HF Duncan PWR SS635-PHZL2-082 User manual

ASSEMBLY INSTRUCTION
Page 1 of 2
Do Not plug the power cord into a power outlet until yourloveseat is fully assembled and in place.
Notes:
1) To help prevent shock and ordamage to yourproduct only plug the power cord into a grounded outlet.
2) Read the operating instructions carefully before operating yourtriple power loveseat.
Ensure both clips on back are
aligned, then press top of back
frame downward until a clicking
sound is heard.
Thank you forpurchasing this quality product. Be sure to unpack carefully looking for small parts which may have come looe during
shipment. Read all in truction and study the drawing carefully before starting the assembly process.
Inside the carton you will find two red plastic bags that have the loveseat's wings in it. Remove the wings from the plastic bag and set
them asideto be used in assembly and installation.
CAUTION: Make sure to read the instructions below before assembling yourtriple power loveseat. We suggest two people
be used in the assembly of your triple power loveseat.
C
AB
DD
The headrest leadwires are yellow.
The lumbarleadwires are grey.
Headrest
Lumbar
E
E
NOTE: This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must
accept any interference,including interference that may cause
undesired operation of the device. Modifications not approved
by the party responsible for compliance could void user's
authority to operate the equipment.
A×1 B×1 D×2 E×2
C×1
Not Included
ITEM: SS635-PHZL2-082 Duncan PWR Loveseat w/PWR Headrest & Lumbar
SS635-PHZL2-088 Duncan PWR Loveseat w/PWR Headrest & Lumbar

Page 2 of 2
OPERATING INSTRUCTION
Product Protected By Following Patents:
Patented Articulating Power Headrest &Lumber
US Patent: 10,736,423
CAUTION:Read the important instructions below before operating your power mechanizedequipment
Do not allow children to play on or operate this power mechanized equipment
ITEM:
IMPORTANT NOTE
·To avoid any risk of suffocation to children or pets, dispose of all plastic bags immediately.
·To ensure proper performance, occasionally check for loose screws and tighten as needed.
Customer Service
If you have any questions regarding the use of this unit,or find that your unit needs service,please contact
your retailer.
USB
Front of Arm
CLOSE
CLOSE& HOME
CLOSE
OPEN
OPEN
OPEN
HEADREST
LUMBAR
FOOTREST
Type-C
Care should always be taken to assure there is nothing in the path of the mechanism before and
during operation.
To recline: Sit on the furniture, and press the front of the button closest to the footrest to smoothly raise the
footrest and recline to any position. To lower the footrest and return to an upright position, press the back side
of the button closest to the footrest.
To adjust headrest: Press the front of the button closest to the backrest to smoothly raise and adjust the
headrest to any position. To lower the headrest and return it to its original position, press the back side of the
button closest to the backrest.
To adjust lumbar support: Press the front of the center button to smoothly raise and adjust the lumbar
support to any position. To lower the lumbar support and return it to its original position, press the back side of
the center button.
To close all: To simultaneously return the headrest, footrest, and lumbar support to their original positions,
press and hold the back side of the button closest to the footrest.
00556A
ITEM: SS635-PHZL2-082 Duncan PWR Loveseat w/PWR Headrest & Lumbar
SS635-PHZL2-088 Duncan PWR Loveseat w/PWR Headrest & Lumbar
