DS-2DF5274-A
Key features
System function:
 1/3" SONY high performance sensor, up to 1280x960 resolution
 ±0.1° Preset Accuracy
 ONVIF(Open Network Video Interface Forum)、CGI(Common Gateway Interface) 、PSIA(Physical Security
Interoperability Alliance), to ensure greater interoperability between different platforms and compatibility
 3D intelligent positioning function
 Power-off memory function: restore PTZ & Lens status after reboot
 IP66 standard (outdoor dome)
 3D DNR
 Fiber optical interface optional
 Scheduled PTZ movement
Camera function:
 Auto iris, auto focus, auto white balance, backlight compensation and auto day & night switch
 Privacy masks programmable
PTZ function:
 360° endless pan range and -5°-90° tilt range
 540°/s Pan Preset Speed and 400°/s Tilt Preset Speed
 0.1°-300°/s Manual Pan Speed and 0.1°-240°/s Manual Tilt Speed
 256 presets programmable, preset image freezing capability
 8 patrols, up to 32 presets per patrol
 4 patterns, with the recording time not less than 10 minutes per pattern
 Park action: auto call up of PTZ movement, after a defined time of inactivity
 7 alarm inputs and 2 alarm outputs
Network function:
 H.264/MJPEG/MPEG4 video compression and the latest Davinci processing chip and platform
 Built-in Web server
 SD/SDHC card local storage
 Dual stream
 Multiple network protocols supported:IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,
RTSP,RTP,TCP,UDP,IGMP,ICMP,DHCP,PPPoE
 1 audio input and 1 audio output

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
4
Application Scenarios
It can be widely applied to places requiring wide-area monitoring and high-definition display, such as rivers, forests,
highways, railways, airports, ports, sentries, squares, parks, scenic sites, streets, stations, large venues, outside of
residential areas, etc.
Specifications
Model
Parameter
DS-2DF5274-A:24VAC,Outdoor
DS-2DF5274-A0:24VAC,Indoor
DS-2DF5274-A3 :24VAC,In-ceiling
1.3 Megapixel 5 Inch Network High Speed Dome
Camera
Image Sensor 1/3’’ Progressive Scan CMOS
Effective Pixel 1300K pixels
Min. Illumination
Color: 0.05Lux@( F1.4, AGC ON)
B/W: 0.005Lux@( F1.4, AGC ON)
White Balance Auto / Manual / One Touch WB / ATW
AGC Auto / Manual
S / N Ratio ≥ 50dB
DNR off/normal/expert
BLC On / Off
Shutter Time 50Hz: 1/25-1/100,000s
60Hz: 1/30-1/100,000s
Day & Night IR Cut Filter
Digital Zoom -
Privacy Mask 24 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the
same video screen
Focus Mode Auto / Semiautomatic / Manual
Lens
Focal Length 4.3-86.0mm, 20x
Zoom Speed Approx.5s(Optical Wide-Tele)
Angle of View 54.1-3.2 degree (Wide-Tele)
Min. Working Distance 10-1,500mm(Wide-Tele)
Aperture Range F1.4- F2.6
Pan and Tilt
Pan Range 360° endless
Pan Speed
Pan Manual Speed: 0.1° -300°/s,
Pan Preset Speed: 540°/s
Tilt Range -5°-90°(Auto Flip)
Tilt Speed
Tilt Manual Speed: 0.1°-240°/s,
Tilt Preset Speed: 400°/s
Proportional Zoom Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset 256

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
5
Patrol 8 patrols, up to 32 presets per patrol
Pattern 4 patterns, with the recording time not less than 10 minutes per pattern
Power-off Memory Support
Park Action Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display On / Off
Preset Freezing Support
Alarm
Alarm Input 7
Alarm Output 2 relay outputs, alarm response actions configurable
Alarm Actions Preset, Patrol, Pattern, SD/SDHC card recording, Relay output, Notification on Client
Input/
Output
Monitor Output 1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
Audio Input Audio input (Line input), 2-2.4V[p-p]; output impedance: 1KΩ, ±10%
Audio Output Line level, impedance: 600Ω
Network
Ethernet 10Base-T / 100Base-TX, RJ45 connector
Max.Image Resolution 1280×960
Frame Rate 50Hz:25fps(1280×960), 25fps (1280×720)
60Hz:30fps(1280×960), 30fps (1280×720)
Image Compression H.264/MJPEG/MPEG4
Audio Compression G.711ulaw/G.711alaw/G.726
Protocols IPv4/IPv6,HTTP,HTTPS,802.1x,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTP,TCP,UDP,IGM
P, ICMP,DHCP,PPPoE
Number of Simultaneous
Live View Up to 10
Dual Streams Support
Mini SD Memory Card Manual REC / Alarm REC.
Built-in SD/SDHC Slot, up to 32GB
User/Host Level Up to 32 users,3 Levels: Administrator, Camera control, Live view only
Security Measures User authentication (ID and PW),
Host authentication (MAC address)
System
Integration
Interface for application
programming Open-ended API, support Onvif, PSIA and CGI, hikvision SDK
Client GUI
Camera Control Pan /Tilt, Zoom, Focus, Click centering, Drag zoom, Iris, Preset position call and program, Auto
mode.
Camera Name Up to 18 characters
Date & Time Display Time: Week: Date, 6 formats on the Client
Reading Patrol Message Display and reading of preset message contained in each patrol via client software
Fiber
Optical
Interface
(available
Data Mode 10Base-T / 100Base-TX
Physical Interface FC
Fiber Wavelength TX1310/RX1550nm
Fiber Type Single Fiber/Single mode

Hikvision Technical Manual
©2006 – 2012 by HIKVISION. All rights reserved.
6
for fiber
dome only) Transmission Distance 20km
General
Menu Language English
RS-485
Protocols(optional) HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power Supply 24VAC/3A
Power Consumption Outdoor dome: Max. 40W (Heater On), Max. 20W(Heater Off)
Indoor/In-ceiling dome: Max. 20W
Working Temperature /
Humidity
-30 ℃-65℃(-22℉-149℉)(outdoor dome) / -10℃-50℃(14℉-122℉)(indoor dome )
90% or less
Protection Level IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection
Mounting Various mounting modes optional
Dimensions
Φ220×325.5mm (Φ8.66”×12.81”)(Outdoor)
Φ183.4×243mm(Φ7.22”×9.57”) (Indoor)
Φ245×236mm(Φ9.65”×9.29”) (In-ceiling)
Weight (approx.) 5Kg (11.02Ibs)
Mount Option Long-arm wall mount: DS-1614ZJ; Indoor short-arm wall mount: DS-1615ZJ
Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ; Power box mount:DS-1634ZJ
Dimensions
Outdoor Indoor Embedded
Bore Size
Unit: mm
