Hisense WTHX1701T Mounting instructions

Installation and usage of drain pipe
Installation and usage of drain pipe
Put the clip at 2-3cm point of drain pipe(side without hook),then install the drain pipe on the connector at back of washing
machine, fasten with clip and hang on cabinet with hook.
Usage of drain pipe
The drain pipe must drain smoothly
1、The height between drain pipe and ground must be less
than 10cm, or will cause drain not smoothly. If drain too
long time, the machine will stop working.
2、Do not trample or squeeze drain pipe.
3、If user do not need so long drain pipe, can cut in the
middle of pipe. To keep draining smoothly, the front
of drain pipe can be cut slanted.
4、If need extend drain pipe, user should buy
extra pipe which is fit for and the length should
be less than 1.5m.
5、If extended pipe is too long, user can cut in
the middle of pipe.

Connect inlet pipe adaptor with faucet
1、Hold the bottom part of locking lever and press down the slider, detach the adaptor from the water
inlet pipe accessories as picture 1
2、Loosen the four screws of inlet pipe adaptor to put on the faucet as picture 2.(if the mouth of faucet
is too big to put on, loosen screws and take off the ring inside as picture 3. The front of faucet must
be balance to prevent leaking. )
3、Fasten four screws evenly as picture 4.
4、Rotate fastening nut tightly as picture 5.
Ps: before rotate fastening nut, the thread is exposed around 4mm. after rotating, the thread is exposed
around 2mm.
nut
Connect inlet pipe with washing machine
1、Do not take off water-proof circle. Check the water-proof
circle dropped or broken every time before using washing
machine. If yes, please contact us immediately.
2、Put inlet pipe thread on the connector of inlet valve.
3、Fasten inlet pipe thread, shake slightly to check
if fasten well.
Water Valve Ring
Connect inlet pipe adaptor with inlet pipe
1、Press slider, insert inlet pipe into adaptor.
2、Hold the locking lever and press down the slider,
until the sound of “pop”.
Before Rotation,about4mm
Ater Rotation,below2mm
Adaptor
Slider
Locking Lever
Inlet Pipe
Screwdriver
Screw
Ring
Mark Label
Pipe nut
Slider
Locking Lever
Adaptor

Maintance
Appearance maintenance
Wipe the machine with soft and dry cloth after every
wash. Do not use chemicals such as cleaning agents
and volatile agents in case any damage.
After working
The machine will buzzer automatically once
finish working.
Do not open faucet when not work. Take off plug
to prevent leaking of water and electric.
Clean inlet pipe mouth
There may be block at the mouth of inlet pipe after
long-term usage, please clean as below steps:
1、Close the faucet, connect power.
2、Start washing machine for 5s (in order to let the
water inside inlet pipe flow into washing tub),
then turn off.
3、Take off inlet pipe, take out net inside. Clean it
then put on again.
Clean filter
1、Press handle of filter follow the direction as below
picture shows, take off the filter.
2、Open it from back as picture shows, clean inside
dirty stuff.
3、After cleaning, close it and install back.
Good maintenance can make sure good washing performance and extend span life
Before maintenance, must take off plug.
1、After working, close faucet. (if necessary, take off inlet pipe as well.)
2、Do put keep water inside for long term. Drain out once finish working.
3、Hang power cord and drain pipe well.
4、Wipe left water on surface and tub, keep tub open for around one hour before close.
If frozen:
1.I n winter, if left water is frozen, the machine may break down. Please take off inlet pipe and drain left water
completely.
2.I f frozen happen, do not operate directly. Pour hot water around 40 degree until drown pulsator. Wait some
minutes, turn it by hand. The machine can be used if pulsator can move.
