Hisense RS741N4WC11 Mounting instructions

RS741N4WC11
RS741N4WB11

Safety and warning info rmation.........2 Using your appliance.......................12
....................15 Helpful hints and tips
Installing your new appliance
............7
.........16 Cleaning and care...............
Description of the appliance..............9
Troubleshooting. .........................17
Display controls........ ........................10
For your safety and correct
usage, before installing and
first using the appliance,
read this user m anual
carefully, including its hints
and warnings.
To avoid unn ecessary
mistakes and accidents, it is
important to make sure that
all people using the appliance
are thoroughly familiar with its
operation and safety features.
Save these instructions and
be sure that they remain
with the appliance if it is
moved or sold, so that
anyone using it throughout
its life will be properly
informed on usage and
safety notices.
For the safety of life and
property, keep the precautions
of these user's instructions as
the manufacturer is not
responsible for damages
caused by omission.
Safety for children and others
who are vulnerable
This appliance can be used
by children aged from 8
years and above, and
pe rs on s with redu ce d
physical, sensory or mental
capabilities or lack of
experience and knowledge if
they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance should not be
carried out by children
without supervision.
Keep all packaging away
from children as there is risk
of suffocation.
Safety and warning informationContents
Disposal of the appliance..............19
Hisense Refrigerator
2
Contents
This appliance is produced in accordance with the following EU
guidelines: 2 014/35/EU, 2 014/30/EU, 2009/125/EC,
EC.643/2009,EU 1060/2010 a nd 2002/96/EC.

3
If you are discarding the
appliance, pull the plug out
of the socket, cut the
connection cable (as close
to the appliance as you can)
and remove the door to
prevent children from
suffering an electric shock
or from closing
themselves inside.
If this appliance, featuring a
magnetic door seals, is to
replace an older appliance
having a spring lock (latch)
on the door or lid, please
make the spring lock
unusable before you
discard the old appliance .
This will reduce the risk of
trapping children or animals
inside.
General safety
WARNING –This
appliance is intended to
be used in household and
similar applications such as
-staff kitchen areas in shops,
offices and other working
environments;
-farm houses and by clients
in hotels, motels and other
residential type
environments;
-bed and breakfast type
environments;
-catering and similar non-ret
WARNING — Do not store
explosive substances such
as aerosol cans with a
flammable propellant in this
appliance.
Hisense Refrigerator
WARNING — If the supply
cord is damaged, it must be
replaced by the
manufacturer , its service
agent or similarly qualified
persons in order to avoid a
hazard.
WARNING — Keep
ventilation openings in the
appliance enclosure or in
any built-in structure
clear
of obstruction.
WARNING — Do not use
mechanical devices or
other means to accelerate
the defrosting process,
other than those
recommended by the
manufacturer.
WARNING — Do not
damage the refrigerant
circuit.
WARNING — Do not use
electrical appliances inside
the food storage
c o m p a r t m e n t s o f t h e
appliance, unless they are
of the type recommended
by the manufacturer.
WARNING — The
refrigerant and insulation
are flammable.
When dis posing of the
appliance, do so only at an
a u t h o r i z e d w a s t e
disposal center. Do not
expose to flame.

4
Refrigerant
The refrigerant isobutene
(R600a) is contained within
the refrigerant circuit of the
appliance. This is a natural
gas with a high level of
environmental compatibility,
wh ich is neverth ele ss
flammable . During
transportation and
installation of the appliance,
ensure that none of the
components of the
refrigerant circuit becomes
damaged.
The refrigerant (R600a) is
flammable.
Caution:risk of fire
If the refrigerant circuit
is damaged:
-Avoid naked flames and
sources of ignition.
-Thoroughly ventilate the
room in which the appliance
is situated.
It is dangerous to alter the
specifications or modify this
product in any way.
Any damage to the cord
may cause a shortcircuit,
fire, and/or electric shock.
Electrical safety
1.The power cord must not
be lengthened.
2.Make sure that the
power plug is not crushed
or damaged. A crushed or
damaged power plug may
overheat and cause a fire.
3.Make sure that you can
access the main plug of the
appliance.
4.Do not pull the main
cable.
5.If the power plug socket
is loose, do not insert the
power plug. There is a risk
of electric shock or fire.
6.You must not operate the
a p pl i a nc e wi th out the
interior lighting lamp cover.
7.The fridge should only be
supplied with single phase
alternating current of 220 ~
240V / 50Hz . If the supply
fluctuates outside this range
an automatic A.C. voltage
regulator
of more than 350W
should be used. The fridge
should be plugged into an
adequately earthed supply
Hisense Refrigerator
Daily use
Do not store flammable
gas
or liquids in the
appliance, there is a risk of
explosion.
Do not operate any
electrical appliances in

5
When unplugging always
pull the plug from the
mains socket. Do not pull
on the cable.
Do not place hot items near
the plastic components of
this appliance.
Do not place food products
directly against the air
outlet on the rear wall.
Store pre-packed frozen
food in accordance with the
frozen food manufacture
instructions.
The manufactures storage
recommendations should be
strictly adhered to. Refer to
relevant instructions for
storage.
Do not place carbonated
or fizzy drinks
in the
freezer compartment as it
creates pressure on the
container, which may
Cause it to explode,
resulting
in damage to the appliance.
Frozen food can cause frost
burns if consumed straight
from the freezer compartment.
Do not place the appliance
in direct sunlight.
Keep burning candles,
lamps and other items
with naked flames away from
the appliance
The appliance is only
intended for keeping food a n
d/or beverages for normal
household consumption a s
explained in this instruction
booklet
The appliance is heavy.
Care should
be taken
when moving it.
Do not remove nor touch
items from the freezer
compartment if your hands
are damp/wet, as this could
cause skin abrasions or
frost/freezer burns.
Never use the base,
drawers,
doors etc. to
stand on or as supports.
Frozen food must not be
refrozen once it has been
thawed out.
Hisense Refrigerator
the appliance (e.g.
electric
ice cream
makers, mixers
etc.).
To avoid items falling and
causing injury or damage
to the appliance, do not
overload the door racks
or put too much food in
the crisper drawers.
Caution!
Care and cleaning
Before p e r fo r m i ng
maintenance, switch off
the appliance and
disconnect the mains plug
from the mains socket.

6
Do not clean the appliance
with metal objects, steam
cleaners, ethereal oils,
organic solvents or abrasive
cleansers.
Do not use sharp objects to
remove frost from the
appliance. Use a plastic
scraper.
Installation Important!
For electrical connection
carefully, follow the
instructions given in this
manual.
Unpack the appliance and
check for damage. Do not
connect the appliance if it
is damaged. Report
possible damage
immediately to your
retailer. In this case,
please retain packing.
It is advisable to wait at
least four
hours before
connecting the appliance to
avoid damaging the
compressor.
Adequate air circulation
should be provided
around the appliance. To
achieve sufficient
ventilation. Please follow
the instructions relevant
to installation.
Wherever possible the back
of the product should not be
too close to flammable
materials as some
components are hot in
normal operation.
The appliance must not be
locate close to radiators or
cookers.
Make sure that the mains
plug is accessible following
installation of the appliance.
Service
This product
must be
serviced by an authorized
Service Center or Service
Agent, and only genuine
spare parts must be used
Hisense Refrigerator

7
your should consider the following
guidance WW1 W2 DD1
908 417.5 277 600 1142.5
It is recommended to leave 75mm of
space from the back of the unit to the
open 130°and the refrigerator door
to open 135.See in follow diagrams. Please refer
to the diagrams below.
135°
Leveling of appliance
For sufficient leveling and air
circulating in the lower rear section of
the appliance, the bottom feet may
need to be adjusted. Please use a
suitable spanner.
To allow the doors to self-close, tilt
back the top backwards at about
15mm or 0.5 by turning the°
adjustable feet.
Whenever you want to move the
appliance, remember to turn the feet
back up, so that the appliance can roll
freely. Reinstall the appliance when
relocating.

8
Before you use the product, please
check the handle of the refrigerator. If
the handle is loose, you should fix it
with the hexangular screwdriver in the
clockwise direction, then it can be
used normally.
Warning!
For proper installation, this refrigerator
must be placed on a level surface of
hard material that is the same height
as the rest of the flooring. This surface
should be strong enough to support a
fully loaded refrigerator.
The rollers, which are not castors,
should be only used for forward or
backward movement. Moving the
refrigerator sideways may damage
your floor and the rollers.
adjusta e bottom f etbl e

Description
of
the appliance
View
of
the appliance
Freezer zone LED light
Fresh zone LED light
Freezer door Rack
two-
star
zone
Wind channel cover in fresh
Note Due to unceasing modification
of
our products your refrigerator may be slightly
dif
ferent from this Instruction Manual but its functions and using methods remain
Wind channel cover in freezer Water tank
Freezer
shelf
Fresh
shelf
Freezer door gasket
Freezer drawer Fresh door gasket
Freezer door Rack
Fresh door Rack
6
ice-maker (optional)
Fruit and vegetables Crisper
10
Adjustable feet
9
the same
Freezer
18.Bottle holder
Bottle Rack
13

10
control guidelines. Your
appliance
showing temperature 5 icons showing
mode and and 4 control buttons
Ab
5
3
3
zer
Fridge
Freezer
Unlock 3s
unlock
fridge
super coolsuper freeze
holiday
And the
control panel will display corresponding mode
according to the following sequence.
appliance
button for 3 seconds to
3
unlock
you can press the
lock all the buttons when you finish
temperature setting.
period.
is on, the
You can switch off super cool function by
pressing "Fridge"or "Freezer" button and
the refrigerator temperature setting will
revert back to it's previous setting.
