Highland HIX604B1 Installation instructions

USE AND CARE
INDUCTION COOKTOPS
HIX604B1 HIX906B1

3

Dear customer,
Congratulations on your purchase of a Highland induction cooktop.
In order to make the best use of your appliance, please carefully read the following use and care
manual and keep it for later reference.
SUMMARY
SAFETY ......................................................................................................................................... 4
PRECAUTIONS BEFORE USING ........................................................................................................ 4
USING THE APPLIANCE .................................................................................................................. 5
PRECAUTIONS NOT TO DAMAGE THE APPLIANCE .............................................................................. 6
PRECAUTIONS IN CASE OF APPLIANCE FAILURE ................................................................................ 7
OTHER PROTECTIONS ................................................................................................................... 7
DESCRIPTION OF THE APPLIANCE ........................................................................................... 7
TECHNICAL CHARACTERISTICS ....................................................................................................... 8
CONTROL PANEL .......................................................................................................................... 8
USE OF THE APPLIANCE ............................................................................................................ 9
DISPLAY ...................................................................................................................................... 9
VENTILATION ................................................................................................................................ 9
STARTING-UP AND APPLIANCE MANAGEMENT ..................................................................... 9
BEFORE THE FIRST USE ................................................................................................................. 9
INDUCTION PRINCIPLE ................................................................................................................... 9
SENSITIVE TOUCH ......................................................................................................................... 9
POWER SELECTION ZONE “SLIDER” AND TIMER SETTING ZONE ...................................................... 10
STARTING-UP ............................................................................................................................. 10
PAN DETECTION ......................................................................................................................... 10
RESIDUAL HEAT INDICATION ........................................................................................................ 11
BOOSTER FUNCTION ................................................................................................................ 11
TIMER ....................................................................................................................................... 12
AUTOMATIC COOKING ................................................................................................................. 13
STOP&GO FUNCTION .................................................................................................................. 13
RECALL FUNCTION ..................................................................................................................... 13
« KEEP WARM » FUNCTION .......................................................................................................... 13
BRIDGE AND AUTOMATIC BRIDGE FUNCTION ................................................................................. 14
GRILL FUNCTION ........................................................................................................................ 14
CONTROL PANEL LOCKING ........................................................................................................... 14
COOKING ADVICE ..................................................................................................................... 15
PAN QUALITY ............................................................................................................................. 15
PAN DIMENSION .......................................................................................................................... 15
EXAMPLES OF COOKING POWER SETTING ...................................................................................... 16
MAINTENANCE AND CLEANING .............................................................................................. 16
WHAT TO DO IN CASE OF A PROBLEM .................................................................................. 16
ENVIRONMENT PRESERVATION ............................................................................................. 17
INSTALLATION INSTRUCTIONS ............................................................................................... 18
ELECTRICAL CONNECTION ..................................................................................................... 19

4

SAFETY
Precautions before using
 Unpack all the materials.
 The installation and connection of the appliance must be done
by approved and qualified specialists. The manufacturer cannot
be responsible for damage caused by improper installation or
connection errors.
 During use, the appliance must be correctly installed in suitable
kitchen cabinetry and work surfaces.
 This domestic appliance is designed exclusively for the cooking
of food and specifically excludes any other domestic,
commercial or industrial use.
 Remove all labels and self-adhesive stickers from the ceramic
glass.
 Do not change or alter the appliance.
 The cooktop cannot be used as freestanding unit or as a
working surface.
 The appliance must be grounded and connected in compliance
with local standards and requirements.
 Do not use any extension cable to connect the cooktop.
 The appliance must not be installed above a dishwasher or a
tumble- dryer: steam may damage the electronics.
 The appliance is not intended to be operated by means of
external timer or a separate remote control system.

5

Using the appliance
 Switch the cooktop off after use.
 Keep an eye on the cooktop when cooking with grease or
oils as they may potentially ignite.
 Be careful not to burn yourself during or after using the
cooktop.
 Make sure no cable of any fixed or moving appliance comes
into contact with the ceramic glass or a hot saucepan.
 Magnetic objects (credit cards, calculators, etc.) should not be
placed near the cooktop when in use.
 Metallic objects such as knives, forks, spoons and lids should
not be placed on the cooktop surface as they can get hot.
 In general, do not place any metallic objects except for cooking
containers on the glass surface. In case of untimely activation
or residual heat, they may heat, melt or even burn.
 Never cover the appliance with a cloth or a protection sheet.
This may become very hot and catch fire.
 This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given instruction or are under supervision concerning the use of
the appliance by a person responsible for their safety.
 Children should be supervised to ensure that they do not play
with the appliance.
 This appliance is not intended to be operated by means of an
external timer or separate remote-control system.

6

Precautions not to damage the appliance
 Raw pan bases (i.e. not enamelled cast iron pots) or damaged
saucepans may damage the ceramic glass surface.
 Grit or other abrasive materials may damage ceramic glass
surface.
 Avoid dropping objects, even little ones, on the ceramic glass.
 Do not hit the edges of the glass with saucepans.
 Make sure that the ventilation of the appliance is in accordance
with the manufacturer’s instructions.
 Do not put or leave empty saucepans on the ceramic glass
cooktop.
 Sugar, synthetic materials or aluminium sheets must not come
into contact with the cooking zones. These material may affect
or damage the ceramic glass when cooling: switch on the
appliance and remove immediately from the cooking zone (be
careful not to burn yourself).
 WARNING: Danger of fire: do not store items on the cooking
surface.
 Never place any hot pots or cookware on the control panel.
 If a drawer is situated under the installed appliance, make sure
the space between the contents of the drawer and the base of
the appliance is at least two (2) cm. This is essential to
guarantee correct ventilation.
 Never put flammable objects (for example sprays) into a drawer
underneath the cooktop. Cutlery drawers must be heat -
resistant.

7

In case of appliance failure
 If a defect is noticed, switch off the appliance and turn i t off
at the switchboard.
 If the ceramic glass is cracked or damaged, unplug the
appliance and contact after sales service.
 Servicing must be only done by qualified specialists. Do not
open the appliance by yourself.
 WARNING: If the surface is cracked, switch off the appliance to
avoid the possibility of electric shock.
 If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or similarly qualified person in
order to avoid a hazard.
Other warnings
 Ensure that the pot or pan is always centred on the cooking
zone. The bottom of the pan must cover as much of the cooking
zone as possible.
 For users with a heart pacemaker, the magnetic field could
influence its operating. We recommend discussing this with
their health practitioner.
 Do not to use aluminium or plastic containers: they could melt
on cooking zones that are still hot.
 NEVER try to extinguish a fire with water. Always switch off
the appliance and then cover the flame e.g. with a lid or a fire
blanket.
DO NOT USE INTERMEDIATE REMOVABLE
ACCESSORIES TO HEAT PANS WHICH ARE NOT
ADAPTED TO INDUCTION.
THIS RISKS BURNS AND DETERIORATION OF THE
COOKTOP.

8

DESCRIPTION OF THE APPLIANCE
Technical characteristics
Type Total
Power
Position of
the heating
zone
Dimension Nominal
Power*
1st
Booster
Power*
2nd Booster
Power*
Minimal pan
detection
HIX604B1 7,400 W 4 zones 220x180 mm 2,100 W 2,600 W 3,700 W 100 mm
HIX906B1 11,100 W 6 zones 220x180 mm 2,100 W 2,600 W 3,700 W 100 mm
* The given power may change according to the dimensions and material of the pan.
Control panel
Bridge
display
Keep warm
displays
Timer display
Power display
Timer keys
Timer display
Power selection zone
« Slider » (rear zone)
Keep
warm key
Power selection zone
« Slider » (front zone)
Locking key
On/Off key Pause/
Recall
key

9

USE OF THE APPLIANCE
Display
Display Designation Description
0 Zero The heating zone is activated.
1…9 Powe
r
level Selection of the cooking level.
U No pan detection No pan or inadequate pan.
A
Heat accelerato
r
A
utomatic cooking.
E Erro
r
message Electronic failure.
H
P
Residual heat
1st Booster
2nd Booster
The heating zone is hot.
The 1st Booster is activated.
The 2nd Booster is activated.
U Keep warm Maintain automatically of 42, 70 o
r
94°C.
II Stop&Go The cooktop is in pause.
Grill Function The Grill Function is activated.
Ventilation
The cooling system is fully automatic. The cooling fan starts with a low speed. The ventilation
starts with a high speed when the cooktop is used intensively. The cooling fan reduces speed
and stops automatically when the electronic circuit is cooled.
STARTING-UP AND OPTIMUM USE
Before the first use
Clean your cooktop with a damp cloth and dry the surface thoroughly. Do not use detergent which
risks causing blue-tinted colour on the glass surface.
Induction principle
An induction coil is located under each cooking zone. When it is engaged, it produces a
variable electromagnetic field which produces inductive currents in the ferromagnetic base of
the
pan. The result is a heating-up of the pan located on the heating zone.
Of course the pan has to be magnetic:
 All ferromagnetic pans are suitable (please verify by using a small magnet): cast
iron
and steel pans, enamelled pans, stainless-steel pans with ferromagnetic bases.
 Exclusions: copper, pure stainless-steel, aluminium, glass, wood, ceramic, stoneware.
The induction heating zone adapts automatically to the size of the pan. If the diameter is too
small, the pan doesn’t heat-up. This diameter will vary the function of the heating zone
diameter. If the pan is not adapted to the induction cooktop the display will show [ U ].
Sensitive touch
Your ceramic cooktop is equipped with electronic controls with sensor touch controls.. When your
finger touches the key, the corresponding command is activated. This activation is validated
by a control light, a letter or a number in the display and/or a “beep” sound.
During normal use only touch one sensor key at a time.

10

Power selection zone “SLIDER” and timer setting zone
To select the power with the slider, slide your finger on the “SLIDER” zone. You can directly
access if you put your finger directly on the chosen level.
Starting-up
 Start up / switch off the cooktop:
Action
To start
Control panel
press key [ 0/I ]
Display
[ 0 ]
To stop press key [ 0/I ] nothing or [ H ]
 Start up / switch off a heating zone:
Action
To set
Control panel
slide on the “SLIDER“
Display
[ 1 ] to [ P ]
(adjust the power)
To stop
to the right or to the left
slide to [ 0 ] on “SLIDER“
[ 0 ] or [ H ]
If no input is made within 20 second the electronics return to the waiting position.
Pan detection
This cooktop is fitted with an interactive control system that makes it very easy to use. After
switching on the cooktop, when you put a cookware on the cooking zone, the control system
automatically detects it. This system also automatically indicates you which slider control to use
by displaying a [ 0 ] over it. You then just have to set the expected cooking level.
The pan detection ensures optimum performance. The induction will not work if:
 There is no pan on the cooking zone or if this pan is not suitable for induction. In this
case it is impossible to increase the power and the display shows [ U ]. This symbol
disappears when a compatible pan is put on the cooking zone.
 The pan is removed from the cooking zone. The display shows [ U ]. The symbol [ U ]
disappears when the pan is put back to the induction zone. The cooking continues with
the power level set before.
After use, switch the cooking zone off : don’t leave the pan detection [ U ] active.
Power selection zone “SLIDER” and
timer setting zone
“SLIDER“ Direct access

11

A
B
Residual heat indication
After the cooking zone is turned off, or the cooktop is fully switched off, the cooking zones may
still be hot and indicate[ H ] on the display.
The symbol [ H ] disappears when the cooking zones may safely be touched.
When the residual heat indicators are on, don’t touch the cooking zones and don’t put any heat
sensitive object on them. There is a risk of burns and fire.
Booster function
The Booster function [ P ] and the Double Booster [ ] grant a boost of power to the selected
cooking zone.
If this function is activated the cooking zones operate for 10 minutes with an extra high power.
Booster is ideal for example to heat up large quantities of water rapidly when cooking pasta.
 Start up / Stop the Booster function:
Action Control panel Display
Start up the Booster
Stop the Booster
slide to the end of the “SLIDER”
or press directly on the end of
the “SLIDER”
slide on the “SLIDER“
[ P ]
[ 9 ] to [ 0 ]
 Start up / Stop the double Booster function:
Action Control panel Display
Start up the Booster slide to the end of the “SLIDER”
or press directly on the end of
the “SLIDER”
[ P ]
Start up Double Booster
Stop the Double Booster
Stop Booster
re-press key [ P ]
slide on the “SLIDER“
slide on the “SLIDER“
[ and P ]
[ P ] to [ 0 ]
[ 9 ] to [ 0 ]
 Power management:
The cooktop is divided in 2 or 3 (dep. on model) separate sets of cooking zones, each set
having a maximum power.
If the selected heating levels for the jointly managed zones exceed the maximum available
amount of power, the power management function automatically reduces the power from one of
these zones. The display of this zone blinks first; the level is then automatically reduced to the
highest possible setting.
Heating zone selected The other heating zone: (example: power level 9)
[ P ] is displayed [ 9 ] goes to [ 8 ] and blinks
To activate the Booster function (or double Booster) on several cooking zones at the
same time
use separately power-managed zones (A-B, A-C, B-C or A-B-C).
B C
A
C
AB
BA

12

Timer
The timer can be used simultaneously with all cooking zones with different time settings (from 0
to 99 minutes) for each heating zone.
 Setting and modification of the cooking time :
Action
Select the power level
Control panel
slide on the “SLIDER“
Display
[ 1 ] to [ P ]
Select the Time
r
press simultaneously key [ - ] and [ + ] Timer display on
from the timer until the 
desired display is on 
Decrease the time press key [ - ] from the time
r
[ 60 ] to 59, 58...
Increase the time press key [ + ] from the time
r
Time increase
After a few seconds, the [ min ] display stops with blinking.
The time is confirmed and the timer starts.
 To stop the cooking time:
Action
Select the Timer
Control panel
press simultaneously key [ - ] and [ + ]
Display
Timer display on
from the timer until the 
desired display is on 
Stop the time press key [ - ] from the time
r
[ 000 ]
If several timers are activated, repeat the process.
 Egg timer function :
Egg timer is an independent function. It stops as soon as a cooking zone starts up.
If the egg timer is on and the cooktop is switched off, the timer continues until the programmed
time runs out.
Action
Activate the cooktop
Control panel
press display [ 0/I ]
Display
[ 0 ]
Select the Time
r
press simultaneously key [ - ] and [ + ] [ 000 ]
from the time
r

Decrease the time press key [ - ] from the time
r
[ 60 ] to 59, 58...
Increase the time press key [ + ] from the time
r
Time increase
After a few seconds, the [ min ] display stops blinking. The
time is confirmed and the timer starts.
 Automatic stop at the end of the cooking time:
As soon as the selected cooking time is finished the timer display blinks [ 000 ] and a sound rings.
To stop the sound and the blinking, press the key [ - ] and [ + ].

13

Automatic cooking
All cooking zones are equipped with an automatic cooking setting. The cooking zone starts at full
power for a certain time, and will then reduce automatically to the power at the pre-selected level.
 Start-up :
Action
Power level selection
Control panel
slide on the “SLIDER“ to [ 7 ]
Display
[ 7 ] is blinking with [ A ]
(for example « 7 ») and hold 3s 
 Switching off the automatic cooking :
Action Control panel Display
Power level selection slide on the “SLIDER“ [ 0 ] to [ 9 ]
Stop&Go function
This function stops all the cooktop’s active zones temporarily and then allows restarting with
the same settings.
 Start up/stop the pause function :
Action
Engage pause
Control panel
press [ II ]
Display
[ II ] and control light on
Stop the pause press [ II ]
Press on the animated “slider”
“Slider” animated
previous settings
Recall Function
After switching off the cooktop [ 0/I ], it is possible to recall the last settings.
 cooking stages of all cooking zones (incl. Booster)
 minutes and seconds of programmed cooking zone-related timers
 Keep warm function
The recall procedure is following:
 Press the key [ 0/I ]
 Then press [ II ] before the light stops blinking.
The previous settings are active again.
« Keep warm » Function
This function allows liquids to reach and automatically maintain a temperature of 42°C (baine-
marie cooking in a water bath) 70°C (keeping soups or sauces warm) or 94 °C (continued
simmering).
 To engage, to start the function « Keep warm » :
Action Control panel Display
42°C to engage press once on key [ ] [ U ] and [ ]
70°C to engage press twice on key [ ] [ U ] and [ ]
94°C to engage press 3 times on key [ ] [ U ] and [ ]
To stop slide on the “SLIDER“ [ 0 ] to [ 9 ]
or press key [ ] until [ 0 ] [ 0 ]
The maximum duration on Keep warm is 2 hours.

14

Bridge and automatic Bridge Function
This function allows the use of 2 cooking zones at the same time with the same setting as a
single cooking zone. With this function the Booster function is available on the left and centre
zones.
Action Control panel Display
Activate the cooktop Press key [ 0/I ] [ 0 ]
Activate the bridge Press simultaneously on keep warm key
[ ]of the 2 cooking zones [ 0 ] and [ ]
or
put a great pan on the 2 zones
[ ] blink
and press on the 2 “SLIDER”
[ ]
Increase bridge Slide on the “SLIDER“ which indicates the
power [ 1 ] to [ 9 ]
Stop the bridge Press simultaneously on keep warm key
[ ]of the 2 cooking zones [ 0 ]
Grill Function
Action Control panel Display
Activate the cooktop Press key [ 0/I ] [ 0 ]
put the grill plate on the 2 zones to use
[ ] blink
Activate the Grill Press simultaneously on the « SLIDER » of
the 2 cooking zones [ ]
Increase the Grill Slide on the “SLIDER“ which indicates
the power
Stop the Grill Press simultaneously on the « SLIDER » of
power level on
the slider
the 2 cooking zones [ 0 ]
Control panel locking
To avoid the activation of the cooking zones, in particular during cleaning, the control panel can
be locked (with exception to the On/Off key [ 0/I ]).
Action Control panel Display
Locking the cooktop press [ ] during 6s locking light on
Unlock the cooktop press [ ] during 6s locking light off

15

COOKING ADVICE
Pan quality
Suitable materials : steel, enamelled steel, cast iron, ferromagnetic stainless-steel,
aluminium with ferromagnetic base.
Not suitable materials : aluminium and stainless-steel without ferromagnetic base, copper,
brass, glass, ceramic, porcelain.
The cookware manufacturers specify if their products are suitable for induction. To check if
pans are compatible :
 Put a little water in a pan placed on an induction cooking zone set at level [ 9 ].The
water must heat in a few seconds.
 A magnet sticks on the base of the pan.
Certain pans can make noise when they are placed on an induction cooking zone. This noise
doesn’t mean any failure of the appliance and doesn’t influence the cooking process.
Pan dimension
The cooking zones are, up to a certain limit, automatically adapted to the diameter of the pan.
However the base of a pan must have a minimum of diameter according to the corresponding
cooking zone.
To obtain the best efficiency of your cooktop, please place the pan in the centre of the cooking
zone.

16

Examples of cooking power setting
(the values below are indicative)
Setting Application Example
1 to 2 Melting
Reheating
Sauces, butter, chocolate, gelatine
Dishes prepared beforehand
2 to 3 Simmering
Defrosting
Rice, pudding, sugar syrup
Dried vegetables, fish, frozen products
3 to 4 Steam Vegetables, fish, meat
4 to 5 Water Steamed potatoes, soups, pasta,
fresh vegetables
6 to 7 Medium cooking
Simmering
Meat, liver, eggs, sausages
Goulash, roulade
7 to 8 Cooking Potato chips
9 Frying, roosting
Boiling water
Steaks, omelettes, fried dishes
Water
P and Frying, roosting
Boiling water
Scallops, steaks
Boiling significant quantities of water
MAINTENANCE AND CLEANING
Switch-off the appliance before cleaning.
Do not clean the cooktop if the glass is too hot because there is a risk of burns.
 Remove light marks with a damp cloth with washing up liquid diluted in a little water. Then
rinse with cold water and dry the surface thoroughly.
 Highly corrosive or abrasive detergents and cleaning equipment likely to cause scratches
must be avoided.
 Never use any steam-cleaners or pressure washers to clean the appliance.
 Do not use any objects that may scratch the ceramic glass.
 Ensure that the pan is dry and clean. Ensure that there are no grains of dust on your
ceramic cooktop or on the pan. Sliding rough saucepans will scratch the surface.
 Spillages of sugar, jam, jelly, etc. must be removed immediately to prevent damage
to the ceramic glass surface.

WHAT TO DO IN CASE OF A PROBLEM
The cooktop or the cooking zone doesn’t start-up :
 The cooktop is not connected to the electrical network properly.
 The protection fuse has activated.
 The locking function is active.
 The sensor touch keys are covered with grease or water.
 An object is placed on a sensor key.
The control panel displays [ U ]:
 There is no pan on the cooking zone.
 The pan is not compatible with induction.
 The bottom diameter of the pan is too small.
The control panel displays [ E ] :
 The electronic system is defective.

17

 Disconnect and reconnect the cooktop.

18

One or all cooking zone cut-off :
 The safety system has activated.
 The cooking zones have been active for an extended period of time.
 One or more sensor keys are covered.
 The pan is empty and has overheated.
 The cooktop has activated the automatic Booster level reduction to avoid overheating
Continuous ventilation after cutting off the cooktop :
 This is not a failure, the fan continuous to protect the electronic circuits.
 The fan cooling stops automatically.
The automatic cooking system doesn’t start-up :
 The cooking zone is still hot [ H ].
 The highest Booster level is set [ 9 ].
The control panel displays [ U ] :
 Refer to the section “Keep warm“.
The control panel displays [ II ]:
 Refer to the section “Stop&Go“.
The control panel displays [ ]:
 Refer to the section “Grill Function “.
The control panel displays [ ] or [ Er03 ] :
 An object or liquid covers the sensor keys. The symbol disappear as soon as the
sensor key is released or cleaned.
The control panel displays [ E2 ] :
 The cooktop is overheated. Let it cool and then turn it on again.
The control panel displays [ E8 ] :
 The air inlet of the ventilator is obstructed, remove any obstructions.
The control panel displays [ U400 ] :
 The cooktop is not connected to the electrical mains network. Check the connection and
reconnect the cooktop.
The control panel displays [ Er47 ] :
 The cooktop is not connected to the electrical mains network. Check the connection
and reconnect the cooktop. If one of the symbols above persists, call Highland Service under
03 / 9700 9100.
ENVIRONMENTAL IMPACT
 The packaging material is recyclable.
To ensure optimum functioning of the appliance, it is composed of both recyclable, as well as
materials that may be harmful to the environment.
 Don't dispose of your appliance with the household refuse.
 Contact your local waste collection centre for the recycling of
household appliances.

19

INSTALLATION INSTRUCTIONS
The installation of this cooktop is the exclusive responsibility of specialist installers with due
respect to all local legislation and standards.
.
How to apply the sealing strip:
The sealing strip supplied with the cooktop avoids infiltration of liquids in the cabinet.
Installation has to be done carefully, as per the following drawing.
Fitting - installing:
 The cut-out sizes are:
Model Cut-size
HIX604B1 560 x 490 mm
HIX906B1 750 x 490 mm
 Ensure that there is a distance of 50 mm between the cooktop and the wall or sides.
 The cooktops are classified as “Y” class for heat protection. Ideally the cooktop should be
installed with plenty of space on either side. There may be a wall at the rear and tall units
or a wall at one side. On the other side, however, no unit or divider must stand
higher than the cooktop.
 Any cabinetry that the cooktop is to be installed in, as well as furniture edges, the
laminate coatings and the glue used to fix them, must be able to resist
temperatures of up to 100 °C.
 The edge strips must be heat-resistant.Do not install the cooktop to the top of a non-
ventilated oven or a dishwasher.
 Provide a space of 20 mm underneath the base of the cooktop casing to ensure a good
air
circulation around the electronic controls.
 Don't put any flammable objects
(for example: sprays) or not heat-resistant objects into
any drawer underneath the appliance. .
 To protect the cut-out edge, apply a coat of varnish or special sealant. Particular care must
be given to applying the sealing strip supplied with the cooktop to prevent any leakage into
the supporting furniture. This strip guarantees a correct seal when used in conjunction with
smooth worktop surfaces.
 The safety gap between the cooktop and the rangehood placed above must follow the
guidelines of the rangehood manufacturer. In case of absence of instructions, ensure that
a minimum distance of 760 mm is kept.
 Ensure that the connection cord is not subjected, after installation, to any mechanical
constraint or impact, for example from a drawer.
 WARNING: Use only cooktop guards designed by the manufacturer of the cooking
appliance or indicated by the manufacturer of the appliance in the instructions for use as
suitable or cooktop guards incorporated in the appliance. The use of inappropriate
guards can cause accidents.
Stick the sealing strip (2) two millimeters
from the external edge of the glass, after
removing the protection sheet (3).

20

ELECTRICAL CONNECTION
 The installation of this appliance and the connection to the electrical network must only
be carried out by a qualified electrician according to local rules and regulations.
 .
 Ensure that no parts are under tension after the installation.
 The data p l a t e must be placed on the cooktop casing near the connection box.
 Connection to the mains electricity must be made using an earthed plug, which must be
accessible after installation, or via an omnipolar circuit breaking device with a contact
opening of at least 3 mm.
 The electrical circuit must be separated from the network by suitable devices, for example:
circuit breakers, fuses or contactors.
 If the appliance is not fitted with an accessible plug, a means of disconnecting the
cooktop must be incorporated into the installation, in accordance with local rules
and regulations.
 The power supply cable must be positioned so that it does not touch any of the hot parts
of the cooktop or oven.
Caution!
This appliance must only be connected to a 230 V~ 50/60 Hz network.
Connect the earth wire.
Follow the connection diagram.
The connection box is located underneath at the back of the cooktop casing. To open the cover,
use a medium screwdriver. Place it in the slits and open the cover.
CONNECTION OF THE COOKTOP FOR HIX604B1
Mains Connection Cable diameter Cable Protection calibre
230V~ 50/60Hz 1 Phase + N 3 x 2,5 mm² H 05 VV - F
H 05 RR - F 25 A *
400V~ 50/60Hz 2 Phases + N 4 x 1.5 mm² H 05 VV - F
H 05 RR - F 16 A *
* calculated with the simultaneous factor following the standard EN 60 335-2-6
CONNECTION OF THE COOKTOP FOR HIX906B1
Mains Connection Cable diameter Cable Protection calibre
230V~ 50/60Hz 1 Phase + N 3 x 4 mm² H 05 VV - F
H 05 RR - F 40 A *
400V~ 50/60Hz 2 Phases + N 4 x 2.5 mm² H 05 VV - F
H 05 RR - F 25 A *
400V~ 50/60Hz 3 Phases + N 5 x 1.5 mm² H 05 VV - F
H 05 RR - F 16 A *
* calculated with the simultaneous factor following the standard EN 60 335-2-6
Caution! Be careful that the cables are correctly engaged and tightened.
The manufacturer cannot be held responsible for any incident resulting from incorrect
connection or which could arise from the use of an appliance which has not been
earthed or has been equipped with a faulty earth connection.
