Hitachi JOS 1E User manual

Model
JOS 1E
JET OF STEAM DIGITAL IRON
MAX

Know your steam iron
1.
2.
WATER TANK
3.
SPRAY NOZZLE
4.
LID COVER
(WATER TANK)
5.
STEAM BUTTON
6.
SPRAY BUTTON
7.
VARIABLE
STEAM CONTROL
8.
TEMP. CONTROL
BUTTON
Please read these instructions before using your steam iron.
7
4
5
8
9
10
11
3
2
1
Information
CONTROL PANEL
9. INDICATOR LIGHT
10. SELF CLEAN BUTTON
11. SOLEPLATE
MAX
(STANDBY)
6
1

Before use unroll the power cord
completely.
Remove the plug from the socket before
filling your iron with water.
Always switch your iron off when you
have finished.
Do not remove any fixed covers. Never use
this appliance if it is not working properly,
or if it has been dropped or damaged.
Make sure that children cannot touch the
iron when hot or pull the power cord.
Remove any stickers or
protective foil and unroll mains
Information and advice
Safety first!
As irons heat up quicker than they cool down, always start with
articles requiring low heat (such as synthetic fibres or those with a
gloss or wrinkle finish) and leave those requiring higher temperatures
until last.
WARNING: If you are ironing fabric containing a mixture of fibres,
always select the temperature for the fibre requiring the lowest heat.
For example an article consisting of nylon and wool should be ironed
at the temperature indicated for nylon.
Check the ironing
instructions on the label in
your garment.
Sort fabrics according to
ironing temperature.
For example wool, cotton
and linen.
Temperature Control Setting
Nylon,
Acetate Wool, Silk or
Blends Cotton, Linen
or Steam
Information
Do not leave unattended while it is connect
to the supply mains even if its only for a
short while. Remove the plug from the
socket and stand the iron upright.
Never immerse your iron in water.
If you want to wrap the power cord around
the iron for storage, make sure the iron
has cooled down.
If the suppy cord is damaged it must be
replaced by a qualified person.
2

Using your Iron for the first time
Remove any stickers or
protective foil and unroll the
mains lead.
Gently open the lid cover.
Turn the variable steam control
to Fill your iron with water
to below the maximum level.
( 50ml )
'X'.
Close the lid cover.
If the water in your
area is very hard, the
use of distilled or
demineralised water is
recommended to
prevent scale build up.
Please be careful not to
spill any water onto
the appliance.
Wipe any spillages
with a dry cloth.
i
Information
2
3
Remove any residue which may be left on the sole plate during manufacture.
4
1
3

Never pull the cord to
disconnect the plug
from the wall socket.
i
Information
7
Iron an old cloth until no more
steam is produced and the iron
is dry.
Your iron is now ready for use.
8
Plug into a suitable electrical
socket. Switch on at the mains
supply. The standby indicator
will flash.
5
Press the temperature control
button to MAX and wait for the
control panel light to go green.
Turn the variable steam control
to ' 3 '.
TROUBLESHOOTING
If the iron does not operate,
try the following suggestions:
Make sure the temperature
Make sure the plug is connected
and switched on the mains
control button is set to the 1
dot setting or higher..
Try changing the fuse in the
mains plug.
If you still have problems then
return the unit to your nearest
store.
If water leaks from the sole
plate:
Make sure the steam rotary
knob is set to the '0' position
for dry ironing.
Make sure the temperature
control button is set to setting
3 or above for steam.
MAX
6
4

Steam ironing
Do not start steam ironing until the control panel light goes out.
Thick garments such as
jeans require a greater
amount of steam to iron
them than lighter
garments such as shirts
and blouses.
If the sole plate is not
hot enough, water will
be emitted from the
sole plate before
turning to steam. By
carefully following
these instructions this
can be avoided.
i
Information
Remove the plug from the socket.
12
Turn the variable steam control
to
Fill your iron with water to
below the maximum level.
3
Plug into a suitable electrical
socket. Press the temperature
control button to select the desired
temperature and wait for the
control panel light to go green.
4
Turn the variable steam control
to 1-3.
5
Gently open the lid cover. 'X' .
MAX
Shot of steam:
Press the steam button to release
a shot of steam from the sole
plate.
6
5

Dry ironing
1
Turn the variable steam control
to This will stop the steam
function.
'X'.
Spraying
Ensure there is water in the tank
before spraying.
Press the spray button.
1
Spraying may be used on any
setting.
2
It may be necessary to prime the system by
pressing the spray button several times.
i
Information
6

Draining your iron
Always drain your iron immediately after use and never store your
iron with water in its tank.
If the water in your
area is hard, the
regular use of a
suitable descaler is
recommended.
Clean with a dry cloth.
i
Information
Remove the plug from the socket.
1 2
Turn the variable steam control
to 'X'.
Take your iron to a sink and tip
it forwards so that water drains
from the filling mouth. Shake it
gently to remove all the water.
4
Press the spray button to clear
any water left inside the tank.
5
Gently open the lid cover.
3
7

Self clean (auto clean system)
Self clean should be carried out regularly to prolong the life of your
iron.
When cleaning your
iron's sole plate, never
use scouring pads,
abrasives or harsh
cleaners as this may
scratch the surface.
Always allow your iron
to cool down
completely before
storing.
i
Information
4
Stand your iron upright. Plug
into a suitable electrical socket.
2
Plug back into a suitable electrical
socket. Wait for your iron to
heat up and iron an old cloth to
clean the sole plate.
Remove the plug from the socket
and hold your iron horizontally
over a sink.
3
Turn the temperature control dial
to MAX.Wait for the control
panel light to go green.
Remove the plug from the socket.
Turn the variable
steam control
to 'X' .
Fill your iron with water to the
MAX level.
1
5
MAX
6
Press the self clean button. Keep the
self clean button pressed until the
steam stops. Release the button and
gently shake the unit to disperse
any trapped waker. Dirt is washed
away through the soleplate.
8

Auto off system
When cleaning your
iron's sole plate, never
use scouring pads,
abrasives or harsh
cleaners as this may
scratch the surface.
Always allow your iron
to cool down
completely before
storing.
i
Information
2
3
1
When the iron is returned to
ironing position, the previous
temperature setup is resumed.
4
When the iron is plugged into the
mains supply the unit will “beep”
and the standby indicator will flash.
This will automatically go off when
the temperature control button
is pressed.
If the iron is placed in a horizontal
position and is stationary
(for 30sec) the unit will
automatically go into standby.
The indicator light will flash.
If the unit is left in the verticle
position and is stationary. it will
switch into standby mode after
8 minutes.
9

Control Panel - LED.
LED. IRONING TEMP.
UP
TEMP.
DOWN
GREEN OK OK OK
RED
AMBER Heating Cooling
Heating
up
Selected
temp.
Selected
temp.
When you have chosen your selected temperature the indicator will
glow red. Once the lron has reached the desired temperature the
light will glow green.
The amber LED indicates the transition of temperature
( up or down ) until your selected setting has been reached.
10

Specifications
We continually strive to improve our products, specifications may change without notice.
No part of this publication may be produced, stored in a retrieval system or transmitted in any form or by any means, without the prior permission
in writing of Dixons Stores Group, nor be otherwise circulated in any form or binding or cover other than that in which is published and without a
similar condition including this condition being imposed on the subsequent purchaser.
230V ~ 50Hz 2200W
WARNING. A mains plug severed from the mains lead of this
appliance must be destroyed. A mains plug with bared wires is
hazardous if engaged in a mains output line socket.
Direct
Partmaster Direct can provide accessories, spares, batteries and
replacement parts with Next Day Delivery available upon request.
Please call:
0870 600 1338
(UK customers only)
Calls charged at National Rate
…or visit our website at www.partmaster.co.uk
