  9. HIOS BLG-BC2-3010 User manual

HIOS BLG-BC2-3010 User manual

WT-A009-BC2-301X_BLG-BC2-301X 19A 2019.02

BLG-BC2-3010 / BLG-BC2-3012
専用ケーブルを本機に接続すると、PC や PLC などの周辺機器とデータ送受信ができるようになります。
I/O cable helps a driver connect with external devices such as computer and PLC.
 注意 / CAUTION
<カウンター>設定がオフの場合、データは出力されません。外部機器と通信を行うまえに、設定を
確認してください。
<Counter> Data will not be output when counter fuction is set to off. Please check the setting before
connecting with external devices.

◦ ストレートケーブル / Straight Cable
◦ 全長 / Length:3m
◦ D-Sub 9 ピンメス / D-SUB 9P female
◦
フォーンプラグ / Phone Plug:Ø2.5mm

◦ ストレートケーブル / Straight Cable
◦ 全長 / Length:3m
◦ D-Sub 9 ピンメス / D-SUB 9P female
◦ ワンタッチロックプラグ(6P)/
Insert-to-Lock Plug (6P)

    

付属品を確認する / Checking Supplied Accessories
PC 上で BLG-BC2 の設定を管理したり、ネジ締め合
否判定を確認できる、専用アプリケーション
「Counter_BC2」は、ウェブサイトからダウンロード
してお使いください。
https://hios.com/support/download/#software


BLG-BC2-3010 (for 4000BC2/5000BC2 Series) BLG-BC2-3012 (for 4000BC2-LT/7000BC2)
󱳛 󱳝
󱳛
󱳟
󱳝
󱳡
󱳟
󱳣
󱳡
󱽄
󱽄
󱽄
󱽄󱽄
󱽄 󱽄
󱽄 󱽄 󱽄
󱽄
󱳥󱳧󱳩󱳫
BLG-4000BC2 Series/BLG-5000BC2 Series
BLG-7000BC2
BC2
COUNT CONTROL
M
 注意 /CAUTION
ケーブルのループ箇所は、負荷を低減するために結束バンドで緩
く固定しています。完全に固定しないでください。
Loop point is loosely fastened to reduce a load. Please do not
lock it hard.
T-70BL
HIOS
ROTATION POWER
POWER SUPPLY
HIOS Inc. JAPAN
1
2
ON
OFF
I
T-45BL
T-70BL
T-70BL
HIOS
ROTATION POWER
POWER SUPPLY
HIOS Inc. JAPAN
1
2
ON
OFF
I
専用ケーブルを接続する / Connecting the I/O Cable

This manual suits for next models

1
