HENX H40XZU20-G User manual

40-Volt Cordless Hedge Trimmer
H40XZU20-G, H40XZU20-L
H40XZU22-G, H40XZU22-L
H40XZU24-G, H40XZU24-L
OPERATOR’S MANUAL
WARNING: Read all safety rules and
instructions carefully before operating this tool.
Improper use can cause serious or fatal injury.
Original instructions

2
Table Of Contents
Safety Symbols......................................................................................4
Safety Instructions.................................................................. 5-13
Introduction.......................................................................................... 14
Specifications................................................................................ 14-15
Assembly.............................................................................................. 16
Packing List..........................................................................................16
Description.............................................................................17-18
Operation........................................................................................19-24
Maintenance..........................................................................25-27
Troubleshooting.................................................................... 28-29
Warranty................................................................................ 30-31
Parts List...............................................................................................32

3
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
WARNING: some dust created by power cutting contains chemicals known to
thestateofCaliforniatocause cancer,birthdefectsorotherreproductiveharm.
some examples of these chemicalsare:
Lead from lead-based paints
crystalline silica from bricks and cement and other masonry products, and
Arsenic and chromium from chemically-treated lumber.
Yourrisk from these exposures varies, depending onhow often you do this type of
work. To reduce your exposure to these chemical: work in a well-ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.

4
Safety Symbols
Thepurpose of safety symbolsisto attractyourattention topossibledangers.The
safetysymbols and the explanations withthem deserveyour carefulattentionand
understanding.The symbol warnings do not, by themselves, eliminate any danger.The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to following all instructions listed below
may result in electric shock, fire, and/or serious personal injury.
Symbol meaning
SAFETY ALERT SYMBOL: indicates DANGER,WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
WARNING! The operation of any power tools can result in foreign objects being
thrown into your eyes, which can result in severe eye damage. Before beginning power
tool operation, always wear safety goggles or safety glasses with side shield and a
full face shield when needed. We recommend a Wide Vision safety Mask for use over
eyeglasses or standard safety glasses with side shields. Always use eye protection.

5
Safety Instructions
This page depicts and describes safety symbols that may appear on this product. Read,
understand,andfollowallinstructions onthemachine before attemptingtoassemble
and operate.
safety Alert
indicates a potential personal injury hazard.
Read the
Operator’s
Manual
Toreduce the risk of injury, user must read
operator’s manual.
Eye Protection
Always wear safety goggles or safety glasses
with side shields and a full face shield when
operating this product.
danger- Keep
hands Away
from Blades
contact with blade will result in serious
personal injury.
Do not expose to
rain
Do not expose to rain
Recycle symbols
This product uses lithium-ion (Li-ion)
batteries. Local, state, or federal laws may
prohibit disposal of batteries in ordinary
trash. consult your local waste authority for
information regarding available recycling and/
or disposal options.

6
Charging/Store
the battery pack
Charging and Store the battery pack only in
dry rooms with an ambient temperature of
50°F to 104°F (+10°C to +40°C).
V
Volt
Voltage
A
Amperes
current
hz
hertz
Frequency (cycles per second)
W
Watt
Power
min
Minutes
Time
Alternating
current
Type of current
direct current
Type or a characteristic of current
n
0
no-Load speed
Rotational speed, at no load
... /min
Per Minute
Revolutions per minute
SPM
strokes Per
Minute
stroke speed, at no load
DANGER: People with electronic devices, such as pacemakers, should consult
their physician(s) before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure of the pacemaker.

7
IMPORTANT SAFETY INSTRUCTIONS
1) Avoid Dangerous Environment – Don’t use appliances in damp or wet locations.
2) Don’t Use In Rain.
3) Keep Children Away – All visitors should be kept at a distance from work area.
4) Dress Properly – Do not wear loose clothing or jewelry. They can be caught in moving
parts. Use of rubber gloves and substantial footwear is recommended when working
outdoors. Wear protective hair covering to contain long hair.
5) Use Safety Glasses – Always use face or dust mask if operation is dusty.
6) Use Right Appliance – Do not use appliance for any job except that for which it is
intended.
7) Don’t Force Appliance – It will do the job better and with less likelihood of a risk of injury
at the rate for which it was designed.
8) Don’t Overreach – Keep proper footing and balance at all times.
9) Stay Alert – Watch what you are doing. Use common sense. Do not operate appliance
when you are tired.
10) Store Idle Appliances Indoors – When not in use, appliances should be stored indoors
in dry, and high or locked-up place – out of reach of children.
11) Check Damaged Parts – Before further use of the appliance, a guard or other part that
is damaged should be carefully checked to determine that it will operate properly and
perform its intended function. Check for alignment of moving parts, binding of moving
parts, breakage of parts, mounting, and any other condition that may affect its operation. A
guard or other part that is damaged should be properly repaired or replaced by an
authorized service center unless indicated elsewhere in this manual.
Charging battery pack only in dry conditions and an ambient temperature of 50°F to 104°F
(10°C to 40°C). Protect them from humidity and direct sunlight!
Store the charger, battery pack and machine only in dry places with an ambient temperature
of 50°F to 104°F (10°C to 40°C).
WARNING – To reduce the risk of injury, user must read instruction manual.
WARNING – Risk of Eye Injury. Use Safety Glasses or Similar Eye Protection.
WARNING –To reduce the risk of injury to persons, do not operate without
guards in place.
WARNING –To Reduce the Risk of injury to Persons, Remove Battery Pack When
Not in Use.
WARNING – Read all safety warnings and instructions. Failure to follow the
warnings, and instructions may result in electric shock, fire and/ or serious injury.
 Prevent unintentional starting. Ensure the power switch is in the off-position
before connecting to battery pack, picking up or carrying the appliances.

8
Carrying the appliances with your finger on the power switch, or energizing
appliances that have the switch on, invites accidents.
Make sure the power switch is off and the battery pack is removed before
clearing jammed material, making adjustments, changing accessories,
storing or servicing the appliance. Unexpected actuation of the appliance
while clearing jammed material or servicing may result in serious personal
injury.
Reacharge only with the charger specified by the manufacturer. A charger
that is suitable for one type of battery pack may create a risk of fire when used
with another battery pack.
Use appliance only with specifically designated battery packs. Use of any
other battery packs may create a risk of injury and fire.
When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects
that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or fire.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water.If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
Do not use a battery pack or appliance that is damaged or modified.
Damaged or modified batteries may exhibit unpredictable behavior resulting in
fire, explosion or risk of injury.
Do not expose a battery pack or appliance to fire or excessive temperature.
Exposure to fire or temperature of 130 ℃ can be replaced by the temperature of
265 ℉ .
Follow all charging instructions and do not charge the battery pack or
appliance outside of the temperature range specified in the instructions.
Charging improperly or at temperatures outside of the specified range may
damage the battery and increase the risk of fire.
Have servicing performed by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the product is maintained.
Do not modify or attempt to repair the appliance or the battery packs( as
applicable) except as indicated in the instructions use and care.

9
General Power Tool Safety Warnings
WARNING:Read all safety warnings and instructions. Fail to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
Theterm“powertool”in thewarning referstoyourmains-operated(corded) powertool
or battery-operated (cordless) power tool.
Work Area Safety
Keep work area clean and well lit. cluttered or dark areas invite accidents.
Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep children and bystanders away while operating a power tool. distractions can
cause you to lose control.
Electrical Safety
Battery pack must match the outlet. Never modify the battery pack in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Unmodified
plugs and matching outlets will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
Do not expose power tools to rain or wet conditions. Water entering a power
tooll will increase the risk o f electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp edges or
moving parts. damaged or entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use an extension cord suitable for
outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric
shock. If operating a power tool in a damp location is unavoidable, use a
residual current device (RCD) protected supply. Use of an Rcd reduces the risk of
electric shock.
Personal Safety
Stay alert, watch what you are doing and use common sense when operating a
power tool. Donot use apower tool while youare tired or under the influence of

10
drugs,alcohol or medication.Amoment of inattentionwhileoperating power tools
may result in serious personal injury.
Use personalprotective equipment.Always wear eye protection.Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal injuries.
Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
carrying power tools with your finger on the switch or energizing power tools that
have the switch on invites accidents.
Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
Dress properly. Do not wear loose clothing or jewelry. Keep your hair,clothing and
gloves away from moving parts. Loose clothes, jewelry or long hair can be caught
in moving parts.
If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust devices can
reduce dust-related hazards.
Power Tool Use And Care
Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and more safely at the rate for
which it was designed.
Do not use the power tool if the switch does not turn it on and off. Any power
tool thatcannot becontrolledwith theswitchisdangerousand must be
repaired.
Disconnect the battery pack from the powertool before making any
adjustments,changingaccessories,or storing power tools. such preventive
safety measuresreducetheriskofstartingthepower tool accidentally.
Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of moving parts,

11
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control;
Use the power tool, accessories, tool bits, etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed.Useofthepowertoolfor operationsdifferentfromthoseintendedcould
result in a hazardous situation.
Battery Tool Use And Care
Recharge only with the charger specified by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
Use the battery operated hedge trimmers only with specifically designated
battery packs. Use of any other battery packs may create a risk of injury
and fire.
When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects that can
make a connection from one terminal to another. shorting the battery terminals
together may cause burns or afire.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact.If contact accidentally occurs, flush with water. if liquid contact eyes,
additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
Battery powered hedge trimmers do not have to be plugged into an electrical
outlet; therefore, they are always in operating condition. Be aware of possible
hazards when not using your battery powered hedge trimmer or when changing
accessories. Following this rule will reduce the risk of electric shock, fire, or
serious personal injury.
Do not charge the battery pack outdoors.
Use only the charger supplied by the manufacturer to recharge.
Do not leave hedge trimmers unattended when the battery is inserted. Remove
the battery when the hedge trimmer is not in use and before servicing.
Do not use to pick up flammable or combustible liquids, such as gasoline, or use
in areas where they may be present.
Do not operate hedge trimmers in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust.

12
Service
Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
Hedge Trimmer Safety Warnings
DANGER– Keep hands away from blade. contact with blade will result in
serious personal injury.
Keepallparts ofthebody away from the cutterblade. Donot removecut
material or holdmaterialto becutwhenbladesaremoving.Makesurethe
switchisoff when clearing jammed material. Blades coast after turn off.
Amomentofinattentionwhileoperatingthehedgetrimmermayresultinserious
personal injury.
Carry thehedgetrimmerbythehandlewiththecutterbladestopped.Proper
handlingofthehedgetrimmer willreducepossiblepersonalinjuryfromthecutter
blades.
Hold the power tool by insulated gripping surfaces only, because the cutter
blade may contact hidden wiring. cutter blades contacting a “live” wire may
make exposed metal parts of the power tool “live” and could give the operator
an electric shock.
Use both hands when operating the hedge trimmer. Using one hand
could cause loss of control and result in serious personal injury.
Important Safety Instructions
Do not use the battery-operated hedge trimmer in rain.
Do not charge the battery pack in rain or in wet locations.
Use only with the battery packs and chargers listed below:
Do not grasp the exposed cutting blades or cutting edges when picking up or holding the
hedge trimmer.
do not use on a ladder,rooftop, tree, or other unstable support. stable footing on a solid surface
enables better control of the hedge trimmer in unexpected situations.
never allow children to operate the hedge trimmer.
BATTERY PACK
CHARGER
H40B25,H40B50,
H40B75 ， H40B200
H40MC100(XVE129-4200300)
H40KC400

13
neverremoveortamperwithsafetydevices.checktheirproperoperationregularly. never do
anything to interfere with the intended function of a safety device or to reduce the protection
provided by a safety device.
never operate the hedge trimmer without proper guards, plates, or other safety protective
devices in place.
check damaged parts before further use of the hedge trimmer. A guard or other part that is
damaged should be carefully checked to determine that it will operate properly and perform its
intended function. check for alignment of moving parts, binding of moving parts, breakage of
parts, mounting, and any other condition that may affect its operation.A guard or other part that is
damagedshould be properly repaired or replaced by an authorized service center unless
indicated elsewhere in this manual.
check the blade and motor mounting bolts at frequent intervals for proper tightness. . Also,
visually inspect blade for damage (e.g., bent, cracked, and worn). Replace the blade only with a
blade from the original equipment manufacturer (OEM).
Replace the blade if it is bent or cracked. An unbalanced blade causes vibration that could
damage the motor drive unit or cause personal injury.
if the equipment should start to vibrate abnormally, stop the motor and check immediately
for the cause. Vibration is generally a warning of trouble.
The trimmer shall be used to cut stems less than 3/4" (18mm) thick.
Trim only in daylight or in good artificial light.
Remove or disconnect battery before servicing, cleaning, or removing material from the hedge
trimmer.
Do not wash with a hose; avoid getting water in motor and electrical connections.
When servicing use only identical replacement parts listed in this manual. Use of parts which do
not meet the original equipment specifications may lead to improper performance and
compromised safety.
Follow instructions for lubricating and changing accessories.
Keep handles dry, clean and free from oil and grease.
save these instructions. Refer t o them frequently and use them to instruct others who
may use this tool. if you loan this tool to someone else, also loan these instructions to
them to prevent misuse of the product and possible injury.
Save these instructions!
Intended use
Used for home and highway landscaping pruning.

14
Serial Number Date of Purchase
You shouldrecord both serial number and date of purchase and keep in a safe place for
future reference.
Introduction
Congratulations on your selection of a new generation of 40V Lithium-ion
powered hedge trimmer. it has been designed, engineered and manufactured to
give you the best possible dependability and performance.
should you experience any problem you cannot easily remedy, please contact
Henx customer service center86-574-62037812.
This manual contains important information on to the safe assembly, operation and
maintainance of your hedge trimmer. Read it carefully before using the hedge trimmer.
Keep this manual handy so you can refer to it at any time.

15
Specifications
Voltage
40V DC
no-Load speed
Low Speed:1600/min
High Speed:2100/min
Cutting Length
24" (610mm) □
22” (550mm) □
20”(508mm) □
Weight (Without battery pack, blade guard)
8.5 lb(3.84kg)
Battery
pack
Lithium-Ion
Models
H40B75
H40B50
H40B25
H40B200
voltage
40 VDC
40 VDC
40 VDC
40VDC
Capacity
7.5Ah
5.0Ah
2.5Ah
20Ah
Charger
(model)
H40KC400
Input
120VAC 60Hz, 400W
Output
40VDC, 8A
Allowable
charge
temperature
range
0 - 40 °C
Charger
(model)
H40MC100(XVE129-4200300）
Input
100-120VAC, 50/60Hz, 2.5A Max;
Output
42.0VDC, 3A
Allowable
charge
temperature
range
0 - 40 °C

16
Assembly
WARNING: if any parts are damaged or missing do not operate this product until
the parts are replaced.Use of this product with damaged or missing parts could result
in serious personal injury.
WARNING:do not attempt to modify this product or create accessories not
recommendedfor usewiththishedgetrimmer.Anysuchalterationormodificationis
misuse and could result in a hazardous condition leading to possible serious personal
injury.
WARNING: To prevent accidental starting that could cause serious personal
injury, always remove the battery pack from the tool when assembling parts.
Unpacking
This product has been shipped completely assembled.
carefullyremovetheproductandanyaccessoriesfromthebox.Makesurethat
all items listed in the packing list are included.
inspect the tool carefully to make sure no breakage or damage occurred during
shipping.
do not discard thepacking material untilyou have carefully inspected and
satisfactorily operated the tool.
if any parts are damaged or missing, please return the product to the place of
purchase.
Packing list
PART NAME
QUANTITY
hedge Trimmer
1
Blade guard
1
Operating manual
1

17
Description
Know Your hedge trimmer (fig. 1)
The safe use of this product requires and understanding of the information on the
tool and in this operator’s manual, as well as knowledge of the project you are
attempting. Before use of this product, familiarize yourself with all operating
features and safety rules.
Hand guard
helps protect hand from cutting and deflect chips or other debris away from the
operator’s hands.
Front handle
For easy control of the tool during cutting work.
with overmold improves comfort and grip.
Front switch lever/rear switch lever
The hedge trimmer can be started only if both of the switch levers (in rear and
front of the handle) are depressed simultaneously.
1
power indicate/
faulty alarm
power display
button
Battery power
On /Off
Low Speed Switch
Control Panel

18
Blades
steel blades for cutting hedges and shrubs.
Blade guard
Thebladeguardkeepstheoperatorfromcomingincontactwiththesharpblades
whenthetool is not inuse.italsohelpskeeptheblades frombeing nicked or
damaged when the tool is in storage.
Battery release button
Press to release the battery pack from the tool.
Latch
Locks the battery pack in place when installed on the tool.
Ejection mechanism
Aids in removing the battery.
Mounting slot
guides the battery pack.

19
Operation
WARNING:donot allowfamiliaritywith this product tomake you careless.
Rememberthatacarelessfractionofasecondissufficientto inflictseriousinjury.
WARNING: Always wear eye protection with side shields,
along with hearing
protection. Failure to do so could result in objects being thrown into your eyes and
other possible serious injuries.
WARNING: do not use any attachments or accessories not recommended by the
manufacturer of this product. The use of attachments or accessories not recommended
can result in serious personal injury.
Before each use, inspect the entire product for damaged, missing, or loose parts, such
as screws, nuts, bolts,caps,etc.Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts are replaced.
Application
You may use this product for the purposes listed below:
Trimming andthe forming ofhedges, shrubs,and busheswith a branch diameter of
less than 3/4" (18mm)

20
To install/remove battery pack (fig
. 2 & 3)
WARNING:Always remove thebattery pack fromthe productwhenyouare
assembling parts, making adjustments, cleaning, or when not in use. Removing the
battery pack will prevent accidental starting that could cause serious personal injury.
NOTE: Fully charge the battery pack before first use.
To install
( f ig. 2)
Align the ribs of the battery pack
with the mounting slots in the
hedge trimmer’s battery port.
Press the battery pack down until it
snaps into position.
NOTE:Make sure that the latch on the
hedge trimmer snaps into place and the
battery pack issecured to thetoolbefore
beginning operation.
To remove (fig. 3)
WARNING:Always be aware for the
location of your feet, children, or pets when
pressing the battery-release button. serious
injury couldresultifthebattery packfalls.
Neverremovethebattery pack at a high
location.
Press the battery-release buttonthe
battery pack will disengage from the
latch.
grasp the battery pack and remove it
from the hedge trimmer.
2
3
