Hisense LEDN55T28GP User manual

LED LCD TV
USER’S MANUAL
Before using the TV, Please read this manual
thoroughly, retain it for future reference.
English
ES-
LEDN55T28GP

1
Important safety precautions
Disposal of Used Electrical & Electronic Equipment
The meaning of the symbol on the product, its accessory or
packaging indicates that this product shall not be treated as
household waste. Please, dispose of this equipment at your
applicable collection point for the recycling of electrical &
electronic equipments waste. In the European Union and Other
European countries which there are separate collection systems
for used electrical and electronic product. By ensuring the
correct disposal of this product, you will help prevent potentially
hazardous to the environment and to human health, which could
otherwise be caused by unsuitable waste handling of this
product. The recycling of materials will help conserve natural
resources. Please do not therefore dispose of your old electrical
and electronic equipment with your household waste. For more
detailed information about recycling of this product, please
contact your local city office, your household waste disposal
service or the shop where you purchased the product.
The flash with the symbol of arrowhead,
inside an equilateral triangle alerts the
user about the presence of a dangerous
tension not isolated inside the product
which can be sufficiently powerful to
constitute a risk of electrocution.
The point of exclamation inside an
equilateral triangle alerts the user about
the presence of important operating
instructions and maintenance in the
document enclosed in the package.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Do not open the back cover.
In no case the user is allowed to operate inside
the TV set.
Only a qualified technician from the
manufacture is entitled to operate.

2
Important safety precautions
Please read the following safeguards for your TV and retain for future reference.
Always follow all warnings and instructions marked on the television.
1. Read, Retain, Follow All Instructions
Read all safeties and operations about the TV. Retain them safely for future reference.
Follow all operations and instructions accordingly.
2. Heed Warnings
Adhere to all warnings on the appliance and in the operating instructions.
3. Cleaning
Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive, or aerosol
cleaners. Cleaners can permanently damage the cabinet and screen. Use a soft
dampened cloth for cleaning.
4. Attachments and Equipment
Never add any attachment and/or equipment without approval of the manufacturer as
such additions may result in the risk of fire, electric shock or other personal injury.
5. Water and Moisture
The apparatus shall not be exposed to dripping of splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
6. Setting
Do not place this TV on an unstable cart, stand or table. Placing the TV on an
unstable base can cause the TV to fall, result in serious personal injuries as well as
damage to the TV. Use only a cart, stand, bracket or table recommended by the
manufacturer or salesperson.
7. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable
operation for the TV and to protect it from overheating. Do not cover the ventilation
openings in the cabinet and never place the set in a confined space such as built-in
cabinet unless proper ventilation is provided. Leave a minimum 10 cm gap all around the
unit.
8. Power Source
This TV should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supplied to your home, consult your
appliance dealer or local power company.

3
Important safety precautions
9
any kinds of
any kinds of
.Grounding or Polarization
This TV is equipped with a polarized alternating current line plug (a plug having one
blade wider than the other). This plug will fit into the power outlet only one way. This is a
safety feature. If you are unable to insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug. A warning that an apparatus
with CLASS construction shall be connected to a MAINS socket outlet with a protective
earthing connection.
10. Lightning
For added protection for this TV during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the antenna
or cable system. This will protect the TV from damage due to lightning and power-line
surge.
11.Power Lines
An outside antenna system should not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it can fall into such power lines or
circuits. Where installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.
12.Overloading
Do not overload wall outlets and extension cords as this can result in a risk of fire or
electric shock.
13.Object and Liquid Entry
Never push object into this TV through openings as they may come up
against dangerous voltage points or short-out parts that could result in fire or electric
shock. Never spill liquid on or into the TV.
14.Outdoor Antenna Grounding
If an outside antenna or cable system is connected with the TV, be sure the antenna or
cable system is grounded so as to provide protection against voltage surges and built-up
static charges. Section 810 of the National Electric Code, ANSI/NFPA No. 70-
1984,provides information with respect to proper grounding of the mast and supporting
structure, grounding of the lead in wire to an antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.

Important safety precautions
15.Servicing
Do not attempt to service this TV yourself as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
16.Damage Requiring Service
Unplug the TV from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
(a) When the power - supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen into the TV.
(c) If the TV has been exposed to rain or water.
(d) If the TV operates abnormally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions as an improper adjustment
of other controls may result in damage and will often require extensive work by a qualified
technician to restore the TV to its normal operation.
(e) If the TV has been dropped or the cabinet has been damaged.
17.Replacement Parts
When replacement parts are required, be sure the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the
original part. Unauthorized substitutions may result in fire, electric shock or other
hazards.
18.Safety Check
Upon completion of any service or repair to the TV, ask the service technician to perform
safety checks to determine that the TV is in safe operating condition.
19.Heat
The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers) that product heat.
4

Table of Contents
5
6
6
7
8
11
11
11
12
13
15
17
18
18
19
20
21
22
22
22
23
23
25
26
27
28
29
30
31
View of the Control Panel
Connections to the Other Devices
Using the Remote Control
View of the Remote Control Panel
Basic Operation
Using the Teletext
Digital Multimedia Function
Base Stand Installation Instruction
Trouble Shooting
Specifications
Front
Back
Installing batteries
Remote control range
Channel Setting
Picture Setting
Sound Setting
Screen Setting
Function Setting
PC Setting
Brief function introduction
Keys on the remote control
Digital multimedia interface
Enjoy video files
Enjoy mp3 audio files
Browse the JPEG pictures
Enjoy music when browsing pictures
Browse the text files of TXT format

NO. Component Component Description
Remote receiver
Power indicator
Main power
Power standby
CH
Receiving signals from the remote emitter. Do not block.
Indicates standby mode. There will be no light when the
power switch is in the off position.
Press to turn the main power ON or OFF.
Press to go to the previous channel.
Press to turn your TV on or off(standby mode).
CH
VOL
VOL
SOURCE button
MENU button
Press to go to the next channel.
Press to decrease the volume.
Press to increase the volume.
Press to select the signal source .
Press to activate the on-screen display (OSD).
1
2
3
4
5
6
7
8
9
10
When adjusting, just press the button slightly instead of pressing it too hard.
The design of this product may be changed without notice,just according the real.
Note:
123
IO/
View of the Control Panel
Front
6

Power Input
ANT 75 Ω
HDMI2 USB2
View of the Control Panel
7
Back
AV1
COAXIAL
SCART

The equipment with Video output
function ( such as VCD, DVD,etc.).
VIDEO
L
R
Warning:
Note:
Before connecting the TV to any other electronic device, unplug the TV and
electronic device AC cords from the AC input.
Not all following terminals are included on your TV. The actual one refer to "Back".
Connections to the Other Devices
Connect to other devices
1. Connect to broadcast antenna or the cable TV
Note:
To have an optimal picture quality, it is strongly recommended to have an
external antenna or a cable TV.
- It is recommended that coaxial cable (75Ω ) be used to eliminate the interference
caused by the mismatched impedance.
- The antenna cable should not be bound together with the power cord.
- When using the cable TV, please insert the plug of the coaxial cable (75 Ω)
directly into the antenna outlet.
ANT 75Ω
2. Connect to AV devices
Note:
- Connect video terminal to an appropriate external terminal on A/V device such as a
VCR, DVD or Camcorder with a video cable.
- Connect “R -AUDIO - L” on your set to the corresponding audio terminal with audio
cables on the A/V device.
The video of VIDEO INPUT 1 shares with the Y terminal of component and they use
the same audio(R/L) terminal. Be sure the “video input” is connected correctly when the
video signal is input.
3. Connecting Component Devices (DVD/PVR)
Note:
- Component video(Y, Pb, Pr)transmits video as separate Y, Pb, Pr signals.
Use this connection for high-definition video signals from a DVD or other equipment.
Connect Component inputs (“PR ”, PB ”, “Y”) and audio(R/L) of your set with
to the corresponding component video and audio
(R/L)out connectors on the PVR or DVD.
The "Y, PB and PR ” connectors on your component devices (PVR or DVD) are
sometimes marked with Y, B-Y and R-Y or Y, CB and CR. (Colors for inputs and cables
must correspond on both devices.)
-
Component video and audio cables
8

VGA AUDIO
The equipment with HDMI output jack
( such as DVD players, etc.).
HDMI
USB
4. Connect to devices with USB interface
This unit has standard USB interface and can be connected to the
standard USB1.1 and USB2.0 disks.
- You can either use the USB connection cord or directly insert the
USB into the USB port at the side of the TV.
Connections to the Other Devices
5. Connect to devices with HDMI interface
HDMI High Definition Multimedia Interface
HDMI transmits an all-digital signal and is the recommended choice for playback
from a digital DVD or DVR. No sound connection is needed for HDMI to HDMI
connection.
- HDMI cable connected to the HDMI connector on the TV.
：
6 Connect to PC.
- Connect the D- Sub cable to “VGA” on the rear of your set and the other end to the
port of your computer.
- Connect “ AUDIO ” on the rear of your set to “Audio Out” on
your computer.
with the audio cable
7.Coaxial audio
Connect the coaxial audio device to this jack.
COAXIAL
9
DVD With Component jacks
Y
PB
PR
L
R

HEADPHONE
8 Connect to headphone.
- Connect the headphone jack of the TV set.
The volume of the headphone is automatically adjusted with the main volume of the
TV set.
Connections to the Other Devices
10
9 Connect to the devices with SCART interface.
- It provides a convenient multi-signal connector between the TV set and video
equipment.
CVBS in/out,RGB in

Using the Remote Control
Installing batteries
Installing the remote control batteries
1. Open the battery cover on the back of the remote control.
2. Install two AAA size(1.5V) batteries. Match the “+” and “-” signs on the
batteries to the signs on the battery compartment.
3. Close the battery cover.
1.Dispose of your batteries in a designated disposal area. Do not throw the
batteries into fire.
2. Do not mix battery types or combine used batteries with new ones.
3. Remove depleted batteries immediately to prevent battery acid from leaking
into the battery compartment.
4. If you do not intend to use the remote control for a long time, remove the
batteries.
5.The effective range of remote control is suggested in the figure below.
1. The remote control distance: 8 meters in front of the TV set.
2. The remote control angle: taking the television infrared light receiver window
as an apex, 6 meters away, its controlled angle (left to right) is within 30
degrees, while the vertical angle (up to down)is within 30 degrees.
Note:
Remote control range
11

Display the present screen
information such as the
current channel and the input
source.
Standby button
Numeric button
Picture mode button
Volume up/down button
Menu button
▲/▼ //◄ ►
up/down/left/right
button
Zoom button
Sleep button
Remote sensor
Remote indicator
TV mode switch button
VGA mode switch button
HDMI mode switch button
Sound model button
Mute button
Channel up down button/
Source selecting button
OK button
Multimedia function button
support DMP only for the TV
refer to the multimedia
instruction for more information
(
)
Special function button
refer to edit program
instruction
(
)
Recall the channel on
time you have set
TeleText function button
Switch between different
audio languages
To freeze a picture
on screen
View of the Remote Control Panel
12
Exit the OSD On Screen
Display menu
Control
(
).
Note: The design of the remote control is subject to change and may be
different from the actual one.

-
-
,VGA
- Press [Source]
-
- previous next
-
- Press [Picture] one or more times to select the picture mode which you want. You can
select Standard, Stadium, Game, Cinema, Concert, Studio and User (a mode that you
defined) mode.
- Press [Zoom] to display the aspect ratio, then press [ to select one mode, press
[►/OK] to confirm.
- You can select Auto, Full screen, Normal, Zoom 1, Zoom 2, Smart Zoom, Dot To Dot
mode.
The option of aspect is vary with different source.
Turning your TV on and off
Notes:
Selecting the video source
Adjusting the volume
Changing channels
Selecting the sound mode
To turn your TV on: Connect the TV to an AC power outlet and turn on the power switch
located below the front right hand side of unit. A few seconds later an image will appear
on the screen.
- Turning off to standby mode: Press [Power Standby] on the front panel or on the remote
control to switch to standby mode. You can activate the unit again by pressing[Power
Standby].
Turn the power switch off when you do not intend to use the TV for long periods,
for example overnight. Remove the connection from the wall power outlet if you do not
intend to use the unit for longer period, for example, if you plan to be away for a few days.
Wait at least 5 seconds after turning off if you want to turn on the TV again.
Select the video source depending on the video device you have connected to the TV
set .TV, AV, Component, HDMI and DMP can be chose as the video source.
to select the video source . When the list of video source appears, press
[ ] to select the source, then press [OK] to enter.
Press [VOL VOLV ] to increase or decrease the volume. Press [Mute] to turn off the
Audio. Press [Mute] again to turn on the Audio.
Press [CH CHV] to go to the or channel. Either, Press the number
buttons to select a channel. For example, to select channel 12, press 1, then 2 within 3
seconds.
Press [Sound] one or more times to select the sound mode which you want. Standard,
Live1, Live2, Theater, Music, Speech, User(a mode that you set) mode can be selected.
/
/]
/
/
Selecting the picture mode
Selecting the aspect ratio
Note:
Basic Operation
13

14
-
-
/
◄/►
►
/ ] buttons ◄/►
The menus in the user’s manual may vary slightly from the actual screen.
Setting the sleep timer
Note:
To use the OSD
You can specify the time you want your TV to wait before it automatically turns off. Press
[Sleep] one or more times until the remaining time which you want appears.
You can select Off, 10 minutes, 20 minutes, 30 minutes, 60 minutes,90 minutes, 120
minutes,180 minutes, 240 minutes.
If there are no input signal, the TV set will turn to standby mode automatically after
about 15minutes.
1 Press the [Menu] button to open the main menu.
2 Press the [ ] buttons to select a menu option , then press the [► OK] buttons to enter
the menu or item.
3 Press the [ / ] buttons to select an item, then press the [ ] buttons to adjust the
value or press the [ OK] buttons to enter a submenu.
4 In the submenu, you can press the [ to select the item and press the [ ]
buttons to adjust the value.
5 Press the [Menu] button to return back the previous menu.
6 Press the Exit button to exit the menu.
/
/
Note:
Basic Operation
Balance 0
AVC On
EQ
Sound
Brightness 50
Contrast 50
Color 50
Sharpness 50
Tint 50
Color Temperature Standard
Enhanced Settings
SCREEN
H Position 0
V Position 0
H Size 0
V Size 0
Phase 0
Clock 0
Auto Adjust
Program No. 1
Color System SECAM
Sound System B/G
Fine Tune 0
Manual Install
Program
Auto Install
Edit
Channel
Option
OSD Language English
Blue Screen On
OSD Time 60S
Transparency Off
Startup Menu Off
DCR
Factory Reset

Channel Setting
Note: The Channel setting is only available in TV signal.
Using the Channel menu
:To set the current channel No..
: To set the color system of current channel. There are four modes to be
chosen in all including SECAM, AUTO, PAL and NTSC .
: To set the sound system of current channel. There are four modes to be
chosen in all including B/G, I, D/K and M.
: Under poor reception conditions, or when receiving analogue signals from
distant TV stations, the picture or sound quality might be improved by using the Fine
Tune option .
Program No.
Color System
Sound System
Note: Wrong sound system selected may result in abnormal sound and image.
Fine Tune
Manual Install :Manual Install is only needed when analogue channels are not found
under an automatic tune.
15
Country
To select the country where you will operate the TV.
Add channel only Yes
To only add channels to the existing the TV.
No
To retune and overwrite the existing channel list.
(It is always recommended to select “No”)
Channel
Display the current channel.
Frequency
Display the frequency of the current channel.
: This is the easiest and most effective way to install all channels available
in your area automatically.
in the Auto Install menu, You can select the following options and adjust the setting, then
select the Auto Select option to start automatic search, and this will memorize all the
available channels.
Auto Install will take a few minutes; please wait until finished.
Auto Install

Channel Setting
a. Delete channels
b. Rename channels
Note: You can rename the channel by no more than 5 characters.
c. Move channels
d. Skip channels
Note:
Press the Red button twice to delete the selected channel.
◄ ►] buttons
Press the [YELLOW] button and press the [ to move the selected channel. Press
the [YELLOW] button to confirm.
Press the [BLUE] button to skip the selected channel. Press the [BLUE] button again to
undo it.
The skipped channel can not be selected by CH /V on the remote control, but
they can be selected by using the channel number.
/]
/
/]
Press the [GREEN] button to rename the selected channel Press the [ buttons
to select the characters to represent the station name. Press the [ to
move to the next character and then press the [GREEN] button again to confirm the new
name.
.
16
: Allows you to edit TV programs in the Channel list. After having
searched for channels, you can enter Program Edit menu to select the program you want
to edit.
Program Edit

Picture Setting
Using the Picture menu
Decrease or
◄►
Decrease or Increase ◄ ►
◄►
◄►
: Adjust the color of the image redder or greener to make the image more natural.
◄►
Standard, Warm,
: Set the advanced function of the TV as follows.
It can optimize the picture signal from time and space; reduce the
outside noise interference and return the pure initial signal. It has four ratings:
Low, Middle, High, and Off.
: It can figure out the faintness of the image edge when the image moves
quickly. You can select among Off, Weak, Normal, Strong.
Brightness
Contrast
Color
Sharpness
Color Temperature
3DNR
: Increase the brightness of the image by pressing the
[ ]. The grade shows the brightness of the current image.
: the contrast of the image by pressing [ ] .
The grade reflects the contrast between the image and the background.
: Adjust the brightness of the color by pressing [ ] .
: Increase the sharpness level for clearer images or decrease the
sharpness level for smoother images by pressing [ ].
: Change the color temperature by pressing [ ].
You can select the color temperature from these options: Warmer,
Cooler and Cool.
:
/
/
/
/
/
Tint
Note: Tint can only be available in NTSC system.
Enhanced Settings
MFC
17
Allows you to set your preferred picture mode.

Sound Setting
Using the Sound menu
◄►
he option keeps the audio in a preset
range to eliminate large in volume.
et the users' mode of sound, press the [◄ ►] buttons to select the sound
component of 120HZ, 500HZ, 1.5KHZ, 5KHZ, and 10KHZ. Press the [ ] buttons to
weaken or enlarge the sound to the proper value .
Balance
AVC
Equalizer
: Adjust the balance between the left and right speakers by pressing the
[ ] buttons.
: On or Off can be selected. If On is selected, t
.
:S
/
/
/
18
Screen Setting
Using the Screen menu
H Position/V
HSize/VSize
Clock
Auto Adjust
: Adjust the horizontal position of the video by pressing
the [ ] buttons.
: Adjust the horizontal / vertical size of the image (not available in VGA).
: Adjust the VGA Clock to match the PC clock. (VGA mode only)
: Auto adjust the image position. (VGA mode only)
Position
Phase
/vertical
◄►
: Adjust the VGA phase to match the PC. (VGA mode only)
/
Allows adjust the computer’s desktop content.
Allows you to select an audio-enhancement technique.

19
Function Setting
Using the Option menu
Allows you to select your desired on screen menu language.
ress the [◄ ►] buttons to select your desired on-screen menu language.
Press the [ ] buttons to select the OSD Time and then press the [◄ ►] buttons to
select the display time: Off/10/.../45/60s.
Allows to select the transparency of the on-screen menu.
Press the [ ] buttons to select Transparency and then press the [◄ ►] buttons to
select the transparency of the on-screen menu: Off/1/2/3/4.
Allows to set the Startup Menu On/Off the next time when you turn on
TV.
Press the [ ] buttons to select Startup Menu and then press the [◄ ►] buttons to
select On/Off.
Allows to adjust the backlight automatically.
Press the [ ] buttons to select DCR and press[► OK] to enter the submenu.
Press the [◄ ►] buttons to select DCR On/Off.
Press the [◄ ►] buttons to increase or decrease the backlight manually when DCR is set
to be Off.
OSD Language
Blue Screen
Note:
OSD Time:
Factory Reset
:
P
: Set the background when there is no signal. The background will show
blue screen when it's on and show noise when off.
This option is only available in TV signal.
Allows to select the display time of the on-screen menu.
: Select “Yes” to resume the parameter setting when the product left the
factory. Your TV restores all settings to factory defaults.
/
//
//
//
//
/
/
Transparency:
Startup Menu:
DCR:
