
demanding plant species.
SKYLIGHT PRO RH/RV/H/V are offered as set of 1 up to 8
independent lamps, and are suitable for several smaller
vivariums or one larger enclosure with a width up to 150 cm
and height up to 100 cm depending on the setup.
Parameters of a single SKYLIGHT TINY RH/RV:
Dimensions: 11x9x1,5 cm
Power rating: 6 W
Luminous flux: 700 lm
Colour temperature: 6000 K
CRI: typ. 92
Viewing angle: 120o(RH) lub 60o(RV)
Voltage rating: 12 V DC (only use a dedicated power supply*))
2. Safety instructions
The product is only intended to be used for vivarium lighting,
indoors and at room temperature.
Follow the installation instructions. Do not install the lamp
inside the terrarium and protect it from water.
Keep children and pets other than your terrarium animals
away from the lamp.
Do not use a mechanically damaged device, do not modify
the construction. Do not switch on the device if any cable
(including the power supply) is damaged.
Only intended to be used with one of the dedicated power
supplies*).
Do not exceed electrical ratings!
Do not look directly into the light source.
Turn the lamp only after it is installed
on the terrarium top.
Do not cover the lamp with rugs or blankets.
3. Installation instructions
The SKYLIGHT TINY RH/RV lamps should be placed on
the glass top of the vivarium.
The PMMA glass cover of the LED module should be cleaned
using a soft cloth. Do not clean the lamp when it is turned on.
The power supply plug (5.5x2.1 mm) should be installed in
the SKYLIGHT PRO RH/RV socket before the power supply
mains plug is connected to the timer.
*)List of compatible power supplies:
For 1 TINY RH/RV:
For 2-4 TINY RH/RV:
For 5-8 TINY RH/RV:
SYS1001-1212-T2
SYS1588-3012-T2
SYS1548-6512-T2
or other power supplies with identical parameters.
CAUTION:
Using an inappropriate power supply will result in damage
to the lamp or power supply itself!
4. Repairs and utilization
Do not try to repair a damaged lamp. For information about
lamp service contact your supplier. The LED module in
this lamp is not intended to be replaced by unqualified
personnel. LED modules are available from your supplier,
contact them for details.
Product cannot be disposed of as unsorted municipal waste.
According to the directive 2012/19/UE, the device
should be disposed of at designated collection points.
5. Warranty
SKYLIGHT warrants this product to be free of defects in
material and workmanship under normal use for 2 years from
the date of purchase. The obligation of this warranty is
limited to the repair or replacement of defected elements.
No claim shall be allowed under this warranty if, in the
opinion of SKYLIGHT, this product has been subject to
accident or improper usage, including, but not limited to:
water, damage, improper storage, accidental dropping etc.
Please send the damaged device to your supplier including
power supply and cables, the completed warranty card and
receipt. The serial number on the device has to be the same
as in the warranty card. The obligation of this warranty is
limited to the device bought, and no claim shall be allowed
under this warranty due to damage or loss of any other
objects.

SKYLIGHT
SKYLIGHT TINY RH/RV installation and safety manual EN
www.skylight.blue
SKYLIGHT
2/2
SL_TINY RH/RV_Instruction manual_EN_v1_0_20180617
------------------------------------------------------------------------
WARRANTY CARD
Model: SKYLIGHT TINY RH/RV
Type: ____________________________________________________
Serial numer(s): ___________________________________________
Date of purchase: _________________________________________
Name: ____________________________________________________
___________________________________________________________
Address: _________________________________________________
___________________________________________________________
___________________________________________________________
___________________________________________________________
e-mail: ____________________________________________________
___________________________________________________________
My signature below acknowledges, that I have fully read,
understand and accept this limited warranty agreement.
Date___________________Signature__________________________
