Hifionics HDBR User manual

DIGITAL BASS RESTORATION
HDBR

HDBR
DIGITAL BASS RESTORATION
INDEX PAGE
Congratulations on purchasing the HDBR! You are now the proud owner of the finest
and most accurate bass enhancing and restoration system available.
Specifications and Feature Descriptions...........................................................................................................1
HDBR Drawing and Functions.........................................................................................................................2-3
Application/ Diagram...........................................................................................................................................4
Troubleshooting...................................................................................................................................................5
Product Warranty.................................................................................................................................................6
The contents of this manual may not be reproduced or copied without the written consent of MAXXSONICS USA, Inc.
For instructional videos on wiring
the HDBR, please
visit our YouTube channel at
www.youtube.com/maxxsonicsusainc

HDBR SPECIFICATIONS
HDBR FEATURES
1
Maximum Input Level.............................................................................................15V rms
Maximum Output Level......................................................................................13.5V peak
Frequency Response......................................................................10Hz - 100KHz; +/-1dB
Total Harmonic Distortion.........................................................................................0.003%
Signal to Noise Ratio.................................................................................................130dB
Balanced Input Noise Rejection.................................................................................>60dB
Input Impedance.....................................................................................................10 Kohm
Output Impedance................................................................................................150 Ohms
Power Supply......................................................................................High headroom PWM
Power Draw...............................................................................................................150mA
Recommend fuse rating..............................................................................................1Amp
Bass Driver: The HDBR contains a Bass Driver circuit that accurately recreates and injects
Low Frequency information back into the signal path. What that means in everyday terms is
that the HDBR will give more bass impact to your best compact discs or lowest quality
recordings.
Bass Equalization Circuit: The HDBR has a unique equalization circuit that contours the
restored bass to your speaker systems.
Dash Mount Remote Control: The HDBR comes with a Dash Mountable Remote Control
that allows you to enjoy the effects of the HDBR without having to leave the drivers seat.The
Dash mount Control has an LED indicator that will grow brighter as you add more bass or
dimmer when you decrease it.
Bass Maxximizer Indicator: Not only does the HDBR provide good music to your ears, but
it also gives you some visual enjoyment as well. On the chassis of the HDBR there are three
LED indicators that flash when the bass maxximization circuit is activated.
Bass Output Control: The HDBR has the ability to produce large amounts of deep, ear
blowing bass without damaging your speakers. The Bass Output Control circuit allow the
HDBR to maxximize the bass output of any autosound audio system while restraining
destructive bursts.

HDBR DRAWING
2
RCA
INPUT
BALANCED UNBALANCED
GROUND
ISOLATION
GROUND 200-Ohms
ISOLATED
CENTER
FREQUENCY
FREQUENCY
RANGE
WIDE NARROW
OUTPUT LEVEL
9V .2V
4.5V
7V 2.5V
DIGITAL BASS RESTORATION
HDBR
POWER
FROM
GODS
THE

3
CENTER FREQUENCY:This knob allows you to select the frequency you want the HDBR
bass restoration circuit to maxximize.
FREQUENCY RANGE:This knob allows for you to adjust the range of frequencies from your
center point.All the way to the left will include the maxximum frequencies to maxximize, while
all the way to the right will enhance only a limited amount f frequencies near your CENTER
FREQUENCY.
OUTPUT LEVELCONTROL: This knob allows for you to control the amount of signal voltage
you are sending through the RCAOUTPUTS to your amplifier(s). It is important to note that the
MBC1 has a built in line driver capable of sending an ‘ultra clean’9 volts of signal output to
your amplifier(s). Be sure to reference the end panel silk screening for GAIN/LEVEL
CONTROL on your amplifier(s). Some amplifiers cannot handle the full 9 volts and going
beyond the specified Input range on your amplifier(s) can be damaging.
GROUND ISOLATION: Occasionally alternator whine may appear in the system because the
source unit and amplifier may use different grounds.To help in this situation, we have provided
alternative grounding options. MAKE SURE THE SYSTEM IS OFF BEFORE SWITCHING
THIS SELECTION!
RCAINPUT: In most cases you will leave the selection switch in the BALANCED position. In
some systems the source unit may look for a ground through the RCAconnections. In this
event you would switch the selection to UNBALANCED.
INPUT: RCA’s from source unit connect to this location.
OUTPUT: RCA’s from the HDBR connect to the inputs of your amplifier(s).
REMOTE: The BPR-1 Bass Processor Remote dash mount control connects here.This
remote allows for complete control of your audible subwoofer level along with a LED indicator
which brightens as you increase bass enhancement.
REM / 12V / GND:
-REM: Connects to a 12V+ switched source. The REM cable should have 12V when the
source unit is on and 0V when the source unit is off.Typically this would connect to
the ‘PowerAntenna’output wire on the back of your source units’wiring harness.
-12V: Connects to a 12V constant source. The Positive battery terminal is recommended and a
1 amp in-line fuse is required.
-GND: Connects to a ground location. Be sure that all paint is removed from the area of this
connection on the vehicle chassis.

HDBR WIRING DIAGRAM
4
Source Unit
REMOTE TURN-ON
CHASSIS GROUND
TO BATTERY +12v VIA
5 AMP FUSE
Amplifier
RCA
INPUT
BALANCED UNBALANCED
GROUND
ISOLATION
GROUND 200-Ohms
ISOLATED
CENTER
FREQUENCY
FREQUENCY
RANGE
WIDE NARROW
OUTPUT LEVEL
9V .2V
4.5V
7V 2.5V
DIGITAL BASS RESTORATION
HDBR
POWER
FROM
GODS
THE
MIN MAX
HDBR
BASS REMOTE

5
TROUBLESHOOTING A SYSTEM
Thekeytofindingtheprobleminatroubledsoundsystemistoisolatepartsofthatsysteminalogicalfashiontotrackdownthe
fault.
ThediagnosticsystemwillnotshutdowntheHDBRortheamplifier(s),althoughtheamplifier(s)ownprotectioncircuitrymayshut
the amplifier(s) down should a fault status occur.At which time you will need to consult the owners manual for that particular
amplifier.
Lowoutputpower
1-Checkthatlevelcontrolshavebeensetupproperly.
2 -Make surethat the batteryvoltage, asmeasured at theamplifier(s) andHDBR +12 voltand groundterminals, is 11 voltsor
more.
3-Checkall+12voltandgroundconnections.
Fusesblowing
1-Insurethatthevoltagetotheunitdoesnotexceed15volts.
2-A shortonthemain+12voltcablefromthebatterytothevehiclechassiswillcausethemainfusetoblow.
3-IftheMBC1 isblowingfusescontinuallywithonly+12volt,groundandremoteleadsconnected,theunitmaybefaulty.
Systemdoesnotturnon
1-Checkallfuses.
2-Checkallconnections.
3-Measurethe+12voltandremoteturnonvoltagesattheamplifier(s)andHDBRterminals.Ifthesearenonexistentorlow,take
voltagemeasurementsatfuseholders,distributionblocks,theheadunit’s+12voltandremoteleadstolocalizetheproblem.
Noiseproblems
Systemnoisecanbedividedintotwocategories,hiss,andelectricalinterference.
Hiss,orwhitenoise
1 - High levels of white noise usually occur when level controls are turned up too high - reduce the levels until the noise is no
longerpresent.
2-Anothermajorproblemthatcancauseexcessivehiss,isanoisyheadunit-unplugtheHDBRInputRCA’s,andifthehisslevel
reduces,thesourceunitisatfault.
Electricalinterference
The inside of an automobile is a very hostile electrical environment. The multitude of electrical systems, such as the ignition
system,alternator,fuelpumps,airconditioners,tomentionjustafew,createradiatedelectricalfields,aswellasnoiseonthe+12
voltsupplyandground.Totryandeliminatethisnoise,runawirefromtheradiogroundwiretothegroundinputontheHDBR.
A tickingorwhinethatchangeswithengineRPM:
1-ThisproblemcouldbecausedbyradiationpickupofRCAcablesthataretooclosetoafuelpumporadistributor.
2-Checkthattheheadunitgroundisconnectedstraighttothevehiclechassis,anddoesnotusefactorywiringforground.
3-Tryto supplytheheadunit withaclean +12voltsupplydirectlyfromthebattery+, insteadofusing asupplyfrom theindash
wiring/fusebox.
Aconstant whine:
This type of noise can bemore difficult to pinpoint,but is usually caused by somekind of instability, causing oscillationsin the
system.
1-Checkallconnections,especiallyforgoodgrounds.
2-Makesurethatnospeakerleadsareshortingtoexposedmetalonthevehiclechassis.
3-RCAcablesarenotoriousfortheirproblematicnature,socheckthatthesearegood,inparticulartheshieldconnections.

6
As the manufacturer of Maxxsonics, MB Quart, Hifonics, Crunch and Autotek car audio
products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier
to be free from defects in material and workmanship for one (1) Year from date of purchase.
All other parts and accessories of the system are warrantied to be free from defects in
material and workmanship for one (1) year from date of purchase. Maxxsonics will repair
or replace at it’s option and free of charge during the warranty period, any system
component that proves defective in materials and workmanship under normal installation,
use and service provided that the product is returned to the authorized Maxxsonics dealer
from where it was purchased. A photo copy of the original receipt must accompany the
product being returned.
Valid purchase receipts will contain the name and address of the authorized reseller.
Any damage to the product as a result of misuse, abuse, accident, incorrect wiring,
improper installation, alteration of date code or bar code labels, revolution, natural
disaster, or any sneaky stuff because someone messed up, repair or alteration out side of
our factory or authorized service centers and any thing else you have done that you should
not have done is not covered.
This warranty is limited to defective parts and specifically excludes any incidental or
consequential damages connected therewith. This warranty is not to be construed as an
insurance policy.
Warranty on installation labor, removal, re-installation and freight charges are not the
responsibility of Maxxsonics USA Inc.
Warranty products damaged as a result of insufficient or improper packing materials are
not covered by this limited warranty and such damaged product will be returned “as is”
at the expense of the owner.
Maxxsonics Limited Warranty

PART # F1211
