Highland WeatherTree User manual
Installation & Activation Guide
v2
Thank you for choosing the WeatherTree™. My team has worked hard to make sure your new device is
accurate, easy to use and packed securely. If you have any issues with your new WeatherTree™ please
make sure to call us immediately at 863-844-4263 or email [email protected] so we can make it right.
We hope you find these instructions easy to follow. To make the process a bit easier, we have also created
an installation video. The video can be found at https://youtu.be/5FwfeT7snBE
or by scanning this QR code.
With gratitude,
Steve Maxwell
CEO
UV and Solar
Radiation Sensor
Wind Anemometer
Rain Bucket
Temperature and
Humidity housed by
Solar Radiation Shield
Barometric Pressure, LTE
Radio, Battery
Power Switches,
Status LEDs
Solar Panel
Wind Vane
SUPPLIES INCLUDED
YOU WILL ALSO NEED
13 mm x 2
Drill, 13 mm Drill Socket, 1/8" Drill Bit
4 x 4” Wood Post
13 mm
1 |ASSEMBLY
Select your WeatherTree™ location in an open area free of trees and buildings.
TIP: We recommend using a 4 x 4 inch post that is a minimum of 6 feet above the ground.
If installing on a building, we recommend that the sensor array is higher than the roof.
Pre-drill a pilot hole (using a 1/8”drill bit) into post and install bolt in top hole of mounting
bracket. Do not overtighten, so you can adjust bracket later.
2 |ASSEMBLY
Install Wind Anemometer onto Sensor Array.
Using screwdriver provided, tighten but DO NOT overtighten set screw on side of Wind
Anemometer.
N
3 |ASSEMBLY
Mount sensor Array onto mounting pole. Make sure the rain bucket is facing exactly north.
Using the wrench provided, tighten the U-bolts. NOTE: The device needs to be as close
to north (0) degrees as much as possible for the most accurate readings.
S
45º
13 mm
Adjust solar panel to a 45˚ angle.
4 |ASSEMBLY
Center bubble level and drill the second pilot hole for the bottom bracket bolt.
Install and tighten bottom bracket bolt.
Tighten adjustment bolts on
pole on both sides.
Mount Solar Panel bracket at least 5" below Wind Vane. Solar Panel must be facing south.
Tighten mounting
bracket lever.
Tighten knob.
RESET
5 |ASSEMBLY
Pull battery tab.
Using screwdriver provided, press
the RESET button for 5 seconds. Once
released, the red light should appear.
ON OFF CHG LNK STAT PWR
ON OFF CHG LNK STAT PWR
6 |ASSEMBLY
Press and hold the OFF button for 2 seconds to ensure the unit is o.
Press and hold the ON button until the status (STAT) light is blinkng.
After you press and hold the ON button to put into diagnostic mode, the STATUS LED will
flash for approximately 2 minutes. During that time, the box should pair to the sensor
array. If the status light turns solid after the 2 minutes, the station has successfully paired
to the sensor array and your weather data should get sent to the HUB for viewing.
If the status light never stops blinking after the 2 minutes, reset the sensor array with the
screwdriver, turn o the station box, then hold down the ON button for 5 seconds to start
the pairing process again.
7 |ACTIVATION: NEW CUSTOMERS
Login Page
If you are a new customer, follow the
instructions below. If you are an existing
customer, skip to section 9.
You will need to create your account before
you can set up your Weathertree™.
Go to www.highlandhub.com
and click Create Account.
User Information
Step 1 requires you to fill out your
information including name, email,
username and password. All required
information is noted with an asterisk (*).
Once complete, please be sure to agree to
the Terms of Service.
8 |ACTIVATION: NEW CUSTOMERS
Upload a Pesticide License (optional)
Step 2 allows you to upload your pesticide
license. If you do not have a license, skip this
step by selecting Continue.
Confirmation
Now that you are a HighlandHub user, you must verify
your email. If you do not see the email, check your SPAM
or junk mail folder. Once verified, continue setting up
the WeatherTree™ by immediately following directions in
section 9. NOTE: Do not Log in until you have followed
instructions in section 9.
Setting Up Your Company
Step 3 requires that you enter your company
information. All required information is noted
with an asterisk (*).
9 |ACTIVATION: EXISTING CUSTOMERS
Scanning the QR Code
Locate the QR code on the WeatherTree™.
Using a 4G smartphone (Google Android or Apple iOS) use
your camera to scan the QR code. If your device does not
recognize the QR code, download QR code-reading app
and use it to scan the QR code.
SAMPLESAMPLE
Location Confirmation
Confirm with the map that your location is correct and click
Log in to register. Your screen should display Log in to
register station H****. Some devices may have a delayed
location response. If your location is not correct, select the
Update Location button.
Congratulations! Your WeatherTree™ is now registered.
Having trouble?
NOTE
Enable location services for the next step.
10 |WARRANTY
1 Year Limited Warranty
We warrant the Weather Tree to be free from defects in material and workmanship for one (1) year from the
original date of purchase. We expressly disclaim any implied Warranties of merchantability or fitness for
particular purpose. This express Warranty is the exclusive Warranty covering the Weather Tree. There are
no other express or implied Warranties.
If you believe you have a defective part, return the Weather Tree to us with shipping charges pre-paid,
proof of purchase, and a written explanation of the problem. If we determine the problem is covered by our
Warranty we will repair or replace the defective component(s) at no charge to you.
This Warranty does not cover damage due to improper installation, unauthorized service, negligence,
abuse, misuse, or damage from chemicals, machinery, livestock or other animals, bitter current (or ex-)
spouses, wind, weather, lightning, or other Acts of God.
We are not liable for incidental or consequential damages, whether foreseeable or not. Our liability is
limited to the repair or replacement cost of the Weather Tree for covered defects.
Remedies vary from state to state, and you may have other rights depending on the laws of your state.
For further details or to request a demonstration, contact Taylor Pippin
Highland Ag Solutions is
Highland Precision Ag, Highland Fresh Technologies and Coastal Ag Supply
590 NW 3rd Street, Mulberry, FL 33860 USA | 863-844-4263
Proudly designed and constructed in the USA
