Hisense WH8014V Mounting instructions

使用说明书
80g胶版纸
X08060477
X08060477
版本号
设计
审 核
工 艺
标准化
更改单编号
会签
会签
批准
图形识别符号
重 量 比 例
第 张 共 张
A
平度8kg自动投放通用
2028570
王爱军 2019.04.10
崔维明 2019.04.10
刘泽旺 2019.04.10
程木聪 2019.04.10 石伟泽 2019.04.10
1. 材料：80g 双胶纸，正反面印刷；
2. 印刷为黑白色单色印刷；
3. 所有印刷内容正确、清晰，不得有漏印、误印，无印刷缺陷；
4. 幅面：（210±3）X（145±3），（单位：mm）；
5.
未注公差按照GB/T 1804-m ；
6.颜色及整体效果必须经过研发部确认后方能生产，产品检验以封样件为准；
7.符合 RoHS现行标准要求和REACH指令;
技术要求
说明书安全警示语部分大写字母高度大于3mm。
8.
英文
朱佳明 2019.04.10

X08060477A

SAFETY INFORMATION

1
The manufacturer reserves the right for any modifications
on the product which might be deemed necessary or
useful without informing about it in this IFU.
Before operating your new washing machine, please read
this instruction carefully, and keep it for future reference. If
you have lost it accidentally, ask customer service for e-
copy or hard copy.
Please make sure the socket is grounded securely, the
water source connection is reliable.
4. This appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
5. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
6. Children should be supervised to ensure that they do not
play with the appliance.
7. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
8. The new hose-sets supplied with the appliance are to be
used and that old hose-sets should not be reused.
SAFETY INFORMATION
1.
2.
3.

ensure
Ensure
Single inlet -
Dual inlet - and cold
only
Ensure that the ventilation openings in the base of the washing machine
(if available on your model) are not obstructed by a carpet or other material.
2 3
9. For appliances with ventilation openings in the base, that a
carpet must not obstruct the openings.
10. Children of less than 3 years should be kept away unless
continuously supervised.
The maximum permissible inlet water pressure, 1 MPa, for
appliances intended to be connected to the water mains.
The minimum permissible inlet water pressure, 0.1 MPa, if
this is necessary for the correct operation of the appliance.
The maximum washing capacity is 8kg.
For private domestic use only.
This appliance is intended to be used in household and
similar applications such as:
− staff kitchen areas in shops, offices and other working
environments;
− farm houses;
− by clients in hotels, motels and other residential type
environments;
− bed and breakfast type environments;
− areas for communal use in blocks of flats or in
launderettes.
11.
12.
13.
14.

45
that
the
ing
en
the
from the mains supply,
,
615 mm
855 mm
the mains.
The symbol on the product, or on the documents accompanying the product,
indicates that this appliance may not be treated as household waste. Instead it
shall be handed over to the applicable collection point for there cyclingof electrical
and electronic equipment. Disposal must be carried out in accordance with local
environmental regulations for waste disposal. For more detailed information about
treatment, recovery and recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased
the product.
that

Control panel layout and appearance will depend on the model.
6 7
Clean the outside of the washing machine with a damp cloth. Do not use abrasive
detergents.
Never open the door forcibly or use it as a step.
1. Sort the laundry according to...
Type of fabric / care label symbol
Cottons, mixed fibres, easy care/synthetics, wool, handwash items.
Colour
Separate coloured and white items. Wash new coloured articles separately.
Loading
Wash items of different sizes in the same load to improve washing efficiency and
distribution in the drum.
Delicates
Wash small items (e.g. nylon stockings, belts etc.) and items with hooks (e.g. bras)
in a cloth bag or pillow case with zip. Always remove curtain rings or wash curtains
with the rings inside a cotton bag.
2. Empty all pockets
Coins, safety pins etc. can damage your laundry as well as the appliance drum and
tub.
3. Fasteners
Close zips and fasten buttons or hooks; loose belts or ribbons should be tied
together.
Stain removal
Blood, milk, eggs etc. are generally removed by the automatic enzyme phase of the
programme.
To remove any residual water used during testing by the manufacturer, we
recommend that you carry out a short wash cycle without laundry.
1 Open the tap.
2 Close the door.
3 Pour a little detergent (about 30 ml) into the middle detergent compartment .
4 Select and start a short programme (see separate quick reference guide).
BEFORE THE FIRST WASH CYCLE
PREPARATION OF THE WASHING
DESCRIPTION OF THE WASHING MACHINE
while the
while the
is
is
can
for
for to be
1
2
4
5
6
3

8 9
U
A
.
Open the door.
Powder detergent compartment（Middle）
When the auto dosing function is cancelled,
please place the detergent into this compartment.
compartment
compartment
compartments
middle compartment
H
M

10 11
unds
Select the “Rinse+Spin” programme,reduce the speed to 1000rpm and strat
2 Insert removal tool like slotted screwdriver into the small opening of bottom
baffle, press the bottom baffle downward with much strength and open it.
1
Before emptying the residual water, switch the appliance off and unplug it
fromthe mains socket. Remove the plinth,place a container beneath it.
DRAINING RESIDUAL WATER (depends on model)
1 Pull out emergency drain pipe of machine.
2 Put end of emergency drain pipe into a container.
3 Rotate emergency drain pipe plug and remove it after it becomes loose.
4 Until water runs off naturally.
5 Reinstall emergency drain pipe plug.
6 Fill detergent box with 1L water to check
emergency drain pipe.Check if there is
any leakage at connection of pipe plug.
7 Put emergency drain pipe back.
if it fails to perform spin cycles.
Ensure that the water has
We recommend that you check and clean the filter regularly, at least two or three
times a year.
1. While holding down the release lever on the inner
of the drawer, slide open the drawer and remove
it from the machine.
2. Open the lids of both compartments, add water
and shake to loosen/remove soap residue.
Repeat until clear.
3. Clean the cap valves of both compartments with a
soft brush.
4. Clean the drawer components under running
water using a soft brush.
5.Clean the drawer recess within the machine using
a soft brush. Make sure to clean the cap valves to
prevent clogging.
6. Once cleaning is complete, slide the drawer back
into position ensuring it moves freely into its fully
retracted position.
Powder detergent compartment（Middle）
Powder detergent compartment（Middle）
Powder detergent compartment（Middle）

12 13
3 Put a flat container under filter door and then drain with emergency drain pipe
(see [draining residual water] for specific operation methods). Then, loosen
filter anticlockwise and completely unscrew and remove the filter.
Check the supply hose regularly for brittleness and cracks and replace it if
necessary using a new hose of the same type(available from After-Sales Service
or specialist dealer).
4
5
6
7

14 15
solv
and the power switched ON
too
remove some
compartment detergent
compartment
Spin

16 17
If you wish to connect hot and cold water supply (Fig.1):
1 Fix the red marked inlet hose to the hot water tap and to the inlet valve with the red
filter on the rear side of machine.
2 Fix the other inlet hose to the cold water tap and to the inlet valve with the blue
filter on the rear side of the machine.
Make sure:
a) The connections are tightly fixed
b) Do not invert their position (for example: cold fill into hot inlet valve and vice versa).
If you wish to connect only the cold fill follow the below instructions (Fig. 2):
1 You will need a Y-piece connector. This can be purchased from local hardware or
plumbing supplier.
2 Fix the Y-piece connector to the cold fill tap.
3 Connect the two inlet valves present on the rear part of the machine to the Y-piece
connector using the hoses provided.
Ensure that:
All connections are tightly fixed.
Do not allow children to operate, crawl on, be near or inside your washer.
Note that during the wash cycles, the surface temperature of the porthole door
may increase.
Close supervision of children is necessary when the appliance is used near
children.
Hot / Cold fill fault - For Models with Dual Inlets
Ensure that
Fault Code List
Displayed on Display Window Fault Description
“F01” Water inflow fault
“F03” Drainage fault
Electronic module fault.
“F13” Door lock fault
“F14” Door unlock fault
“F01” displayed on screen
The machine is not fed with water or insufficient water. Check:
Faucet is fully open and has enough water pressure.
Water inlet pipe is knotted or not.
Filtering net of water inlet pipe is blocked or not (refer to maintenance and
repair).
Water pipe is frozen or not.
Press “Start/Pause” key after fault is removed.
If fault occurs again, please contact with after-sale service (refer to after-sale
service.).
“F03” displayed on screen
The washer is not emptied. The washer stops the program being executed. Shut
down the machine and disconnect power supply. Check:
Drain pipe is knotted or not.
Filter in drain pump is blocked or not (refer to the cleaning of filter in drain pump)
“Unb” Unbalance alarm
Overflow or too much foam.
“F24”
else fault code, “F04-F98”
For Models with Single Inlet
Fix the inlet hose to the cold water tap and to the inlet valve on the rear side of the
machine as (Fig. 3).
Fig.1
Hot fill
Red inlet
valve
Blue inlet
valve
Cold
fill
Red inlet
valve
Blue inlet
valve
Cold
Y-
piece
Fig.2
Inlet valve
Cold fill
Fig.3
fill
Fault code
The washer stops when the program is running. The display window shows
fault code “F01”，“F03”, “F13”，“F14”, “F24”, else fault codes from “F04” to “F98”
or “Unb”.

TRANSPORT/HANDING
18 19
adequate for the machine’s 10 A Current Rating.
The electrical power cable must be replaced exclusively by a licensed electrician.
ELECTRICAL CONNECTION
AFTER-SALES SERVICE
If fault code “F13” is shown
Door lock is abnormal. Start program for 20 sec and unlock the washer door
(PTC) to check whether the door is closed.
Open or close it again.
After fault is removed, press “Start/Pause” key. If fault occurs again, disconnect
power supply and contact with after-sale service.
If fault code “F14” is shown
Door open fault.
Action: Press “Start/Pause” button. The washing machine will try to open the door.
The alarm will not be removed until the door is unlocked. Or, press the “On/Off”
button to restart the washing machine, and the alarm will be removed.
If fault code “F24” is shown
Water level reaches overflow level.
Remove it by pressing “Start/Pause” key and
drain away water.
Select and start required program. If fault occurs again, disconnect power supply
and contact with after-sale service.
If else fault code “F04” to “F98” is shown
Electronic module fails.
Press “Power Supply” key for 3 sec to turn off the machine.
After fault is removed, press “Start/Pause” key. If fault occurs again, disconnect
power supply and contact with after-sale service.
If fault code “Unb” is shown
Unbalance alarm shall be solved by the following methods.
1.Laundry winding.
Turn the knob to “off” for 3 seconds for shutdown, open the door, shake the
clothes and put them back into the washing machine, then select the single
dewatering program to dry again.
2.Too light-weighted laundry.
Turn the knob to “off” for 3 seconds for shutdown, open the door, put in one or
two towels, and then select the single dewatering program to dry again.
Spin Start/Pause
