SY SY-HS12 User manual

SY-HS12 4K HDMI Splitter
SY Electronics Ltd, Unit 7, Worrall Street, Salford, Greater Manchester, M5 4TH, United Kingdom
Tel: [phone] –Fax: [phone] –www.sy.co.uk
Installation Guide
SY-HS12
4K HDMI Splitter 1x2

SY-HS12 4K HDMI Splitter
www.sy.co.uk 2
The SY-HS12 is an HDMI splitter that allows the user to repeat a single HDMI or DVI source to 2
displays simultaneously. It is compliant with HDMI 1.4 & HDCP1.4 and supports all HDMI and
DVI resolutions up to 4K & 1080p 3D. The SY-HS12 will automatically recognize the resolution
and HDCP compliance status of the input signal. The input signal is automatically equalized for
reliable transmission and with proper EDID Management.
The SY-HS12 can be used in a variety of applications, such as monitoring, conference room,
large-screen displaying, digital signage, television, education, command & control centre, smart
home etc.
Features
2 simultaneous HDMI outputs
Hot-plug support
Compliant with HDMI 1.4, capable to transmit 1080p 3D or 4K signals
Transmits 1080p HDMI up to 15m
High bandwidth: 10.2Gbps
HDCP compliant
Auto-identify input resolution
Support EDID management, automatically adopt the resolution of the first detected
display from output port 1 or 2
Intuitive indicators for connection status & input HDCP compliance status
Panel Description
Front Panel
Name
Description
Power
indicator
Illuminates red when powered on
Input HDCP
compliance
Indicator
Indicates the HDCP compliance status of the input signal:
Solid green when the input signal has HDCP
Blinks green when the input signal is not with HDCP
Remains off when there is no input signal
Output signal
Indicators
Illuminates green when there is HDMI output, signal on HDMI OUTPUT 1
and 2 respectively
SERVICE
USB port, used for firmware update.

SY-HS12 4K HDMI Splitter
3 www.sy.co.uk
Rear Panel
Name
Description
IN
HDMI input port (left most) connects with a HDMI or DVI source device
such as DVD / BluRay
OUT
HDMI output ports, connect to HDMI displays
5V
Power socket, plug in the provided 5V DC power adapter
System Connection
System Diagram
The following diagram illustrates the typical input and output connections for the SY-HS12:
Connection Procedures
Connect a HDMI / DVI source device (e.g. BluRay DVD) to the HDMI INPUT socket of SY-HS12
with HDMI cable.
Connect HDMI displays to HDMI OUTPUT sockets of SY-HS12 with HDMI cable.
Plug a DC 5V power adapter to the power port of SY-HS12.
Note:
1. All the ports support hot-plug detection. Be aware that hot plugging a display may
result in a splash screen on the display.
2. Output HDCP compliance status depends on the input signal. When the input signal

SY-HS12 4K HDMI Splitter
www.sy.co.uk 4
contains HDCP, so does the output; when the input does not have HDCP, neither does
the output.
3. A HDMI signal contains both HDMI video signal and embedded audio signal (PCM,
Dolby Digital, DTS, and DTS-HD), while a DVI signal contains only the video signal.
4. Pictures shown in this manual are for reference only, different model and
specifications are subject to the real product.
5. SY-HS12 is capable to switch input signal format according to the displays.
For example, when the input signal is HDMI and the display can only support DVI
signal, SY-HS12 will switch the signal into DVI format.
EDID Management
SY-HS12 comprises 1 HDMI input port & 2 HDMI output ports, EDID management helps in
distributing and routing signals from the source at the resolution of the first detected display
(detecting from output 1~2).
For example: when output 1 connects with a 1080p display, SY-HS12 will select 1080p as output
resolution and distribute 1080p signal to displays connected to output 1~2.
Note: If the display connected to output 2 doesn’t support the 1080p signal, there will be no
output on that display.
Specifications
Video Connectors
Input
1 HDMI –female type A HDMI 1.4
Output
2 HDMI –female type A HDMI 1.4
Video General
Max data rate
10.2Gbit/s
Max Resolution
4Kx2K, 1080P 3D@60Hz
Max Pixel Clock
340MHz
Gain
0dB
HDCP
Compliant with HDCP1.4
EDID
In-built EDID management

SY-HS12 4K HDMI Splitter
5 www.sy.co.uk
General
Temperature
0~ 55°C
Humidity
10% ~ 90%
PSU
5V DC 1A
Power Consumption
2.5 W
Dimension (W*H*D)
100 x 11 x 70 mm
Weight
0.08kg
Supported Input Video Formats
Input Resolution
HDMI
DVI
720 x 480p @ 60Hz
Yes
Yes
720 x 480i @ 30Hz
Yes
Yes
720 x 576p @ 50Hz
Yes
Yes
720 x 576i @ 25Hz
Yes
Yes
1280 x720p @ 50Hz
Yes
Yes
1280 x720p @ 60Hz
Yes
Yes
1920 x 1080p @ 25Hz
Yes
Yes
1920 x 1080p @ 50Hz
Yes
Yes
1920 x 1080p @ 60Hz
Yes
Yes
1920 x 1080i @ 25Hz
Yes
Yes
1920 x 1080i @ 30Hz
Yes
Yes
3840 x 2160i @ 25Hz
Yes
No
3840 x 2160i @ 30Hz
Yes
No
1080p 3D @ 60Hz
Yes
No
Note: SY-HS12 supports 4k & 3D HDMI signals, please use quality HDMI cables that are
compliant with HDMI1.4 for better transmission when connecting 4K or 3D sources.

SY-HS12 4K HDMI Splitter
www.sy.co.uk 6
Safety Instructions
To ensure reliable operation of these product as well as protecting the safety of any person using
or handling these devices while powered, please observe the following instructions.
1. Use the power supplies provided. If an alternate supply is required, check Voltage,
polarity and that it has sufficient power to supply the device it is connected to.
2. Do not operate either of these products outside the specified temperature and humidity
range given in the above specifications.
3. Ensure there is adequate ventilation to allow this product to operate efficiently.
4. Repair of the equipment should only be carried out by qualified professionals as these
products contain sensitive devices that may be damaged by any mistreatment.
5. Only use these products in a dry environment. Do not allow any liquids or harmful
chemicals to come into contact with these products.
6. Due to the weight and physical size of some of these matrix switchers, correct Manual
Handling and Lifting procedures should be observed at all times while handling these
products in order to minimise the risk of injury.
After Sales Service
1. Should you experience any problems while using this product, firstly refer to the
Troubleshooting section in this manual before contacting SY Technical Support.
2. When calling SY Technical Support, the following information should be provided:
Product name and model number
Product serial number
Details of the fault and any conditions under which the fault occurs.
3. This product has a two year standard warranty, beginning from the date of purchase as
stated on the sales invoice. Online registration of this product is required to activate the
full three year extended warranty. For full details please refer to our Terms and
Conditions.
4. SY Product warranty is automatically void under any of the following conditions:
The product is already outside of its warranty period
Damage to the product due to incorrect usage or storage
Damage caused by unauthorised repairs
Damage caused by mistreatment of the product
5. Please direct any questions or problems you may have to your local dealer before
contacting SY Electronics.
