HIDITION GAMING T-1 User manual

GAMING IN-EAR HEADSET
MANUAL

© 2021 Makina international Inc.

Contents
01 Product Includes
02 Package Includes
03 Quick Start
04 How to manage products
05 Audio and MIC Volume Setting
06 How to manage products
07 Specifications
08 Precautions in Using Device
3 ~ 5
6 ~ 7
8 ~ 12
13 ~ 15
16 ~ 17
18 ~ 19
20 ~ 21
22 ~ 23

01
Product Includes
3

GAMING IN-EAR HEADSET
MMCX Connector (M)
MIC Spliter
Adjustable-fit
Boom-MIC Hanger
Unit
MIC Head
MIC
ON/OFF Switch
3.5mm
4-Pole Plug
4

MMCX Connector (M)
Left Unit
Right Unit
Nozzle
Earcap
MMCX Connector (F)
5

02
Package Includes
6

Earcaps
Cable tie Y adapter
for PC
S/M/L
M M
L L
SS
GAMING IN-EAR HEADSET
7

03
Quick Start
How to wear T-1
8

Select your optimal ear-tip size: Small, Medium, Large.
(T-1 will be pre-assembled with medium-sized tips.)
then replace the pre-existing tips
to your liking on both sides.
Locate the cable (connected with
adjustable boom mic + unit)
around your ears.
2
1
① With the mic splitter tightly sealed,
② rotate T-1 from the top of your ears
and ③ insert the unit into your ears with
the over-ear method.
3
①
②
③
9

Locate the Adjustable boom mice hanger
onto your tragus and bend it upwards.
(So the mic's head would face your mouth)
5
① Adjust the adjustable-fit boom mic hangers
and ② mic splitters to tightly seal
to your ears and facial curves.
6
① With the mic splitter tightly sealed,
② bend the adjustable boom mic hangers
facing down.
4①
②
①
②
10

Plug T-1's cables into your gaming device,
and it's time for you to enjoy
T-1's HIGHEND GAMING SOUND.
8
Rotate the right side unit of T-1
and insert the device into your earholes.
(Over-ear method)
7
With the microphone splitter fixed, bend the Adjustable-fit boom microphone hanger outward
(the side that adheres closely to the body) to set the microphone splitter more tightly to the ear.
*Tips
HOLD
11

If the wearing is not perfect, refer to the “Tips”(Page12) section.
Spread the Adjustable-fit
boom microphone hanger
like the right image.
1
Proceed again
from the 2nd to 6th steps of "Quick Start."
2
Adjust the fit again
12

04
How to use MMCX Connetors
13

2. Pull away cables from the connectors
in a parallel motion.
2
Hold the unit
and its MMCX Connector (M) Housing
with both of your hands.
(As of close as possible to its seams)
1
Cable Disassembly
14

Tightly seal the unit to the MMCX
until you hear it click.
2
Sort out the Left and Right sides of the unit
and the MMCX Connector Housing.
1
Make sure you differentiate the Left and Right sides
before its reassembly/replacement.
Warning
Cable Replacement
R
15

05
Audio and MIC Volume Setting
16

Microphone Boost
+10.0 dB
When there's not enough volume
to input the microphone in a PC environment
When using it in a PC environment
Window - Settings - System - Sound - Sound Contol Panel
- Recording - Properties - Levels - Microphone Boost
When there is not enough microphone input volume in a PC (window) environment,
enter the Sound Settings in the above path and raise the microphone amplification
to +10.0 dB or +20.0 dB in the Level tab. The input/output environment may vary
depending on some motherboard or sound card settings.
1. Insert the Y adapter for PC into the 4-pole 3.5mm plug terminal of T-1.
2. Connect the microphone input and sound output terminals separately.
17

06
How to manage products
18

How to store products
Please wrap the Adjustable-fit boom microphone hanger in a wide circle so that
the shape does not collapse.
Tip: If you wrap it around a cable tie and store it, you can prevent
tangled problems with other products.
How to clean and manage nozzles.
Warning: Do not use highly volatile materials when cleaning the product.
If a nozzle is clogged with
foreign substances, turn it upside down
and shake it off with a brush.
After using T-1, always keep
the ear tips and nozzles clean.
19
