Hitachi L32A01 B User manual

L32A01 A
GB
F
D
I
Instructions for use
Notice d'utilisation
Bedienungsanleitung
Istruzioni per l'uso
LCD olo r TelevisionCu
Télévision Couleur LCD
LCD-Farb-TV-Gerät
Televisione a Colori LCD

GB - 1 -
Contents
3DS ............................................................ 15
Feature Menu............................................. 15
PIP .............................................................. 15
PIP ON-OFF ............................................................ 15
PIP Picture ............................................................. 15
PIP Position ............................................................ 15
PIP Source ............................................................. 15
PIP SWAP .............................................................. 15
PAP ............................................................ 15
PAP ON-OFF ........................................................... 15
PAP Picture ............................................................. 15
PAP Source ............................................................. 16
PAP SWAP .............................................................. 16
SleepTimer ................................................ 16
Child Lock .................................................. 16
Language ...................................................16
AV-2 Out .................................................... 16
PCAudioIn................................................. 16
Blue Background ....................................... 16
Menu Background ...................................... 16
MenuTimeout............................................. 16
Teletext Language .....................................16
Default Zoom ............................................. 16
InstallMenu ................................................ 16
Program Table ............................................ 17
Name ....................................................................... 17
Insert ...................................................................... 17
Delete ..................................................................... 17
APS (Auto Programming System) ............................ 17
A.P.S. (Auto Programming System)
Country ...................................................... 17
Program ..................................................... 17
Band .......................................................... 18
Channel ...................................................... 18
Colour System ........................................... 18
Sound System ........................................... 18
FineTune ................................................... 18
Search ....................................................... 18
Store .......................................................... 18
Install menu inAV modes ........................... 18
Colour System ......................................................... 18
VCR ......................................................................... 18
Store .......................................................... 18
Source menu ............................................. 18
PC Mode ........................................................... 19
Installation .................................................. 19
MenuSystem inPC mode........................... 19
Sound Menu/Feature Menu ........................ 19
PCPicture Menu......................................... 19
PCPOSITIONMenu .................................... 19
Autoposition ............................................... 19
H (Horizontal) Position ............................... 19
V (Vertical) Position ................................... 19
Phase ........................................................ 19
Safety Precautions ........................................... 3
Features ............................................................. 6
Accessories ...................................................... 6
LCD TV Front View ........................................... 7
Rear View and Peripheral Connections ....... 7
Remote Control Buttons ................................. 8
Installation Of The TFT TV To The Wall .......... 9
Preparation ...................................................... 11
Before Switching On Your TV ....................... 11
Power Connection ..................................... 11
Connections To The Aerial Input Socket ..... 11
Inserting Batteries In The Remote Control
Handset ..................................................... 11
Handlingthe Remote Control ...................... 11
Operating Range for the Remote Control ... 11
Switching The TV ON/OFF .............................. 12
Navigating the Menu System ........................ 12
Initial Settings ................................................. 12
Basic Operations ............................................ 12
Operation with the buttons on the TV........ 12
VolumeSetting ........................................... 12
ProgrammeSelection ................................. 12
EnteringMainMenu.................................... 12
AV Mode ....................................................13
Operation with Remote Control .................. 13
VolumeSetting ........................................... 13
Programme Selection (Previous or next
programme) ............................................... 13
Programme Selection (direct access):....... 13
Menu System .................................................. 13
Picture Menu.............................................. 13
Mode.......................................................... 13
Contrast/Brightness/Sharpness/Colour/
Hue ............................................................13
ColourTemp ............................................... 13
Noise Reduction......................................... 13
FilmMode ................................................... 13
3DComb ....................................................14
Picture Zoom.............................................. 14
Reset ......................................................... 14
Sound Menu............................................... 14
Volume.......................................................14
Equalizer ....................................................14
Balance...................................................... 14
Headphone ................................................14
volume ..................................................................... 14
sound mode ............................................................. 14
balance ................................................................... 14
Sound Mode............................................... 14
AVL ...........................................................14
Effect......................................................... 14
Dynamic Bass............................................ 14
Subwoofer ................................................14
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:171

GB - 2 -
DotClock....................................................19
SoundinPCmode ......................................19
Other Features ................................................ 20
TV Status ...................................................20
MuteIndicator ............................................20
PIPandPAPModes .................................... 20
AV Modes.................................................. 20
Zoom Modes ..............................................20
Auto ...........................................................20
Zoom ......................................................... 20
Cinema.......................................................20
16:9 Zoom.................................................. 20
Subtitle.......................................................20
4:3 ............................................................. 21
14:9 Zoom.................................................. 21
Panoramic.................................................. 21
Freeze Picture ........................................... 21
Teletext ............................................................. 21
Connect Peripheral Equipment .................... 22
HighDefinition ............................................22
Via The Scart.............................................22
Via Aerial Input........................................... 22
Decoder .....................................................22
Connect a decoder with an aerial socket to
the TV ........................................................22
Connect a decoder without an aerial socket
to the TV ....................................................22
TV And Video Recorder............................. 22
PlaybackNTSC ..........................................22
CameraAnd Camcorder............................. 22
To Connect To AV Input ..............................22
To Connect To S-VHS Input........................22
Connect The Decoder To The Video
Recorder....................................................22
Connecting Headphones (optional)............ 22
Audio Lineout.............................................22
Connecting Subwoofer.............................. 22
Tips ................................................................... 23
Care Of The Screen ..................................23
PoorPicture ............................................... 23
NoPicture .................................................. 23
Sound ........................................................23
RemoteControl ..........................................23
Peripheral Equipment Connections ............ 24
Aerial Connection ........................................... 24
Specifications .................................................. 25
SignalInput ................................................27
Appendix A: PC Input Typical Display
Mod es ............................................................... 28
Appendix B: AV and HDMI Signal
Compatibility ................................................... 29
Appendix C: Main and PIP-PAP Picture
Combinations .................................................. 30
Addendum to the instruction book. ............ 30
UK Guarantee ................................................... 31
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:172

GB - 3 -
Safety Precautions
Please read the following recommended safety pre-
cautions carefully for your safety.
IMPORTANT SAFETY
INFORMATION ON OPERATING
YOUR TV
Do’s and Don’ts
DO’s
This Television has been designed and manu-
factured to meet international safety standards,
but like any electrical equipment, care must be
taken if you are to obtain the best results and
safety is to be assured.
DO read the operating instructions before you
attempt to use the equipment.
DO consult your dealer if you are in any doubt
about installation, operation or safety of your
equipment.
DO be careful with glass panels or doors on
equipment.
ThisTVissuppliedwitha fittedmainsplug. This
plug must not be cut off as it maycontain a spe-
cialradiointerferencefilter,theremovalofwhich
could lead to impaired performance. If you wish
to extend the lead, obtain an appropriate safety
approved extension lead or consult your dealer.
Observe the manufacturers instructions when
connectingextensionleadstotheTV. Checkthe
fuse rating on the new plug, this should be fitted
witha5AmpfusewhichconformstoeitherASTA
or BSI (BS1 362) approvals, these are easily
identifiable byeither the or symbols. If
you are in any doubt about the installation of an
extension lead, please consult a competent
electrician.
DON’Ts
DON’T continue tooperate the equipmentif you
are in anydoubt about it working normally, or if it
is damaged in any way switch off, withdraw the
mains plug and consult your dealer.
DON’T place water filled vessels on top of T.V.
cabinets.
DON’T remove any fixed cover as this may ex-
pose dangerous voltages.
DON’T leave equipment switched on when it is
unattended unless it is specifically stated that it
is designed for unattended operation or has a
stand-by mode. Switch off using the switch on
the equipment and make sure your family know
howtodothis. Specialarrangementsmayneed
to be made for infirm or handicapped people.
DON’T useequipmentsuchaspersonalstereos
or radios so that you are distracted from the re-
quirements of traffic safety. It is illegal to watch
television whilst driving.
DON’T obstructtheventilationoftheequipment,
for example with curtains or soft furnishings.
Overheating will cause damage and shorten the
life of the equipment.
DON’TusemakeshiftstandsandNEVERfixlegs
or stands to the TV with any screws other than
those provided - to ensure complete safety al-
ways use the manufacturers approved stand
with the fixings provided.
DON’T allowelectricalequipmenttobeexposed
to rain or moisture.
ABOVE ALL
• NEVER let anyone, especially children push
anything into holes, slots or any other open-
ing in the case - this could result in a fatal
electric shock.
•NEVER guess or take chances with electrical
equipment of any kind - it is better to be safe
than sorry!
Surely connect
the ground wire.
Be sure to ground the connection properly.
Connect the ground terminal of TV with the ground terminal provided at
the power outlet using the enclosed power cord. If the provided plug
does not fit your outlet, consult an electrician for replacement of the
obsolete outlet.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:173

GB - 4 -
1.Power Source
TheTV set should be operated onlyfrom a220-240 V
AC, 50 Hz outlet. Ensure that you select the correct
voltage setting for your convenience.
2.Power Cord
Do not place the set, a piece of furniture, etc. on the
power cord (mains lead) or pinch the cord. Handle
thepower cord by the plug. Donot pull out the plug by
tugging the cord and never touch the power cord
when your hands are wet as this could cause a short
circuit or electric shock. Nevermakea knot in the cord
or tie it with other cords. The power cords should be
placed in such a way that they are not likely to be
stepped on. A damaged power cord can cause fire or
give you an electric shock. When it is damaged and
needs to be changed, it should be done by qualified
personnel.
3. Moisture and Water
Donotusethisequipmentinahumidanddampplace
(avoid the bathroom, the sink in the kitchen, and near
the washing machine). Do not expose this equipment
to rain or water, as this may be dangerous and do not
place objects filled with liquids, such as flower vases,
on top. Avoid from dripping or splashing.
Ifanysolidobjectorliquidfallsintothecabinet,unplug
the TV and have it checked by qualified personnel
before operating it any further.
4.Cleaning
Before cleaning, unplug the TV set from the wall out-
let. Donot useliquidor aerosol cleaners. Use soft and
dry cloth.
5. Ventilation
Theslots and openings onthe TV set areintended for
ventilation and to ensure reliable operation. To pre-
ventoverheating, theseopeningsmust not beblocked
or covered in anyway.
6. Heat and Flames
The set should not be placed near to naked flames
and sources of intense heat, such as an electric
heater. Ensure that no naked flame sources, such as
lighted candles, are placedontop of the TV. Batteries
shall not be exposed to excessive heat such as sun-
shine, fire or the like.
7. Lightning
In case of storm and lightning or when going on holi-
day, disconnect the power cord from the wall outlet.
8. Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts which
are specified by the manufacturer or have the same
specifications as the original one. Unauthorized sub-
stitutions may result in fire, electrical shock, or other
hazards.
9. Servicing
Please refer all servicing to qualified personnel. Do
notremove the cover yourself as this may result in an
electric shock.
10. Waste Disposal
Instructions for waste disposal:
• Packaging and packaging aids are recyclable and
shouldprincipally be recycled. Packaging materials,
such as foil bag, must be kept away from children.
• Battery, including those which are heavy metal-free,
should not be disposed of with household waste.
Please dispose of used battery in an environmen-
tally sound manner. Find out about the legal regula-
tions which apply in your area.
• Cold cathode fluoresant lamp in LCD PANEL con-
tains a small amount of mercury; please followlocal
ordinates or regulations for disposal.
Information for users applicable
in European Union countries
This symbolontheproduct oron itspackagingmeans
that your electrical and electronic equipment should
be disposed at the end of life separately from your
household wastes. There are separate collection
systems for recycling in EU.
Formore information, pleasecontact thelocal author-
ity or the dealer where you purchased the product.
11. Disconnect Device
Themains plug is used to disconnect TV set from the
mains and therefore it shall remain readily operable.
12. Excessive sound pressure from earphones and
headphones can cause hearing loss.
13. To prevent injury, this device must be securely
attached to the wall in accordance with the in-
stallation instructions when mounted to the wall
(if the option is available).
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:174

GB - 5 -
14. Connection to a television
distribution system (Cable TV etc.)
from tuner:
Apparatus connected to the protective earthing of
the building installation through the mains connection
or through other apparatus with a connection to pro-
tective earthing - and to a television distribution sys-
tem using coaxial cable, may in some circumstances
create a fire hazard.
To ground the antenna system properly, be sure that
the cable grounding is connected with the building's
grounding system. Note that the connection should
follow IEC 60364-7-707 and IEC 603646-5-548 stan-
dards which require that the grounding should be as
close as possible to the cable connection.
VHF/UHF
75
REAR OF THE TV
CABLE TV
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:175

GB - 6 -
Features
• Remote controlled 32” colour LCD TV.
• 100 programmes from VHF, UHF bands or cable
channels can be preset.
• It can tune cable channels.
• Controlling the TV is very easy by its menu driven
system.
• It has 3 Scart sockets for external devices (such as
video, video games, audio set, etc.)
• Stereo sound system (German+Nicam).
• Full function Teletext (1000 pages).
• Fastext, TOP text.
• Headphone connection.
•A.P.S. (Automatic Programming System).
•All programmes can be named.
• Forward or backward automatic tuning.
•Sleeptimer.
• Child Lock.
• Automatic sound mute when no transmission.
•NTSCPlayback.
•AV in and S-VIDEO in are available.
• It has two HDMI connectors for Digital Video and
Audio. This connection is also designed to accept
HighDefinitionsignals.
•AVL (Automatic Volume Limiting)
• When novalid signal is detected, after 5 minutes the
TV switches itself automatically to stand-by mode.
• PLL (Frequency Search)
•PCInput
• Plug&Play for Windows 9X, ME, Vista, 2000, XP.
•Audio Line Out
Accessories
UKPlug
EUPlug
15PinD-SUB VGACable.
PhonoL+Rto3.5mmJackAudioCable.
RGB2
TV/DTT
I/II
MENU GUIDE
DVD SAT
INPUT
RETURN
OK
P
1
2
3
4
5
6
7
8
9
0
AV1
AV2
AV3AV3
AV4
AV5
HDMI1
HDMI2
....
+
RemoteController
CLE-984
Batteries
2 X AA
Instruction Book
Quick Guide
WallMountKit
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:176

GB - 7 -
LCD TV Front View
FRONTVIEW
Rear View and Peripheral Connections
S-VIDEOInput
Video Input
Audio Inputss
Headphone
Audio Line Outss
Subwoofer Output
Power Cord Input
Power On/Off Switch
HDMIInput2
HDMIInput1
PCVGAInput
PCAudioInput
RF
Component VideoInputs (YPBPR)
ComponentAudioInputss
SCART1
SCART 2
SCART3
For Service Use Only
Note: Because FAV CVBS and SVHS Y are connected parallelly, the picture may blend if the two peripherals are used at the same
time. Likewise, because SVHS C and SCART II R are connected parallelly, the picture may blend if the two peripherals are used
at the same time. Thus these two are not to be used at the same time.
SOURCE SELECT
MENU BUTTON
PROGRAMME UP/DOWN
VOLUME UP/DOWN
STANDBY BUTTON
Standby LED
IR Receiver
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:177

GB - 8 -
Remote Control Buttons
** These buttons can control most Hitachi DVD Players and Recorders.
RGB2
TV/DTT
I/II
MENU GUIDE
DVD SAT
INPUT
RETURN
FUNCTION
OK
P
1 2
3
4 5
6
78
9
0
AV1
AV2
AV3
AV4
AV5
HDMI1
HDMI2
....
+
= Stand by On/Offf
= Info
DVD = Select DVD
TV/DTT = TV / Quit Menu
= Hold in teletext mode, Freeze picture
/ = Volume Up/ Down
= Mute On/Off
RED (Only use in Teletext mode)
GREEN(Only use in Teletext mode)
= Teletext On-Offf
= Time / Teletext & TVTV
= Menu On/Off

/

/

/

= Cursor buttons
+
FUNCTION = No function
= Equalizer Sound Mode
= Aspect ratio
= No Function
Control buttons for DVD players/recorders (**)
= Go back to previous menu
OK = Enter
/ / GUIDE =IndexPage
....
= TXT Subtitlein TV mode; Subpage in teletext mode.
= Reveal
BLUE (Only use in Teletext mode)
YELLOW (Only use in Teletext mode)
P+/ - = Programme Up/ Down
= Mono/Stereo - DualA-B
= PIP, PAP On-Off / PATAT
0 - 9 = Digit buttons
/INPUT =INPUT
31
SATT = Select SAT
32
= No function
33
= Picture mode
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:178

GB - 9 -
Installation Of The TFT TV To The Wall
1- To install the TFT TV on the wall, first of all, foot assembly should be removed. (Figure 1). Unscrew the 6
screws (M4 x 12) that attach the foot assembly to the TFT panel and remove the foot assembly from the
TFTpanel.
2- Decide the place on the wall where the TFT panel would be placed. Fix the wall mounting stencil on the
wall.
The stencil is used for placing the wall hangers on the wall, properly.
3- Level and mark with a pencil the 4 mounting points on each wall hanger.
Drill pilot holes for the plastic anchors (7x30) and then fix the wall hangers with 8 screws
(4 x 30).
4- Raise the TFT panel and hang it to the holes on the wall hanger from the 4 hanging screws at the rear of the
TFTpanel.
Figure 1
TFT PANEL
6 SCREWS
(M4 x 12)
FOOTASSEMBLY
IMPORTANT
1. Please follow the installation instructions carefully as failure to do so may result in injury or damage to the
set.
2. If you do not feel confident in carrying out the installation yourself, please ask a specialist installer to carry
out the installation for you.
3. The wall anchors provided are for solid (brick, concrete etc) walls only. For all other wall types please obtain
the correct fixings for the wall type from your hardware retailer. If you are unsure which anchors to use,
please seek professional advice.
4. To avoid potential injury it is advisable to have assistance from another person to carry out this installation.
5. Hitachi assumes absolutely no responsibility for injuries or damages that may occur due to improper
installationandhandling.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:179

GB - 10 -
“Attention: Only the original wall bracket should be used with this product”
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1710

GB - 11 -
Preparation
Forventilation,leave a space of at least 10 cm freeall
around the set. To prevent any fault and unsafe situ-
ations, please do not place any objects on top of the
set.
Use this apparatus in moderate climates.
Before Switching On Your TV
Power Connection
IMPORTANT: The TV set is designed to operate on
220-240V AC, 50 Hz.
•After unpacking, allow the TV set to reach the ambi-
ent room temperature before you connect the set to
themains.
Connections To The Aerial Input Socket
•Connect theaerial or cableTVplugto theAerialinput
socket located at the rear of the TV and connect the
cable plug coming out from the TV out socket lo-
cated on the devices (VCR, DVB etc.) to this socket
as well.
Inserting Batteries In The Remote
Control Handset
WARNING : Remotecontrolis batteryincluded.Aplas-
tic protector is used to disconnect the batteries in
order to prevent the battery life from reducing. Please
remove the plastic protector before the first use.
• Remove the battery cover located on the back of the
handset by gently pulling backwards from the indi-
cated part.
• Insert two AA/R6 or equivalent type batteries inside.
Placethebatteries intherightdirections andreplace
the battery cover.
Note: Remove the battery from remote control hand-
set when it is not to be used for a long period. Other-
wise it can be damaged due to any leakage of bat-
tery.
Handling the Remote Control
• It could cause corrosion or battery leakage andmay
result in physical injury and/or property damage in-
cluding fire.
• Never mix used and new batteries in the device.
•Replaceallthebatteriesinadeviceatthesametime.
• Remove the batteries if the remote control is not
going to be used for an extended period of time.
• To avoid possible failure, read the following instruc-
tions and handle the remote control properly.
• Do not drop or cause impact to the remote control.
• Do not spill water or any liquidon theremote control.
• Do not place the remote control on a wet object.
• Do not place the remote control under the direct
sunlight or near sources of excessive heat.
Operating Range for the Remote Control
• Point the top of the remote control toward the LCD
TV's remote sensor LED while pressing a button.
RGB2
TV/DTT
I/II
MENU GUID E
DVD S AT
INPUT
RETURN
OK
P
1 2
3
4 5
6
7 8
9
0
AV1
AV2
AV3AV3
AV4
AV5
HDMI1
HDMI2
....
+
30
30
Remote range is approximately 7m/23ft.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1711

GB - 12 -
Switching The TV ON/OFF
To switch the TV on:
Your TV will switch on in two steps:
1- Connectthepowercordtothesystem.PressPower
On/Off switch. Then the TV switches itself to
stand-by mode (optional).
2- To switch on the TV from stand-by mode either:
Press a digit button on the remote control so that a
programme number is selected, or Press the "-P/CH"
or "P/CH+" button on the TV or press the P+ or P-
button on the remote control, so that last mode
switched off is selected.
By either method the TV will switch on.
To switch the TV off:
• Press the “ (stand-by)” button on the remote con-
trol or On/Off switch on theTV, so the TV will switch
to stand-by mode.
To power down the TV completely, press On/Off
switch
or,
Unplug the power cord from the mains socket.
Navigating the Menu System
MENU
GUIDE
RETURN
OK
+
For Displaying
Menu Options For Navigation
To Confirm Choices
1- Press to display the menu.
2- Press

/

button to select an icon.
3- Use

/

button to highlight. Press

for more
optionsinanalogueTVmode.UseOK inDTVmode
for viewing a submenu.
4- Press

/

buttons to change the settings. Press
OK to set as default.
5- To exit the menu or return from sub-menu screen,
press .
These explanations are available for the navigation
of the whole menu system. To select options that are
explained in the following parts, refer to “Navigating
The Menu System”.
Initial Settings
When the TV is turned on for the first time, Auto
Programme menu will be displayed on the screen
Becausethis is the first time the TV is used, there are no
channelsstoredinthememoryandthefollowingmessage
appears on the screen.
Country
Language
UK
Ok
Cancel
PLEASE CHECK ANTENNA CABLE
AUTO. PROGRAMMING SYSTEM
TXT Language
Auto Program
By pressing or button, adjust the Country item
and press to highlight “Language” item. Use
or button to set “Language”. Use or but-
tons to select “TXT Language” and set it by using
or buttons. Press “OK” button to continue:
For more information on this process, see “Install
Menu” section.
Basic Operations
You can operate your TV using both the remote
control and onset buttons.
Operation with the buttons on the TV
Volume Setting
• Press -button to decrease volume or +
button to increase volume, so a volume level scale
(slider) will be displayed at the middle of the bottom
on the screen.
Programme Selection
•PressP/CH + button toselect the next programmeor
P/CH - button to select the previous programme.
Entering Main Menu
• Press the MENU button to enter Main menu. In the
Mainmenuselectsub-menuusing P/CH - or P/CH +
buttons and enter the sub-menu using -or
+buttons. To learnthe usage of themenus, refer to
the Menu System sections.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1712

GB - 13 -
AV Mode
Press the AV buttonat the control panel on the theTV
to switch your TV to AV modes.
Operation with Remote Control
The remote control of your TV is designed to control
all the functions of the model you selected. The func-
tions will be described in accordance with the menu
system of your TV.
Functions of the menu system are described in the
following sections.
Volume Setting
Press +button to increase volume. Press -
button to decrease volume. A volume level scale
(slider) will be displayed in the middle at the bottom of
the screen.
Programme Selection (Previous or next
programme)
• Press P - button to select the previous programme.
• Press P + button to select the next programme.
Programme Selection (direct access):
Press digit buttons on the remote control to select
programmes between 0 and 9. TV will switch to the
selected programme. To select programmes between
10-99 (for analogue), press the digit buttons con-
secutively which programme you want to select (eg.
forprogramme 27, first press 2 and then7). When it is
late to press second digit button only the first digit
programme will be displayed. The limit of the delay
time is 3 seconds.
Pressdirectlytheprogrammenumbertoreselectsingle
digitprogrammes.
Menu System
Picture Menu
Mode
Contrast
Brightness
Sharpness
Colour
In the picture menu; if PC, YPbPr or HDMI modes is
selected, resolution information is displayed at the
bottom of the menu OSD.
Mode
By pressing

/

button, select Mode. Press

/

button to choose from one of these options: Cinema,
Dynamic and Natural.
Contrast/Brightness/Sharpness/Colour/Hue
By pressing

/

button, select the desired Option.
Press

/

button to set the level.
Hint: Hue is displayed in picture menu when the TV
receives an NTSC signal.
Colour Temp
• By pressing

/

button select Colour Temp.
• Press

/

to choose from one of these options:
Cool, Normal and Warm.
Noise Reduction
By pressing

/

button select Noise Reduction.
Press

/

to choose from one of these options:
Low, Medium, High or Off.
Film Mode
Films are recorded at a different number of frames
per second to normal television programmes.
By pressing

/

button, select Film Mode.
Press

/

button to set this feature On or Off. Turn
this feature on when you are watchingfilms to see
the fast motion scenes clearly.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1713

GB - 14 -
3D Comb
3D Comb is used to improve colour transitions and
colour quality of pictures.
By pressing

/

button, select 3D Comb. Press

/

button to set this feature On or Off.
Note: 3D Comb feature is not functional in NATU-
RAL picture mode.
Picture Zoom
By pressing

/

button select Picture Zoom.
Use

/

buttons, to change picture zoom to Auto,
16:9, 4:3, Panaromic, 14:9 Zoom, Cinema, Sub-
title or Zoom.
Reset
By pressing

/

button, select Reset. Press

or
OK button to reset the picture modes to factory de-
fault settings.
Sound Menu
SOUND
Volume
Equalizer
Balance
Headphone
Sound Mode
Volume
By pressing

/

select Volume . Press

/

button to change the level of the Volume.
Equalizer
By pressing

/

select Equalizer.Press

/

button to change the Equalizer setting. In equalizer
menu, the mode can bechangedto Pop, Rock, Jazz,
Flat, Classic or User. Select the desired frequency
by

/

button and increase or decrease the fre-
quency gain by pressing

/

button.
Note: Equalizer menu settings can be altered only
when the Equalizer Mode is in User.
Balance
By pressing

/

selectBalance.Press

/

button
to change the level of the balance.Balance level can
be adjusted between -32 and +32.
Headphone
By pressing

/

button, select Headphone. Press

button to enter hedphone menu.
volume
By pressing

/

button, select Volume. Press

button to increase hp volume level. Press

button to
decrease hp volume level. Headphone volume level
can be adjusted between 0 and 63.
sound mode
By pressing

/

button, select Sound Mode. Press

/

button to change sound mode.
Sound mode is used to identify sound mode of the
headphone and can be set to mono, stereo, dual I or
dual II according to the transmission.
balance
By pressing

/

button, select Balance. Press

buttonto increase balance tothe right. Press

button
to decrease balance to the left. Balance level can be
adjusted between -32 and +32.
Press theMENU buttontoreturnto the previousmenu.
Sound Mode
By pressing

/

select Sound Mode. Press

/

button, you can select Mono, Stereo, Dual I or Dual II
mode,onlyiftheselectedchannelsupportsthatmode.
AVL
By pressing

/

selectAVLVL. Press

/

button to
set the AVL as on or off.
Effect
By pressing

/

select Effect. Press

/

button
to set Effect as on or off.
Dynamic Bass
Dynamic Bass is used to increase bass effect of the
TV set.
By pressing

/

button, select Dynamic Bass. By
pressing

/

button set Dynamic bass to Low, High
orOff.It isnot recommended toselect Highif listening
at high volume levels. There is a subwoofer output
that can accept an active subwoofer if you wish to
create very high levels of Bass.
Subwoofer is active only if Dynamic Bass is set to
Off.
Subwoofer
It is possible to connect an external, activesubwoofer
to the set to give a much deeper bass effect.
By pressing

/

button, select Subwoofer..
Subwoofer can be set to On or Off.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1714

GB - 15 -
Dynamic Bass is not available if Subwoofer is set to
On.
Set Subwoofer to On when you connect an external
subwoofer to the set.
3DS
By pressing

/

button, select 3DS. 3DS can be
set to On or Off.
Set 3DS to On when you connect an external
subwoofer to the set.
If you select “3DS” On, AVL, Effect and Equalizer
items will be invisible.
Feature Menu
FEATURE
Sleep Timer
Child Lock
Language
PIP
PAP
PIP
In the Feature menu, highlight PIP item by pressing

/

buttons. Press

buttontoenterPIP submenu:
PIP
PIP Position
PIP Picture
PIP Source
PIP SWAP
PIP ON-OFF
Off
PIP ON-OFF
You can activate or deactivate PIP mode by pressing

/

button.
PIP Picture
Press

button to enter PIP Picture submenu. Ad-
justmentsofContrast,Brightness,Sharpness,Colour,
Reset and Store items in this part are identical with
Picture menu in the analogue TV menu System.
Refer to Picture menu explanations in the previous
parts.
PIP Position
Select PIP Position item by using

/

button.
Use

/

button to adjust PIP position.PIP Posi-
tion info will be displayed at the bottom of the menu
OSD.You can directly change PIP position by press-
ing

/

buttons.
Positionsavailableare: Bottom Right, Bottom Centre,
Bottom Left, Top Left, Top Center and Top Right.
PIP Source
Select PIP Source item by using

/

button. Use

/

button to set PIP source.
Note: When main picture source is TV, AV-1, AV-2
or AV-3, PIP Window can only be set to HDMI-
1, HDMI-2, AV-5, PC source or vice versa.
PIP SWAP
SelectPIP SWAP itembyusing

/

button. Use

/

button to set. This function enables to swap be-
tween the main and thePIP picture.
PAP
In the Feature menu, highlight PAP item by pressing

/

buttons. Press

buttontoenterPAPAP submenu:
PAP
Off
PAP Picture
PAP Source
PAP ON-OFF
PAP SWAP
PAP ON-OFF
You can activate or deactivate PAP mode by press-
ing

/

button.
PAP Picture
Press

button to enter PAP Picture submenu. Ad-
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1715

GB - 16 -
justmentsofContrast,Brightness,Sharpness,Colour,
Reset and Store items in this part are identical with
Picture menu in the Menu System. Refer to Picture
menu explanations in the previous parts.
PAP Source
Select PAP Source item by using

/

button.Use

/

button to set PAP source.
Note: When main picture source is TV, AV-1, AV-2
or AV-3, PIP window can only be set to
HDMI-1, HDMI-2, YPbPr (AV-5), PC source or vice
versa.
PAP SWAP
Select PAP SWAP item by using

/

button. Use

/

button. This function enables to swap between
the main and the PAP picture.
Note: See Appendix C for all PIP/PAT modes.
Sleep Timer
By pressing

/

select Sleep Timer. Press

/

button to set the Sleep Timer.
The timer can be programmed between Off and 120
minutes in steps of 10 minutes.
Child Lock
By pressing

/

select Child Lock.
Press

/

button to set the Child Lock on or off.
When on is selected, the TV canonlybe controlled by
the remote control handset. In this case the control
panel buttons will not work (except for theSTANDBY
button). Hence, if one of these buttons is pressed,
“Child Lock On” will be displayed on the screen when
the menu screen is not visible.
Language
By pressing

/

button, select Language.Use

/

button to select the language. Available language
options are; English, French, German, Italian, Span-
ish, Portuguese, Dutch, Greek, Swedish, Norwegian,
Danish, Finnish, Turkish, Croatian, Slovenian, Polish,
Czech, Hungarian, Russian, Bulgarian, Greek, Slo-
vak.
AV-2 Out
By pressing

/

selectAV-2 Out.Use

/

button,
to set AV-2 Out to TV, AV-1, AV-3, FAV, YPbPr Au-
dio or PC Audio.
Note: When TV Source is set to HDMI, HDMI Audio
setting will be available among AV-2 Out options.
PC Audio In
By pressing

/

select Pc Audio In.By pressing

/

button, you can change the PC Audio In to TV,,
AV-1, AV-2, AV-3, FAV, YPbPr Audio, PC Audio.
Blue Background
You can set the TV to automatically change to a blue
screen if the signal is weak or absent, or when there
is no input from an external device.
The Blue Background feature can be turned on or off
by pressing

/

button.
Menu Background
By pressing

/

button, select Menu Background.
Transparency level is adjusted by pressing

/

button.
Menu Timeout
By pressing

/

button, select Menu Timeout.
Press

/

button to change menu timeout to 15 sec,
30 sec or 60 sec.
Teletext Language
By pressing

/

button, select Teletext Language.
Press

/

button to change Teletext Language to
West, East, Turk/Greek,Cyrillic, or Arabic.
Default Zoom
Defaultzoomisafeaturethatprovidesthezoommode
of the TV set to be switched to the selected default
zoom mode (Panoramic, 4:3 ,14:9 zoom) in case no
WSS or 4:3 signal by end-user.
By pressing

/

button, select Default Zoom. Youou
canset Default Zoom to Panoramic, 4:3 or14:9 Zoom
by pressing

/

button.
Install Menu
INSTALL
Program Table
Program
Band
Channel
Colour System
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1716

GB - 17 -
Program Table
By pressing

/

button, select Program Table.
Press

to display Program Table.
P02 C 04
P03 C 05
P04 BBC 1
P05 CH 4
P06 BBC 2
P07 C 04
P08 C 07
P09 C 12
P10 C 15
P11 S 18
P12 S 29
P13 S 31
P14 S 33
P15 S 34
P16 S 35
P17 S 36
P18 S 37
P19 S 40
P20 C 21
Name
Delete
Insert
APS
P01 BBC 1
Program Table
By moving the cursor in four directions you can reach
20 programmes in the same page. You can scroll the
pages up or down by pressing the navigation buttons
to seeall the programmes in TV mode (except theAV
mode).Bycursoraction,programmeselection isdone
automatically.
Name
To change the name of a decided programme, select
the programme and press the RED button.
Thefirstletter oftheselectednamewillbehighlighted.
Press

/

button to change that letter and

/

buttontoselecttheotherletters. Bypressing the RED
button, you can store the name.
Insert
Select the programme which you want to insert by
navigationbuttons.PresstheGREEN button.Bynavi-
gation buttons move the selected programme to the
decidedprogrammespaceandpress theGREEN but-
ton again.
Delete
To delete a programme, press the YELLOW button.
Pressing the YELLOW button again erases the se-
lected programme from the programme list, and the
programmes below shift one up.
APS (Auto Programming System)
When you press theBLUE button forAPS,Auto Pro-
gramming System Menu will appear on the screen.
Country
WARNING!
All Prestored Programs
will be deleted
UK
Ok
Cancel
Auto Program
A.P.S. (Auto Programming System) Country
Press

/

button to select your country. If you want
to exit fromA.P.S. function, press the BLUE button.
When you press OK or RED button for starting APS,
all stored programs will be erased and the following
screen will be displayed:
UK
P 03 - C 04
63.75 MHz
6%
63.75 MHz
Cancel
APS is running...
Whenever you press the BLUE button, A.P.S. func-
tion stops and Program Table appears on the screen.
If you wait until the end of A.P.S., Program Table is
displayed with the programmes found and located.
Program
By pressing

/

button, select Program. Press

/

button to select theprogram number. You can also
enteranumberviadigitbuttonsontheremotecontrol.
There are 100 program storage between 0 and 99.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1717

GB - 18 -
Band
Band can be selected either Cor Sby press

/

button.
Channel
Channel can be changed by

/

button or Digit
Buttons.
Colour System
By pressing

/

button, select Colour System.
Press

/

button to change the colour system to
PAL,SECAM,PAL60 or AUTO.
IfSound System issettoI, SECAMisnot available for
the Colour System.
Note: In AV mode, you can choose NTSC 3.58 and
NTSC 4.43 as well.
Sound System
By pressing

/

button, select Sound System.
Press

/

buttonto changethe sound system toBG,,
I,L,L’,DK.
Fine Tune
Bypressing

/

button,select Fine Tune. Press

/

button to adjust the tuning.
Search
By pressing

/

button, select Search. Press

/

button to start program searching.You can also
enter the desired frequency via digit buttons when
search item is highlighted.
Store
By pressing

/

button, select Store. Press

or
OK button to store the adjustments. “Stored...” will
be displayed on the screen.
Install menu in AV modes
The following screen appears in the install menu:
INSTALL
Colour System
Store
VCR
Colour System
By pressing

/

selectColour System. By press-
ing

/

button, you can change the colour system to
PAL, SECAM, PAL 60, NTSC 4,43, NTSC 3,58 or
AUTO.
VCR
By pressing

/

select VCR. By pressing

/

button, you can set the VCR to ON or OFF.
Store
By pressing

/

button, select Store. Press

or
OK button to store the adjustments. “Stored...” will
be displayed on the screen.
Source menu
Bypressing / button, select thefifthicon. Source
menu appears on the screen.
SOURCE
TV
AV-1
AV-2
AV-3
AV-3 S
In source menu, highlight a source by pressing

/

button and switch to that mode by pressing

or
OK button. Source options are; TV, AV-1, AV-2,
AV-3, AV-3 S, FAV, S-Video, YPbPr, HDMI-1,HDMI-
2and PC.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1718

GB - 19 -
PC Mode
Installation
• Power off both ComputerandDisplaybefore making
any connections.
• Set your PC’s resolution correctly before connect-
ing to the TV. See the table onAppendixAon page
28.
• Use 15-pindisplay cable to connect a PC to the LCD
TV.
Menu System in PC mode
Sound Menu/Feature Menu
The items in these menus are described at Sound &
Feature Menu explained in “Menu System”.
PC Picture Menu
By pressing

/

button, select the second icon. PC
Picture menu appears on the screen.
Brightness, Contrast and Colour Temperature adjust-
ments in this menu are identical to adjustments de-
finedinTVpicture menuin“MENUSYSTEM”.
PC POSITION Menu
By pressing

/

button, select the sixth icon. PC
POSITION menu appears on the screen.
PC POSITION
Autoposition
H Position
V Position
Phase
Dot Clock
Autoposition
If you shift the picture horizontally or vertically to an
unwanted position, usethis item to putthe picture into
correct place automatically.
• Select Autoposition item by using

/

buttons.
Press orOK button.
Warning: Auto position adjustment recommended to
be done with the full screen image for the proper
adjustment.
H (Horizontal) Position
This item shifts the image horizontally to right hand
side or left hand side of the screen.
•Select H Position item by using

/

button.
• Use

/

button to adjust the value.
V (Vertical) Position
This item shifts the image verticallytowards thetop or
bottom of the screen.
•Select V Position item by using

/

button.
• Use

/

button to adjust the value.
Phase
Depending on the resolution and scan frequency that
you input to the TV Set, you may see a hazy or noisy
picture on the screen. In such a case you can use
thisitem toget aclearpictureby trialand error method.
• Use

/

button to adjust the value.
Dot Clock
Dot Clock adjustments correct interference that ap-
pear as vertical banding in dot intensive presenta-
tionslikespreadsheetsorparagraphsortextinsmaller
fonts.
• Use

/

button to adjust the value.
Sound in PC mode
• Connect the PC’sAudiooutput to theTV’sPC Audio
In socket with an audio cable.
A01-IB-ENG-(L32A01 A)-MB22-ANALOG-32810W-(RRC1001-2511E)-(BASIC PIP)-10051693-50111148.p6509.07.2007, 11:1719
