Hilti SID 14-A User manual

Operating instructions en
Mode d’emploi fr
Manual de instrucciones es
SID/SIW
14-A/18-A
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

껾
껼
껽
껽
껻
꼁
꼄꼄 꼃꼃
꼀
꼅
껿
% $K % $K %  $K %  $K
%  $K
꼄 꼄꼂 꼂
1
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

ETL listed to US and Canadian safety standards
Homologué ETL (conforme aux normes de sécurité américaines et canadiennes)
Producto homologado según normas de seguridad americanas y canadienses
Produto homologado de accordo com as normas de segurança americanas e canadianas
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

2 3
54
6723
6
7
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

14.4 Volt Li-Ion
1.6 Ah
14.4 Volt Li-Ion
1.6 Ah
8


9
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
1
ORIGINAL OPERATING INSTRUCTIONS
SID 14A / SID 18A / SIW 14A /
SIW 18A cordless impact
driver/wrench
It is essential that the operating instructions are read before the power tool
is operated for the first time.
Always keep these operating instructions together with the power tool.
Ensure that the operating instructions are with the power tool when it is
given to other persons.
Contents
1 Generalinformation ........................... 2
2 Description ................................. 4
3 Inserttools,accessories ........................ 5
4 Technicaldata ............................... 6
5 Safetyinstructions ............................ 8
6 Beforeuse................................. 14
7 Operation ................................. 16
8 Careandmaintenance......................... 19
9 Troubleshooting ............................. 20
10 Disposal .................................. 21
11 Manufacturer’swarranty-tools................... 22
1These numbers refer to the corresponding illustrations. The illustrations
canbefoundonthefold-outcoverpages. Keepthesepagesopenwhile
studying the operating instructions.
In these operating instructions, the designation “the power tool” always
refers to the SIW 14A, SIW 18A, SID 14A or SID 18A cordless impact
wrench / screwdriver with battery fitted.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
2
Operating controls and parts 1
@SIW square drive
;SID hex. socket drive
=Light
%Control switch (with electronic speed control)
&Forward / reverse switch
(Motor brake
)Torque selector switch
+SID/W 18A battery release buttons
§SID/W 14A battery release button
/Charge status and fault display (Li-ion battery)
:Belt hook (optional)
1 General information
1.1 Safety notices and their meaning
DANGER
Draws attention to imminent danger that will lead to serious bodily injury or
fatality.
WARNING
Draws attention to a potentially dangerous situation that could lead to
serious personal injury or fatality.
CAUTION
Draws attention to a potentially dangerous situation that could lead to slight
personal injury or damage to the equipment or other property.
NOTE
Draws attention to an instruction or other useful information.
1.2 Explanation of the pictograms and other information
Warning signs
General warning Warning: electricity Warning: caustic
substances
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
3
Obligation signs
Wear eye protection Wear a hard hat Wear ear protection Wear protective
gloves
Wear breathing
protection
Symbols
Read the operating
instructions before
use
Return waste
material for
recycling.
Volts Direct current
Rated speed under
no load
Revolutions per
minute
Revolutions per
minute
Location of identification data on the power tool
The type designation can be found on the type identification plate and the
serial number on the side of the motor housing. Make a note of this data in
your operating instructions and always refer to it when making an enquiry to
your Hilti representative or service department.
Type:
Generation: 01
Serial no.:
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
4
2 Description
2.1 Use of the product as directed
The SID 14-A, SIW 14-A, SID 18-A and SIW 18-A are hand-held cordless
impact screwdrivers/wrenches. They are designed for driving and removing
screws in wood, metal, masonry and concrete and for tightening and
releasing nuts and bolts.
Working on materials hazardous to the health (e.g. asbestos) is not
permissible.
Do not use the battery as a power source for other unspecified appliances.
Modification of the power tool or tampering with its parts is not permissible.
To avoid the risk of injury, use only genuine Hilti accessories and insert
tools.
The power tool should not be used for applications that require a precise
torque. For applications that require a precise torque or where only a special
limited torque is permitted, there is a risk of over-tightening and damage to
the screw or workpiece. For these types of application, use a tool with a
predefined torque setting to prevent over-tightening.
Observe the information printed in the operating instructions concerning
operation, care and maintenance.
The power tool is designed for professional use and may be operated,
serviced and maintained only by trained, authorized personnel. This
personnel must be informed of any special hazards that may be encountered.
The power tool and its ancillary equipment may present hazards when used
incorrectly by untrained personnel or when used not as directed.
The working environment may be as follows: construction site, workshop,
renovation, conversion or new construction.
Nationally applicable industrial safety regulations must be observed.
2.2 The items supplied include (toolbox versions):
1 Power tool
1 Operating instructions
1 Hilti toolbox
2.3 The items supplied include (cardboard box versions):
1 Power tool
1 Operating instructions
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
5
2.4 Additional items required for operating the tool
B 18/1.6 LiIon, B 18/2.6 LiIon, B 18⁄3.3 LiIon, B 14/1.6 LiIon or
B 14/3.3 LiIon battery with C4⁄3690, C4⁄36350, C 4/36, C 4/36ACS
or C 4/36ACS TPS charger.
2.5 Liion battery charge status
LEDs light constantly LEDs blink Charge status C
LED1,2,3,4 -C≧75%
LED1,2,3 -50 % ≦ C < 75 %
LED 1, 2 -25 % ≦ C < 50 %
LED 1 -10 % ≦ C < 25 %
-LED 1 C<10%
3 Insert tools, accessories
Designation Short designation Description
Bit holder S-BH 50
Charger for Li-ion bat-
teries
C4/36ACS
Charger for Li-ion bat-
teries
C4/36
Charger for Li-ion bat-
teries
C 4/3690
Charger for Li-ion bat-
teries
C 4/36350
Battery B 14/3.3, B 14/1.6
LiIon
Battery B18/1.6LiIon
Battery B 18/2.6 Liion
Battery B18/3.3LiIon
Belt hook
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
6
Designation Description
Bits Hex. bit, bit adapter, drill bits with
hex. shank
Sockets Impact wrench sockets
4 Technical data
Right of technical changes reserved.
Power tool SID 14A SIW 14A
Rated voltage 14.4 V 14.4 V
Weight (including bat-
tery and chuck)
1.3 kg (2.87 lb) 1.3 kg (2.87 lb)
Dimensions (L x W x
H)
151 mm (5.94") x
81 mm (3.19") x
228 mm (8.98")
154 mm (6.06") x
81 mm (3.19") x
228 mm (8.98")
Rated no-load running
speed, pos. I
0…1,000/min 0…1,000/min
Rated no-load running
speed, pos. II
0…1,500/min 0…1,500/min
Rated no-load running
speed, pos. III
0…2,500/min 0…2,300/min
Impact speed Max. 3,100/min Max. 3,400/min
Speed adjustment Three settings Three settings
Standard screws M8  M16 M8  M16
High-strength screws M6  M12 M6  M12
Chuck ¹/₄" hex. socket with
locking sleeve
¹/₂" square drive with
ball-notch retention
and ³/₈" with locking
ring
Speed control Electronic, by way of
the control switch
Electronic, by way of
the control switch
Forward / reverse Electronic switch with
interlock to prevent
switching while run-
ning
Electronic switch with
interlock to prevent
switching while run-
ning
Deep discharge pro-
tection
Yes Yes
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
7
Power tool SID 18A SIW 18A
Rated voltage 21.6 V 21.6 V
Weight (including bat-
tery and chuck)
1.5 kg (3.31 lb) 1.5 kg (3.31 lb)
Dimensions (L x W x
H)
151 mm (5.94") x
94 mm (3.7") x
228 mm (8.98")
154 mm (6.06") x
94 mm (3.7") x
228 mm (8.98")
Rated no-load running
speed, pos. I
0…1,000/min 0…1,000/min
Rated no-load running
speed, pos. II
0…1,500/min 0…1,500/min
Rated no-load running
speed, pos. III
0…2,500/min 0…2,300/min
Impact speed Max. 3,450/min Max. 3,500/min
Speed adjustment Three settings Three settings
Standard screws M8  M16 M8  M16
High-strength screws M6  M12 M6  M12
Chuck
Speed control Electronic, by way of
the control switch
Electronic,bywayof
the control switch
Forward / reverse Electronic switch with
interlock to prevent
switching while run-
ning
Electronic switch with
interlock to prevent
switching while run-
ning
Deep discharge pro-
tection
Yes Yes
NOTE
The torque selector switch can be used to select three torque settings.
Power tool Position I Position II Position III
SID 14A 50 Nm (37 lb/ft) 100 Nm (74 lb/ft) 150 Nm
(111 lb/ft)
SIW 14A (³⁄₈"
square drive)
65 Nm (48 lb/ft) 115 Nm (85 lb/ft) 160 Nm
(118 lb/ft)
SIW 14A
(½" square
drive)
80 Nm (59 lb/ft) 120 Nm (89 lb/ft) 185 Nm
(136 lb/ft)
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
8
Power tool Position I Position II Position III
SID 18A 60 Nm (44 lb/ft) 110 Nm (81 lb/ft) 165 Nm
(122 lb/ft)
SIW 18A (³⁄₈"
square drive)
75 Nm (55 lb/ft) 120 Nm (89 lb/ft) 175 Nm
(129 lb/ft)
SIW 18A
(½" square
drive)
90 Nm (66 lb/ft) 135 Nm
(100 lb/ft)
200 Nm
(148 lb/ft)
Battery B 18/1.6 LiIon B 18/2.6 LiIon B 18/3.3 LiIon
Rated voltage 21.6 V 21.6 V 21.6 V
Battery capacity 1.6 Ah 2.6 Ah 3.3 Ah
Energy content 34.56 Wh 56.16 Wh 71.28 Wh
Weight 0.48 kg (1.06 lb) 0.78 kg (1.72 lb) 0.78 kg (1.72 lb)
Temperature
monitoring
Yes Yes Yes
Type of cell Li-ion Li-ion Li-ion
No. of cells 612 12
Battery B14/1.6LiIon B 14/3.3 LiIon
Rated voltage 14.4 V 14.4 V
Battery capacity 1.6 Ah 3.3 Ah
Energy content 23.04 Wh 47.52 Wh
Weight 0.36 kg (0.79 lb) 0.58 kg (1.28 lb)
Temperature monitor-
ing
Yes Yes
Type of cell Li-ion Li-ion
No. of cells 4 8
5 Safety instructions
NOTE
The safety rules in section 5.1 contain all general safety rules for power tools
which, in accordance with the applicable standards, require to be listed in
the operating instructions. Accordingly, some of the rules listed may not be
relevant to this tool.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
9
5.1 General power tool safety warnings
a) WARNING
Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future reference. The
term “power tool” in the warnings refers to your mains-operated (corded)
power tool or battery-operated (cordless) power tool.
5.1.1 Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
b) Do not operate power tools in explosive atmospheres, such as in
the presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
5.1.2 Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces such as
pipes, radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering
a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use
a residual current device (RCD) protected supply. Use of an RCD
reduces the risk of electric shock.
5.1.3 Personal safety
a) Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
10
or under the influence of drugs, alcohol or medication. Amoment
of inattention while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the
off‐position before connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying power tools with your
finger on the switch or energising power tools that have the switch on
invites accidents.
d) Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool
may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes,
jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used.
Use of dust collection can reduce dust-related hazards.
5.1.4 Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at
therateforwhichitwasdesigned.
b) Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous
and must be repaired.
c) Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
to operate the power tool. Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
11
before use. Many accidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance
with these instructions taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
5.1.5 Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A
chargerthatissuitableforonetypeofbatterypackmaycreateariskof
fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs.
Use of any other battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from one terminal to
another. Shorting the battery terminals together may cause burns or a
fire.
d) Under abusive conditions, liquid may be ejected from the battery,
avoid contact. If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help. Liquid ejected
from the battery may cause irritation or burns.
5.1.6 Service
a) Have your power tool serviced by a qualified repair person using
only identical replacement parts. This will ensure that the safety of the
power tool is maintained.
5.2 Additional safety precautions
5.2.1 Personal safety
a) Hold power tool by insulated gripping surfaces, when performing an
operation where the fastener may contact hidden wiring. Fasteners
contacting a "live" wire may make exposed metal parts of the power
tool "live" and could give the operator an electric shock.
b) Wear ear protectors. Exposuretonoisecancausehearingloss.
c) Use auxiliary handles, if supplied with the tool. Loss of control can
cause personal injury.
d) Breathing protection must be worn if the power tool is used without
a dust removal system for work that creates dust.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
12
e) Improve the blood circulation in your fingers by relaxing your hands
and exercising your fingers during breaks between working.
f) Avoid touching rotating parts. Switch the power tool on only after
bringing it into position at the workpiece. Touching rotating parts,
especially rotating insert tools, may lead to injury.
g) Activate the safety lock (forward / reverse switch in the middle
position) before storing or transporting the power tool.
h) Children must be instructed not to play with the power tool.
i) The power tool is not intended for use by children, by debilitated
persons or those who have received no instruction or training.
j) WARNING: Some dust created by grinding, sanding, cutting and
drilling contains chemicals known to cause cancer, birth defects,
infertility or other reproductive harm; or serious and permanent
respiratory or other injury. Some examples of these chemicals are:
lead from lead-based paints, crystalline silica from bricks, concrete
and other masonry products and natural stone, arsenic and chromium
from chemically-treated lumber. Your risk from these exposures varies,
depending on how often you do this type of work. To reduce exposure
to these chemicals, the operator and bystanders should work in a
well-ventilated area, work with approved safety equipment, such as
respiratory protection appropriate for the type of dust generated,
and designed to filter out microscopic particles and direct dust
away from the face and body. Avoid prolonged contact with dust.
Wear protective clothing and wash exposed areas with soap and
water. Allowing dust to get into your mouth, eyes, or to remain on your
skin may promote absorption of harmful chemicals.
5.2.2 Power tool use and care
a) Secure the workpiece. Use clamps or a vice to secure the work-
piece. The workpiece is thus held more securely than by hand and both
hands remain free to operate the power tool.
b) Check that the insert tools used are compatible with the chuck
system and that they are secured in the chuck correctly.
c) Ensure fastener and attachment will withstand the level of torque
generated by the tool. Excessive torque may overstress, strip or
damage the fastener/attachment and possibly lead to personal injury.
5.2.3 Cordless tool use and care
a) Ensure the switch is in the off position before inserting battery pack.
Inserting the battery pack into power tools that have the switch on invites
accidents.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
13
b) Do not expose batteries to high temperatures or fire. This presents
a risk of explosion.
c) Do not disassemble, squash or incinerate batteries and do not sub-
ject them to temperatures over 80°C (176°F). A risk of fire, explosion
or injury through contact with caustic substances may otherwise result.
d) Avoid ingress of dampness.Dampness may cause a short circuit
resulting in a risk of burning injury or fire.
e) Do not use batteries other than those approved for use with the
applicable power tool or appliance. Use of other batteries or use of
the battery for purposes for which it is not intended presents a risk of
fire and explosion.
f) Observe the special instructions applicable to the transport, storage
and use of Li-ion batteries.
g) Remove the battery before storing or transporting the power tool.
h) Avoid short-circuiting the battery. Check that the terminals on the
battery and in the power tool are free from foreign objects before
inserting the battery in the power tool. Short circuiting the battery
terminalspresentsariskoffire, explosion and chemical burns.
i) Do not charge or continue to use damaged batteries (e.g. batteries
with cracks, broken parts, bent or pushed-in and/or pulled-out
contacts).
j) If the battery gets too hot to touch, this may indicate that it is faulty.
Place the tool in a location where it can be kept under observation,
well away from flammable materials, and allow it to cool down.
Contact Hilti Service after the battery has been allowed to cool.
5.2.4 Electrical safety
Before beginning work, check the working area (e.g. using a metal
detector) to ensure that no concealed electric cables or gas and water
pipes are present. External metal parts of the power tool may become live,
for example, when an electric cable is damaged accidentally. This presents
a serious risk of electric shock.
5.2.5 Work area
a) Ensure that the workplace is well lit.
b) Ensure that the workplace is well ventilated. Exposure to dust at a
poorly ventilated workplace may result in damage to the health.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
14
5.2.6 Personal protective equipment
The user and any other persons in the vicinity must wear ANSI Z87.1-
approved eye protection, a hard hat, ear protection, protective gloves
and breathing protection while the machine is in use.
6Beforeuse
6.1 Battery use and care
NOTE
Battery performance drops at low temperatures. Use the tool only after
fully charging the battery. This ensures that maximum battery capacity is
available. Change to a second battery as soon as a drop in performance is
noticed. Recharge the battery immediately so that it is ready for reuse.
Store the battery in a cool, dry place. Never store the battery where it is
exposed to direct sunlight or sources of heat, e.g. on heaters / radiators or
behind a motor vehicle windscreen. Batteries that have reached the end of
their life must be disposed of safely and correctly to avoid environmental
pollution.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02

en
15
6.2 Charging the battery
DANGER
Only used the specified Hilti battery packs and Hilti battery chargers
which are listed under "Accessories".
6.2.1 Charging a new battery for the first time
Charge the battery fully before using it for the first time.
6.2.2 Charging a previously used battery
Ensure that the outer surfaces of the battery are clean and dry before
inserting it in the corresponding charger.
Read the operating instructions for the charger for further information about
the charging procedure.
Lithium-ion battery packs are ready to use at any time, even when only
partially charged. Charging progress is indicated by the LED display (see
charger operating instructions).
6.3 Fitting the battery
CAUTION
Before fitting the battery, check that the power tool is switched off and
that the safety lock is engaged (forward/reverse switch in the middle
position). Use only the Hilti batteries approved for use with this power
tool.
CAUTION
Check that the terminals on the battery and in the power tool are free
from foreign objects before inserting the battery in the power tool.
1. Push the battery into the power tool from the rear as far as it will go and
until it is heard to engage with a double click.
2. CAUTION If it is not fitted securely, the battery could fall out while
you are working with the tool.
CAUTION A falling battery may present a risk of injury to yourself or
others.
Before beginning the work, check that the battery is fitted securely to
the tool.
Printed: 30.09.2013 | Doc-Nr: PUB / 5070695 / 000 / 02
