HIK VISION DS-IX2001-A3U User manual

Intelligent Fusion Server
User Manual

Legal Informaon
User Manual
©2019 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
About this Manual
The Manual includes instrucons for using and managing the Product. Pictures, charts, images and
all other informaon hereinaer are for descripon and explanaon only. The informaon
contained in the Manual is subject to change, without noce, due to rmware updates or other
reasons. Please nd the latest version of this Manual at the Hikvision website ( hps://
www.hikvision.com/en/ ).
Please use this Manual with the guidance and assistance of professionals trained in supporng the
Product.
Trademarks
and other Hikvision's trademarks and logos are the properes of
Hikvision in various jurisdicons.
Other trademarks and logos menoned are the properes of their respecve owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND “WITH
ALL FAULTS AND ERRORS”. HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR
PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION
BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES,
INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS
INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION,
WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY,
OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS,
AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION, PRIVACY
LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK, VIRUS
INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE TIMELY
TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
Intelligent Fusion Server User Manual
i

YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.
Intelligent Fusion Server User Manual
ii

Regulatory Informaon
FCC Informaon
Please take aenon that changes or modicaon not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protecon against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is likely to
cause harmful interference in which case the user will be required to correct the interference at his
own expense.
FCC Condions
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two
condions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operaon.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with
"CE" and comply therefore with the applicable harmonized European
standards listed under the EMC Direcve 2014/30/EU, the RoHS Direcve
2011/65/EU.
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collecon points.
For more informaon see: hp://www.recyclethis.info .
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the
product documentaon for specic baery informaon. The baery is
marked with this symbol, which may include leering to indicate cadmium
(Cd), lead (Pb), or mercury (Hg). For proper recycling, return the baery to
your supplier or to a designated collecon point. For more informaon see:
hp://www.recyclethis.info .
Intelligent Fusion Server User Manual
iii

Preface
Applicable Models
This manual is applicable to DS-IX2001-A3U/X and DS-IX2003-A3U/X.
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
Intelligent Fusion Server User Manual
iv

Contents
Chapter 1 Introducon ............................................................................................................... 1
1.1 Key Features ........................................................................................................................... 1
1.2 PC Requirements .................................................................................................................... 1
Chapter 2 Conguraon Wizard .................................................................................................. 2
2.1 Login ...................................................................................................................................... 2
2.2 Create Cluster ........................................................................................................................ 3
2.2.1 Add Nodes ..................................................................................................................... 3
2.2.2 Create Stand-alone Cluster ........................................................................................... 4
2.2.3 Create Master and Backup Cluster ................................................................................ 7
2.3 Add Face List Library .............................................................................................................. 8
2.4 Add Personnel Informaon .................................................................................................... 9
2.5 Create Analysis Task ............................................................................................................. 10
2.5.1 Add Camera ................................................................................................................ 10
2.5.2 Create Real-me Analysis Task .................................................................................... 12
2.5.3 Create Video Record Analysis Task .............................................................................. 15
2.6 Add Arming .......................................................................................................................... 19
2.6.1 Add List Arming ........................................................................................................... 19
2.6.2 Add Stranger Arming ................................................................................................... 20
2.6.3 Add License Plate Arming ........................................................................................... 21
2.7 Enable Frequency Alarm ...................................................................................................... 22
2.8 Enable Personnel Archive .................................................................................................... 24
2.9 Reset Standard ..................................................................................................................... 25
Chapter 3 Smart Applicaon ..................................................................................................... 27
3.1 Live View .............................................................................................................................. 27
3.2 Alarm Search ........................................................................................................................ 29
3.2.1 List Alarm .................................................................................................................... 29
Intelligent Fusion Server User Manual
v

3.2.2 Stranger Alarm ............................................................................................................ 30
3.2.3 Frequently Appeared Person Alarm ............................................................................ 32
3.2.4 License Plate Alarm ..................................................................................................... 33
3.3 Personnel Archive ................................................................................................................ 34
3.4 1 V 1 Comparison ................................................................................................................. 36
Chapter 4 Smart Search ............................................................................................................ 38
4.1 Face Picture Search .............................................................................................................. 38
4.1.1 Search by Facial Feature .............................................................................................. 38
4.1.2 Search by Face Picture ................................................................................................ 39
4.1.3 Conrm Idencaon ................................................................................................. 40
4.2 Human Body Search ............................................................................................................. 41
4.2.1 Search by Physical Aribute ........................................................................................ 41
4.2.2 Search by Human Body Feature .................................................................................. 42
4.3 Vehicle Search ...................................................................................................................... 43
4.3.1 Search by Vehicle Aribute ......................................................................................... 43
4.3.2 Search by Vehicle Picture ............................................................................................ 44
Chapter 5 System Management ................................................................................................ 46
5.1 Cluster Management ........................................................................................................... 46
5.1.1 Delete Node ................................................................................................................ 46
5.1.2 Restart Node ............................................................................................................... 46
5.1.3 Power O Node ........................................................................................................... 46
5.1.4 Add More Nodes to Cluster ........................................................................................ 47
5.1.5 Disband Cluster ........................................................................................................... 47
5.2 Operaon and Maintenance ................................................................................................ 48
5.2.1 Check Hardware Status ............................................................................................... 48
5.2.2 Check Service Status ................................................................................................... 48
5.3 System Conguraon ........................................................................................................... 49
5.3.1 General Conguraon ................................................................................................. 49
Intelligent Fusion Server User Manual
vi

5.3.2 Service Conguraon .................................................................................................. 49
5.3.3 Pre-Classicaon Conguraon .................................................................................. 50
5.3.4 Time Conguraon ..................................................................................................... 50
5.3.5 User Management ...................................................................................................... 51
5.3.6 Display Coguraon .................................................................................................... 52
5.3.7 Live View Conguraon .............................................................................................. 53
5.3.8 Person Paern Conguraon ...................................................................................... 53
5.3.9 Restore Default ........................................................................................................... 54
5.4 Log Search ............................................................................................................................ 55
5.5 Soware Updang ............................................................................................................... 55
5.6 Online User .......................................................................................................................... 56
5.7 Help ...................................................................................................................................... 56
5.8 Version ................................................................................................................................. 56
5.9 Log out ................................................................................................................................. 56
Intelligent Fusion Server User Manual
vii

Chapter 1 Introducon
Intelligent fusion server (hereaer referred as the sever), equipped with professional GPU card,
integrates deep learning-based algorithms of facial analysis, picture structuralizaon and video
structuralizaon. It combines analysis, storage and applicaon as one. By recognizing, analyzing,
modelling and comparing pictures of faces, human bodies or vehicles, the intelligent fusion server
can perform funcons as list alarm, creang personnel archives, personnel trace analysis, searching
by human body picture, vehicle arming, and so forth. The server is widely applied for city,
community, school, company, industrial area and other face recognion scenarios.
1.1 Key Features
• Human face list management.
• Human face list library arming.
• Human face detecon in dierent monitoring scenarios.
• Rapid search for human face informaon in capture library.
• Supports list alarm, stranger alarm, high frequency alarm and license plate alarm.
•Sengs of alarm popup and sound.
• Supports to establish archives for each personnel.
• Supports to generate personnel paern.
• Rapid 1V1 face similarity comparison.
• Supports to search picture by aribute or picture, and display search results in order of similarity
from high to low or in me order.
• Supports personnel idencaon and display search results in order of similarity from high to
low.
• Supports to view the usage of device resource.
• User permission management of admin, operator and consumer.
• NTP me synchronizaon and manual me synchronizaon.
• Supports soware updang.
1.2 PC Requirements
You can get access to the server with Web browser.
The requirements for your PC are shown as below.
•Operang system: Microso Windows 7, Microso Windows 8.
• CPU: Intel Penum IV 3.0 GHz or above.
• Memory: 1G or larger.
•Resoluon: 1024 × 768 or higher.
• Web browser: Internet Explorer 8 to 11.
Intelligent Fusion Server User Manual
1

Chapter 2 Conguraon Wizard
2.1 Login
You can get access to the server with web browser.
Note
You shall acknowledge that the use of the product with Internet access might be under network
security risks. For avoidance of any network aacks and informaon leakage, please strengthen
your own protecon. If the product does not work properly, please contact with your dealer or the
nearest service center.
Steps
1. Open web browser, enter the IP address of the server and then press Enter.
Figure 2-1 Login Interface
2. Enter User Name (admin) and Password.
3. Click Login.
Figure 2-2 Home Page
Intelligent Fusion Server User Manual
2

Note
• If the server is inaccessible, go to Internet Opons → Advancement , check Enable TLS1.1
and Enable TLS1.2.
• The specic interface depends on the product.
Aer admin user logs in, the server will jump to the homepage where you can view informaon
such as Alarm Stascs, Camera Stascs, and Capture Stascs.
2.2 Create Cluster
Note
The nodes that create micro video cloud cluster should be same with that of creang analysis
cluster. Otherwise, excepon may occur.
2.2.1 Add Nodes
Before You Start
The node is online and on the same subnet with the server.
Note
The specic parameter values lled in the relevant interfaces below are for reference only. You
need to congure relevant parameter values according to actual needs.
Steps
1. Go to System Management → Cluster Management → Node Management
2. Click Add.
Figure 2-3 Add Notes
3. Enter Name, Nodes IP, User Name and Password.
4. Click OK.
Intelligent Fusion Server User Manual
3

Figure 2-4 Congure Nodes Informaon
Note
If there are mulple nodes to be added, please follow the steps above to nish.
2.2.2 Create Stand-alone Cluster
Single node can create standalone cluster. Aer creang cluster, the server can analyze data.
Before You Start
The node is online.
Steps
1. Go to System Management → Cluster Management , and click Create Cluster.
Figure 2-5 Click Create Cluster
2. Select the desired node, and click Next.
Intelligent Fusion Server User Manual
4

Figure 2-6 Select Nodes
3. Click zookeeper, kaa, MongoDB, appServer respecvely and check the desired nodes.
Figure 2-7 Deploying Service
4. Click Start Deploying.
5. Click OFF aer deploying is completed.
Intelligent Fusion Server User Manual
5

Figure 2-8 Click OFF
6. Clik Resource Conguraon to allocate resources for face picture analysis and face video
analysis.
Face Picture Analysis Path
Intelligent analysis of face aributes in pictures.
Face Video Analysis Path
Intelligent analysis of face aributes in videos.
Structured Picture Analysis Channel
Intelligent analysis of target (human body or vehicle) aributes in pictures.
Structured Video Analysis Channel
Intelligent analysis of target (human body or vehicle) aributes in videos.
Note
If no resource is allocated, the server cannot process the analysis task.
Figure 2-9 Allocate Resource
Intelligent Fusion Server User Manual
6

2.2.3 Create Master and Backup Cluster
Two or more nodes can create a master and backup cluster. Data can only be analyzed aer the
cluster is created.
Before You Start
The nodes are online and in the same subnet.
Steps
1. Go to System Management → Cluster Management , and click Create Cluster.
2. Select the desired nodes, and click Next.
3. Click zookeeper, kaa, MongoDB, appServer respecvely and check the desired nodes.
4. Click appServer and enter an unused IP address in Virtual IP.
5. Click Start Deploying.
6. Click OFF aer deploying is completed.
7. Clik Resource Conguraon to allocate resources for face picture analysis and face video
analysis.
Face Picture Analysis Path
Intelligent analysis of face aributes in pictures.
Face Video Analysis Path
Intelligent analysis of face aributes in videos.
Structured Picture Analysis Channel
Intelligent analysis of target (human body or vehicle) aributes in pictures.
Structured Video Analysis Channel
Intelligent analysis of target (human body or vehicle) aributes in videos.
Note
If no resource is allocated, the server cannot process the analysis task.
Intelligent Fusion Server User Manual
7

Figure 2-10 Allocate Resource
2.3 Add Face List Library
Add dierent list libraries, including normal library, blacklist library and VIP library.
Steps
1. Go to List Management, and click Add.
Figure 2-11 List Library Interface
2. Congure relevant parameters in the dialogue box according to actual demands. Here we take
blacklist arm library as an example.
Intelligent Fusion Server User Manual
8

Figure 2-12 Add Face List Library
Note
Only when List Library Type is set as Arm Library can the alarming and personnel archive
funcon be implemented.
3. Aer seng, click OK.
4. Oponal: Aer adding face list library, you can click to modify list library informaon and
click to delete it.
Note
• The passerby library is created by default and cannot be deleted. It is used to add captured
stranger face pictures.
•Deleng a list library will delete all relevant personnel informaon.
• Only non-arm list library can be deleted.
2.4 Add Personnel Informaon
Before You Start
Face List library has been added.
Steps
1. Click the desired list library to add personnel.
Figure 2-13 Click List Library
2. Click Add, input relevant parameters in the dialogue box, and upload face picture.
Intelligent Fusion Server User Manual
9

Figure 2-14 Add Personnel Informaon
Note
•Name and Birthday are required, enter dierent contents according to actual demands.
• The server supports uploading face picture in the format of jpg, jpeg, bmp, f and png.
3. Click OK.
4. You can edit, delete or search aer personnel informaon add.
• Edit personnel informaon: move your mouse to the item, and click .
• Delete personnel informaon: move your mouse to the item, and click .
• Search personnel informaon: move your mouse to the item, and click .
2.5 Create Analysis Task
Analysis task includes real-me analysis task and local video record analysis task. Before creang
analysis task, you should add respecve resource like camera, video record and etc.
2.5.1 Add Camera
Add the desired camera for arming.
Before You Start
Obtain the IP address, user name and login password of the camera.
Steps
Note
• Add one camera only for each me.
• indicates control center and indicates area. The camera should be added to control center
rst before added to area. Here we take adding camera to control center "test" as an example.
1. Go to Target Arming → Task Management → Camera Management .
Intelligent Fusion Server User Manual
10

2. Go to Administraon-admin → .
Figure 2-15 Add Control Center
3. Select Control Center as Type and enter the name of control center.
4. Click OK.
5. Click the newly-added control center and enter informaon in the popup window.
Figure 2-16 Add Camera
6. Click OK.
7. Click .
8. Select Area as Type and enter the name of area.
Intelligent Fusion Server User Manual
11

Figure 2-17 Add Area
9. Click OK.
Note
The area name supports number, lowercase and uppercase, and special characters “-, _”, and up
to 32 characters are allowed.
10. Click the newly-added area and then click Add.
Figure 2-18 Add Camera to Area
Note
The camera can be armed only when it is added to area.
11. Select the desired camera.
12. Click OK.
Note
Both control centers and areas can be added to the control center, but only cameras can be
added to the area.
2.5.2 Create Real-me Analysis Task
Real-me analysis task is used to conduct real-me analysis of targets in monitoring scene.
Intelligent Fusion Server User Manual
12
