HIdRos WZA Series User manual

Multiple instructions:
&RQVXOWWKHVSHFL¿FSDUW
5HDGDQGXQGHUVWDQG
the instructions before
XQGHUWDNLQJDQ\ZRUNRQ
the unit
RETAIN FOR FUTURE REFERENCE
,QFRUSRUDWHGLQWKLVGRFXPHQWDUHWKHIROORZLQJ
'HFODUDWLRQRIFRQIRUPLW\
7HFKQLFDOPDQXDO
TECHNICAL MANUAL
GROUND SOURCE WATER TO WATER HEAT PUMPS
WZA
SERIES
MTEC.3810.GB-C-1 2SHUDWLRQDQGPDLQWHQDQFHPDQXDO:=$VHULHV(QJOLVKRev. C 09-2020

Declaration of conformity
We declare under our own responsibility that the below equipment complies in all parts with the CEE and EN directives.
The declaration of conformity is enclosed to the technical booklet enclosed with the unit. The unit contains fluorinated greenhouse gases.
Reproduction, data storage and transmission, even partial, of this publication, in any form, without the prior written authorisation of the
company, is prohibited. The company can be contacted for all inquiries regarding the use of its products.
The company follows a policy of continuous product development and improvement and reserves the right to modify specifications,
equipment and instructions regarding use and maintenance at any time, without notice.

6
6
6
6
6
7
7
8
8
9
10
10
10
10
11
11
12
13
14
16
19
20
20
21
22
22
22
23
23
24
24
25
26
27
28
28
28
29
30
31
31
36
37
38
39
40
41
42
43
43
TABLE OF CONTENTS
1 Introduction
1.1 Preliminary information ..........................................................................
1.2 Purpose and content of the instructions ..............................................................
1.3 Keeping the instructions ..........................................................................
1.4 Updating the instructions .........................................................................
1.5 How to use these instructions ......................................................................
1.6 Residual risks ..................................................................................
1.7 General information on safety symbols ...............................................................
1.8 Safety symbols used .............................................................................
1.9 Limits of use and non-permitted uses ................................................................
1.10 Identification of the unit ..........................................................................
2 Safety
2.1 Warnings on potentially dangerous toxic substances.....................................................
2.2 Handling .....................................................................................
2.3 Prevent the inhalation of high vapour concentrations ....................................................
2.4 Procedures in case of accidental refrigerant leakage .....................................................
2.5 Main toxicological information on the type of refrigerant used .............................................
2.6 First Aid measures...............................................................................
3 Technical characteristics
3.1 Unit description ................................................................................
3.2 Versions available ...............................................................................
3.3 Description of accessories ........................................................................
3.4 Technical data..................................................................................
3.5 Use limits .....................................................................................
3.6 Compressor partialisation steps.....................................................................
3.7 Correction factors ...............................................................................
3.8 Sound data ....................................................................................
4 Installation
4.1 General warnings and use of symbols................................................................
4.2 Health and safety of workers.......................................................................
4.3 Personal protection devices .......................................................................
4.4 Receipt and inspection ..........................................................................
4.5 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.6 Unpacking ....................................................................................
4.7 Lifting and handling .............................................................................
4.8 Positioning and minimum technical spaces ...........................................................
4.9 Hydraulic connections ...........................................................................
4.10 Chemical characteristics of the water ................................................................
4.11 Minimum water content of utility /sanitary circuit.......................................................
4.12 Hydraulic circuit filling...........................................................................
4.13 Emptying the system .............................................................................
4.14 Typical installations .............................................................................
4.15 Electrical connections: preliminary safety information ...................................................
4.16 Electrical data ..................................................................................
4.17 Electrical connections............................................................................
4.18 Principle cooling layouts..........................................................................
5 Start-up
5.1 Preliminary checks ..............................................................................
5.2 Operating characteristics .........................................................................
5.3 Control panel ..................................................................................
5.4 Procedures ....................................................................................
6 Utility use
6.1 Main functions .................................................................................
6.2 User pages display ..............................................................................
7 Unit maintenance
7.1 General warnings ...............................................................................
7.2 Access to the unit ...............................................................................
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
4

44
44
46
47
47
47
48
49
TABLE OF CONTENTS
7.3 Scheduled maintenance ..........................................................................
7.4 Periodic and initial start-up checks ..................................................................
7.5 Cooling circuit repair ............................................................................
8 Decommissioning
8.1 Disconnecting the unit ...........................................................................
8.2 Decommissioning, disposal and recycling ............................................................
8.3 WEEE Directive (EU only) .........................................................................
9 Diagnosis and troubleshooting
9.1 Troubleshooting ................................................................................
9.2 Possible anomalies and possible remedies ............................................................
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
5

1 INTRODUCTION
1.1 PRELIMINARY INFORMATION
The reproduction, storage and transmission, even partial, of this publication in any form without the prior written authorisation of the Company
is prohibited.
The machine, to which these instructions refer, has been designed for the uses that will be presented in the specific paragraphs, compatibly
with its performance characteristics. Any contractual or non-contractual liability of the Company is excluded for damage caused to persons,
animals or property, installation errors, adjustment and maintenance or for improper use. All uses not expressly indicated in this manual are
not permitted.
This documentation provides informational support and cannot be considered as a contract with third parties.
The Company implements a policy of improvement and constant development of its products. It therefore reserves the right to make changes
to the specifications, set-ups and documentation at any time, without notice and without having to update what has already been delivered.
1.2 PURPOSE AND CONTENT OF THE INSTRUCTIONS
These instructions are intended to provide essential information for the selection, installation, use and maintenance of the machine. They have
been prepared in compliance with the legislative provisions issued by the European Union and with the technical regulations in force on the
date of issuing of the instructions themselves.
The instructions include instructions for avoiding reasonably foreseeable improper use.
1.3 KEEPING THE INSTRUCTIONS
The instructions must be placed in a suitable place, away from dust, humidity and must be easily accessible to users and operators.
The instructions must always accompany the machine throughout its life cycle and must therefore be transferred to any subsequent user.
1.4 UPDATING THE INSTRUCTIONS
It is advisable to always check that the instructions are updated to the latest revision available.
Any updates sent to the customer must be kept as an annex to this manual.
The Company is available to provide any information regarding the use of its products.
1.5 HOW TO USE THESE INSTRUCTIONS
The instructions are an integral part of the machine.
Users or operators must consult the instructions before any operation on the machine and in any case of uncertainty regarding
transportation, handling, installation, maintenance, use and dismantling of the machine.
In these instructions, to draw the attention of the operators and users to the operations to be carried out in safety, the graphic
symbols reported in the following paragraphs have been inserted.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
6

1INTRODUCTION
1.6 RESIDUAL RISKS
The machine was designed to minimise the risks to the safety of those persons who will interact with it. During the project it was not technically
possible to completely eliminate the causes of risk. Therefore it is absolutely necessary to refer to the following instructions and symbols.
PARTS
CONSIDERED RESIDUAL RISK MODES PRECAUTIONS
Inside the unit:
compressors and
gas delivery pipes.
Burns Contact Avoid contact,
use protective gloves.
Inside the unit:
electrical cables
and metal parts.
Electrocution,
severe burns.
Insulation fault of power
supply cables, live metal
parts.
Adequate electrical protection of the supply lines;
utmost care in making the earthing connection of the
metal parts.
Outside of the unit:
area around the
unit.
Intoxications,
severe burns.
Fire due to short circuit or
overheating of the supply
line upstream of the unit's
electrical panel.
Section of the cables and protection system of the power
supply line complying with the standards in force.
High pressure safety
valve.
Intoxications,
severe burns,
hearing loss.
Intervention of the high
pressure safety valve with
the compartment of the
cooling circuit open.
Avoid opening the refrigeration circuit compartment
as much as possible; carefully check the condensing
pressure value; use all the personal protection
equipment required by law. PPE must also protect
against gas leakage from the safety valve. The discharge
of these valves is directed to avoid causing damage to
persons or property.
Entire unit
Bursting or exploding,
injuries, burns, poisoning
due to external fire.
Fire due to natural disasters
or the combustion of
elements adjacent to the
unit.
Prepare the necessary fire-fighting equipment and/or
adequate signs indicating that the unit is under pressure.
Entire unit
Bursting or exploding,
injuries, burns, poisoning,
electrocution due to
natural disasters or
earthquake.
Breakage, failure due
to natural disasters or
earthquake
Prepare the necessary precautions, both electrical
(adequate differential thermal breaker and electrical
protection of the power supply lines; maximum care
in making the earth connection of the metal parts),
and mechanical (for example, dedicated anti-seismic
anchors or anti-vibration mountings to prevent breakage
or accidental falls)
1.7 GENERAL INFORMATION ON SAFETY SYMBOLS
Individual safety symbols in accordance with ISO 3864-2:
PROHIBITION
A black symbol inserted in a red circle with a red diagonal indicates an action that must not be performed.
WARNING
A black graphic symbol inserted in a yellow triangle with black borders indicates a danger.
COMPULSORY ACTION
A white symbol inserted in a blue circle indicates an action that must be performed to avoid a risk.
Combined safety symbols in accordance with ISO 3864-2:
The graphic warning symbol is completed with additional safety information (text or other symbols).
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
7

1 INTRODUCTION
GENERIC DANGER
Strictly observe all the indications next to the pictogram. Failure to follow the instructions can generate risk situations with
possible consequent damage to the health of the operator and of the user in general.
ELECTRICAL HAZARD
Strictly observe all the indications next to the pictogram.
The symbol indicates machine components or, in this manual, identifies actions that could generate electrical hazards.
MOVING PARTS
The symbol indicates moving machine components that could generate risks.
HOT SURFACES
The symbol indicates components of the machine with a high surface temperature that could generate risks.
CUTTING SURFACES
The symbol indicates components or parts of the machine that could cause cutting injuries upon contact.
GROUND CONNECTION
The symbol identifies the point of the machine for grounding.
READ AND UNDERSTAND THE INSTRUCTIONS
Read and understand the machine instructions before performing any operation.
RECOVERABLE OR RECYCLABLE MATERIAL
1.9 LIMITS OF USE AND NON-PERMITTED USES
The machine has been designed and built exclusively for the uses described in the paragraph "Limits of use" of the technical manual.
Any other use is prohibited as it could generate risks for the health of operators and users.
However, the unit is not suitable to be operated in environments:
• With potentially explosive or excessively dusty atmospheres;
• Where vibrations are present;
• Where there are electromagnetic fields;
• In which aggressive atmospheres are present;
• Outdoors.
1.8 SAFETY SYMBOLS USED
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
8

1
Manufacturer: PD322111
Contiene gas fluorurati ad effetto serra disciplinati dal protocollo di Kyoto
Contains fluorinated greenhouse gasses covered by the Kyoto protocol
Modello
Model
123456
2 3/2017
R410A
Kg Kg
2 2088
400V-3ph+N-50Hz
bar bar
-30 °C +130 °C -30 °C +130 °C
Matricola
Serial number
Categoria PED
PED Category
Tipo refrigerante
Refrigerant type
Tensione-Fasi-Frequenza
Voltage-Phases-Frequency
LATO BASSA PRESSIONE
LOW PRESSURE SIDE
LATO ALTA PRESSIONE
HIGH PRESSURE SIDE
Gruppo fluido
Fluid group GWP
Carica refrigerante
Refrigerant charge
C1
C3
C2
Min Max Min Max
C4
F.L.A. (A) F.L.I. (kW)
PS
Temperatura di progetto
Design temperature
Peso a vuoto
Weight
Temperatura di progetto
Design temperature
CO2Equivalente
CO2Equivalente
Data di fabbricazione
Manifacture date
PS

bar
A P
SSURE SIDE
nza
ency
ONE
Hz
C
CO
2
Equ
Equiva
valente
ente
INTRODUCTION
1.10 IDENTIFICATION OF THE UNIT
Each unit is equipped with an identification plate that shows the main information of the machine.
The data on the plate may differ from that shown in the technical manual as the latter contains the data of the standard units without accessories.
For electrical information not present on the label, refer to the wiring diagram.
A fac-simile of a plate is shown below.
The identification label must never be removed from the unit.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
9
9LD(0DWWHL
3LRYHGL6DFFR3',WDO\
[phone]
LQIR#KLGURVLW
ZZZKLGURVHX

2 SAFETY
2.1 WARNINGS ON POTENTIALLY DANGEROUS TOXIC SUBSTANCES
 ,GHQWLŎFDWLRQRIWKHW\SHRIŏXLGXVHG5$
• Difluoromethane (HFC-32) 50% by weight CAS No.: 000075-10-5
• Pentafluoroethane (HFC-125) 50% by weight CAS No.: 000354-33-6
 ,GHQWLŎFDWLRQRIWKHW\SHRIRLOXVHG
The lubricating oil used in the cooling circuit of the unit is of the polyester type. In any case, always refer to what is indicated on the compressor
plate.
For any further information regarding the characteristics of the refrigerating fluid and oil used, refer to the safety data sheets
available from the manufacturers of refrigerant and lubricating oils.
ENVIRONMENTAL PROTECTION: Carefully read the ecological information and the following instructions.
Users and maintenance personnel must be adequately informed about the risks due to the handling of potentially toxic
substances. Failure to observe the above instructions may cause personal injury or damage the unit.
Main Ecological Information on the refrigerants used.
2.1.3 Persistence and degradation
The refrigerating fluids used decompose in the lower atmosphere (troposphere) relatively quickly.The decomposed products are highly dispersible
and therefore have a very low concentration. They have no influence on photochemical smog, meaning that they are not one of the VOC volatile
organic compounds (as established by the guidelines of the UNECE agreement). R410A refrigerants (R32 and R125) do not damage the ozone
layer. These substances are regulated by the Montreal protocol (1992 revision) and by EC regulation no. 2037/200 dated 29 June 2000.
 (IIHFWVRQHIŏXHQWWUHDWPHQW
Discharges into the atmosphere of these products do not cause long-term water contamination.
2.1.5 Exposure control and individual protection
Use protective clothing and gloves; always protect the eyes and face.
2.1.6 Occupational exposure limits
HFC-32 TWA 1000 ppm
HFC-125 TWA 1000 ppm
2.2 HANDLING
2.3 PREVENT THE INHALATION OF HIGH VAPOUR CONCENTRATIONS
Atmospheric concentrations of refrigerant must be kept to a minimum and kept as low as possible, below the occupational exposure limit.
Vapours are heavier than air, and dangerous concentrations can form near the ground, where general ventilation is poor. In this case, ensure
adequate ventilation. Avoid contact with naked flames and hot surfaces, because toxic and irritating decomposition products can be formed.
Avoid contact between the liquid and the eyes or skin.
2.4 PROCEDURES IN CASE OF ACCIDENTAL REFRIGERANT LEAKAGE
Ensure adequate personal protection (using means of respiratory protection) during cleaning operations.
If the conditions are sufficiently safe, isolate the source of the leak. If the amount of the leak is limited, allow the material to evaporate provided
that adequate ventilation is ensured. If the leak is significant, adequately ventilate the area.
Contain spilled material with sand, earth or other suitable absorbent material.
Prevent the refrigerant from entering drains, sewers, basements or work holes, because suffocating vapours can form.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
10

2SAFETY
Strictly follow the warnings and first aid procedures below.
2.5 MAIN TOXICOLOGICAL INFORMATION ON THE TYPE OF REFRIGERANT USED
2.5.1 Inhalation
A high atmospheric concentration can cause anaesthetic effects with possible loss of consciousness.
Prolonged exposures can cause abnormal heart rhythms and sudden death.
Higher concentrations can cause asphyxia due to the reduced oxygen content in the atmosphere.
2.5.2 Contact with the skin
Splashes of sprayed liquid can cause frost burns. It is unlikely to be dangerous due to skin absorption.
Prolonged or repeated contact may cause removal of skin fat, resulting in dryness, cracking and dermatitis.
2.5.3 Eye contact
Splashes of sprayed liquid can cause frost burns.
2.5.4 Ingestion
Although highly unlikely, it can cause frost burns.
2.6 FIRST AID MEASURES
2.6.1 Inhalation
Remove the victim from the source of exposure, keep them warm and at rest. Administer oxygen if necessary. Give artificial respiration if
breathing has stopped or shows signs of stopping. If there is cardiac arrest perform external cardiac massage. Request medical assistance.
2.6.2 Contact with the skin
In case of contact with the skin, wash immediately with warm water. Thaw the epidermal tissue with water. Remove contaminated clothing.
Clothing can stick to the skin in case of frost burns. If there is irritation or blistering, seek medical assistance.
2.6.3 Eye contact
Wash immediately with eye wash or with clean water, keep eyelids open for at least ten minutes.
Request medical assistance.
2.6.4 Ingestion
Do not induce vomiting. If the injured person is conscious, rinse the mouth with water and administer 200-300 ml of water to be drunk.
Request medical assistance.
2.6.5 Further medical treatment
Symptomatic treatment and supportive therapy as indicated. Do not administer adrenaline and sympathomimetic drugs following exposure,
due to the risk of cardiac arrhythmia.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
11

3 TECHNICAL SPECIFICATIONS
3.1 UNIT DESCRIPTION
The series heat pumps are particularly suitable for use in groundwater or geothermal probes. These units find their ideal application in
combination with radiant panel heating systems or in all situations in which maximum efficiency is required in heating mode. The units have
been designed to have an extremely efficient heating performance and can operate with a water temperature of up to 60°C.
The units are available in various versions both in the 2-pipe configuration on the utility side and in the 4-pipe configuration on the utility
side. All versions are able to produce domestic hot water; the 2-pipe versions through the activation of an external 3-way valve, the 4-pipe
versions using a dedicated hydraulic circuit used for domestic hot water which allows its production regardless of the unit's operating mode.
The available versions and the wide range of accessories make it possible to identify the model and the most suitable solution for the type of
system served.
3.1.1 Carpentry
All units are produced in hot-dip galvanised sheet metal and painted with polyurethane powders in the oven at 180°C to ensure the best
resistance to atmospheric agents. The carpentry is self-supporting with removable panels to facilitate inspection and maintenance of the internal
components.
3.1.2 Cooling circuit
The refrigerant gas used in these units is R410A. The refrigeration circuit is created using components from leading international companies and
according to the regulations concerning the brazing and welding processes.
The cooling circuit includes: filter drier, electronic thermostatic valve, cycle reversing valve, Schrader valves for maintenance and control and
a safety device (according to the PED regulation).
3.1.3 Compressor
The compressors are of the scroll type, optimised for heating applications with a particular structure that offers high efficiencies especially when
the source temperature is low. The compressors are supplied with a thermal protection relay embedded in the electric windings. Inspection of
the compressors is possible through the front panel of the unit which allows maintenance even with the units in operation.
3.1.4 Source exchanger
The source side exchangers, with braze-welded plates, are made of AISI 316 stainless steel. They are of the single circuit type. Use of this type of
heat exchangers greatly reduces the refrigerant charge of the unit compared to traditional shell and tube evaporators, and increases its cooling
capacity. The exchangers are insulated in the factory using closed cell material and are protected by a temperature probe used as an antifreeze
protection probe.
3.1.6 Utility exchangers
The utility side exchangers are made of braze welded plates and AISI 316 stainless steel. They are of the single circuit type. All units are equipped
with a "sub-cooler" to increase the efficiency of the refrigeration cycle. The exchangers are insulated in the factory using closed cell material.
3.1.7 Electrical panel
The electrical panel is made in compliance with the European standards EN60204. Access to the electrical panel is possible by removing the
front panel of the panel, being sure to position the main door interlock switch in the OFF position. The following components are also present
as standard: Main switch, thermomagnetic circuit breakers to protect the compressors and fuses to protect the pumps and auxiliary circuits,
compressor relay and pump relay. The panel is also equipped with a terminal board with a configurable digital input and voltage-free digital
outputs.
3.1.8 Microprocessor
All units are equipped with microprocessor control. The microprocessor controls the following functions: water temperature regulation,
antifreeze protection, compressor timing, compressor start-up sequence, alarm reset, alarm management and operation LED. On request the
microprocessor can be connected to remote BMS control systems. The technical office is available to study, together with the customer, different
solutions using the most popular communication protocols.
3.1.9 Control and Protection Devices
All the units are supplied as standard with the following control and protection devices: supply water temperature probes on source side
heat exchanger and on utility side heat exchanger, manual reset high pressure switch, compressor uniperometric protection, pump thermal
protection, high and low pressure transducers, source circuit and utility circuit differential pressure switch.
3.1.10 Hydraulic kit
The HFE series units are equipped with a hydraulic kit consisting of the following:
• utility circuit: variable speed circulation pump, expansion vessel (on some models), water flow sensor (differential pressure switch),
connection for filling and draining water;
• source circuit: variable speed circulation pump (or modulating two-way valve, for the well version) regulated by the microprocessor
to optimise the operating conditions of the cooling circuit, expansion vessel (on some models), water flow sensor (pressure switch
differential for the probe and flow switch version - to be installed on site - for the well version), connection for filling and draining
water;
• sanitary circuit (for the R version): variable speed circulation pump regulated by the microprocessor to maximise the recovery of
condensation heat.
The HFS series units are not equipped with the components described above which, however, can be installed on the system and managed by
the unit's microprocessor. The units include a flow sensor (flow switch) on the utility exchanger and on the source one.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
12
The units are equipped with a hydraulic kit consisting of the following:

3TECHNICAL SPECIFICATIONS
3.1.11 Electronic thermostatic valve
All the units are equipped with an electronic thermostatic valve, in order to optimise the functioning of the cooling circuit and to maximise the
energy efficiency of the system in all operating conditions that can be implemented on the system.
3.2 VERSIONS AVAILABLE
All units are hot/cold reversible, with cycle inversion on the cooling circuit.
3.2.1 Version (without heat recovery)
The units in this version are equipped with a single heat exchanger on the utility side to produce hot water in heating operation or chilled water
in cooling operation (the two operating modes are alternatives to each other). The unit must be installed on a "two-pipe" type system.
3.2.2 Version with domestic hot water diverter valve management
The units in the version without heat recovery can be configured to manage a diverter valve to heat a storage tank to be used for the production
of domestic hot water. In this way, in each of the operating modes described above, if the temperature in the domestic hot water storage tank
falls below a selected value, the unit will be set up to bring it back to the determined set value, positioning the diverter valve appropriately. This
operating mode is a priority and an alternative to operation for the utility (in heating or cooling).
The unit must be installed on a "two-pipe" type system; a three-way diverter valve (not included in the machine) must be installed on the unit's
outlet connection for heating of the domestic hot water storage tank.
The configuration of the control to manage the diverter valve should be performed in the factory and as such it is necessary to communicate
this requirement during the order phase.
3.2.3 Version /P4S (with total heat recovery)
The units in the version with total heat recovery, in addition to the one on the utility side, are equipped with an additional heat exchanger
dedicated to domestic hot water heating. This exchanger is installed on the compressor discharge line, upstream of the cycle reversing valve,
through which the high pressure and temperature refrigerant passes both in heating and in cooling operation; this exchanger is sized in such a
way as to completely dissipate the condensation heat of the refrigeration circuit.
Thanks to this component, the units in version /R can perform all the functions described in the previous paragraph, but with some considerable
advantages. Firstly, if the conditions exist to do this, it is possible to transfer to the storage of heat recovered by the domestic hot water exchanger
while the unit is operating in heating or cooling mode. Furthermore, when switching from cooling to domestic hot water operation or vice-versa,
there will be no mixing of water at different temperatures between the utility circuit and the sanitary circuit, as in the case of the diverter valve.
The unit must be installed on a "four-pipe" type system (two for the utility circuit and two for the domestic hot water circuit - in this case, the
two circuits are completely separate). If the temperature in the domestic hot water storage tank falls below a selected value, the unit will be set
to return it to the determined set value, transferring heat through the dedicated exchanger. In heating mode, if the necessary conditions exist,
the unit will simultaneously transfer high-temperature heat to the domestic water storage and heat to a temperature below the utility circuit; in
this case, the advantage is to transfer the share of heat at high temperature to an efficiency comparable with that of low temperature heating. In
cooling mode, if the necessary conditions exist, the unit will extract heat from the utility circuit and transfer it, as far as possible, to the sanitary
circuit, disposing of the remainder in the source; in this case the heat transferred to the sanitary circuit is produced completely free, as, if it were
not recovered, it would be dissipated in source.
In both cases, the heat recovery mechanism can occur even if the temperature in the domestic hot water storage has reached the set point; this
is why it is not uncommon for the domestic hot water storage to be found at temperatures above the set temperature.
The sanitary exchanger circuit must be created by providing an expansion vessel, a safety valve, a filling and discharge connection (not included
in the unit).
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
13

3
GEO HFE06 HFE08 HFE12 HFE16 HFE20 HFE24 HFE33 HFE42
TECHNICAL SPECIFICATIONS
3.3 DESCRIPTION OF ACCESSORIES
3.3.1 GEO HFE 6-42
Function
Web kit (remote control)
It is used to monitor and supervise the machine
via the Internet
Modbus RS485 serial port kit
It allows communication with supervision systems
with the Modbus protocol
KONNEX serial port kit
It allows communication with supervision systems
with the Konnex protocol
RS485 BACnet serial port kit
It allows communication with supervision systems
with the Bacnet protocol
MY-ZONE T/U room thermostat
kit
Room thermostat for temperature and humidity.
Max 30
MY-BOARD expansion kit for
MY-zone kit
Expansion card for the control of dehumidifiers,
circulation pumps, zone valves and mixers.
RS485 board kit
FIELD-BUS for zones
Required to connect Galileus5 with Myzone and
Myboard
MY-POWER 3PH kit
It meters and optimises self-consumption of the
energy produced by the photovoltaic system.
Version for three-phase meter.
Soundproofing kit
The soundproofing kit must be installed on the
compressor to reduce the noise of the heat pump
(the soundproof panels
are installed as standard). If purchased together
with the kit heat pump, it is installed at the
factory.
GEO/M soft starter kit
Electromechanical device installed in factory
instead of the compressor contactor on single-
phase unit. It reduces the maximum value of the
compressor starting current by varying the supply
voltage of the motor through the management of
a dedicated starting capacitor.
GEO/T soft starter kit
Factory installed electronic device on three-
phase units. It reduces the maximum value of the
compressor starting current through the use of an
inverter which supplies the motor by varying the
frequency such as to limit the inrush current.
GEO/T soft starter kit
GEO/T soft starter kit
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
14
WZA 06 08 12 16 20 24 33 40
3.3.1 Rubber vibration dampers (KAVG)
To be installed beneath the unit base and the ground to avoid the transmission of vibrations (and the noise) to the building.
3.3.2 RS485 serial interface card modbus protocol (INSE)
This controller card enables the controller to communicate with other devices on a BMS using Modbus protocol.
3.3.3 Electronic soft starter (DSSE)
All units are supplied, standard with the soft starter device who minimize the peak starting current of the compressor reducing down to the same
value of the nominal maximum input current.
3.3.4 Remote control panel (PCRL)
All units are supplied with microprocessor control panel with high definition display, mounted on board of the unit and it is remotable up to
50 mt. distance.
3.3.5 Low noise version (LS00)
This version includes the complete acoustic insulation of the unit with compressor jackets and insulating material made with high density media
and the interposition of heavy bitumen layer.

3
GEO HFS60 HFS80 HFS100
TECHNICAL SPECIFICATIONS
Function
Mixing kit
It allows the delivery temperature of the conditioning system
to be adjusted
Remote control web kit It is used to monitor and supervise the machine via the Internet
Modbus RS485 serial port kit
It allows communication with supervision systems with the Modbus
protocol
KONNEX serial port kit
It allows communication with supervision systems with the Konnex
protocol
RS485 BACnet serial port kit
It allows communication with supervision systems with the Bacnet
protocol
MY-ZONE T/U room thermostat kit Room thermostat for temperature and humidity. Max 30
MY-BOARD expansion kit for MY-zone kit
Expansion card for the control of dehumidifiers, circulation pumps,
zone valves and mixers.
RS485 FIELD-BUS board kit for zones Required to connect Galileus5 with Myzone and Myboard
MY-POWER 3PH kit
It meters and optimises self-consumption of the energy produced by the
photovoltaic system. Version for three-phase meter.
Rubber anti-vibration kit
Anti-vibration feet and hardware for fixing to the unit to be installed
on site during positioning of the machine. It is used to dampen the
vibrations transmitted by the heat pump to the structure on which it
rests.
For smaller units, the antivibration feet are included in the group supply.
Soundproofing kit
The soundproofing kit must be installed on the compressor to attenuate
thenoise of the heat pump (the soundproof panels are
installed as standard). If purchased together with the kit heat pump, it is
installed at the factory.
Soundproofing kit
Soft starter kit
Factory installed electronic device on three-phase units. It reduces the
maximum value of the compressor starting current through the use of an
inverter which supplies the motor by varying the frequency such as to
limit the inrush current.
Soft starter kit
Soft starter kit
Pump kit
Faired module including geothermal, system and domestic hot water
pumps. The electric power circuit of the pumps must be prepared by the
customer.
The pumps for circulating hydraulic fluids between the machine and the
geothermal probes, the system storage and the domestic hot water puffer
are commanded by means of a control provided by dedicated outputs
arranged in the electrical panel of the unit.
Pump kit
Pump kit
GEO/R pump kit
GEO/R pump kit
GEO/R pump kit
3.3.2 GEO HFS 60-100
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
15
WZA - WZA/RV 06 08 12 16 20 24 33 40
LS00
DSSE
KAVG
PCRL
INSE
Main switch
Microprocessor control
Water pumps
LS low noise version
Electronic soft starter
Rubber anti-vibration mounts
Remote control panel
Serial interface card RS485
STANDARD
OPTIONAL

3
06 08 12 16 20 24 33 42 60 80 100
kW 5,76 7,54 10,2 13,2 17,1 21,0 25,4 33,8 48,8 64,6 85,4
kW 1,30 1,65 2,17 2,86 3,71 4,36 5,52 7,79 11,7 15,8 20,0
W/W 4,43 4,57 4,68 4,60 4,60 4,82 4,60 4,34 4,19 4,09 4,28
m3/h 0,991 1,30 1,75 2,26 2,93 3,61 4,37 5,81 8,40 11,1 14,7
kPa 65 62 58 50 67 60 110 80 21 26 19
W 70 70 70 70 140 140 310 310 -- -- --
kW 4,52 5,97 8,10 10,5 13,5 16,0 20,2 26,0 37,2 48,8 65,4
m3/h 1,35 1,78 2,41 3,12 4,02 4,76 6,02 7,74 11,1 14,6 19,5
kPa 5955896151418748374433
W 70 70 140 140 140 140 310 310 -- -- --
kW 5,35 7,00 9,42 12,2 15,8 19,5 23,6 31,8 46,2 60,3 80,7
kW 1,86 2,37 3,11 4,10 5,32 6,25 7,92 10,4 16,0 21,6 26,5
m3/h 0,920 1,20 1,62 2,10 2,72 3,35 4,06 5,47 7,95 10,4 13,9
kPa 6662575541525390192217
W 70 70 70 70 70 140 140 140 -- -- --
kW 7,40 9,69 13,0 16,4 21,8 25,6 32,8 42,3 60,0 79,3 105
kW 1,29 1,62 2,16 2,77 3,78 4,36 5,56 7,77 11,8 16,0 20,4
W/W 5,74 5,98 6,02 5,92 5,77 5,87 5,90 5,44 5,10 4,97 5,14
m3/h 1,27 1,67 2,24 2,82 3,75 4,40 5,64 7,28 10,3 13,6 18,1
kPa 5956493754468865323928
kW 6,17 8,15 11,0 13,8 18,3 21,4 27,5 34,5 48,3 63,3 84,6
m3/h 1,06 1,40 1,88 2,37 3,14 3,68 4,73 5,94 8,30 10,9 14,5
kPa 346779914212518
kW 9,46 12,5 16,6 20,9 27,5 32,7 41,6 47,5 65,3 86,9 118
kW 1,28 1,52 2,11 2,81 3,74 4,26 5,66 8,63 12,9 16,8 22,0
W/W 7,39 8,19 7,84 7,44 7,35 7,68 7,35 5,51 5,06 5,18 5,35
m3/h 1,63 2,14 2,85 3,59 4,73 5,62 7,16 8,18 11,2 14,9 20,2
kPa 5850373033336645384635
kW 10,7 13,9 18,6 23,6 31,0 36,8 47,0 56,2 78,2 104 140
m3/h 1,90 2,46 3,30 4,18 5,49 6,52 8,33 9,95 13,9 18,4 24,7
kPa 5145543134424125577053
TECHNICAL SPECIFICATIONS
Modello GEO HFE / HFS
Winter operation (1)
Heat output
compressor power consumption
COP
System side
System water flow rate
Useful head (pressure drop for HFS)
Pump power consumption
Geothermal side
Cooling capacity to be exchanged in the probe
Probe fluid flow rate
Useful head (pressure drop for HFS)
Pump power consumption
DHW Side (4)
Heat output
compressor power consumption
DHW flow rate
Useful head (pressure drop for HFS)
Pump power consumption
Winter operation (2)
Heat output
compressor power consumption
COP
System side
System water flow rate
Useful head (pressure drop for HFS)
Well side
Cooling capacity to be exchanged in the well
Well fluid flow rate
Exchanger pressure drop
Summer operation (3)
Cooling capacity
compressor power consumption
EER
System side
System water flow rate
Useful head (pressure drop for HFS)
Geothermal side
Heat output to be exchanged in probe
Probe fluid flow rate
Useful head (pressure drop for HFS)
3.4 TECHNICAL DATA
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
16
WZA Model 40

3
06 08 12 16 20 24 33 42 60 80 100
-- A++ A++ A++ A++ A++ A++ A++ A++ A++ A++ A++
kWh/kWh 5,41 5,68 5,66 5,67 5,69 6,07 6,03 5,79 5,79 5,79 5,79
% 208,4 219,2 218,3 218,8 219,7 234,8 233,0 223,4 223,4 223,4 223,4
-- A++ A++ A++ A++ A++ A++ A++ A++ A++ A++ A++
kWh/kWh 4,21 4,31 4,38 4,44 4,39 4,80 4,82 4,69 4,69 4,69 4,69
% 160,5 164,4 167,1 169,6 167,6 184,1 184,9 179,4 179,4 179,4 179,4
tipo Scroll
nr./nr. 1/1 1/1 1/1 1/1 1/1 2/1 2/1 2/1 2/1 2/1 2/1
Type/GWP R410A / 2088
kg 2,2 2,2 2,9 2,9 4,6 4,6 5,0 5,5 6,0 7,5 9,0
t CO2eq. 4,6 4,6 6,0 6,0 9,6 9,6 10,4 11,4 12,5 15,7 18,8
V/Ph/Hz
230/1/50
400/3/50+N 400/3/50+N
A (1 f) 15 19 25 -- -- -- -- -- -- -- --
A (3 f) 7 8 10 12 16 18 23 30 42 50 68
A (1 f) 62 85 110 -- -- -- -- -- -- -- --
A (3 f) 30 45 54 64 78 63 75 92 132 143 208
mm 620 x 575 x
1.000 620 x 650 x 1.080 800 x 880 x 1.070 1.100 x 1.000 x 1.770
kg 146 153 169 195 215 262 302 320 425 465 505
“ G 1” 1”1/4 1”1/2
dB(A) 48 49 50 52 54 56 60 62 66 68 69
dB(A) 62 63 65 67 69 71 75 77 82 84 85
TECHNICAL SPECIFICATIONS
Modello GEO HFE / HFS
Energy efficiency (5)
Energy class in low temperature
SCOP in low temperature
Ks, h at low temperature
Energy class at medium temperature
SCOP at medium temperature
Ks, h at medium temperature
Cooling circuit
Compressor type
Number of compressors/cooling circuits
Refrigerant / Global Warming Potential
Refrigerant charge (R version)
Refrigerant charge in CO2 equivalent (R version)
Other data
Electrical power supply
Maximum current consumption:
Inrush current
Dimensions (l x d x h)
Net weight
hydraulic connection diameters
Sound pressure at 1m (6)
Sound power (according to ISO 3744)
(1) Performance in heating conditions (according to EN 14511)
Utility circuit: radiant system • °C 30/35 • In/Out
External circuit: geothermal probe with 20% propylene glycol mixture in water • °C 0/-3 • In/Out
(2) Performance in heating conditions (according to EN 14511)
Utility circuit: radiant system • °C 30/35 • In/Out
External circuit: well water • °C 10/5 • In/Out
(3) Cooling performance under the conditions (according to EN 14511)
Utility circuit: radiant system • °C 23/18 • In/Out
External circuit: geothermal probe with 20% propylene glycol mixture in water • °C 30/35 • In/Out
(4) Production of domestic hot water under conditions
Utility circuit: domestic hot water storage • °C 40/50 • In/Out
External circuit: geothermal probe 20% mixture of glycoled water propylene glycol 20 % • °C 0/-3 • In/Out
(5) Variable temperate climate (according to EU Regulation 811/2013)
(6) Sound pressure level in open field at 1 m from the unit (according to ISO 3744)
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
17
WZA Model 40

3
GEO
F.L.I.
(kW)
F.L.A.
(A)
L.R.A.
(A)
cosphi
L.R.A.
(A)*
F.L.I.
(kW)
F.L.A.
(A)
F.L.I.
(kW)
F.L.A.
(A)
F.L.I.
(kW)
F.L.A.
(A)
F.L.I.
(kW)
F.L.A.
(A)
L.R.A.
(A)
L.R.A.
(A)*
HFE 06 M 230/1/50 2,7 13 60 0,91 36 0,07 0,58 0,07 0,58 0,07 0,58 2,9 15 62 38
HFE 08 M 230/1/50 3,6 17 83 0,91 50 0,07 0,58 0,07 0,58 0,07 0,58 3,8 19 85 52
HFE 12 M 230/1/50 4,8 23 108 0,91 65 0,14 1,1 0,07 0,58 0,07 0,58 5,1 25 110 67
HFE 06 400/3/50 + N 2,6 4,8 28 0,77 17 0,07 0,58 0,07 0,58 0,07 0,58 2,8 6,5 30 19
HFE 08 400/3/50 + N 3,3 6,2 43 0,77 26 0,07 0,58 0,07 0,58 0,07 0,58 3,5 7,9 45 28
HFE 12 400/3/50 + N 3,9 7,4 52 0,77 31 0,14 1,1 0,07 0,58 0,07 0,58 4,2 10 54 33
HFE 16 400/3/50 + N 5,2 10 62 0,77 37 0,14 1,1 0,07 0,58 0,07 0,58 5,5 12 64 39
HFE 20 400/3/50 + N 6,9 13 75 0,77 45 0,14 1,1 0,14 1,1 0,07 0,58 7,3 16 78 48
HFE 24 400/3/50 + N 3,9 7,4 52 0,77 31 0,14 1,1 0,14 1,1 0,14 1,1 8,3 18 63 42
HFE 33 400/3/50 + N 5,2 9,7 62 0,77 37 0,31 1,4 0,31 1,4 0,14 1,1 11 23 75 50
HFE 42 400/3/50 + N 6,9 13 75 0,77 45 0,31 1,4 0,31 1,4 0,14 1,1 15 30 92 62
HFS 60 400/3/50 + N 10 21 111 0,77 67 - - ----204213288
HFS 80 400/3/50 + N 14 25 118 0,77 71 - -----275014396
HFS 100 400/3/50 + N 17 34 174 0,77 104 ------3468208138
TECHNICAL SPECIFICATIONS
3.4.1 Total electrical consumption
Electrical
power supply
(V-Ph-Hz)
Maximum values
Compressor Geothermal
pump System pump Domestic hot
water pump Total
F.L.A.: maximum current consumption. F.L.I.: maximum power consumption.
L.R.A.: inrush current. L.R.A.*: inrush current with soft starter.
Compressor: for units with two compressors, the data refers to the single compressor.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
18
WZA
06 400/3/50 + N 2,6 4,8 28 0,77 17 0,07 0,58 0,07 0,58 0,07 0,58 2,8 6,5 30 19
08 400/3/50 + N 3,3 6,2 43 0,77 26 0,07 0,58 0,07 0,58 0,07 0,58 3,5 7,9 45 28
12 400/3/50 + N 3,9 7,4 52 0,77 31 0,14 1,1 0,07 0,58 0,07 0,58 4,2 10 54 33
16 400/3/50 + N 5,2 10 62 0,77 37 0,14 1,1 0,07 0,58 0,07 0,58 5,5 12 64 39
20 400/3/50 + N 6,9 13 75 0,77 45 0,14 1,1 0,14 1,1 0,07 0,58 7,3 16 78 48
24 400/3/50 + N 3,9 7,4 52 0,77 31 0,14 1,1 0,14 1,1 0,14 1,1 8,3 18 63 42
33 400/3/50 + N 5,2 9,7 62 0,77 37 0,31 1,4 0,31 1,4 0,14 1,1 11 23 75 50
40 400/3/50 + N 6,9 13 75 0,77 45 0,31 1,4 0,31 1,4 0,14 1,1 15 30 92 62

3
10
20
30
40
50
60
70
-30 -20 -10 0 10 20 30 40
-10
-5
0
5
10
15
20
20 30 40 50 6025 35 45 55
A B
TECHNICAL SPECIFICATIONS
3.5 USE LIMITS
Heating Cooling
Source water outlet temperature (°C)Source water outlet temperature (°C)
Utility water outlet temperature (°C) Utility water outlet temperature (°C)
A
With the addition of an adequate quantity of glycol in the source
circuit
GEO HFS 60-80-100
B
With the addition of an adequate quantity of glycol in
the utility circuit
 8WLOLW\H[FKDQJHUZDWHUŏRZUDWH
The nominal water flow refers to a temperature difference between input and output of the utility exchanger of 5°C. The maximum permissible
flow rate is the one with a temperature difference of 3°C. Higher values can cause overly high pressure drops.
The minimum permitted water flow is the one with a temperature difference of 8°C.
Insufficient water flow rates can cause abnormal operating temperatures in the cooling circuit resulting in intervention of the safety devices and
the unit stopping.
3.5.2 Utility hot water temperature (winter operation)
Once the system is fully operational, the temperature at the entrance to the utility and/or domestic hot water exchanger must not fall below
30°C; lower values can cause compressor malfunctions with the possibility of breakage.
The maximum outlet water temperature of the utility exchanger must not exceed 65°C from size 06 to 40 and 60°C from 60 to 100. Otherwise
the action of the safety devices stops the unit.
3.5.3 Chilled water temperature (summer operation)
The minimum temperature permitted at the utility heat exchanger outlet is 5°C; it is possible to produce water up to -5°C by adding an adequate
quantity of glycol in the utility circuit. For lower temperatures the unit requires structural changes. In this case, contact our technical department.
The maximum water temperature produced is 18°C.
3.5.4 Source water temperature
The minimum water outlet temperature from the source side exchanger (with glycoled water), in heating mode, is -20°C for sizes from 06 to 40
and -10°C for sizes from 60 to 100.
The appliances, in their standard configuration, are not suitable for installations in a saline environment.
The units are built according to the technical standards and safety rules in force in the European Community. The units
have been exclusively designed for heating, air conditioning and domestic hot water (DHW) production and must be
used for this purpose, compatibly with their performance characteristics. Any contractual or non-contractual liability of
the Company is excluded for damage caused to persons, animals or property, installation errors, adjustment and mainte-
nance or for improper use. All uses not expressly indicated in this manual are not permitted.
In case of operations outside of these values, please contact the Company.
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
19
10
20
30
40
50
60
70
-30 -20 -10 0 10 20 30 40

3
12
HFE 06 100% --
HFE 08 100% --
HFE 12 100% --
HFE 16 100% --
HFE 20 100% --
HFE 24 50% 50%
HFE 33 50% 50%
HFE 42 50% 50%
HFS 60 50% 50%
HFS 80 50% 50%
HFS 100 50% 50%
CCF IPCF WFCF PDCF
0 0 1,00 1,00 1,00 1,00
10 -3.2 0,985 0,985 1,02 1,08
20 -7.8 0,980 0,990 1,04 1,12
30 -14.1 0,970 0,980 1,08 1,18
40 -22.3 0,960 0,970 1,14 1,25
358
CCCP 0,99 1 1,02
IPCF 0,99 1 1,01
0.00005 0.0001 0.0002
CCCP 1 0,98 0,94
IPCF 1 0,98 0,95
TECHNICAL SPECIFICATIONS
3.6 COMPRESSOR PARTIALISATION STEPS
NUMBER OF COMPRESSORS
Model
3.7 CORRECTION FACTORS
3.7.1 Glycol use correction factors
Percentage of
ethylene glycol (%)
Freezing
point (°C)
CCF: Cooling capacity correction factor. IPCF: Power consumption correction factor.
WFCF: Water flow rate correction factor. PDCF: Pressure drop correction factor.
The correction factors of the water flow rate and the pressure drops must be applied to the values obtained without the use of glycol. The
water flow rate correction factor is calculated in such a way as to maintain the same temperature difference that would be obtained without
the use of glycol. The pressure drops correction factor is applied to the correct water flow value of the water flow correction factor.
3.7.2 Different correction factors t
Water temp. difference (°C)
CCCP = Power correction factor IPCF = Power consumption correction factor
3.7.3 Fouling factor different correction factors
Fouling factor
CCCP = Power correction factor IPCF = Power consumption correction factor
Rev. C 09-2020MTEC.3810.GB-C-1 Operation and maintenance manual serie WZA English
20
06
08
12
16
20
24
33
40
