HENX H36DCG120A01 Operation instructions

Power Trimmer and Brush Cutter
MODEL: H36DCG120A01
Original Instruction
36-volt Lithium-ion Trimmer and Brush cutter
Ningbo Aosheng Machine Co.,Ltd.
W
WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
A
No.77 West Nantang Road, Linshan Industrial Park,
315462, Yuyao City,
Zhejiang , P.R. China
Tel: [phone] Fax:[phone]

B

C
D E

G
H3 H4
O P
R4
S
X2
Y

READ ALL
INSTRUCTIONS!
Residual Risk! People with electronic devices, such as pacemakers, should
consult their physician(s) before using this product. Operation of electrical
equipment in close proximity to a heart pacemaker could cause interference or
failure of pacemaker.
WARNING: To ensure safety and reliability, all repairs and replacements should
be performed by a qualified service technician.
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger.
The instructions and warnings they give are no substitutes for proper accident
prevention measures. Read, understand, and follow all safety symbols on the
machine before trying to assemble and operate it.
WARNING:Be sure to read and understand all safety instructions in this
operator’s manual, including all safety alert symbols such as “DANGER,”
“WARNING,” and “CAUTION” before using this tool. Failure to follow all
instructions listed below may result in electric shock, fire, and/or serious personal
injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: indicates DANGER, WARNING, or CAUTION. May be
used in conjunction with other symbols or pictographs.
WARNING:The operation of any power tools can result in foreign objects being
thrown into your eyes, which can result in severe eye damage. Before beginning
power tool operation, always wear safety googles or safety glasses with side
shields and a full face shield when needed. We recommend a wide vision safety
mask for use over eye glasses or standard safety glasses with side shields.
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product.

Read, understand and follow all instructions on the machine before attempting to
assemble and operate.
Safety Alert
Indicates a potential personal injury hazard.
Read Operator’s
Manual
To reduce the risk of injury, user must read and
under- stand the operator’s manual before
using this product.
Wear Eye
Protection
Always wear safety goggles or safety glasses
with side shields and a full face shield when
operating this product.
Wear Ear
Protection
Always wear sound barriers (ear plugs or ear
mufflers) to protect your hearing.
Wear Head
Protection
Wear an approved safety Standard hat to
protect your head.
Wear Protective
Gloves
Protect your hands with gloves when handling
blade or blade guard. Heavy-duty, nonslip
gloves improve your grip and protect your
hands.
Wear Safety
Footwear
Wear non-slip safety footwear when using this
equipment.

Danger- Keep
hands Away
from Blades
Contact with blade will result in serious
personal injury.
Keep sufficient
distance away
from electrical
power lines
To prevent electrocution, do not operate within
33 ft. (10m) of overhead electrical lines.
Contact with or use near power lines may
cause serious injury or electric shock resulting
in death.
Falling objects
Be aware of falling objects during the operation
of pole saw and extended-reach hedge
trimmer.
Noise label
A noise label marked with the declared noise
emission value shall be shown on the machine.
Do not expose to
rain
Do not expose the machine to rain.
DANGER —
Keep
Bystanders Away
Do not operate the machine when children or
others are nearby.
Blade thrust
Be aware of blade thrust during operation

Keep bystanders
away
Ensure that other people and pets remain at
least 15m away from the liner trimmer when it is
in use.
Max. speed for
output spindle
Max. speed for output spindle of grass trimmer
and brush cutter shall be marked on the
machine.
General Power Tool Safety Warnings
WARNING Read all safety warnings, instructions, illustrations and
specifications provided with this power tool. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
1)Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or

moving parts. Damaged or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-skid safety shoes, hard hat
or hearing protection used for appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.

4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c) Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding
of moving parts, breakage of parts and any other condition that may affect
the power tool’s operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the work
to be performed. Use of the power tool for operations different from those
intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe
handling and control of the tool in unexpected situations
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer.A charger
that is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that can

make a connection from one terminal to another.Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help.Liquid ejected from the battery may cause
irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified.Damaged or
modified batteries may exhibit unpredictable behaviour resulting in fire, explosion
or risk of injury.
f) Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool
outside the temperature range specified in the instructions. Charging
improperly or at temperatures outside the specified range may damage the battery
and increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool is
maintained.
b) Never service damaged battery packs. Service of battery packs should only
be performed by the manufacturer or authorized service providers.
Lawn Trimmer Safety Warnings
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Safe operating practices
Training
a) Read the instructions carefully. Be familiar with the controls and the correct use of the
machine.
b) Never allow children or people unfamiliar with these instructions to use the machine.
Local regulations can restrict the age of the operator.

c) Keep in mind that the operator or user is responsible for accidents or hazards
occurring to other people or their property.
Preparation
a) Before use, always visually inspect the machine for damaged, missing or misplaced
guards or shields.
b) Never operate the machine while people, especially children, or pets are nearby.
Operation
a) Wear eye protection and stout shoes at all times while operating the machine.
b) Avoid using the machine in bad weather conditions especially when there is a risk of
lightning.
c) Use the machine only in daylight or good artificial light.
d) Never operate the machine with damaged guards or shields or without guards or
shields in place.
e) Switch on the motor only when the hands and feet are away from the cutting means.
f) Always disconnect the machine from the power supply.
1) whenever the machine is left unattended;
2) before clearing a blockage;
3) before checking, cleaning or working on the machine;
4) after striking a foreign object;
5) whenever the machine starts vibrating abnormally.
g) Take care against injury to feet and hands from the cutting means.
h) Always ensure that the ventilation openings are kept clear of debris.
Maintenance and storage
a) Disconnect the machine from the power supply before carrying out maintenance or
cleaning work.
b) Use only the manufacturer’s recommended replacement parts and accessories.
c) Inspect and maintain the machine regularly. Have the machine repaired only by an
authorized repairer.
d) When not in use, store the machine out of the reach of children.

Brush Cutter Safety Warnings
Training
a) Read the instructions carefully. Be familiar with the controls and the proper
use of the machine.
b) Never allow people unfamiliar with these instructions or children to use the
machine. Local regulations can restrict the age of the operator.
c) Keep in mind that the operator or user is responsible for accidents or
hazards occurring to other people or their property.
Preparation
a ） Never operate this product while people, especially children or pets are nearby.
b
） Wear eye protection and stout shoes at all times while operating this product.
c
） The distance between the machine and bystanders shall be at least 15m.
d) The 3-teeth blades of brush cutters shall be well packed during transport to prevent
personal injury or damage.
Operation
a ） Do not operate the brush cutter when the operator is tired,ill or under the influence of
alcohol or drugs.
b
） Keep bystanders, children and pets at least 15m away from the machine while it is
in operation.
c
） Never operate the brush cutter with damaged guards or shields or without guards or
shields in place.
d
） Wear eye protection, hearing protection and stout shoes at all times while operating
the machine.
e
） Take care against injury to feet and hands from the cutting means.
f
） Use the brush cutter only in daylight or good artificial light.
g
） Switch on the motor only when the hands and feet are
away from the cutting means.
h ） Always ensure that the ventilation openings are kept clear of debris.
i ） Always disconnect the brush cutter from the power

supply (i.e. remove the plug from
the mains or remove the disabling device).
Whenever leaving the brush cutter unattended;
◾before clearing a blockage;
◾before checking, cleaning or working on the brush cutter;
◾after striking a foreign object;
◾whenever the brush cutter starts vibrating abnormally.
Maintenance and Storage
a)
Disconnect the brush cutter from the power supply or remove the disabling device)
before carrying out maintenance or cleaning work.
b) Use only the manufacturer’s recommended replacement parts and accessories.
c) Inspect and maintain the brush cutter regularly. Have the
machine repaired only by an
authorized technician.
d) When not in use, store the brush cutter out of the reach of children.
Noise and Vibration Declaration
The declared vibration total value and the declared noise emission values have been
measured in accordance with a standard test method and may be used for comparing
one tool with another. The declared vibration total value may also be used in a
preliminary assessment of exposure.
Warning!
The vibration and noise emission during actual use of the power tool can differ from the
declared total value depending on the ways in which the tool is used, in particular, what
kind of work piece is machined.
It is necessary to identify safety measured to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running idle
in addition to the trigger time)
Try to minimize the impact of vibration and noise. Exemplary measures to reduce
vibration exposure include wearing gloves while using the tool, limiting working time, and
using accessories in good condition.

Battery Pack and Charger Safety Warnings
If under extreme conditions any electrolyte should escape from the battery, it's essential
to avoid contact with skin. If electrolyte does come into contact with your skin, rinse it off
with water. In the event of electrolyte contact with your eyes, it's essential to consult a
doctor.
a
） This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
b
） Children should be supervised to ensure that they do not play with the appliance.
c
） Before the use of the charger, read the instruction manual for it carefully.
d
） During the charge process, the current used should correspond to the current of the
battery charger.
e
） Never let moisture, rain or splashed water reaches the charging location.
f
） The ambient temperature must not exceed 40 ° C. Never expose the device to
direct insulation.
g
） If the electrical cable is damaged, the wire may only be replaced by the
supplier or by his repair workshop. Have repairs carried out only by an authorized
specialist only.
h
） Always keep the surface of the charger free from dust and dirt.
i
） Do not throw batteries into water or fire, risk of explosion!
j
） Never discharge the battery completely and recharge occasionally if not used for a
prolonged period.
This power trimmer and brush cutter can only be used with the following battery
pack and charger
Battery pack
Charger
H36B25
H36B50
H36B75
H40KC400
H40MC100 (XVE129-4200300)

SPECIFICATIONS
PACKING LIST
Cutting unit
Trimmer head
3-teeth metal blade
Voltage
36 VDC
36 VDC
No-load Speed
5000-6000 /min
5000-6000 /min
Cutting Line Type
2.3mm nylon twist line
/
Cutting Blade
/
3-Teeth blade
Cutting width
40cm
25.5cm
Weight(without
battery pack)
4.35kg
4.64kg
LPA
LwA
Vibration
Part Name
Quantity
Brush cutter
1
3-teeth blade with sheath
1
Guard assembly
1
Nut
1

Outer flange
1
Hex wrench
1
Multifunctional wrench
1
Double-shoulder strap
1
Operator’s manual
1
