Hisense HS2100 User manual

Before using the soundbar, please read this manual thoroughly and retain
it for future reference.
USER MANUAL
2.1CH Soundbar With Wireless Subwoofer
Model: HS2100

2
ENEN
Contents
1. Important Safety Instructions......................................................................................................... 3
1.1 Safety.........................................................................................................................................................................................................3
1.2 Warning....................................................................................................................................................................................................4
2. What’s in the Box .............................................................................................................................. 5
3. Product Diagram .............................................................................................................................. 6
3.1 Main Unit ................................................................................................................................................................................................6
3.2 Wireless Subwoofer..............................................................................................................................................................................6
3.3 Remote Control .....................................................................................................................................................................................7
4. Preparations ..................................................................................................................................... 7
4.1 Prepare the Remote Control.............................................................................................................................................................7
4.2 Replace the Remote Control Battery .............................................................................................................................................7
4.3 Placement and Mounting..................................................................................................................................................................8
4.4 Wall Mounting (if using option-B)...................................................................................................................................................8
5. Connections...................................................................................................................................... 9
5.1 Use the HDMI ARC Socket..................................................................................................................................................................9
5.2 Use the OPTICAL Socket.....................................................................................................................................................................9
5.3 Use the AUX Socket..............................................................................................................................................................................9
5.4 Connect Power ................................................................................................................................................................................... 10
6. Pair up with the Subwoofer........................................................................................................... 10
6.1 Automatic pairing.............................................................................................................................................................................. 10
6.2 Manual pairing.................................................................................................................................................................................... 10
6.3 Use the Hisense EzPlay Function.................................................................................................................................................. 10
7. Basic Operation .............................................................................................................................. 11
7.1 Standby/ON ......................................................................................................................................................................................... 11
7.2 Auto-Standby / Auto-Wake............................................................................................................................................................ 11
7.3 Select Modes ....................................................................................................................................................................................... 11
7.4 Adjust the Volume............................................................................................................................................................................. 11
7.5 Turn the Surround Sound ON/OFF.............................................................................................................................................. 12
7.6 Select Equalizer (EQ) Eect............................................................................................................................................................. 12
7.7 Adjust the Bass/Treble ..................................................................................................................................................................... 12
7.8 Adjust the Brightness....................................................................................................................................................................... 12
7.9 Factory reset ........................................................................................................................................................................................ 12
8. AUX/ OPTICAL/HDMI ARC Operation............................................................................................ 12
9. USB Operation ................................................................................................................................ 13
10. Bluetooth Operation...................................................................................................................... 13
11. Troubleshooting............................................................................................................................. 14
12. Specications.................................................................................................................................. 15

3
ENEN
If the provided plug does not t into your
outlet, consult an electrician for replacement
of the obsolete outlet.
10 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11 Only use attachments/accessories specied
by the manufacturer.
12 Use only with the cart, stand,
tripod, bracket or table specied
by the manufacturer, or sold with
the apparatus. When a cart or rack
is used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
13 Unplug the apparatus during lightning
storms or when unused for long periods of
time.
14 Refer all servicing to qualied personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the unit has been exposed to rain
or moisture, does not operate normally, or
has been dropped.
15 This equipment is a Class II or double
insulated electrical appliance. It has been
designed in such a way that it does not
require a safety connection to electrical
earth.
16 The apparatus shall not be exposed to
dripping or splashing. No objects lled with
liquids, such as vases, shall be placed on the
apparatus.
17 Minimum distance around the apparatus for
sucient ventilation is 5cm.
18 The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers,table-cloths, curtains, etc.
19 No naked ame sources, such as lighted
candles, should be placed on the apparatus.
20 Batteries should be recycled or disposed of
as per state and local guidelines.
21 The use of apparatus in moderate or tropical
climates.
1. Important Safety Instructions
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated“dangerous voltage”within
the product’s enclosure that may be of
sucient magnitude as to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
1.1 Safety
1 Read these instructions – All the safety and
operating instructions should be read before
this product is operated.
2 Keep these instructions – The safety and
operating instructions should be retained for
future reference.
3 Heed all warnings – All warnings on the
appliance and in the operating instructions
should be adhered to.
4 Follow all instructions – All operating and
usage instructions should be followed.
5 Do not use this apparatus near water – The
appliance should not be used near water or
moisture – for example, in a wet basement or
near a swimming pool and the like.
6 Clean only with a dry cloth.
7Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8Do not install near any heat sources such as
radiators, heaters, stoves, or other apparatus
(including ampliers) that produce heat.
9 Do not defeat the safety purpose of the
polarized or grounding plug. A polarized
plug has two blades with one wider than the
other. A grounding plug has two blades and
a third grounding prong. The wide blade or
the third prong is provided for your safety.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC
ÉLECTRIQUE NE PAS OUVRIR

4
ENEN
Caution:
- Use of controls or adjustments or
performance of procedures other than those
described herein, may result in hazardous
radiation exposure or other unsafe operation.
- To reduce the risk of re or electric shock, do not
expose this apparatus to rain or moisture.The
apparatus must not be exposed to dripping or
splashing and objects lled with liquids, such as
vases, must not be placed on apparatus.
- The mains plug/appliance coupler is used as
the disconnect device, the disconnect device
must remain readily operable.
- Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
1.2 Warning
• The battery (batteries or battery pack) shall
not be exposed to excessive heat such as
sunshine, re or the like.
• Before operating this system, check the
voltage of this system to see if it is identical
to the voltage of your local power supply.
• Do not place this unit close to strong
magnetic elds.
• Do not place this unit on the amplier or
receiver.
• If any solid object or liquid falls into the
system, unplug the system and have it
checked by qualied personnel before
operating it any further.
• Do not attempt to clean the unit with
chemical solvents as this may damage the
nish. Use a clean, dry or slightly damp cloth.
• When removing the power plug from the
wall outlet, always pull directly on the plug,
never yank on the cord.
• Changes or modications to this unit not
expressly approved by the party responsible
for compliance will void the user’s authority
to operate the equipment.
• The rating label is pasted on the bottom or
back of the equipment.
Battery usage CAUTION
To prevent battery leakage which may result in
bodily injury, property damage, or damage to the
apparatus:
- Install all batteries correctly, + and - as
marked on the apparatus.
- Do not mix old and new batteries.
- Do not mix alkaline, standard (Carbon-Zinc) or
rechargeable (Ni-Cd, Ni- MH, etc.) batteries.
- Remove batteries when the unit is not used
for a long time.
Correct Disposal of this product. This
marking indicates that this product
should not be disposed with other
household wastes throughout the EU.
To prevent possible harm to the
environment or human health from
uncontrolled waste disposal, recycle it
responsibly to promote the sustainable
reuse of material resources. To return
your used device, please use the return
and collection systems or contact the
retailer where the product was
purchased. They can take this product
for environmental safe recycling.
We hereby declares that this product is
in compliance with the essential
requirements and other relevant
provisions of RED Directive 2014/53/EU
and UK Radio Equipment Regulations
2017.

5
ENEN
2. What’s in the Box
* Power cord quantity and plug type vary by regions.
* AAA Batteries / AUX cable / Optical cable are not available in some locations.
* Images, illustrations and drawings shown on this User Manual are for reference only, actual
product may vary in appearance.
RMain Unit
RWall mount kit
£AUX cable *
（3.5mm-3.5mm audio cable）
£OPTICAL cable *
RHDMI cable RAC Power cord *
RWireless Subwoofer
1 2 3
RRemote Control
£AAA Batteries x 2 *
RUser Manual / Quick Start
Guide/Wall Mount Guide
HDMI

6
ENEN
11
12
3 4 5
681097
3. Product Diagram
3.1 Main Unit
1Remote Control Sensor
Receive signal from the remote control.
2LED Indicators
Lamp Mode
●●Red Standby
●●Green AUX
●●Blue BT (Bluetooth)
●●Orange OPTICAL
●●White HDMI ARC
●●Yellow USB
3(ON/OFF) Button
Switch the soundbar between ON and
Standby mode.
4(SOURCE) Button
Select the play function.
5+/－(Volume) Buttons
Increase/decrease the volume level.
6AC~ Socket
Connect to the power supply.
7AUX Socket
Connect to an external audio device.
8USB Socket
The USB socket is for service only.
9OPTICAL Socket
Connect to an optical audio output on the
TV.
10 HDMI ARC Socket
Connect to a TV via HDMI cable.
11 Wall hanging points
3.2 Wireless Subwoofer
1 2 3
1AC~ Power Cord
Connect to power.
2PAIR button
Press activate the pairing function between
the main unit and the subwoofer.
3PAIR Indicator
Light stops blinking once the Subwoofer is
paired with the Soundbar.

7
ENEN
1
3
7
9
2
4
5
6
8
11
10
12
3.3 Remote Control
1Switch the unit between ON and STANDBY
mode.
2(SOURCE) Select the play function.
3SURR Adjust the surround ON/OFF.
4(BT) Select the Bluetooth mode. Press and hold the
(BT) button to activate the pairing function
in Bluetooth mode or disconnect the existing
paired Bluetooth device.
5EQ Select a preset sound eect.
6/ Skip to previous/next track in BT / USB mode.
7VOL+/VOL-Increase/decrease the volume level.
8Play/pause/resume playback in BT / USB mode.
9BASS +/－Adjust bass level.
10 TREBLE +/－Adjust treble level.
11 DIMMER +/－Adjust LED brightness.
12 (MUTE) Mute or resume the sound.
Precautions Concerning Batteries
• Be sure to insert the batteries with correct
positive“”and negative “”polarities.
• Use batteries of the same type. Never use
dierent types of batteries together.
• Either rechargeable or non-rechargeable
batteries can be used. Refer to the
precautions on their labels.
• Be aware of your ngernails when removing
the battery cover and the battery.
• Do not drop the remote control.
• Do not allow anything to impact the remote
control.
• Do not spill water or any liquid on the remote
control.
• Do not place the remote control on a wet
object.
• Do not place the remote control under direct
sunlight or near sources of excessive heat.
• Remove the battery from the remote control
when not in use for a long period of time, as
corrosion or battery leakage may occur and
result in physical injury, and/or property
damage, and/or re.
• Do not use any batteries other than those
specied.
• Do not mix new batteries with old ones.
• Never recharge a battery unless it is
conrmed to be a rechargeable type.
4. Preparations
4.1 Prepare the Remote Control
The provided Remote Control allows the unit to
be operated from a distance.
• Even if the Remote Control is operated within
the effective range 19.7 feet (6m), remote
control operation may be impossible if there
are any obstacles between the unit and the
remote control.
• If the Remote Control is operated near other
products which generate infrared rays, or if
other remote control devices using infra-red
rays are used near the unit, it may operate
incorrectly. Conversely, the other products
may operate incorrectly.
4.2 Replace the Remote Control Battery
1 Press and slide the back cover to open the
battery compartment of the remote control.
2 Insert two AAA size batteries. Make sure the (+)
and (–) ends of the batteries match the (+) and
(–) ends indicated in the battery compartment.
3 Close the battery compartment cover.

8
ENEN
1
2
3
580 mm / 22.8”
AB
1 2 3
4.3 Placement and Mounting
Placement
A If your TV is placed on a table, you can place
the unit on the table directly in front of the
TV stand, centered with the TV screen.
B If your TV is attached to a wall, you can
mount the unit on the wall directly below the
TV screen.
4.4 Wall Mounting (if using option-B)
Note:
- Installation must be carried out by qualied
personnel only. Incorrect assembly can result in
severe personal injury and property damage (if
you intend to install this product yourself, you
must check for installations such as electrical
wiring and plumbing that may be buried inside
the wall). It is the installer’s responsibility to
verify that the wall will safely support the total
load of the unit and wall brackets.
- Additional tools (not included) are required for
the installation.
- Do not overtighten screws.
- Keep this instruction manual for future reference.
- Use an electronic stud nder to check the wall
type before drilling and mounting.
WARNING
• To prevent injury, this apparatus must be securely
attached to the oor/wall in accordance with the
installation instructions.
• Suggested wall mounting height: ≤ 1.5 meters.
1. Drill 2 parallel holes (Ø 5.5-6 mm each
according to wall type) in the wall. The
distance between the holes should be
580mm.
2. Insert the supplied wall anchors into 2 screw
holes on the wall. Insert the supplied wall
bracket screws through the wall brackets into
the wall anchors. Fix and tighten the screws
on the wall.
3. Hang the unit on the wall mount brackets.
1 2 3

9
ENEN
HDMI ARC
HDMI ARC
OPTICAL
USB
.KGJVNUTK
BA
OPTICAL



Tip: The Soundbar may not be able to decode all
digital audio formats from the input source. In this
case, the Soundbar will mute. This is NOT a defect.
Ensure that the audio setting of the input source
(e.g. TV, game console, DVD player, etc.) is set to
PCM or Dolby Digital (Refer to the user manual
of the input source device for its audio setting
details) with HDMI ARC / OPTICAL input.
5.3 Use the AUX Socket
A. Use a 3.5mm to 3.5mm audio cable to
connect the TV’s or external audio device
headphone socket to the AUX socket on the
unit.
B. Use a RCA to 3.5mm audio cable to connect
the TV’s audio output sockets to the AUX
socket on the unit.
HDMI ARC
HDMI ARC
OPTICAL
USB
.KGJVNUTK
BA
OPTICAL



5. Connections
5.1 Use the HDMI ARC Socket
The ARC (Audio Return Channel) function allows
you to send audio from your ARC- compliant TV to
your soundbar through a single HDMI connection.
To enjoy the ARC function, please ensure your
TV is both HDMI-CEC and ARC compliant and set
up accordingly. When correctly set up, you can
use your TV remote control to adjust the volume
output ( VOL + /–and Mute ) of the soundbar.
- Connect the HDMI cable from unit's HDMI
ARC socket to the HDMI (eARC) socket on
your ARC compliant TV. Then press the
remote control to select HDMI eARC.
HDMI ARC
HDMI ARC
OPTICAL
USB
.KGJVNUTK
BA
OPTICAL



Tips:
• Your TV must support the HDMI-CEC and
ARC function. HDMI-CEC and ARC must be
set to On.
• The setting method of HDMI-CEC and ARC
may differ depending on the TV. For details
about ARC function, please refer to the
owner’s manual.
• Only HDMI 1.4 or higher version cable can
support the ARC function.
5.2 Use the OPTICAL Socket
- Connect an OPTICAL cable to the TV’s
OPTICAL OUT socket and the OPTICAL
socket on the unit.

10
ENEN
5.4 Connect Power
Risk of product damage!
- Ensure that the power supply voltage
corresponds to the voltage printed on the
back or the underside of the unit.
- Before connecting the AC power cord,
ensure you have completed all other
connections.
Soundbar
• Connect the mains cable to the AC~ socket of
the Sound Bar and then into a mains socket.
Subwoofer
• Connect the mains cable to the AC~ socket of
the subwoofer and then into a mains socket.
HDMI ARC
HDMI ARC
OPTICAL
USB
.KGJVNUTK
BA
OPTICAL



* Power cord quantity and plug very by regions.
6. Pair up with the Subwoofer
6.1 Automatic pairing
The subwoofer and soundbar will automatically
pair when both units are plugged into the mains
sockets and turned on. No cable is needed for
connecting the two units.
• Determine the status based on the wireless
Subwoofer indicator.
Lamp Status
Fast blink Subwoofer in pairing mode
Slow blink Connection / Pairing Failed
Constant on Connected / Pairing successful
NOTE:
- Do not press the PAIR button on the rear of
the subwoofer, except for manual pairing.
- If the automatic pairing fails, pair the
subwoofer with the Soundbar manually.
6.2 Manual pairing
1. Ensure that all the cables are well connected
and the Soundbar is in Standby mode.
2. Press and hold the PAIR button on the rear
of the subwoofer for a few seconds. The
subwoofer will enter the pairing mode and
the Pair Indicator will blink quickly.
3. Press
the button on the Soundbar or on the
remote control to switch the Soundbar on.
4. After the wireless connection succeeded, the
Pair Indicator will light up.
5. If the Pair indicator blinks, the wireless
connection has failed. Unplug the cable of
the subwoofer and then reconnect the main
cable after 4 minutes. Repeat step 1 ~ 4.
NOTE:
• If the wireless connection fails again, check
if there is conict or strong interference (for
example, interference from an electronic
device) around your location. Remove these
conicts or strong interferences and repeat
the above procedures.
• The subwoofer should be within 6m (19.7
feet) of the soundbar in an open area.
• If the Soundbar is not connected with the
subwoofer and it is in On mode, the POWER
Indicator will ash. Follow step 1 ~ 4 above
to pair the subwoofer to the Soundbar.
6.3 Use the Hisense EzPlay Function
For Hisense EzPlay, when the Soundbar connects
with a Hisense TV via HDMI ARC, therr will be a
Soundbar Setting menu on the TV, and you can
control this menu via you TV remote to control
most of the Soundbar features.

11
ENEN
TV menu example (different models may have
dierent menus) :
Setting--sound--Soundbar Setting.
Note:
• This function is available only when both
Soundbar and TV support Hisense Ezplay.
• This function requires Soundbar and TV
connected via HDMI ARC, and the CEC of the
TV must be trned ON.
• If everting setting right, for the first time
connect, there would be a tip on the TV
screen to guide you find the Soundbar
setting menu.
7. Basic Operation
7.1 Standby/ON
When you rst connect the main unit to the mains
socket, the main unit will be in Standby mode.
• Press the button on the unit or on the
remote control to switch the unit ON.
• Press the button again to switch the unit
back to STANDBY mode.
• Disconnect the mains plug from the mains
socket if you want to switch the unit OFF
completely.
7.2 Auto-Standby / Auto-Wake
• [Auto-Standby] The soundbar automatically
turns to Standby mode after about 15
minutes if the TV or the external soundbar
is disconnected (or USB, BT function bit
playback pause), or switched o.
• [Auto-Wake] If a TV or an external device
is connected (OPTICAL socket), the unit will
switch on automatically when the TV or the
external device is switched on.
Auto-standby ON/OFF
Turn on the soundbar, press and hold the[ ]
[+] button at the same time on the soundbar to
activate and deactivate the auto-standby:
Lamp Mode
●●●●●●●●
Auto Standby On:
Your Soundbar has been programmed to
enter Standby mode automatically when
no audio is detected for 15 minutes.
●●●●●●
Auto Standby O:
You can turn o the Auto Standby to keep
your Soundbar always working.
Activate and Deactivate the Auto-Wake:
In optical mode, press the VOL+, VOL+, ,
buttons on the remote control to activate and
deactivate the auto-wake:
Lamp Mode
●●●●●●●●
Auto-Wake On
The Soundbar will wake up automatically
when audio input is detected.
●●●●●● Auto-Wake o
The Soundbar does not wake up automatically.
7.3 Select Modes
• Press the (SOURCE) button repeatedly
on the unit or on the remote control to select
the desired mode.
• The indicator light on the front of the main
unit will show which mode is currently in use.
Lamp Mode
●●Red Standby
●●Green AUX
●●Blue BT (Bluetooth)
●●Orange OPTICAL
●●White HDMI ARC
●●Yellow USB
7.4 Adjust the Volume
• Press the VOL+/ VOL- buttons on the unit or
on the remote control to adjust the volume.
• If you wish to turn the sound o, press the
(MUTE) button on the remote control. Press
the (MUTE) button again or press the VOL
+/－buttons to resume normal listening.
FPO

12
ENEN
• When adjusting the volume, the indicator
will increase / decrease the amount of
light. According to the corresponding light
display / blinking (Fig), determine the current
volume level.
min ●●●●●●● －
●●●●●●●
●●●●●●●
●●●●●●●
●●●●●●●
●●●●●● ●
●●●●●●●
max ●●●●●●● +
7.5 Turn the Surround Sound ON/OFF
• Press the SURR button on the remote control
to turn on the surround sound. Press this
button again to turn o the surround sound.
7.6 Select Equalizer (EQ) Eect
• While playing, press the EQ button on the
remote control to select desired preset
equalizers: music, movie, news, game,
sport, night.
• LEDs blink for 3 sec to show current EQ mode
according to the EQ mode denition (Fig).
Music
Movie
News
Game
Sport
Night
●●●●●●●●
●●●●●●●●●
●●●●●●●●●●
●●●●●●●●●●●
●●●●●●●●●●● ●
●●●●●●●●●●●●●
7.7 Adjust the Bass/Treble
• Press the BASS +/－buttons on the remote
control to adjust bass level (bass +5 / bass -5).
• Press the TREBLE +/－buttons on the
remote control to adjust treble level (treble
+5 / treble -5).
min (-5) ●●●●●●● －
BASS
TREBLE
●●●●●●●
●●●●●●●
●●●●●●●
●●●●●●●
●●●●●● ●
●●●●●●●
max (+5) ●●●●●●● +
7.8 Adjust the Brightness
- Press the DIMMER +/－button on the
remote control to select brightness level.
7.9 Factory reset
Reset device to default setting.
• Turn on the soundbar, press and hold the
+and －buttons at the same time on the
soundbar, all LEDs light up for 5 seconds,
standby LED in Red.
MODE DEFAULT
SOURCE OPTICAL
Volume 30
Surround ON
Dimmer MAX
Bass 0
Treble 0
EQ Music
AutoWake OFF
AutoStandby ON
8. AUX/ OPTICAL/HDMI ARC
Operation
1 Ensure that the unit is connected to the TV or
audio device.
2 Press the button repeatedly on the unit
or on the remote control to select AUX,
OPTICAL, HDMI ARC mode.
3 Operate your audio device directly for
playback features.
4 Press the VOL +/－button to adjust the
volume to your desired level.
Tip: The Soundbar may not be able to decode all
digital audio formats from the input source. In this
case, the Soundbar will mute. This is NOT a defect.
Ensure that the audio setting of the input source
(e.g. TV, game console, DVD player, etc.) is set to
PCM or Dolby Digital (Refer to the user manual
of the input source device for its audio setting
details) with HDMI ARC / OPTICAL input.
FPO

13
ENEN
9. USB Operation
1 Insert the USB device.
HDMI ARC
HDMI ARC
OPTICAL
USB
.KGJVNUTK
BA
OPTICAL



2 Press the button repeatedly on the unit
or on the remote control toselect USB mode.
3 During playback:
Start, pause or resume play
, Skip to the previous or next track
Tips:
• The unit can support USB devices with up to
32 GB of memory.
• This unit can play WAV / WMA / MP3 / FLAC.
• This product may not be compatible with
certain types of USB storage devices.
• If you use a USB extension cable, USB hub,
or USB Multifunctional card reader, the USB
storage device may not be recognized.
• Do not remove the USB storage device while
reading les.
10.Bluetooth Operation
Through Bluetooth, connect the Soundbar with
your Bluetooth device (such as an iPad, iPhone,
iPod touch, Android phone, or laptop), and then
you can listen to the audio les stored on the
device through your Soundbar speakers.
First time pairing
1 Press the (SOURCE) button on the unit
or the button on the remote control to
select Bluetooth mode. The Blue indicator
will ash slowly.
2 Activate your Bluetooth device and select
the search mode.
3 Select “Hisense HS2100” in the pairing
list. After audio prompt, the system is
successfully connected and Blue indicator
will light up solidly.
• If you want to connect your soundbar with
another Bluetooth device, press and hold
the / Pair button on the remote control
to disconnect the currently connected
Bluetooth device. Follow step 2-3 to pair
your Bluetooth device.
To disconnect the Bluetooth function,
you can :
- Switch to another function on the unit.
- Disable the function from your Bluetooth
device.
- Press and hold the button, the Bluetooth
device will be disconnected from the
soundbar.
Listen to music from Bluetooth Device
- If the connected Bluetooth device supports
Advanced Audio Distribution Prole (A2DP),
you can listen to the music stored on the
device through the player.
- If the device also supports Audio Video
Remote Control Prole (AVRCP), you can use
the player's remote control to play music
stored on the device.
1. Pair your device with the player.
2. Play music via your device (if it supports A2DP).
3. Use supplied remote control to control play
(if it supports AVRCP).
Start, pause or resume play
, Skip to the previous or next track
Tips:
• The operational range between the Sound
Bar and the device is approximately 8 metres.
• Before connecting a Bluetooth® device to
the Sound Bar, ensure you know the device’s
capabilities.
• Compatibility with all Bluetooth® devices is
not guaranteed.
• Any obstacle between the device and the
Sound Bar can reduce operational range.
• Keep this player away from other electronic
devices that may cause interference.
• The player will also be disconnected when
your device is moved beyond the operational
range.

14
ENEN
11.Troubleshooting
To keep the warranty valid, never try to repair the
system yourself. If you encounter problems when
using this unit, check the following points before
requesting service.
No power
• Ensure that the AC cord of the apparatus is
properly connected .
• Ensure that there is power at the AC outlet.
• Press standby button to turn the unit on.
Remote control does not work
• Before you press any playback control
button, rst select the correct source.
• Reduce the distance between the remote
control and the unit.
• Insert the battery with its polarities (+/-)
aligned as indicated.
• Replace the battery.
• Aim the remote control directly at the sensor
on the front of the unit.
No sound
• Make sure that the unit is not muted. Press
or VOL+/– button to resume normal
listening.
• Press
button on the unit or on the remote
control to switch the soundbar to standby
mode. Then press the button again to
switch the soundbar on.
• Unplug both the soundbar and the
subwoofer from the mains socket, then plug
them again. Switch on the soundbar.
• Ensure the audio setting of the input source
(e.g.TV, game console, DVD player, etc.) is set to
PCM or Dolby Digital mode while using digital
(e.g. HDMI, OPTICAL, COAXIAL) connection.
• The subwoofer is out of range, please move
the subwoofer closer to the soundbar. Make
sure the subwoofer is within 5 m of the
soundbar (the closer the better).
• The soundbar may have lost connection with
the subwoofer. Re-pair the units by following
the steps on the section “Pairing the Wireless
Subwoofer with the Soundbar”.
• The unit may not be able to decode all digital
audio formats from the input source. In this
case, the unit will mute. This is NOT a defect.
device is not muted.
I can’t nd the Bluetooth name of
this unit on my Bluetooth device for
Bluetooth pairing
• Ensure the Bluetooth function is activated on
your Bluetooth device.
• Ensure you have paired the unit with your
Bluetooth device.
The Soundbar turns o
• When the unit's external input signal
level is too low, the unit will be turned off
automatically in 15 minutes. Please increase
the volume level of your external device.
The Subwoofer is idle or the indicator
of Subwoofer do not light up.
• Please unplug power cord from the mains
sockect, and plug it in again after 4 minutes
to reset the subwoofer.

15
ENEN
12.Specications
Brand Hisense
Model HS2100
Soundbar
Power Supply 100-240V~ 50/60Hz
Power Consumption 20 W
< 0.5 W (StandBy)
USB
5V 500mA
Hi-Speed USB (2.0) / FAT32 / FAT16
32G (max) , WAV / WMA / MP3 / FLAC.
Dimension (WxHxD) 800 x 60 x 90 mm / 31.5" x 2.4" x 3.5"
Net weight 2.5 kg
Audio input sensitivity 700mV
Frequency Response 120Hz - 20KHz
Operating Temperature 0°C - 45°C
Wireless Specication
Bluetooth version / proles
Bluetooth frequency range
Bluetooth Max. transmitting power
V 5.3 (A2DP, AVRCP)
2400 MHz ~ 2483.5 MHz
≤ 5 dBm
2.4G Wireless frequency range
2.4G Max. transmitting power
2400 MHz ~ 2483 MHz
≤ 6 dBm
Modulation Type GFSK, π/4 DQPSK
Subwoofer
Power Supply 100-240V~ 50/60Hz
Power Consumption 20 W
< 0.5 W (StandBy)
Dimension (W x H x D) 110 x 300 x 350 mm / 4.3" x 11.8" x 13.8"
Net weight 3.4 kg
Frequency Response 40Hz - 120Hz
Amplier (audio output power)
Total 120 W
Soundbar 30 W x 2
Subwoofer 60 W
Remote Control
Distance/Angle 19.7 feet (6m) / 30°
Battery type AAA (1.5V x 2)
• Design and specications are subject to change without notice.
FPO

Trademarks
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Hisense is under license. Other trademarks and trade names are those of their
.respective owners
The Adopted Trademarks HDMI, HDMI High-Denition Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other
.countries
Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are
.trademarks of Dolby Laboratories
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. (for companies
headquartered in the U.S./Japan/Taiwan) or under license from DTS Licensing Limited (for all other
companies). DTS, Digital Surround, Virtual:X, and the DTS logo are registered trademarks or trademarks of
DTS, Inc. in the United States and other countries. © 2021 DTS, Inc. ALL RIGHTS RESERVED.
Roku, the Roku logo, Roku TV, Roku TV Ready, and the Roku TV Ready logo are trademarks and/or
registered trademarks of Roku, Inc. This product is Roku TV Ready-supported in the United States,
Canada, and Mexico. Countries are subject to change. For the most current list of countries in which this
product is Roku TV Ready-supported, please email r[email protected].
FCC INFORMATION (for US customers)
Warning:
- This equipment should be installed and operated with
minimum distance 20cm between the radiator & your
body.
- Changes or modications to this unit not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.”
NOTE:
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
• However, there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment o and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio / TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
includinginterference that may cause undesired
operation.
• Shielded cables must be used with this unit to ensure
compliance with the Class B FCC limits.
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of
the device.
Réglement de la FCC (pour les clients américains)
Avertissement :
- Pour rester en conformité avec les consignes d’exposition aux
RF, placez le produit à au moins 20 cm des personnes proches.
- Les changements ou modications de cet appareil non
expressément approuvées par la partie responsable de la
conformité pourraient annuler l’autorisation de l’utilisateur à
utiliser l’équipement.
REMARQUE :
• Ce dispositif a été testé et déclaré conforme aux limites
d’un dispositif numérique de classe B, conformément à
la partie 15 des règles de la FCC.
• Cependant, il n’est pas garanti que des interférences
ne se produiront pas dans une installation particulière.
Si cet appareil provoque des interférences nuisibles
à la réception radio ou de télévision, ce qui peut être
déterminé en mettant l’appareil hors tension, l’utilisateur
est encouragé à essayer de corriger l’interférence par
une ou plusieurs des mesures suivantes :
- Réorienter ou déplacer l’antenne de réception.
- Augmenter la distance entre l’appareil et le récepteur.
- Brancher l’appareil à une prise sur un circuit diérent de
celui sur lequel le récepteur est branché.
- Consulter le revendeur ou un technicien radio/TV
expérimenté.
Cet appareil est conforme à la partie 15 des règles de la
FCC. Son fonctionnement est soumis aux deux conditions
suivantes :
(1) ce dispositif ne peut pas causer d’interférences nuisibles et
(2) cet appareil doit accepte r toute inter férence reçue, y
compris les interférences qui peuvent causer un mauvais
fonctionnement.
• Des câbles blindés doivent être utilisés avec cet apparei
l pour assurer la conformité avec les limites de la classe B
de la FCC.fonctionnement de I'appareil.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
EN
FR
Ces limites ont pour but d'assurer une protection
raisonnable contre le brouillage nuisible dans une
installation résidentielle. Cet équipement produit,
utilise et peut émettre de l'énergie en radio fréquence
et, s'il n'est pas installé et utilisé conformément aux
directives, il peut causer un brouillage nuisible dans les
communications radio.
WARNING: This product can expose you
to chemicals including Lead, which is
known to the State of California to cause
cancer. For more information go to:
www.P65Warnings.ca.gov.
IC Notice: CAN ICES-3(B)/NMB-3(B) Avis d’Industrie Canada: CAN ICES-3(B)/NMB-3(B)

FCC INFORMATION (for US customers)
Warning:
- This equipment should be installed and operated with
minimum distance 20cm between the radiator & your
body.
- Changes or modications to this unit not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.”
NOTE:
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
• However, there is no guarantee that interference will not
occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment o and on, the user is encouraged to try
to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio / TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
includinginterference that may cause undesired
operation.
• Shielded cables must be used with this unit to ensure
compliance with the Class B FCC limits.
This device contains licence-exempt transmitter(s)/receiver(s)
that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is
subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including
interference that may cause undesired operation of
the device.
Réglement de la FCC (pour les clients américains)
Avertissement :
- Pour rester en conformité avec les consignes d’exposition aux
RF, placez le produit à au moins 20 cm des personnes proches.
- Les changements ou modications de cet appareil non
expressément approuvées par la partie responsable de la
conformité pourraient annuler l’autorisation de l’utilisateur à
utiliser l’équipement.
REMARQUE :
• Ce dispositif a été testé et déclaré conforme aux limites
d’un dispositif numérique de classe B, conformément à
la partie 15 des règles de la FCC.
• Cependant, il n’est pas garanti que des interférences
ne se produiront pas dans une installation particulière.
Si cet appareil provoque des interférences nuisibles
à la réception radio ou de télévision, ce qui peut être
déterminé en mettant l’appareil hors tension, l’utilisateur
est encouragé à essayer de corriger l’interférence par
une ou plusieurs des mesures suivantes :
- Réorienter ou déplacer l’antenne de réception.
- Augmenter la distance entre l’appareil et le récepteur.
- Brancher l’appareil à une prise sur un circuit diérent de
celui sur lequel le récepteur est branché.
- Consulter le revendeur ou un technicien radio/TV
expérimenté.
Cet appareil est conforme à la partie 15 des règles de la
FCC. Son fonctionnement est soumis aux deux conditions
suivantes :
(1) ce dispositif ne peut pas causer d’interférences nuisibles et
(2) cet appareil doit accepte r toute inter férence reçue, y
compris les interférences qui peuvent causer un mauvais
fonctionnement.
• Des câbles blindés doivent être utilisés avec cet apparei
l pour assurer la conformité avec les limites de la classe B
de la FCC.fonctionnement de I'appareil.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
EN
FR
Ces limites ont pour but d'assurer une protection
raisonnable contre le brouillage nuisible dans une
installation résidentielle. Cet équipement produit,
utilise et peut émettre de l'énergie en radio fréquence
et, s'il n'est pas installé et utilisé conformément aux
directives, il peut causer un brouillage nuisible dans les
communications radio.
WARNING: This product can expose you
to chemicals including Lead, which is
known to the State of California to cause
cancer. For more information go to:
www.P65Warnings.ca.gov.
IC Notice: CAN ICES-3(B)/NMB-3(B) Avis d’Industrie Canada: CAN ICES-3(B)/NMB-3(B)

HS2100
HS2100_IFU-EN_V06_230421
