Herzan Silencer User manual

H
HE ER RZ ZA AN N S SI IL LE EN NC CE ER R
D
DE ES SK KT TO OP P A AC CO OU US ST TI IC C E EN NC CL LO OS SU UR RE E
-
- U US SE ER R G GU UI ID DE E - -
T
TA AB BL LE E O OF F C CO ON NT TE EN NT TS S
Description ..........................................................................................................2
Features................................................................................................................2
Contents...............................................................................................................3
Unpacking the System......................................................................................3
Switching Door Orientation ............................................................................3
Installing Instrument.........................................................................................4
Cable Management...........................................................................................5
Maintenance........................................................................................................5
Best Practices ......................................................................................................6
Upgrades..............................................................................................................6
Feedback ..............................................................................................................7

DESCRIPTION
This User Guide describes how to use the Herzan Silencer acoustic enclosure. This desktop
enclosure provides acoustic isolation for the instrument with multiple layers of sound-
damping materials. The system is designed to be accessed from either the left or right side
–both the door and cable ports are reversible.
FEATURES
Cable Port with
Damping Foam
Removable
Port Cover
Lifting Handle
Acoustic Dampening Foam
Door Latch
Hinge
Attachment
Vibration
Isolation
(Optional)

Fill Screws
CONTENTS
Desktop Enclosure
Removable Cable Port Cover
Cable Port Damping Foam
2.5 mm Hex Wrench - Accessory
UNPACKING THE SYSTEM
−Remove top of large box. Remove box's outer walls. Remove enclosure from
packing bag. IMPORTANT: Save all packing materials for subsequent use.
−Place enclosure on rigid desk or table. CAUTION: The enclosure is heavy (95+ lbs);
two people should lift the enclosure using handles on side. NOTE: Do not support
enclosure weight with the door, as doing so can adversely affect the door’s
alignment.
−Disengage latch and open enclosure door. Remove accessory wrench.
SWITCHING DOOR ORIENTATION
−The door can be hinged on the right or left side,
depending on which orientation is preferable for
continued use. The switch can be easily accomplished
using the 2.5 mm hex wrench provided in the
accessory bag. Remove the hex wrench from the
accessory bag.
−Use wrench to detach fill screws from door and body of enclosure. There are twelve
fill screws total. Keep fill screws for subsequent reattachment

Latch Attachment Screws
−Use wrench to detach latch attachment screws. Note
orientation of latch parts. Keep screws and latch parts for
subsequent reattachment.
−Support weight of enclosure door from below. Use
wrench to detach screws which attach the hinge to the
enclosure body. Remove door.
−Use wrench to detach hinges from door. Use wrench to
attach hinges to enclosure body on opposite side.
−Put enclosure door back into place and support weight
from below. Use wrench to attach hinge to door.
−Use wrench to reattach door latch. Use wrench to
reattach fill screws.
INSTALL INSTRUMENT
At this point, install the instrument to be used inside the enclosure. Please refer to
instrument manual for instructions on installing instrument.
Hinge Attachment Screws

CABLE MANAGEMENT
−There are cable ports on both sides of the enclosure. Upon installing instrument,
decide which side of the enclosure the instrument cables should be ported
through. If necessary, remove port cover and place in port which will not be
used.
−Remove damping foam from cable port to be used. Feed instrument cables out
through port.
−Outside of enclosure, compress two pieces of damping foam around cables.
Push foam and cables into cable port (see picture above). Adjust as necessary to
ensure a good seal around the cables.
MAINTENANCE
−The enclosure can be cleaned using general cleaning agents and a soft cloth. Do
not use abrasive cleaning materials as it may degrade the paint.
−Keep enclosure door closed and latched when the enclosure is not in use to avoid
undue strain on hinges.
−Contact Herzan for replacement parts.
Removable Port Cover
Cables Installed
Step 3 Detail
Removable Port
Cover Detail

BEST PRACTICES
−When choosing a location for the enclosure, avoid rooms in close proximity to
noise-generating machines, such as production machines, large HVAC systems,
or elevator shafts. If possible, choose a room on the ground floor. Avoid
rooms with raised floors.
−Avoid places within the room that are near open doors, open windows, HVAC
ducts, and high foot traffic areas. To reduce overall vibration levels, place the
enclosure near a load-bearing wall.
−Place the enclosure on a rigid table or desk. Tables or desks which lack rigidity
may impart additional noise into the system.
−Don’t place noise-generating equipment such as CPUs or pumps on the
enclosure or on the supporting table. If possible, place noise-generating
equipment in a separate room.
−Cables entering the enclosure should be slack. Stiff cables transmit parasitic
vibrations. If the cables connect to noise-generating equipment, weight should
be added to cables to dampen transmission of noise.
−Before beginning sensitive measurements, close and latch the enclosure door.
UPGRADES
There are a number of upgrades available to improve the performance and usability
of your enclosure. Please contact Herzan to learn more. Upgrades include:
−Air-based vibration isolation
−Active vibration cancellation
−Electromagnetic interference shielding
−Temperature stability
−Internal lighting
−Custom cable management solutions
−Shelves and custom mounting options

FEEDBACK
Herzan welcomes your feedback! Please let us know what we can do to improve our
products. You can reach us at [email protected] or [phone]. We look
forward to hearing from you!
