Hitachi Zw140-6 User manual

ENMPTC-NA1-3ZW140-6 • 150-6 • 150PL-6 WHEEL LOADER OPERATOR'S MANUAL

PRINTED IN JAPAN (E) 2022, 09

URL:https://www.hitachicm.com

ENMPTC-NA1-3

PART NO.

Operator's Manual

Serial No. 005201 and up

This book is printed on recycled paper.

140-6

150-6

150PL-6

Wheel Loader

INTRODUCTION

Read this manual carefully to learn how to operate and

service your machine correctly. Failure to do so could

result in personal injury or machine damage.

This standard specification machine can be operated

under the following conditions without being modified.

Atmospheric Temperature: -20 °C to 45 °C (-4 °F to 113 °F)

Altitude: 0 m to 2000 m (0 ft to 6600 ft)

In case the machine is used under conditions other than

described above, consult your authorized dealer.

This manual should be considered a permanent part of

your machine and should remain with the machine when

you sell it.

This machine is of metric design. Measurements in this

manual are metric. Use only metric hardware and tools as

specified.

Right-hand and left-hand sides are determined by

facing in the direction of forward travel.

Write product identification numbers in the Machine

Numbers section. Accurately record all the numbers

to help in tracing the machine should it be stolen.

Your dealer also needs these numbers when you order

parts. If this manual is kept on the machine, also file the

identification numbers in a secure place off the machine.

Use only diesel fuel with quality specified in JIS K-2204,

EN-590 or ASTM D-975 which contents 15 ppm or lower

sulfur.

Also use fuel that complies with solid contamination level

of class 18/16/13 of ISO4406-1999 (solid contamination

includes dust). If the fuel specified above is not used,

exhaust gas that exceeds the regulation values may be

discharged, causing serious problem on the engine.

Consult your authorized dealer.

Warranty is provided as a part of Hitachi’s support

program for customers who operate and maintain their

equipment as described in this manual. The warranty is

explained on the warranty certificate which you should

have received from your dealer.

This warranty provides you with the assurance that

Hitachi will back its products where defects appear within

the warranty period. In some circumstances, Hitachi also

provides field improvements, often without charge to the

customer, even if the product is out of warranty.

Should the equipment be abused, or modified to

change its performance beyond the original factory

specifications, the warranty will become void and field

improvements may be denied.

Setting fuel delivery above specifications or otherwise

overpowering machines will result in such action.

Only qualified, experienced operators officially licensed

(according to local law) should be allowed to operate

the machine. Moreover, only officially licensed personnel

should be allowed to inspect and service the machine.

PRIOR TO OPERATING THIS MACHINE, INCLUDING

COMMUNICATION SYSTEM, IN A COUNTRY OTHER

THAN A COUNTRY OF ITS INTENDED USE, IT MAY

BE NECESSARY TO MAKE MODIFICATIONS TO IT SO

THAT IT COMPLIES WITH THE LOCAL REGULATORY

STANDARDS (INCLUDING SAFETY STANDARDS)

AND LEGAL REQUIREMENTS OF THAT PARTICULAR

COUNTRY. PLEASE DO NOT EXPORT OR OPERATE

THIS MACHINE OUTSIDE OF THE COUNTRY OF ITS

INTENDED USE UNTIL SUCH COMPLIANCE HAS

BEEN CONFIRMED. PLEASE CONTACT HITACHI

CONSTRUCTION MACHINERY CO., LTD. OR ANY OF

OUR AUTHORIZED DISTRIBUTOR OR DEALER IF YOU

HAVE ANY QUESTIONS CONCERNING COMPLIANCE.

In this manual, urea water is indicated as DEF/AdBlue®.

“DEF” stands for the Diesel Exhaust Fluid. AdBlue®

is a registered trademark of the Verband der

Automobilindustrie e.V. (VDA).

All information, illustrations and specifications in this manual are based on the latest product information available at the

time of publication. The right is reserved to make changes at any time without notice.

INDEX

ENMPTC-NA1-3

SAFETY

SAFETY SIGNS

COMPONENTS NAME

GETTING ON/OFF THE MACHINE

OPERATOR’S STATION

BREAK-IN

OPERATING ENGINE

DRIVING MACHINE

OPERATING MACHINE

TRANSPORTING

MAINTENANCE

MAINTENANCE UNDER SPECIAL ENVIRONMENTAL CONDITIONS

STORAGE

TROUBLESHOOTING

SPECIFICATIONSSPECIFICATIONS

OPTIONAL ATTACHMENTS

INDEXINDEX

MACHINE NUMBERS
