High End Systems Studio Command Series User manual

Series
Studio Command 1200
Studio Command 700
Studio Command H
User Manual
©High End Systems, Inc. 2005, All Rights Reserved
Information and specifications in this document are subject to change without notice. High End
Systems, Inc. assumes no responsibility or liability for any errors or inaccuracies that may
appear in this manual.
Trademarks used in this text: High End Systems, WholeHog III, xSpot Xtreme, Technobeam,
Studio Spot, Studio Color, Studio Color 250, Studio Spot 250, Studio Beam, and Lithopatterns
are registered trademarks; and Studio Command, TalkBack, Internal Effects, the High End
Systems globe logo, Light Burst, the Hog logo are trademarks of High End Systems, Inc. or High
End Systems Europe Ltd. Belden is a registered trademark of Belden, Inc. Philips is a registered
trademark of Philips Lighting Company. Krytox is a registered trademark of DuPont.
Other trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. High End Systems disclaims any proprietary
interest in trademarks and trade names owned by others.
Studio Command™ User Manual
P/N 60600252 V4.2
Printed in the USA
January, 2007

ii Studio Command User Manual
Contacting High End Systems®
U.S. and the Americas
Sales Department High End Systems, Inc.
2105 Gracy Farms Lane
Austin, TX 78758 USA
voice: 512.836.2242
fax: [phone]
Toll Free: 800.890.8989
Customer Service High End Systems, Inc.
2105 Gracy Farms Lane
Austin, TX 78758 USA
voice: 800.890.8989
fax: [phone]
toll free: 800.890.8989
World Wide Web: http://www.highend.com

Studio Command User Manual iii
Declaration of Conformity
according to ISO/IEC Guide 22 and EN45104
Manufacturer’s name: High End Systems, Inc.
Manufacturer’s address: 2105 Gracy Farms Lane
Austin, Texas 78758 USA
Distributor’s name: High End Systems, Inc.
Distributor’s address: 2105 Gracy Farms Lane
Austin, Texas 78758 USA
Declares that the product
Product Name: Studio Command 1200/700, Studio Command H
Product Number: All
Product Options: All
conforms to the following EEC directives:
73/23/EEC, as amended by 93/68/EEC
89/336/EEC, as amended by 92/31/EEC and 93/68/EEC
Equipment referred to in this declaration of conformity was first manufactured in compliance
with the following standards in 2005:
Safety: EN 60598-1 : 1997
EN 60598-2-17 ; 1990
A1-A3 : 1998
A13: 1999
EMC:
EN 55022 Conducted Emissions Class A
Radiated Emissions Class A
ANSI C63.4 Class A
FCC 47 CFR Part 15 Class A
VCCI V-1/2001.04 Class A
EN 55024 EN 61000-4-2 4/8kV
EN 61000-4-3 A1 3V/m
EN 61000-4-4 1kV/0.5kV
EN 61000-4-5 2kV/1kV
EN 61000-4-6 3 Vrms
EN 61000-4-11 >95%-0.5p, 30%-25p,>95%-250p
EN 61000-3-2 Class A
EN 61000-3-3
USA, Thursday, March 06, 2008
Kenneth Stuart Hansen, Compliance Engineer

iv Studio Command User Manual
Product Modification Warning
High End Systems products are designed and manufactured to meet the requirements of United
States and International safety regulations. Modifications to the product could affect safety and
render the product non-compliant to relevant safety standards.
Mise En Garde Contre La Modification Du Produit
Les produits High End Systems sont conçus et fabriqués conformément aux exigences des
règlements internationaux de sécurité. Toute modification du produit peut entraîner sa non
conformité aux normes de sécurité en vigueur.
Produktmodifikationswarnung
Design und Herstellung von High End Systems entsprechen den Anforderungen der U.S.
Amerikanischen und internationalen Sicherheitsvorschriften. Abänderungen dieses Produktes
können dessen Sicherheit beeinträchtigen und unter Umständen gegen die diesbezüglichen
Sicherheitsnormen verstoßen.
Avvertenza Sulla Modifica Del Prodotto
I prodotti di High End Systems sono stati progettati e fabbricati per soddisfare i requisiti delle
normative di sicurezza statunitensi ed internazionali. Qualsiasi modifica al prodotto potrebbe
pregiudicare la sicurezza e rendere il prodotto non conforme agli standard di sicurezza
pertinenti.
Advertencia De Modificación Del Producto
Los productos de High End Systems están diseñados y fabricados para cumplir los requisitos de
las reglamentaciones de seguridad de los Estados Unidos e internacionales. Las modificaciones
al producto podrían afectar la seguridad y dejar al producto fuera de conformidad con las
normas de seguridad relevantes.
Important Safety Information
Instructions pertaining to continued protection against fire, electric shock, and injury to persons are found in
Appendix C. Please read all instructions prior to assembling, mounting, and operating this equipment.
Important: Informations De Sécurité
Les instructions se rapportant à la protection permanente contre les incendies, l’électrocution, excessif et aux
blessures corporelles se trouvent dans l’Annexe C. Veuillez lire toutes les instructions avant d’assembler, de
monter ou d’utiliser cet équipement.
Wichtige Sicherheitshinweise
Sicherheitsanleitungen zum Schutz gegen Feuer, elektrischen Schlag, und Verletzung von Personen finden Sie
in Anhang C. Vor der Montage, dem Zusammenbau und der Intbetriebnahme dieses Geräts alle Anleitungen
sorgfältig durchlesen.
Informazioni Importanti Di Sicurezza
Le istruzioni sulla protezione da incendi, folgorazione, e infortuni sono contenute nell’appendice C. Si prega di
leggere tutte le istruzioni prima di assemblare, montare e azionare l’apparecchiatura.
Informacion Importante De Seguridad
En el Apéndice C se encuentran instrucciones sobre protección continua contra incendios, descarga eléctrica,
y lesiones personales. Lea, por favor, todas las instrucciones antes del ensamblaje, montaje y operación de
este equipo.
FCC Information
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and

Studio Command User Manual v
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own
expense.
Safety Symbols
The following international caution and warning symbols appear in margins throughout this
manual to highlight messages.
Warranty Information
Limited Warranty
Unless otherwise stated, your product is covered by a one year parts and labor limited warranty.
Dichroic filters and LithoPatterns®high resolution glass gobos are not guaranteed against
breakage or scratches to coating. It is the owner’s responsibility to furnish receipts or invoices
for verification of purchase, date, and dealer or distributor. If purchase date cannot be provided,
date of manufacture will be used to determine warranty period.
Returning an Item Under Warranty for Repair
It is necessary to obtain a Return Material Authorization (RMA) number from your dealer or
point of purchase BEFORE any units are returned for repair. The manufacturer will make the
final determination as to whether or not the unit is covered by warranty. Lamps are covered by
the lamp manufacturer’s warranty.
Any Product unit or parts returned to High End Systems must be packaged in a suitable manner
to ensure the protection of such Product unit or parts, and such package shall be clearly and
prominently marked to indicate that the package contains returned Product units or parts and
with an RMA number. Accompany all returned Product units or parts with a written explanation
of the alleged problem or malfunction. Ship returned Product units or parts to: 2105 Gracy
Farms Lane, Austin, TX 78758 USA.
Note: Freight Damage Claims are invalid for fixtures shipped in non-factory
boxes and packing materials.
CAUTION: This symbol appears adjacent to Caution
messages. Not heeding these messages could result in
personal injury and/or damage to equipment.
WARNING: This symbol appears adjacent to high
voltage warning messages. Not heeding these
messages could result in serious personal injury.
This symbol indicates the minimum focus distance
from a combustible object.
This symbol cautions against mounting the fixture on a
flammable surface.
This symbol indicates that, while operating, equipment
surfaces may reach very high temperatures. Allow the
fixture to cool before handling.

vi Studio Command User Manual
Freight
All shipping will be paid by the purchaser. Items under warranty shall have return shipping paid
by the manufacturer only in the Continental United States. Under no circumstances will freight
collect shipments be accepted. Prepaid shipping does not include rush expediting such as air
freight. Air freight can be sent customer collect in the Continental United States.
REPAIR OR REPLACEMENT AS PROVIDED FOR UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. HIGH END SYSTEMS, INC. MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, WITH RESPECT TO ANY PRODUCT, AND HIGH END SPECIFICALLY DISCLAIMS ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HIGH END
SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGE,
INCLUDING LOST PROFITS, SUSTAINED OR INCURRED IN CONNECTION WITH ANY PRODUCT
OR CAUSED BY PRODUCT DEFECTS OR THE PARTIAL OR TOTAL FAILURE OF ANY PRODUCT
REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT, TORT (INCLUDING
NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, AND WHETHER OR NOT SUCH DAMAGE WAS
FORESEEN OR UNFORESEEN.
Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized
repairs or parts. This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state.
Patents
This product may use one or more of the following patents: US 4,392,187; US 4,602,321; US 4,688,161;
US 4,701,833; US 4,709,311; US 4,779,176; US 4,800,474; US 4,962,687; US 4,972,306; US 4,980,806;
US 5,010,459; US 5,031,078; US 5,073,847; US 5,078,039; US 5,186,536; US 5,209,560; US 5,278,742;
US 5,282,121; US5,307,295; US 5,329,431; US 5,331,822; US 5,367,444; US 5,402,326;US 5,430,629;
US 5,432,691; US 5,454,477; US 5,455,748; US 5,506,762; US 5,515,254; US 5,537,303; US5,545,951;
US 5,580,164; US 5,590,954; US 5,590,955; US 5,640,061; US 5,647,662; US5,665,305; US 5,691,886;
US 5,728,994; US 5,758,955; US 5,758,956; US 5,769,527; US5,774,273; US 5,798,619; US 5,806,951;
US 5,823,661; US 5,825,548; US5,828,485; US 5,829,868; US 5,857,768; US 5,882,107; US 5,934,794;
US 5,940,204; US 5,945,786; US5,953,152; US 5,980,066; US 6,048,080; US 6,327,103; US 6,048,081;
US 6,057,958; US6,054,816; US 6,126,288; US 6,142,652; US 6,172,822; US 6,188,933;US 6,208,087;
US 6,219,093; US 6,220,730; US 6,241,366; US 6,255,787; US 6,256,136; US 6,278,542; US6,288,828;
US 6,327,103; US 6,421,165; US 6,430,934; US 6,466,357; US 6,502,961; USD347,113; US D350,408;
US D359,574; US D360,404; US D365,165; US D366,712; US D370,080; US D372,550; US D377,338;
US D381,740; US D409,771; US 6693392; US 6719433; EP 0662275; EP 0767398; DE 621495; DE 655144;
DE 797503; EP 0475082; GB 2 043 769 B; GB 2 055 842 B; GB 2 283 808 B; GB 2 290 134 B; GB 2 291 814 B;
GB 2 292 530 B; GB 2 292 896 B; GB 2 294 909 B; GB 2 295 058 B; GB 2 303 203 B; GB 2 306 887 B;
GB 2 307 036 B; GB 2 316 477 B; MR0862-1996; M9,604,224.9

Studio Command Series User Manual vii
Table of Contents
User Manual ................................................................................................... i
Contacting High End Systems® ..................................................................... ii
Declaration of Conformity ............................................................................ iii
Important Safety Information .................................................................... iv
FCC Information....................................................................................... iv
Safety Symbols......................................................................................... v
Warranty Information ................................................................................... v
Limited Warranty....................................................................................... v
Returning an Item Under Warranty for Repair................................................ v
Freight.................................................................................................... vi
Patents ................................................................................................... vi
Chapter 1: Product Overview
Model Comparison ....................................................................................... 1
Studio Command™ Features ............................................................................ 2
Fixture ....................................................................................................... 2
All Models................................................................................................. 2
Studio Command 1200/700 Model Only........................................................ 2
Operation ................................................................................................... 2
Construction ............................................................................................... 3
Related Products and Accessories ..................................................................... 4
Specifications ................................................................................................. 5
Mechanical ................................................................................................. 5
Environmental ............................................................................................. 5
Electrical .................................................................................................... 6
Power...................................................................................................... 6
Fuses....................................................................................................... 6
Cable and Connector Specifications ................................................................ 7
Lamp Specifications ..................................................................................... 7
Chapter 2: Setup and Configuration
Unpacking the Fixture ..................................................................................... 9
Installing an Attachment Plugs ........................................................................ 9
Installing an Attachment Plug - U.K. Only ..................................................... 10
Vigtig Fikker Heds Information - Danmark .................................................... 10
Installing the Lamp (Studio Command-H Fixtures Only) ..................................... 10
Mounting the Fixture ..................................................................................... 11
Mounting the Fixture Upright ....................................................................... 11

viii Studio Command Series User Manual
Mounting the Fixture on a Truss .................................................................. 11
Truss or Other Support System ................................................................. 12
Safety Cable........................................................................................... 12
Clamp.................................................................................................... 12
Mounting Procedure................................................................................. 12
Linking the Fixtures ...................................................................................... 13
Data Cabling and Connectors ...................................................................... 13
DMX data cables: .................................................................................... 13
Cable Connectors:................................................................................... 14
Setting Up a DMX Link ............................................................................... 15
Standalone Fixture Linking .......................................................................... 16
Terminating the Link .................................................................................. 16
Powering On the Fixture ................................................................................ 17
Uploading Latest Fixture Software .................................................................. 17
Assigning a DMX Start Channel ...................................................................... 18
Determining the DMX Start Channel ............................................................. 19
Chapter 3: The Menu System
On-Board Programming Capability .................................................................. 21
Navigating the Menu System ......................................................................... 21
Studio Command Menu Options ...................................................................... 22
Preset Menu (PRST) ................................................................................... 23
Setting Preset Playback (PLAY).................................................................. 23
Editing or Creating an On-Board Memory Scene (EDIT) ................................ 24
Copying an On-Board Memory Scene (COPY) .............................................. 24
Capturing a Preset Scene (CAPT)............................................................... 25
Enabling the Preset Default (DFLT) ............................................................ 25
Set Menu (SET) ......................................................................................... 26
Setting Factory Defaults (FACT) ................................................................ 26
Swapping Pan and Tilt (SWAP).................................................................. 26
Inverting Tilt (T/IN)................................................................................. 27
Inverting Pan (P/IN) ................................................................................ 27
Changing the Display Output (DSPL).......................................................... 28
Inverting LED Characters (D/IN)................................................................ 28
Setting the Lamp Warning Message (LMPL)................................................. 29
Data Loss Shutter Close (DLOS)................................................................ 29
Mode Menu (MODE) ................................................................................... 30
Setting the User Type (USER) ................................................................... 30
Copying User Presets (PRST) .................................................................... 30
Copying User Settings (SETT) ................................................................... 31
Copying User Presets and Settings (ALL) .................................................... 31
Crossloading Fixture Software (XLD).......................................................... 32

Studio Command Series User Manual ix
Test Menu (TEST) ...................................................................................... 33
Homing the Fixture (HOME) ...................................................................... 33
Turning the Lamp On or Off (LAMP) ........................................................... 33
Copying the Boot Code (BOOT) ................................................................. 33
Performing Self Tests (SELF)..................................................................... 34
Placing the Fixture in Setup Mode (S/UP).................................................... 34
Testing the LED Display (DISP) ................................................................. 35
Changing Encoder Operation (ENCD).......................................................... 35
Information Menu (INFO) ............................................................................ 36
Viewing Sensor Information (SENS)........................................................... 36
Viewing Fixture DMX Status and Parameter Values (FIXT)............................. 37
Viewing DMX Data for Another Device (DATA) ............................................. 38
Viewing the Current Logic Board Temperature (PCB) .................................... 39
Viewing the Current Fixture Head Temperature (HEAD) ................................ 39
Resetting Fixture Hours (F/RS).................................................................. 40
Viewing the Current Fixture Hours (F/HR)................................................... 40
Resetting Lamp Hours (L/RS) (Studio Command 1200/700 models only)......... 40
Viewing the Number of Current Lamp Strikes (L/ST) .................................... 41
Viewing the Current Lamp Hours (L/HR) ..................................................... 41
Viewing the Current Software Version (VER) ............................................... 41
Scene Creation, Looping and Playback Example ................................................ 42
Step-by-Step Scene Creation ...................................................................... 42
Creating a Loop ......................................................................................... 45
Playing Back a Loop ................................................................................... 45
Synchronizing Preset Playback ..................................................................... 46
Chapter 4: Fixture Programming
TalkBack™ Support for Remote Access ............................................................ 47
DMX Programming Overview .......................................................................... 48
Full Speed verses MSpeed Control ............................................................... 48
DMX Programming Options ......................................................................... 48
Programming with a DMX Console ................................................................ 48
DMX Programming Using the Onboard Menu System ...................................... 49
Parameter Function Descriptions .................................................................... 49
Pan and Tilt Parameters ............................................................................. 49
Color Function Parameter ........................................................................... 49
Cyan, Magenta, and Yellow Parameters ........................................................ 50
Zoom Parameter ....................................................................................... 50
Shutter Function Parameter ........................................................................ 50
Studio Command 1200/700 Models............................................................ 50
Studio Command H Model ........................................................................... 51
Dim Parameter .......................................................................................... 52

xStudio Command Series User Manual
MSpeed (Motor Speed) Parameter ............................................................... 52
Macro Parameter ....................................................................................... 52
Control Parameter ..................................................................................... 53
Studio Command 1200/700 ..................................................................... 53
Studio Command H.................................................................................. 53
Chapter 5: General Maintenance
Replacing Parts ............................................................................................ 55
Replacing Fuses ........................................................................................ 55
Replacing the Lamp ................................................................................... 58
Optimizing the Lamp .................................................................................. 59
Motor Gear Maintenance ................................................................................ 61
Chapter 6: Troubleshooting
Alphanumeric Display Error Messages ............................................................. 63
Status LEDs ................................................................................................. 68
General Troubleshooting ............................................................................... 69
Upload and Crossload Troubleshooting ............................................................ 71
Appendix A: Studio Command™ DMX Protocol
Studio Command 1200 Protocol ..................................................................... 73
Studio Command 700 Protocol ....................................................................... 76
Studio Command-H Protocol .......................................................................... 80
Appendix B: MSpeed Conversion Table.................................................... 83
Appendix C: Important Safety Information ............................................ 85
Appendice C: Importantes Informations Sur La Sécurité ................................. 87
Anhang C: Wichtige Hinweise Für Ihre Sicherheit ........................................... 88
Apéndice C: Información Importante De Seguridad ........................................ 89
Appendice C: Importanti Informazioni Di Sicurezza ........................................ 90
Vigtig Sikkerhedsinformation ....................................................................... 91
Appendix D: Menu Map
Studio Command Menu Map .......................................................................... 93

Studio Command Series User Manual 1
Chapter 1:
Product Overview
Studio Command 1200 Studio Command 700 Studio Command H
Input Voltage 200-230 V 100-230 V 100-230 V
Lamp 1200 MSR* 700 MSR* 1000 W
Color Temperature 5900 K 5600 K 3200 K
Fixture Output 15,000 lumens 11,000 lumens 5,500 lumens
The Studio Command Series offer powerful washlights featuring a large exiting beam with a
compact head. All models use a patented lenticular array optical system to enhance the
homogeneity of the projected light. The moving yoke fixtures feature an adjustable field angle
from 18 to 32 degrees, and a CMY dichroic color-mixing system that provides rapid and quiet
color changes.
Studio Command 1200 and 700 models use proven Philips long-life MSR lamps. These models
also offer a variable mechanical and electronic strobe, boosted with the Light Burst™ effect, and
a mechanical douser for smooth fade to black. The Studio Command 1200/700 models uses 14
channels on a DMX link.
The Studio Command H model offers a Tungsten source and works with standard theater
dimming racks. The H model requires 13 DMX channels plus one channel dedicated to the
dimmer.
All Studio Command fixtures provide an option for standalone programming and support
TalkBack™technology that allows any DMX console supporting TalkBack protocol to remotely
access the Studio Command onboard menu system.
Model Comparison
* 7200°K MSR 1200/2 and MSR 700/2 lamps are approved alternatives

CHAPTER 1
Product Overview
2Studio Command Series User Manual
Studio Command™Features
Fixture
All Models
• 540° pan 240° tilt
• Optical encoders to automatically correct the beam’s position if the fixture’s head is jarred
from its programmed position.
• Shutter construct parameters including ramp, snap, and synchronous strobing functions.
• Time code synchronization in stand-alone mode via master/slave links to any combination of
xSpot®Xtreme, Technobeam®, Studio Spot®, Studio Color®, Studio Color®250, Studio
Spot®250, Studio Beam®, and Studio Command™ fixtures.
• DMX analyzer for easy DMX troubleshooting.
• Lamp interlock douses the lamp if the lamp cap is opened while the lamp is on.
• Remote fixture power up and shut down.
Studio Command 1200/700 Model Only
• Smooth full-field dimming without changing color temperature or beam shape.
• Electronic strobe in addition to a variable conventional strobe to 10 Hz.
• Full optical dimming and fade-to-black.
• Light burst lamp boosting and lightning effects.
Operation
• High-resolution DMX512 programming control.
• TalkBack protocol support for remote fixture control.
• Fat output beam (8 inches (200 mm) in diameter)
• Integral, fully variable zoom adjustable from 8°–13° beam angle and an 18°–32° field angle.
• Fully dichroic colors that never fade
• Full control over color mixing from smooth, stepless movement (allowing slow, imperceptible
color fades) to rapid snap color changes
• Quiet performance even during snap color changes
• Even, soft-edged wash with good beam distribution for easy blending
• Live color fading from one color to another at any speed
• On-board Preset DMX programming via the fixture’s menu system for stand-alone operation.
• Easy-to-program alphanumeric LED (light emitting diode) display.
• Two user Preset modes (A and B), each with an on-board 16-scene memory for a total of 32-
scene memory per fixture in stand-alone mode.
• DMX macro channel factory-programmed with four Internal Effects™ macros.

CHAPTER 1
Product Overview
Studio Command Series User Manual 3
Construction
• Exterior design minimizes light leakage.
• Universal power supply automatically selects the appropriate voltage for the fixture:
—200V–230V for Studio Command 1200
—100V–230V at 50-60 Hz for Studio Command 700 and Studio Command H models
• 5-pin XLR connectors. (Studio Command 1200/700 models also provide connections for 3-pin
XLR data cables).
• Exclusive High End Systems, Inc. multi-phase technology for stunningly fast, smooth, and
quiet yoke movement.
• LED status indicators streamline troubleshooting.
• Precision stepper motors control dimmer, shutter function, and color mixing.
• Compact and lightweight
• Color temperature control via an optional Gel Holder accessory.
• Studio Command H models provide a lamp to dimmer power cable for connection to standard
theatrical dimmers.

CHAPTER 1
Product Overview
4Studio Command Series User Manual
Related Products and Accessories
The following table lists other products you can utilize with the Studio Command and optional
accessories available from your High End Systems dealer/distributor.
For more information about optional accessories, contact either your High End Systems®
dealer/distributor, High End Systems Sales, or visit the High End Systems Web site. For contact
information, see Contacting High End Systems® on page ii.
Part Description Part Number
MSR 1200 replacement lamp (5900K) 55030077
MSR 1200/2 alternative lamp (7200K) 55030047
MSR 700 replacement lamp (5600K) 55030069
MSR 700/2 alternative lamp (7200K) 55030048
1000 W, 100 V replacement Lamp for Studio Command H model 55030078
1000 W, 115 V replacement Lamp for Studio Command H model 55030071
1000 W, 230 V replacement Lamp for Studio Command H model 55030072
1000 W, 240 V replacement Lamp for Studio Command H model 55030079
Heavy duty 3-pin XLR cable (10’) 55050005
Whole Hog®III Lighting Console 25020001
Hog iPC Lighting Console 74020001
Heavy duty 3-pin XLR cable (25’) 55050006
Heavy duty 3-pin XLR cable (50’) 55050007
Heavy duty 3-pin XLR cable (100’) 55050008
Heavy duty 5-pin XLR cable (10’) 55050017
Heavy duty 5-pin XLR cable (25’) 55050018
Heavy duty 5-pin XLR cable (50’) 55050019
Heavy duty 5-pin XLR cable (100’) 55050020
Upload Dongle 26040002
Galvanized safety cable 12040001
Cheeseborough clamp 55040014
Gel Frame Holder accessory 78040001

CHAPTER 1
Product Overview
Studio Command Series User Manual 5
Specifications
Mechanical
Dimensions: 352mm x 544mm x 526mm
13.9in x 21.4in x 20.7in
Weight: 1200/700 Model - 24.9 kg (55 lbs)
H Model - 21.7 kg (48 lb)
Environmental
Maximum ambient temperature, (Ta): 50° C (122° F)
Maximum exterior surface temperature: 160° C (320° F)
543 mm
485 mm
(21.4 in)
(19.1 in)
335 mm
(13.2 in)
355 mm
484 mm
(14 in)
(19 in)
49 mm
34 mm
(1.3 in)
(2.7 in)
69 mm
(.6 in)
16 mm
144 mm
(5.7 in)
(1.9 in)
526 mm
(20.7 in)
(15.4 in)
(5.3 in)
135 mm
391 mm
119 mm
(4.7 in)
295 mm (11.6 in)
352 mm
(13.9 in)
502 mm
(19.8 in)
Ø

CHAPTER 1
Product Overview
6Studio Command Series User Manual
Electrical
Power
Model Maximum Rated Power
Studio Command 1200 230 V @ 6.1 AMP 1400 W
Studio Command 700 230 V @4.3 AMP 1200 W
Studio Command H 230 V @ 5.2 AMP* 1200 W
* Total fixture and dimmer controlled lamp
Fuses
Logic Board Fuses:
F1 - 2.5A, 250V, Slow Blow only (5 mm x 20 mm)
F2 - 2.5A, 250V, Slow Blow only (5 mm x 20 mm)
Motor Power Supply Fuses:
F1 - 6.3A, 250V, Slow Blow only (5 mm x 20 mm)
F2 - 6.3A, 250V, Fast Blow only (5 mm x 20 mm)
Filter Board Fuses:
F1 - 16A, 250V, Fast Blow only (5 mm x 20 mm)
F2 - 16A, 250V, Fast Blow only (5 mm x 20 mm)
Voltage Surge: A surge of 2000V or more may damage the power supply.
WARNINGS:
Minimum distance to flammable objects: 3.28 ft (1.0 m)
Minimum distance to lighted object: 6.56 ft (2.0 m)
Do not mount on a flammable surface.
Warning: Class 1 equipment - This equipment must be earthed.
1
2

CHAPTER 1
Product Overview
Studio Command Series User Manual 7
Cable and Connector Specifications
DMX data cables: Belden®9841 or equivalent (meets specifications for EIA RS-485
applications) with the following characteristics:
• 2-conductor twisted pair plus a shield
• maximum capacitance between conductors - 30 pF/ft.
• maximum capacitance between conductor and shield - 55 pF/ft.
• maximum resistance of 20Ω/ 1000 ft.
• nominal impedance 100-140Ω
DMX data connectors, 1200/700 Model: 3-pin or 5-pin male and female XLR connectors
DMX data connectors, H Model: 5-pin male and female XLR connectors
DMX data terminators: Male XLR connector with 120 ohm terminator
Lamp Specifications
Studio Command 1200 Studio Command 700
Studio Command H
Primary Lamp Alternate Lamp Primary Lamp Alternate Lamp
Lamp: PHILIPS
MSR1200 PHILIPS MSR1200/2 PHILIPS MSR700 PHILIPS MSR700/2 PHILIPS
7002 Y
Luminous Flux 110,000lm 110,000lm 56000lm 55000 lm 29,000lm
Arc Length 10 mm 10 mm 8 mm 8 mm N/A
Color
Temperature 5900K 7200K 5600K 7200K 3200K
Lamp Life 50% 800 hrs 800 hrs 1000 hrs 1000 hrs 250 hrs
CRI 95 85 95 80 100
CIE X=.325;
Y=.320 X=.302; Y=.320 X=.330; Y=.330 X=.302; Y=.320

CHAPTER 1
Product Overview
8Studio Command Series User Manual

Studio Command Series User Manual 9
Chapter 2:
Setup and Configuration
Unpacking the Fixture
Unpack your Studio Command™fixture and verify that it arrived
undamaged. Inspect both the outside of the fixture for physical
damage and the inside of the fixture for damage to glass
components.
To access the internal components, release the two bezel latches
(one latch located on each side of the fixture’s head) and remove
the bezel.
If the fixture is damaged, notify both the shipping agent and your
sales agent immediately.
Do not discard the shipping carton and packing materials. The carton and packing
materials are specifically designed to protect the product during transport.
High End Systems assumes no responsibility for products that are damaged during transport.
Always return a product for repair in its original shipping carton and packing materials.
Note: Before sending anything to the factory, call your High End Systems
dealer/distributor for a Return Material Authorization (RMA) number.
The factory cannot accept any goods shipped without an RMA number.
Installing an Attachment Plugs
Studio Command fixtures do not ship with molded attachment plugs on the fixture power cable
and, in the case of Studio Command-H fixtures, the dimmer power cable. Different locations
(even within the same country) may require a different attachment plug to connect your fixture
to a power outlet. Because of the variety of attachment plugs used worldwide, High End
Systems, Inc. cannot make specific recommendations for the particular attachment plug you
should use. Contact a local authority if you are unsure which type of attachment plug you need
to obtain. Note that the cores in the mains lead are colored according to the following code:
• green and yellow = earth
• blue = neutral
• brown = live
Removing the bezel
bezel latch

Warning: Class 1 equipment - This equipment must be
earthed.
CHAPTER 2
Setup and Configuration
10 Studio Command Series User Manual
Installing an Attachment Plug - U.K. Only
In the United Kingdom, the colours of the cores in the mains lead of this equipment may not
correspond with the colored markings identifying the terminals in your plug. Therefore, install
an attachment plug in accordance with the following code:
• The core which is coloured green and yellow must be connected to the plug terminal which is
marked with the letter “E” or by the earth symbol , or coloured green, or green/yellow.
• The core which is coloured blue must be connected to the terminal which is marked with the
letter “N” or coloured black.
• The core which is coloured brown must be connected to the terminal which is marked with the
“lateral” or coloured red.
Vigtig Fikker Heds Information - Danmark
Advarsel: Beskyttelse mod elektrisk chock.
Vigtigt!
Lederne med gul/groen isolation maa kun tilsluttes en klemme maerket
Installing the Lamp (Studio Command-H Fixtures Only)
1. Tilt the fixture’s head to access the lamp cap and
using a wide tip, flat head screwdriver, loosen
(but do not remove) the two lamp assembly
screws.
2. Pull the lamp assembly straight out of the
fixture. The lamp assembly is connected to the
fixture by lamp socket wires. Support the lamp
assembly while replacing the lamp. Do not
allow the lamp socket wires to support the
weight of the lamp assembly.
3. Remove all packaging materials from the new
lamp. Holding the new lamp by its ceramic base,
gently press the two base pins into the
B
lamp socket until the lamp is firmly
seated.
Caution: When handling the new lamp, avoid contact with
the lamp glass. If the lamp glass is soiled by oil or
dirt from skin, gloves, etc., clean the cold lamp
glass with an alcohol wipe. A soiled lamp could
overheat and burst, causing damage to the fixture.
eller
A
