Titan TTI827HDC User manual

Original Instructions_MNL_TTI827HDC_V1_211102
WARNING: Read the instructions before using the product!
EN
Cordless hedge
trimmer
18V 45cm SOLO
TTI827HDC

EN
02
Let’s
Getting started...
In more detail...
get started...
Safety information
Your product
Before you start
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
02
03
14
15
18
19
20
23
25
26
27
29
31
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.

EN
03
Getting started...
TTI827HDC by TITAN Safety information
Safety warnings
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodied plugs and matching outlets will reduce risk
of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
General power tool safety warnings
Work area safety
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.

EN
04
Getting started...
TTI827HDC by TITAN
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
inuence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
2. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection
used for appropriate conditions will reduce personal
injuries.
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source, picking up or carrying the tool. Carrying
Safety warnings
Safety information

EN
05
Getting started...
TTI827HDC by TITAN
power tools with your nger on the switch or energising
power tools that have the switch on invites accidents.
4. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
2. Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.Such
preventive safety measures reduce the risk of starting
Safety information

EN
06
Getting started...
TTI827HDC by TITAN
the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power too repaired
before use. Many accidents are caused by poorly
maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a hazardous
situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
Battery tool use and care
1. Recharge only with the charger specified by then
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used with
another battery pack.
2. Use power tools only with specifically designated
Safety warnings
Safety information

EN
07
Getting started...
TTI827HDC by TITAN
battery packs. Use of any other battery packs may
create a risk of injury and re.
3. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or a re.
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
5. Do not use battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or
risk of injury.
6. Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130 °C may cause explosion.
7. Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk of
re.
Service
1. Have your power tools serviced by a qualied repair
person using only identical replacement parts. This
will ensure that safety of the power tool is maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Safety information

EN
08
Getting started...
TTI827HDC by TITAN
Hedge trimmer safety warnings:
1. Keep all parts of the body away from the blade. Do
not remove cut material or hold material to be cut
when blades are moving. Blades continue to move
after the switch is turned off. A moment of inattention
while operating the hedge trimmer may result in serious
personal injury.
2. Carry the hedge trimmer by the handle with the
blade stopped and taking care not to operate any
power switch. Proper carrying of the hedge trimmer will
decrease the risk of inadvertent starting and resultant
personal injury from the blades.
3. When transporting or storing the hedge trimmer,
always fit the blade cover. Proper handling of the
hedge trimmer will decrease the risk of personal injury
from the blades.
4. When clearing jammed material or servicing the
unit, make sure all power switches are off and
the battery pack is removed or disconnected.
Unexpected actuation of the hedge trimmer while
clearing jammed material or servicing may result in
serious personal injury.
5. Hold the hedge trimmer by insulated gripping
surfaces only, because the blade may contact hidden
wiring or its own cord. Blades contacting a "live" wire
may make exposed metal parts of the hedge trimmer
"live" and could give the operator an electric shock.
6. Keep all power cords and cables away from cutting
area. Power cords or cables may be hidden in hedges
or bushes and can be accidentally cut by the blade.
7. Do not use the hedge trimmer in bad weather
conditions, especially when there is a risk of lightning.
Safety warnings
Safety information

EN
09
Getting started...
TTI827HDC by TITAN
This decreases the risk of being struck by lightning.
Additional safety warnings for battery pack
1. Battery pack needs to be charged before use. Always
refer to the charger’s instruction and charge it properly.
2. Remove the battery pack from the product when not
in use.
3. Don’t maintain the battery pack on the charger
when not in use.
4. After extended periods of storage, it may be
necessary to charge and discharge the battery pack
several times to obtain the maximum performance.
5. Longer life and better performance can be obtained
if the battery is charged when the air temperature is
between 18 °C and 24 °C. Do not charge the battery
in air temperature below 5 °C or above 40 °C. This
is important as it can prevent serious damage to the
battery.
6. Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric shock.
7. Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh air
and seek medical assistance in the event of discomfort.
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems separate
from each other.
Additional safety warnings for battery pack
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and low-
noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and these
Safety information

EN
10
Getting started...
TTI827HDC by TITAN
instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure they
are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
(HAVS) e.g. fingers going white; as well as specific
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the safety
directions and follow them to the letter. This will help to
prevent risks and hazards.
1. Always be alert when using this product, so that you
can recognise and handle risks early. Fast intervention
can prevent serious injury and damage to property.
2. Switch the product off and remove the battery pack
if there are malfunctions. Have the product checked by
a qualied professional and repaired, if necessary, before
you operate it again.
Safety warnings
Safety information

EN
11
Getting started...
TTI827HDC by TITAN
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of injury
and damage remain. The following dangers can arise
in connection with the structure and design of this
product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by ying
objects.
Safety information

EN
12
Getting started...
TTI827HDC by TITAN
Symbols
Safety information
On the product, the rating label and within these instructions you will find
amongothers the following symbols and abbreviations. Familiarise yourself with
them to reduce hazards like personal injuries and damage to property.
VVolt, (direct current voltage) mAh Milliampere per hour
/min or Per minute °C Degree Celsius
min-1
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimeter m/s² Metres per second squared
dB(A) Decibel (A-rated)
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction Note / Remark.
manual.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week of
manufacturing (Wyy)
Wear hearing protection. Wear eye protection.
Wear a dust mask. Wear protective gloves.
Wear protective, slip-resistant footwear.
Wear tight-tted protective clothes.
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class III.
Do not expose the product to rain or wet conditions (moisture).
Keep hands away from moving cutting device!

EN
13
Getting started...
TTI827HDC by TITAN
Objects thrown by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance
from the product when it is in operation. In general, children must not
come near the area where the product is.
Guaranteed sound power level value in 87 dB.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
Crossed out dust bin. Batteries and battery packs should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling
advice.
Do not dispose of battery packs in rivers or immerse in water.
Do not dispose of battery packs in re. They will explode and cause
injury.
Do note expose battery packs to heat in excess of 40 °C.
Do not charge or store the battery pack in temperatures below 5 °C
(41 °F) and above 40 °C (104 °F).
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
Safety information

EN
14
Getting started...
TTI827HDC by TITAN
Your product
Your product
1
2
3
456
7
8
9
10
11
13
12
12a
12b
12c
1. Cutting device (blade)
2. Front safeguard
3. Safety switch
4. Front handle
5. Air vents
6. Rear handle
7. Battery docking port
8. On/off switch
9. Rear safeguard
10. Housing
11. Blade cover
12. Battery pack
a. Battery capacity indicators
b. Battery capacity button
c. Release button
13. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.

EN
15
Getting started...
TTI827HDC by TITAN
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
you nd that parts are missing or show damage do not use the product but
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
Before you start
You will need
(items not supplied)
Suitable personal protective equipment
Lubricant for blade
(items supplied)
Blade cover (11)
Battery pack (12)
Charger (13) and its manual
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
Setup
WARNING! Before using the product, familiarise yourself with the
operating features read the entire instruction manual paying particular
attention to the safety rules and operating procedures.
Do not connect the product to battery pack (12) before it is completely
assembled!

EN
16
Getting started...
TTI827HDC by TITAN
Setup
NOTE: Always attach the blade cover (11) when the product is not in
use, for storage and transportation.
To attach the blade cover (11), align and push the blade cover onto
the cutting device (blade) (1).
Attaching / releasing the battery pack
Before you start
Blade cover
1. Remove the blade cover (11) from the cutting device (blade) (1) before
operation (Fig. 1).
2. Keep the blade cover (11) safely.
11
1
Fig. 1
Battery pack
1. Align the battery pack (12) with the
sliding slots of the battery docking port
(7) and slide the battery pack (12) in to
attach it. Ensure it clicks in place (Fig. 2).
2. Press the release button (12c) and
remove the battery pack (12) from the
battery docking port (7) (Fig. 3).
7
12
Fig. 2
7
12c
12
1.
2.
Fig. 3
Charging the battery pack
The battery pack (12) for this product has been shipped in a low charge
condition.
Charge it fully before rst use.
Refer to the charger’s instruction manual (TTB804CHR) for the details.

EN
17
Getting started...
TTI827HDC by TITAN Before you start
Battery capacity indicators
The battery pack (12) is equipped with the battery capacity indicators (12a)
which are used to give an indication of the battery pack’s remaining capacity.
Press the battery capacity button (12b) to check battery capacity (Fig. 4).
The LEDs will stay lit for approximately 2 seconds.
76-100%
51-75%
26-50%
5-25%
<5%
12
12b
12a
Fig. 4

18
EN TTI827HDC by TITAN
In more detail...
In more
detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical specications
Declaration of conformity
19
20
23
25
26
27
29
31

EN
19
In more detail...
TTI827HDC by TITAN
Intended use
Switching on/off
This cordless hedge trimmer TTI827HDC is designated with a rated voltage of
18 V . It is designed only to be used with the battery pack which is listed in
the chapter of “Technical specications”.
The product is intended for cutting and trimming of hedges, bushes and shrubs
in domestic gardens. The maximum cutting capacity must be observed. Do not
cut branches exceeding the stated maximum capacity.
The use of this product in case of rain or humid environment is prohibited.
For safety reasons it is essential to read the entire instruction manual before
rst operation and to observe all the instructions therein.
This product is intended for private domestic use only, not for any commercial
trade use. It must not be used for any purposes other than those described.
1. Ensure the cutting device (blade) (1) does not touch any objects. Remove
the blade cover (11) from the cutting device (blade) (1) before switching the
product on.
2. Hold the product with one hand on the front handle (4) and the other hand on
the rear handle (6).
3. Squeeze the safety switch (3) and hold it in position (Fig. 5, step 1).
4. Squeeze the on/off switch (8) to switch the product on (Fig. 5, step 2).
5. Release either the on/off switch (8) or the safety switch (3) to switch the
product off.
Product functions
3
6
8
4
1.
2.
1
Fig. 5

EN
20
In more detail...
TTI827HDC by TITAN
General operation
Operation
Trimming times
1. Check the product, its battery pack and charger as well as accessories for
bdamage before each use. Do not use the product if it is damaged or shows
wear. Take care of any problem you find or have the product checked by
qualied specialist.
2. Double check that the accessories and attachments are properly xed.
3. Always hold the product on its handles. Keep the handles dry to ensure safe
support.
4. Ensure that the air vents are always unobstructed and clear. Clean them if
necessary with a soft brush. Blocked air vents may lead to overheating and
damage the product.
5. Switch the product off immediately if you are disturbed while working by other
people entering the working area. Always let the product come to complete
stop before putting it down.
6. Do not overwork yourself. Take regular breaks to ensure you can concentrate
on the work and have full control over the product.
green leaf hedges
evergreens
conifers and other fast growing shrubs
June to October
April and August
every 6 - 8 weeks
Trimming
NOTE: Try to keep the cutting device angled at approximately 15° to
the cutting surface.
1. Make sure that the blade cover (11) is removed, and the battery pack (12) is
assembled before operation.
2. Ensure that no people or animals are in the work area.
3. Cut and remove branches exceeding the cutting capacity of this product using
a proper pruner before operation.
4. Always hold the product rmly with both hands on front handle (4) and rear
handle (6). Never operate this product using only one hand.
5. Do not rush and do not attempt to cut too much with one stroke of the cutting
device.
6. First cutting both sides from the bottom upwards to the top. This will prevent
any of the cuttings falling into the path of the area still to be cut (Fig. 6).
