Hisense RB406N4AD2 Mounting instructions

Contents
2For your safety and correct usagebefore installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to make sure that all people using the appliance are thoroughly familiar with its operation and safety features. Save these instructions and be sure that they remain with the appliance if it is moved or sold, so that anyone using it throughout its life, will be properly informed on its usage and safety notices.For the safety of life and property, keep the precautions of these user's instructions as the manufacturer is not , responsible for damages caused by omission.Hisense RefrigeratorSafety for children and otherswho are vulnerable peopleAccording to EN standardAccording to IEC standardThis appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.



  


  
!" #
   

Keep all packaging away from children as there is risk of suffocation.If you are discarding the appliance, pull the plug out of the socket, cut the connection cable (as close to the appliance as you can) and remove the door to prevent children playing from suffering an electric shock or from closing themselves inside it.If this appliance, featuring a magnetic door seals, is to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make the spring lock unusable before you discard the old appliance. This will prevent it from becoming a death trap for a child.
General safety
WARNING —This appliance is intended to be used in household and similar applications such as-staff kitchen areas in shops, offices and other working environments;-farm houses and by clients in hotels, motels and other residential type environments;-bed and breakfast type environments; -catering and similar non-retail applications.WARNING — Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.WARNING — If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.WARNING — Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.WARNING — Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.WARNING — Do not damage the refrigerant circuit.WARNING — Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.Hisense Refrigerator3

WARNING — The refrigerant and insulation blowing gas are flammable. When disposing of the appliance, do so only at an authorized waste disposal centre. Do not expose to flame.WARNING —When positioning the appliance, ensure the supply cord is not trapped or damaged.WARNING —Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.RefrigerantThe refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance, a natural gas with a high level of environmental compatibility, which is nevertheless flammable. During transportation and installation of the appliance, ensure that none of the components of the refrigerant circuit becomes damaged.The refrigerant (R600a) is flammable.WARNING:risk of fireIf the refrigerant circuit should be damaged:-Avoid opening flames and sources of ignition.-Thoroughly ventilate the room in which the appliance is situated.WARNING — Refrigerators contain refrigerant andgases in the insulation. Refrigerant and gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.Replacing the illuminating lampsWARNING—The illuminating lamps must not be replaced by the user! If the illuminating lamps is damaged, contact the customer helpline for assistance.This warning is only for refrigerators that contain illuminating lamps.Hisense Refrigerator4

Daily useDo not store flammable gass or liquids in the appliance,There is a risk of an explosion.Do not operate any electrical appliances in the appliance(e.g.electric ice cream makers,mixers etc.).When unplugging always pull the plug from the mains socket,do not pull on the cable.Do not place hot items near the plastic components of this appliance.
Electrical safety
1.The power cord must not be lengthened.2. Make sure that the power plug is not crushed or damaged. A crushed or damaged power plug may overheat and cause a fire.3. Make sure that you can access the main plug of the appliance.4. Do not pull the main cable.5. If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock or fire.6.You must not operate the appliance without the interior lighting lamp cover.7.The fridge is only applied with power supply of single phase alternating current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage exceeds the above scope, for safety sake, be sure to apply A.C. Automatic voltage regulator of more than 350W to the fridge. The fridge must employ a special power socket instead of common one with other electric appliances. Its plug must match the socket with ground wire.It is dangerous to alter the specifications or modify this product in any way. Any damage to the cord may cause a shortcircuit, fire, and/or electric shock.Hisense Refrigerator5

Do not place food products directly against the air outlet on the rear wall.Store pre-packed frozen food in accordance with the frozen food manufacture’s instructions.The appliances manufactures storage recommendations should be strictly adhered to.Refer to relrelevant instructions for storage.Do not place carbonated or fizzy drinks in the freeze compartment as it creates pressure on the container,which may cause it to explode,resulting in damage to the appliance.Frozen food can cause frost burns if consumed straight from the freezer compartment.Do not place the appliance in direct sunlight. Keep buring candles,lamps and other items with naked flames away from the appliance so that do not set the appliance on fire. The appliance is intended for keeping food stuff and/or beverages in normal household as explained in this instruction booklet The appliance is heavy.Care should be taken when moving it.Do not remove nor touch items from the freezer compartment if your hands are damp/wet,as this could cause skin abrasions or frost/freezer burns.Never use the base,drawers, doors etc. to stand on or as supports.Frozen food must not be refrozen once it has been thawed out.Do not consume ice popsicles or ice cubes straight from the freezer as this can cause freezer burn to the mouthand lips.To avoid items falling and causing injury or damage to the appliance, do not overload the door racks or put too much food in the crisper drawers.caution!Care and cleaningHisense Refrigerator6

Adequate air circulation should be around the appliance, lacking this leads to overheating. To achieve sufficient ventilation, follow the instructions relevant to installation.Wherever possible the back of the product should not be too close to a wall to avoid touching or catching warm parts (compressor, condenser) to prevent the risk of a fire, follow the instructions relevant to installation.The appliance must not be locate close to radiators or cookers.Make sure that the mains plug is accessible after the installation of the appliance.ServiceAny electrical work required to do the servicing of the appliance should be carried out by qualified electrician or competent person.This product must be serviced by an authorized Service Center, and only genuine spare parts must be used.1)If the appliance is Frost Free.2)If the appliance contains freezer compartment.Installation Important!For electrical connection carefully, follow the instructions given in this manual.Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is damaged. Report possible damages immediately to the place you bought it. In this case retain packing.It is advisable to wait at least four hours before connecting the appliance to allow the oil to flow back in the compressor.Before maintenance, switch off the appliance and disconnect the mains plug from the mains socket.Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic solvents or abrasive cleansers.Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.Hisense Refrigerator7





'((                                 

