High End Systems ecodome User manual

User Manual
High End Systems, Inc.
2217 West Braker Lane
Austin, TX 78758 U.S.A.
[phone]
www.highend.com
p/n 60600135 Version 1.0
ecodome®

For the latest product updates and information not contained
in this manual, visit the High End Systems Product Support page at:
http://info.highend.com/service/prodsupt.html

Ecodome®User Manual i
ecodome
User Manual
© High End Systems, Inc. 1999, All Rights Reserved
Information and specifications in this document are subject to change without notice. High End
Systems, Inc. assumes no responsibility or liability for any errors or inaccuracies that may appear in
this manual.
Trademarks used in this text: Lightwave Research, High End Systems, Studio Color, and
LithoPatterns are registered trademarks; and Studio Spot, Studio Color 250, Studio Spot 250, the
Lightwave Research logo, and the High End Systems globe logo are trademarks of High End
Systems, Inc. Belden is a registered trademark of Belden, Inc. Fram is a registered trademark of
Allied Signal. ETL and C-ETL are registered trademarks of Intertek Testing Services. Other
trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their products. High End Systems disclaims any proprietary interest in
trademarks and trade names owned by others.
For patent information, see the inside back cover of this manual.
Ecodome®User Manual
P/N 60600135 Version 1.0 February, 1999
Printed in the USA
C.C.
®

ii Ecodome®User Manual
Contacting High End Systems
U.S. and the Americas:
Sales Department: High End Systems, Inc.
2217 West Braker Lane
Austin, TX 78758 USA
voice: [phone]
FAX: [phone]
Customer Service: High End Systems, Inc.
2227 West Braker Lane
Austin, TX 78758 USA
voice: [phone]
24-hour FAX: [phone]
24-hour voice mail: [phone]
or [phone]
U.S. West Coast: High End Systems, Inc.
8200 Haskell Avenue
Van Nuys, CA 91406 USA
voice: [phone]
FAX: [phone]
World Wide Web: http://www.highend.com
Europe: High End Systems GmbH
Lohstrasse 22
D-85445 Schwaig
Germany
voice: [phone]
FAX: [phone]
Singapore: High End Systems Singapore Pte. Ltd.
1 Tannery Road 06-05
Cencon 1
Singapore 1334
voice: [phone]
FAX: [phone]

Ecodome®User Manual iii
Declaration of Conformity
according to ISO/IEC Guide 22 and EN45104
Manufacturer’s name: Lightwave Research
Manufacturer’s address: 2217 West Braker Lane
Austin, Texas 78758 USA
Distributor’s name: High End Systems, Inc.
Distributor’s address: 2217 West Braker Lane
Austin, Texas 78758 USA
Declares that the product
Product Name: Ecodome
Product Number: Universal Ecodome 115
Universal Ecodome 208-230
Product Options: All
conforms to the following EEC directives:
73/23/EEC, as amended by 93/68/EEC
89/336/EEC, as amended by 92/31/EEC and 93/68/EEC
Equipment referred to in this declaration of conformity first manufactured in 1999 in
compliance with the following standards:
Safety: EN 60598-1: 1993
EMC: EN 55022, 1987 Class A ITE
IEC 801-2, 1991 Level 3 (6/8 kV)
IEC 801-3, 1991 Draft 5, Level 2 (3 V/m)
IEC 801-4, 1988 Level 2 (1 kV/0.5 kV)
ENV 50204, 1996 Level 2 (3 V/m)
USA, July 15, 1999
Kenneth Stuart Hansen, Compliance Engineer

iv Ecodome®User Manual
Product Modification Warning
High End Systems products are designed and manufactured to meet the requirements of
United States and International safety regulations. Modifications to the product could
affect safety and render the product non-compliant to relevant safety standards.
Mise En Garde Contre La Modification Du Produit
Les produits High End Systems sont conçus et fabriqués conformément aux exigences des
règlements internationaux de sécurité. Toute modification du produit peut entraîner sa
non conformité aux normes de sécurité en vigueur.
Produktmodifikationswarnung
Design und Herstellung von High End Systems entsprechen den Anforderungen der U.S.
Amerikanischen und internationalen Sicherheitsvorschriften. Abänderungen dieses
Produktes können dessen Sicherheit beeinträchtigen und unter Umständen gegen die
diesbezüglichen Sicherheitsnormen verstoßen.
Avvertenza Sulla Modifica Del Prodotto
I prodotti di High End Systems sono stati progettati e fabbricati per soddisfare i requisiti
delle normative di sicurezza statunitensi ed internazionali. Qualsiasi modifica al prodotto
potrebbe pregiudicare la sicurezza e rendere il prodotto non conforme agli standard di
sicurezza pertinenti.
Advertencia De Modificación Del Producto
Los productos de High End Systems están diseñados y fabricados para cumplir los
requisitos de las reglamentaciones de seguridad de los Estados Unidos e internacionales.
Las modificaciones al producto podrían afectar la seguridad y dejar al producto fuera de
conformidad con las normas de seguridad relevantes.
Important Safety Information
Instructions pertaining to continued protection against fire, electric shock, exposure to
excessive ultraviolet (UV) radiation, and injury to persons are found in Appendix A.
Please read all instructions prior to assembling, mounting, and operating this equipment.
Important: Informations De Sécurité
Les instructions se rapportant à la protection permanente contre les incendies,
l’électrocution, l’exposition à un rayonnement ultraviolet (UV) excessif et aux blessures
corporelles se trouvent dans l’Annexe A.
Veuillez lire toutes les instructions avant d’assembler, de monter ou d’utiliser cet
équipement.

Ecodome®User Manual v
Wichtige Sicherheitshinweise
Sicherheitsanleitungen zum Schutz gegen Feuer, elektrischen Schlag, übermäßige UV-
Strahlung und Verletzung von Personen finden Sie in Anhang A.
Vor der Montage, dem Zusammenbau und der Intbetriebnahme dieses Geräts alle
Anleitungen sorgfältig durchlesen.
Informazioni Importanti Di Sicurezza
Le istruzioni sulla protezione da incendi, folgorazione, esposizione eccessiva a raggi
ultravioletti (UV) e infortuni sono contenute nell’appendice A.
Si prega di leggere tutte le istruzioni prima di assemblare, montare e azionare
l’apparecchiatura.
Informacion Importante De Seguridad
En el Apéndice A se encuentran instrucciones sobre protección continua contra
incendios, descarga eléctrica, exposición excesiva a radiación ultravioleta (UV) y lesiones
personales.
Lea, por favor, todas las instrucciones antes del ensamblaje, montaje y operación de este
equipo.
Warranty Information
Limited Warranty
Unless otherwise stated, your product is covered by a two year parts and labor limited
warranty. It is the owner’s responsibility to furnish receipts or invoices for verification of
purchase, date, and dealer or distributor. If purchase date cannot be provided, date of
manufacture will be used to determine warranty period.
Returning an Item Under Warranty for Repair
It is necessary to obtain a Return Material Authorization (RMA) number from your dealer
or point of purchase BEFORE any units are returned for repair. The manufacturer will
make the final determination as to whether or not the unit is covered by warranty. Lamps
are covered by the lamp manufacturer’s warranty.
Any Product unit or parts returned to High End Systems must be packaged in a suitable
manner to ensure the protection of such Product unit or parts, and such package shall be
clearly and prominently marked to indicate that the package contains returned Product
units or parts and with an RMA number. Accompany all returned Product units or parts
with a written explanation of the alleged problem or malfunction. Ship returned Product
units or parts to: 2227 West Braker Lane, Austin, TX 78758 USA.
Note: Freight Damage Claims are invalid for fixtures shipped in non-factory boxes
and packing materials.

vi Ecodome®User Manual
Freight
All shipping will be paid by the purchaser. Items under warranty shall have return
shipping paid by the manufacturer only in the Continental United States. Under no
circumstances will freight collect shipments be accepted. Prepaid shipping does
not include rush expediting such as air freight. Air freight can be sent customer collect in
the Continental United States.
REPAIR OR REPLACEMENT AS PROVIDED FOR UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER. HIGH END SYSTEMS, INC. MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO ANY PRODUCT, AND HIGH
END SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. HIGH END SHALL NOT BE LIABLE FOR ANY
INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGE, INCLUDING LOST PROFITS,
SUSTAINED OR INCURRED IN CONNECTION WITH ANY PRODUCT OR CAUSED BY
PRODUCT DEFECTS OR THE PARTIAL OR TOTAL FAILURE OF ANY PRODUCT
REGARDLESS OF THE FORM OF ACTION, WHETHER IN CONTRACT, TORT
(INCLUDING NEGLIGENCE), STRICT LIABILITY OR OTHERWISE, AND WHETHER OR
NOT SUCH DAMAGE WAS FORESEEN OR UNFORESEEN.
Warranty is void if the product is misused, damaged, modified in any way, or for
unauthorized repairs or parts. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.

Ecodome®User Manual vii
Table of Contents
Introduction
The Dome .....................................................................................................................intro-1
Optional Accessories ....................................................................................................intro-1
Specifications ................................................................................................................intro-2
Model Numbers .....................................................................................................intro-2
Dimensions ............................................................................................................intro-2
Weight ....................................................................................................................intro-2
Electrical Specifications .........................................................................................intro-2
Environmental Specifications ................................................................................intro-2
DMX Data Cabling .................................................................................................intro-3
Test Standards ........................................................................................................intro-3
Safety ......................................................................................................................intro-3
Caution and Warning Symbols ....................................................................................intro-4
Chapter 1 Installing the Ecodome®Base
Intended Audience .............................................................................................................1-1
Unpacking Ecodome®........................................................................................................1-1
Saving the Shipping Materials .....................................................................................1-1
Shipping Ecodome®to Another Location ...........................................................1-1
Contents of the Dome Box ...........................................................................................1-2
Contents of the Housing Box .......................................................................................1-2
Contents of the Base Box .............................................................................................1-3
Building a Foundation ........................................................................................................1-3
Installation Requirements ............................................................................................1-4
Foundation Layout ......................................................................................................1-4
Assembling and Mounting the Base ...................................................................................1-6
Chapter 2 Installing the Fixture
Connecting the Cabling ......................................................................................................2-5
Final Component Assembly .............................................................................................2-11
Chapter 3 Performing Maintenance
Servicing the Fixture ..........................................................................................................3-1
Servicing Ecodome®..........................................................................................................3-1
Cleaning Ecodome®....................................................................................................3-1
Checking Intake/Exhaust ..............................................................................................3-2
Replacing Air Filters .....................................................................................................3-2
Oiling the Blower Motor ..............................................................................................3-3
Appendix A Important Safety Information
Appendice A Important: Informations De Sécurité .......................................................A-2
Anhang A Wichtige Sicherheitshinweise ........................................................................A-4

viii Ecodome®User Manual
Appendice A Informazioni Importanti Di Sicurezza .......................................................A-5
Apendice A Informacion Importante De Seguridad ......................................................A-7
Vigtig Sikkerhedsinformation - DANMARK ......................................................................A-8
Table of Figures
Figure 1-1. Ecodome road case. .......................................................................................1-1
Figure 1-2. Ecodome dome. ..............................................................................................1-2
Figure 1-3. Contents of the housing box. ...........................................................................1-2
Figure 1-4. Contents of the base box. ................................................................................1-3
Figure 1-5. Correct mounting position. .............................................................................1-3
Figure 1-6. Recommended foundation layout for Ecodome. ...........................................1-5
Figure 3-1. Location of the air filters. ................................................................................3-2
Figure 3-2. Oiling the blower motor. ................................................................................3-3
Table of Tables
Table intro-1. Ecodome Optional Accessories ............................................................intro-1

Ecodome®User Manual Introduction intro-1
Introduction
IntroductionIntroduction
Introduction
Congratulations on your purchase of the Ecodome®architectural housing. Ecodome is a
weather-resistant, modular outdoor housing system designed for the Studio 250™ series
and the Studio 575™ series of fixtures from High End Systems®, Inc. Ecodome’s
ergonomic styling is both attractive and unobtrusive and gives a clean look to any
architectural setting in which it operates.
Ecodome’s high-density polymer is colored neutral gray. However, Ecodome can be
ordered in custom colors to match existing architectural schemes. For more information
on ordering a custom color, see “Optional Accessories” below.
The Dome
The dome is made of high impact, UV-resistant polycarbonate and allows full use of
Studio 250 and Studio 575 series fixture’s pan movement. However, the Ecodome
housing limits the fixture’s visible tilt range to the available 180° tilt area of the dome. Once
the light beam passes beyond the available 180° tilt area of the dome, it will be blocked by
the Ecodome housing.
Note: If you plan to use a Studio Spot 575 or Studio Spot 250 fixture in Ecodome,
you must install light blocks to protect the Ecodome housing from possible
damage due to the fixture’s light beam shining directly on the inside of the
housing. For more information on installing light blocks, see page 2-4.
Optional Accessories
Table -1 below shows the optional accessories available for Ecodome from your High End
Systems®dealer/distributor:
Call*- For more information about optional accessories, contact either your High End
Systems dealer/distributor, High End Systems sales department, or visit the High End
Systems web site. For contact information, see “Contacting High End Systems” on page ii.
Table intro-1. Ecodome Optional Accessories
Name Part Number
Optional Ecodome colors Call*
Fram CA 5056 air filter 99170003
Round dome 28010005
Ecodome road case 28070001

intro-2 Introduction Ecodome®User Manual
Specifications
Model Numbers
Model: Universal Ecodome
Manufacturer: Lightwave Research
Distributor: High End Systems, Inc.
2217 W. Braker Lane
Austin, Texas, 78758 USA
Dimensions
Height: 45 in. (115 cm)
Width: 32 in. (80 cm)
Depth: 32 in. (80 cm)
Weight
Dome: 7 lbs (3 kg)
Housing: 15 lbs (7 kg)
Base: 45 lbs (20 kg)
Assembled (no fixture installed): 67 lbs (30 kg)
Electrical Specifications
Universal Ecodome 115: 115V, 50/60 Hz, 930W maximum
Universal Ecodome 208-230: 208-230V, 50/60 Hz, 930W maximum
Refer to the fixture’s user manual for the rated power and voltage of the fixture you plan to
install inside Ecodome.
Warning: Class I equipment - For continued protection against electric
shock, connect this equipment to a power source that is
protected by a Ground Fault Circuit Interrupt (GFCI).
Environmental Specifications
• Ingress Protection: IP 45
• Suitable for outdoor use
(720 mm)
28.36 in.
(64 mm)
R 2.50 in. (146 mm)
5.75 in.
(177 mm)
7.00 in.
(576 mm)
22.70 in.
(395 mm)
15.56 in.
(1150 mm)
45.26 in.
(800 mm)
31.50 in.
(711 mm)
28.00 in.

Ecodome®User Manual Introduction intro-3
DMX Data Cabling
DMX data cables: Belden®9841 or equivalent (meets specifications for EIA RS-485
applications) with characteristics listed below:
• 2-conductor twisted pair plus a shield
• maximum capacitance between conductors - 30 pF/ft.
• maximum capacitance between conductor and shield - 55 pF/ft.
• maximum resistance of 20 Ω/1000 ft.
• nominal impedance 100–140 Ω
• 22–24 AWG with insulation having a dielectric rating of 300 volts or higher
DMX data connectors: 3-pin male and female XLR connectors
DMX data terminators: male XLR connector with 120 ohm terminator
Test Standards
Ecodome conforms to the following standards:
• UL 1572
• EN 60598-1
• CSA 22.2 No. 9
•EMCstandards:
• EN 55022, Class A ITE
• IEC 801-2, Level 3 (6/8kV)
• IEC 801-3, Level 2 (3 V/m)
• IEC 801-4, Level 2 (1kV/.5kV)
• ENV 50204, 1996 Level 2 (3 V/m)
Safety
• Maximum ambient temperature (Ta): 40° C (104° F).
• Maximum exterior surface temperature: 62° C (144° F).
• Suitable for mounting on normally flammable surfaces.
• Not for residential use.

intro-4 Introduction Ecodome®User Manual
Caution and Warning Symbols
The following international symbols appear in margins throughout this manual to highlight
caution and warning messages.
Caution: This symbol appears adjacent to Caution messages. Not heeding
these messages could result in personal injury and/or damage to
equipment.
Warning: This symbol appears adjacent to high voltage warning messages.
Not heeding these messages could result in serious personal
injury.
Fire Hazard: This symbol indicates that a fire hazard is present. Not
heeding these messages could result in serious personal
injury.

Ecodome®User Manual Installing the Ecodome®Base 1-1
1
Chapter 1
Chapter 1Chapter 1
Chapter 1
Installing the Ecodome
Installing the EcodomeInstalling the Ecodome
Installing the Ecodome®Base
BaseBase
Base
Intended Audience
Ecodome must be installed by a qualified electrician only. This manual is intended for
electricians and/or building contractors already familiar with electrical wiring and
construction.
Unpacking Ecodome®
Ecodome ships in three separate boxes—one for the dome, one for the housing, and one
for the base. Carefully unpack each box and inspect the contents for damage. If any of the
items listed in this section are missing or damaged, you must notify both the shipping agent
and your sales agent immediately.
Saving the Shipping Materials
Do not discard the shipping box and packing materials. The box and packing materials are
specifically designed to protect the product during transport.
High End Systems, Inc. assumes no responsibility for products damaged during transport.
Therefore, you should return a product for repair in its original shipping carton and
packing materials.
Note: Before sending anything to the factory, be sure to call your High End
Systems, Inc. dealer/distributor for a Return Material Authorization (RMA)
number. The factory cannot accept any goods shipped without an RMA
number.
Shipping Ecodome®to Another Location
Ecodome was not designed to be shipped while a fixture
is installed inside Ecodome. If you need to ship
Ecodome to another location, High End Systems, Inc.
strongly recommends you do the following:
1. Remove the fixture installedin Ecodome and repack
the fixture in its original packaging and container.
2. Either disassemble Ecodome and repack it in its
original packaging and containers, or pack the fully
assembled Ecodome in a road case (see Figure 1-1). Figure 1-1. Ecodome road case.

1-2 Installing the Ecodome®Base Ecodome®User Manual
For more information on obtaining an Ecodome road case, see “Optional Accessories”
on page intro-1.
Caution: Shipping Ecodome with a fixture installed could damage both the
fixture and Ecodome.
Contents of the Dome Box
The dome box contains one round dome (see Figure 1-2). Carefully remove the dome
and inspect it for cracks or scratches. If you notice cracks or scratches not caused by
shipping damage, carefully repack it in its original container and contact High End Systems
customer service (see “Contacting High End Systems” on page ii).
Contents of the Housing Box
The housing box contains one housing with an attached clamp and four labels (see Figure
1-3).
Figure 1-2. Ecodome dome.
Figure 1-3. Contents of the housing box.
clamp
LIGHTWAVE
LIGHTWAVE

Ecodome®User Manual Installing the Ecodome®Base 1-3
1
Contents of the Base Box
The base box contains one base with an attached clamp, two light blocks, and various
hardware needed for installation (see Figure 1-4).
Building a Foundation
Cautions: (1) Ecodome should not be mounted on a wall, upside-down, or
on a surface inclined more than 45°.
Figure 1-4. Contents of the base box.
tamper-
resistant
screwdriver
1/2" regular
washers (4) 1/2" split
washers (4) 1/2" hex nuts (4) 3/8" hex
nuts (4) 3/8" hex
screws (4) 3/8" regular
washers (4)
3/32" allen
wrench
light
block (2)
8-32 x 3/8" pan
head screws (4)
clamp
Figure 1-5. Correct mounting position.
0º (level) 45º (maximum)
OK OK

1-4 Installing the Ecodome®Base Ecodome®User Manual
(2) Allow at least 24 in. (61 cm) clearance around intake and
exhaust vents.
Warning: Risk of fire and shock. This product is to be installed by a
qualified electrician only.
Installation Requirements
1. Ecodome must be installed in accordance with local and national building and
electrical codes.
2. The foundation on which Ecodome is installed must be at least 6 in. (15 cm) above
ground level.
3. Ecodome must not be installed in low-lying areas subject to flooding. Ecodome must
be mounted on a site that provides adequate drainage so that Ecodome is never
immersed in standing water.
4. Ecodome model “Universal Ecodome” is to be used only with High End Systems
fixture models “Studio Color 575-M,” “Studio Color 575-S,” “Studio Color,” “Studio
Spot,” “Studio Color 250,” or “Studio Spot 250.”
Foundation Layout
You will need:
• suitable foundation materials (concrete, steel, wood, etc.) to build a 32 in. (81 cm)
minimum diameter foundation
• four 1/2" Unified National Coarse (UNC) studs for mounting Ecodome
Use the following guidelines to build the Ecodome foundation:
1. Construct a foundation of suitable material (concrete, steel, wood, etc.) that allows at
least 32 in. (81 cm) minimum diameter. Make sure the top of the foundation is at least
6 in. (15 cm) above ground level.

Ecodome®User Manual Installing the Ecodome®Base 1-5
1
2. Install four 1/2" mounting studs into the foundation in a square pattern with the center
of the studs measuring 17 inches apart (see Figure 1-6).
Figure 1-6. Recommended foundation layout for Ecodome.
6.00" min.
4 mounting
studs
32.00"
8.50"
17.00"
32.00"
8.50"
17.00"
32.00"

1-6 Installing the Ecodome®Base Ecodome®User Manual
Assembling and Mounting the Base
This section shows how to mount the Ecodome base on the foundation you have already
prepared.
You will need:
• ratchet and
• 3/4" deep socket
•6"extension
•scissors
• four 1/2" regular washers (supplied with Ecodome)
• four 1/2" split washers (supplied with Ecodome)
• four 1/2" mounting nuts (supplied with Ecodome)
Use scissors to cut the cable tie wrap on the cables under the Ecodome base.
1
power and DMX
data cables
