PanoVu PT Series Target Capture Camera·Quick Start Guide
i
i
PanoVu PT Series
Target Capture Camera
Quick Start Guide

PanoVu PT Series Target Capture Camera·Quick Start Guide
i
i
Quick Start Guide
COPYRIGHT © 2017 Hangzhou Hikvision Digital Technology Co., Ltd.
ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures,
graphs are the properties of Hangzhou Hikvision Digital Technology
Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”).
This user manual (hereinafter referred to be “the Manual”) cannot
be reproduced, changed, translated, or distributed, partially or
wholly, by any means, without the prior written permission of
Hikvision. Unless otherwise stipulated, Hikvision does not make any
warranties, guarantees or representations, express or implied,
regarding to the Manual.
About this Manual
This Manual is applicable to PanoVu PT Series Target Capture
Camera.
The Manual includes instructions for using and managing the
product. Pictures, charts, images and all other information
hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without
notice, due to firmware updates or other reasons. Please find the
latest version in the company website
(http://overseas.hikvision.com/en/).
Please use this user manual under the guidance of professionals.
Trademarks Acknowledgement
and other Hikvision’s trademarks and logos are the
properties of Hikvision in various jurisdictions. Other trademarks and

PanoVu PT Series Target Capture Camera·Quick Start Guide
ii
ii
logos mentioned below are the properties of their respective
owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS,
AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY,
SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND
NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION,
ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO
YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT
DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR
DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF
PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL
NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER
ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET
SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL
RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS
PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE

PanoVu PT Series Target Capture Camera·Quick Start Guide
iii
iii
APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT
THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.
0504091071102

PanoVu PT Series Target Capture Camera·Quick Start Guide
iv
iv
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC compliance: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the Low Voltage Directive

PanoVu PT Series Target Capture Camera·Quick Start Guide
v
v
2015/35/EU, the EMC Directive 2014/30/EU, the RoHS Directive
2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment,
or dispose of it at designated collection points. For more information,
please see: www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information,
please see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (A)/NMB-3(A) standards
requirements.

PanoVu PT Series Target Capture Camera·Quick Start Guide
vi
vi
Safety Instruction
These instructions are intended to ensure that user can use the
product correctly to avoid danger or property loss.
The precaution measure is divided into “Warnings” and “Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment damage may occur if any of the
cautions are neglected.
Warnings
In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region.
Refer to technical specifications for detailed information.
Input voltage should meet both the SELV (Safety Extra Low Voltage)
and the Limited Power Source with 24 VAC or 12 VDC according to
the IEC60950-1 standard. Refer to technical specifications for
detailed information.
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

PanoVu PT Series Target Capture Camera·Quick Start Guide
vii
vii
Do not connect several devices to one power adapter as adapter
overload may cause over-heating or a fire hazard.
Make sure that the plug is firmly connected to the power socket.
Make sure that the power has been disconnected before you wire,
install or dismantle the camera.
When the product is mounted on wall or ceiling, the device shall
be firmly fixed.
If smoke, odor or noise rise from the device, turn off the power at
once and unplug the power cable, and then contact the service
center.
If the product does not work properly, contact your dealer or the
nearest service center. Never attempt to disassemble the camera
yourself. (We shall not assume any responsibility for problems
caused by unauthorized repair or maintenance.)
Cautions
If the camera fails to synchronize local time with that of the
network, you need to set up camera time manually. Visit the
camera (via web browser or client software) and enter system
settings interface for time settings.
Make sure the power supply voltage is correct before using the
camera.
Do not drop the camera or subject it to physical shock, and do not
expose it to high electromagnetism radiation. Avoid installation on
vibrations surface or places subject to shock (ignorance can cause
device damage).

PanoVu PT Series Target Capture Camera·Quick Start Guide
viii
viii
Do not touch senor modules with fingers. If cleaning is necessary,
use clean cloth with a bit of ethanol and wipe it gently. If the
camera will not be used for an extended period, replace the lens
cap to protect the sensor from dirt.
Do not aim the camera at the sun or extra bright places. Blooming
or smearing may occur otherwise (which is not a malfunction),
and affect the endurance of sensor at the same time.
The sensor may be burned out by a laser beam, so when any laser
equipment is in using, make sure that the surface of sensor will
not be exposed to the laser beam.
Do not place the camera in extremely hot, cold, dusty or damp
locations, and do not expose it to high electromagnetic radiation.
To avoid heat accumulation, good ventilation is required for
operating environment.
Keep the camera away from liquid while in use.
While in delivery, the camera shall be packed in its original packing,
or packing of the same texture.
Improper use or replacement of the battery may result in hazard
of explosion. Replace with the same or equivalent type only.
Dispose of used batteries according to the instructions provided
by the battery manufacturer.

PanoVu PT Series Target Capture Camera·Quick Start Guide
ix
ix
Table of Contents
1 Overview......................................................................................... 1
1.1 Appearance .............................................................................. 1
1.2 Cable Descriptions .................................................................... 1
1.3 Alarm Output............................................................................ 2
2 Installation...................................................................................... 3
2.1 Installing the Memory Card ...................................................... 4
2.2 Installing the Hold Hoop ........................................................... 4
2.3 Installing the Camera ................................................................ 6
2.3.1 Wall Mounting................................................................... 6
2.3.2 Pendant Mounting .......................................................... 10
2.3.3 Base Mounting ................................................................ 11
3 Setting the Camera over the LAN ................................................. 14
3.1 Wiring .................................................................................... 14
3.2 Activating the Camera ............................................................ 15
3.2.1 Activation via Web Browser............................................. 15
3.2.2 Activation via SADP Software .......................................... 17
3.3 Modifying the IP Address........................................................ 18
4 Accessing via Web Browser .......................................................... 20

PanoVu PT Series Target Capture Camera·Quick Start Guide
1
1
1Overview
1.1 Appearance
Appearance of the camera is shown in 错误!未找到引用源。.
Figure 1-1 Appearance
1.2 Cable Descriptions
Cable interfaces of the camera are shown in Figure 1-2. The cables
are distinguished by different colors. Refer to the labels attached on
the cables for identification.
Notes:
The cables vary depending on different camera models.
Make sure the camera is power-off before you connect the
cables.
The extension cord for the power adapter should be no longer
than 15 m.

PanoVu PT Series Target Capture Camera·Quick Start Guide
2
2
Power Cord
(12 VDC)
Network Cable
Alarm Cable
Audio Cable
GND
Figure 1-2 Cables of Camera
1.3 Alarm Output
Alarm output is shown in Figure 1-3.
Relay Output
OUT (n) DC
OUT (n)
Direct load
+
-
Relay Output
OUT (n)
OUT (n)
DC 30V
1A
Power Supply
GND Output
~220V AC
FireWire
Zero
Line
JQC-3FG
Relay
(10A 250VAC)
Figure 1-3 Alarm Output

PanoVu PT Series Target Capture Camera·Quick Start Guide
3
3
2Installation
Before you start:
Check the package contents and make sure that the device in the
package is in good condition and all the assembly parts are included.
Notes:
Do not power up the camera until the installation is finished. To
ensure the safety of personnel and equipment, all the
installation steps should be done with power supply off.
Do not drag the camera with its waterproof cables; otherwise
the waterproof performance is affected.
Figure 2-1 Do not Drag

PanoVu PT Series Target Capture Camera·Quick Start Guide
4
4
2.1 Installing the Memory Card
You can install the memory card for local storage.
Note:
If you need to insert or pull out the memory card, make sure the
power is off.
Steps:
1. Unscrew the screws on the memory card slot cover and open the
cover as shown in 错误!未找到引用源。.
Memory Card Slot
Figure 2-2 Open the Memory Card Slot Cover
2. Insert the memory card into the memory card slot.
3. Install the memory card slot cover back, and tighten the screws to
fix it.
Note:
Do not remove the water-proof ring when installing the memory
card.
2.2 Installing the Hold Hoop
If you need to install the camera to the cross-bar, you need to install
the hold hoop first.

PanoVu PT Series Target Capture Camera·Quick Start Guide
5
5
Steps:
1. Open three hold hoops.
2. Encircle the hold hoops around the cross-bar, and tighten the hold
hoops as shown in Figure 2-3.
Figure 2-3 Tighten the Hold Hoops
Note:
You can install the camera to the hold hoop with the certain
mounting bracket, such as the wall mounting bracket or the base
mounting bracket, as shown in Figure 2-4.
Figure 2-4 Install the Camera to the Hold Hoop

PanoVu PT Series Target Capture Camera·Quick Start Guide
6
6
2.3 Installing the Camera
2.3.1 Wall Mounting
Before you start:
Make sure the camera is power-off before you install the camera.
And you need to prepare the wall mounting bracket first.
Notes:
For cement wall, you need to use the expansion screw to fix the
bracket. The mounting hole of the expansion pipe on the wall
should align with the mounting hole on the bracket.
For wooden wall, you can just use the self-tapping screw to fix
the bracket.
Make sure that the wall is strong enough to withstand more
than eight times the weight of the camera and its accessories.
Steps:
1. Install the base plate.
1). Drill four screw holes on the wall according to the screw holes
on the base plate.
2). Insert four M8*80 screws into the screws holes.
3). Fix the base plate onto the wall with the flat gaskets, the
spring washers, and the screw nuts as shown in Figure 2-5.

PanoVu PT Series Target Capture Camera·Quick Start Guide
7
7
Figure 2-5 Fix the Base Plate
2. Fix the bracket hanger to the camera with four 1/4 UNC screws as
shown in Figure 2-6.
¼ UNC Screw
Bracket Hanger
Figure 2-6 Fix the Bracket Hanger
3. Install the camera to the wall mounting bracket.
1). Push the wall mounting bracket into the space of the bracket
hanger, and fix the bracket with two M6*16 screws as shown
in Figure 2-7.

PanoVu PT Series Target Capture Camera·Quick Start Guide
8
8
M6*16 Screw
M6*16 Screw
Figure 2-7 Install the Camera to the Bracket
2). Route the cables through the water-proof plug, and place the
cables in the bracket junction box as shown in Figure 2-8.
Bracket Junction Box
Cables
Water-proof Plug
Figure 2-8 Route the Cables

PanoVu PT Series Target Capture Camera·Quick Start Guide
9
9
4. Connect the cables.
1). Hang the safety rope of the bracket to the safety hook on the
base plate as shown in Figure 2-9.
Safety Rope
Safety Hook
Figure 2-9 Hang the Safety Rope
2). Connect the corresponding cables, and place the cables in the
bracket junction box.
5. Align the bracket junction box with the base plate, and fix them
with four M6*18 screws as shown in Figure 2-10.
Bottom Screws
Fixing Screws of Junction Box
Protective Film Side Screws
Figure 2-10 Fix the Junction Box

PanoVu PT Series Target Capture Camera·Quick Start Guide
10
10
6. Adjust the horizontal and vertical angels.
1). Unscrew the bottom screws (do not remove), and adjust the
horizontal angel.
2). Unscrew the side screws (do not remove), and adjust the
vertical angel.
Notes:
Activate the camera first for live view, and adjust the
horizontal and vertical angels according to the surveillance
requirements.
We recommend you to adjust the horizontal angel to -10°
for the better view.
7. Remove the protective films after installation.
2.3.2 Pendant Mounting
Before you start:
Make sure the camera is power-off before you install the camera.
And you need to prepare the pendant mounting bracket first.
Notes:
The installation steps of pendant mounting are similar to the
installation steps of wall mounting. Refer to section 2.3.1 Wall
Mounting for details.
The steps of adjusting angles are slightly different. Unscrew the
horizontal fixing screws to adjust the horizontal angel, and
unscrew the side screws to adjust the vertical angel.
