HIK VISION DS-KAD706 User manual

Video Audio Distributor
Installaon Guide

Legal Informaon
Installaon Guide
©2019 Hangzhou Hikvision Digital Technology Co., Ltd.
About this Manual
This Manual is subject to domesc and internaonal copyright protecon.
Hangzhou Hikvision Digital Technology Co., Ltd. ("Hikvision") reserves all
rights to this manual. This manual cannot be reproduced, changed,
translated, or distributed, parally or wholly, by any means, without the
prior wrien permission of Hikvision.
Please use this user manual under the guidance of professionals.
Trademarks
and other Hikvision marks are the property of
Hikvision and are registered trademarks or the subject of applicaons for
the same by Hikvision and/or its aliates. Other trademarks menoned in
this manual are the properes of their respecve owners. No right of license
is given to use such trademarks without express permission.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HIKVISION
MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, REGARDING THIS MANUAL. HIKVISION DOES
NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING
THE USE OF THE MANUAL, OR THE CORRECTNESS, ACCURACY, OR
RELIABILITY OF INFORMATION CONTAINED HEREIN. YOUR USE OF THIS
MANUAL AND ANY RELIANCE ON THIS MANUAL SHALL BE WHOLLY AT YOUR
OWN RISK AND RESPONSIBILITY.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT
Video Audio Distributor Installaon Guide
i

TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER
ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;
HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT
LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO
ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION
SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH
ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
Video Audio Distributor Installaon Guide
ii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
FCC compliance: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protecon against harmful
interference in a residenal installaon. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not
occur in a parcular installaon. If this equipment does cause harmful
interference to radio or television recepon, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separaon between the equipment and receiver.
—Connect the equipment into an outlet on a circuit dierent from that to
which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to
the following two condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operaon.
Video Audio Distributor Installaon Guide
iii

EU Conformity Statement
This product and - if applicable - the supplied accessories too are
marked with "CE" and comply therefore with the applicable
harmonized European standards listed under the EMC Direcve
2014/30/EU, the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol
cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collecon points. For more informaon
see: www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery
that cannot be disposed of as unsorted municipal waste in the
European Union. See the product documentaon for specic
baery informaon. The baery is marked with this symbol,
which may include leering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the baery to your
supplier or to a designated collecon point. For more informaon
see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
Video Audio Distributor Installaon Guide
iv

Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger Indicates a hazardous situaon which, if not avoided, will or
could result in death or serious injury.
Cauon Indicates a potenally hazardous situaon which, if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
Note Provides addional informaon to emphasize or
supplement important points of the main text.
Video Audio Distributor Installaon Guide
v

Contents
1 Appearance ................................................................................................ 1
2 Wiring Descripon ...................................................................................... 2
3 Installaon .................................................................................................. 3
A. Cables ........................................................................................................ 4
Video Audio Distributor Installaon Guide
vi

1 Appearance
Figure 1-1 Video/Audio Distributor Appearance
Table 1-1 Descripon
No. Descripon
1 Power Indicator
2 Network Interface
3 Cascade Network Indicaor
4 Network Indicaor
5 Power Input
6 Reset Buon
7 Cascade Interface
8 Terminals
Video Audio Distributor Installaon Guide
1

2 Wiring Descripon
Wire the devices with power supply cables as picture shown below.
Door staon should be connected to CH6 of the video/audio distributor with two-
wire cables.
Indoor Staon should be connected to any terminal of CH1 to CH5 of the video/
audio distributor with two-wire cables.
Cauon
Make sure all the related equipment is power-o during the installaon.
Figure 2-1 Wiring Descripon
Video Audio Distributor Installaon Guide
2

3 Installaon
Before You Start
•Make sure the device in the package is in good condion.
Make sure all the related equipment is power-o during the installaon.
Check the product specicaon for the installaon environment.
Steps
1. Fix the DIN rail onto the wall.
Note
You are required to ulize a matched DIN rail.
2. Press the red clip upward, and lock it to the DIN rail.
Figure 3-1 Install the Video/Audio Distributor
Video Audio Distributor Installaon Guide
3

A. Cables
Table A-1 Wiring Cables
Roung Path 24AWG
(0.2mm²)
20AWG
(0.5mm²)
18AWG
(0.8mm²)
RVV 4
DS-KAD706 -
DS-KAD706-S
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 35
m
DS-KAD706-S -
DS-KAD706-S
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 35
m
DS-KAD706-
DS-KD8003-
IME2
Transmission
Distance ≤ 35
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 35
m
DS-KAD706-
DS-KH6320-
WTE2
Transmission
Distance ≤ 35
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 60
m
Transmission
Distance ≤ 35
m
Video Audio Distributor Installaon Guide
4

UD13580B
