Hitachi LE55W806 User manual

IMPORTANT SAFETYINSTRUCTIONS....................................................................... 2-6
INSTALLING THE TABLETOP STAND 7
FIRST TIME USE ....................................................................................................... 10-12
TV OPERATION ........................................................................................................ 13-19
CONNECTIONS
NETWORK SETTINGS
TO OTHER EQUIPMENT .............................................................. 20-22
TROUBLESHOOTING ......................................
............................................................. 36-37
.....................................
............................................................. 23-35
SPECIFICATIONS.......................................................................................................... 38
.............................................................
LIMITED WARRANTY...............................................................................................
39-40
APPENDIXES................................................................................................................. 43
Thank you for purchasing this Hitachi product. Please read these instructions carefully.
For additional assistance please call 1-888-333-1899(U.S.A. or Puerto Rico), or 01-800-700-4321(Mexico) or visit our
website at www.hitachi.us/tv.
Keep this owner's guide for future reference.
Record the model number and serial number of your LCD Television for future reference.
This information is located on the back of the television.
MODEL NUMBER SERIAL NUMBER
ES-G122201
TABLE OF CONTENTS
Simulated image.
Image may differ from actual product.
Models
Owner’s Guide
LE55W806
55” Class (54.64” Diagonal)
LE48W806
48” Class (47.61” Diagonal)

TO PREVENT ELECTRIC SHOCK, THIS APPLIANCE MUST BE CONNECTED TO AN OUTLET WITH A
PROTECTIVE EARTHING CONNECTION.
2
This TV has an Auto Shut Off feature that will automatically turn off the TV if there is no video signal detected within 15minutes.
Additionally this TV has LED backlighting which has greater energy saving benefits versus conventional CCFL type TV.

3

This product contains lead. Dispose of this product in accordance with applicable environmental laws .For product recycling and
disposal information,contact your local government agency or www.eRecycle.org (in California),the Electronic Industries Alliance at
www.eiae.org(in the US) or the Electronic Product Stewardship Canada at www.epsc.ca (In Canada).For more information,call
"1-888-333-1899."
(1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference
that may cause undesired operation.
4
This apparatus shall be connected to a mains socket outlet with a protective earthing connection.

5

4 inches
4 inches
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block
ventilation holes, or set up near radiators. Do not place in direct sunlight. When placing on a shelf leave 4 inches (10 cm) free space
around the entire unit.
Notes when mounting the LCD TV on a wall
If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV for advice, and have the equipment pro-
fessionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV.
The screws ISO M6 thread type should be used. The insertion length must be within 12 - 16mm.
If the insertion length is less than 12mm, the weight can not be maintained.
If the insertion length is more than 16mm, a space is created between the Wall Mount Bracket and the Television.
(Insertion Length) = (Screw Length) - (Washers Thickness) - (Mounting Bracket Thickness)
If the unit is to be mounted on a cabinet smaller than length of the unit, it could result in an unstable location and the unit may tumble
over, creating a risk of personal, possibly fatal injury. Also, this would damage the product seriously. Accordingly, Hitachi accepts no
responsibility or liability for any injuries or property damage resulting from the improper installation.
YES!! NO !!
SAFETY PRECAUTIONS
YES!! NO!!
Securing to a Wall
1. Use metallic wire, clamp and screw (not provided) on the rear of the LCD TV as shown below.
2. Use proper hardware (drywall anchor, masonry screw, etc) to secure other end of wire to wall. 2.
4 inches
Wire
Wire
Screw M6×12
Clamp
6
This TV is designed for tabletop or wall mounted use only. Please follow the guidelines below for safe use of this product.
Notice For Use With Included Tabletop Stand

Installing the Tabletop Stand
7
1. Use the four screws(GB/T 818-2000 M5x12) which are
in the accessories bag to attach the base plate.
2. Use the two screws(GB/T818-2000 M4X12) which are
in the accessories bag to attach the cover plate.
4. Please secure the assembled base are installed to
the TV. Make sure that the three hooks on the stand of
the head bracket inserted into the three slots at the
rear of TV.
5.Use the four screws(GB/T818-2000 M5X12) which are in
the accessories bag to attach the base stand to the TV set.
3. Use the two screws(SJ2822-87 ST4X14) which are
in t h e accessories bag to attach the cover plate.
1 2
3 4
5

8
in accordance with FCC rules.
TM
Manufactured under license from Real Sound Lab. SIA. CONEQ is a trademark of Real Sound Lab, SIA.
CONEQ delivers clear, rich sound using proprietary professional equalizing technology. Dialog is clear and music sounds
more dynamic when the speakers are perfectly optimized.
TM
CONEQ HA MODE (Hearing Aid) technology produces natural sound for the hearing impaired. The listener can enjoy
details in music and clear dialog often without the help of a hearing aid.
TM
Unique space saving design combines a 55"/ 48" LCD color TV with the 6 features noted below and more!

9
20
2
6
7
5
23
23
25
26
27
27
28
29
30
31
Connections to other equipment
Network Settings
Network Connection
Connecting to a Wireless Network
Wireless Setting
Home Network Settings
Media Share Settings in computer
Setting to Share Files
Internet-based Services
VUDU HD Movies
VUDU Apps
Netflix
YouTube
Other
View the Shared Files on TV
Digital Media Player
Enjoy Video Files
Enjoy Music Files
Browse the Pictures
Troubleshooting
Specifications
Limited Warranty
End User License Agreement for HITACHI DTV Software
End User License Agreement for Open Source Sofrware
Appendixes
Starting setup
Using the Channels Menu
Using the Video Menu
Using the Audio Menu
Using the Setup Menu
Using the Parental Controls Menu
Before using your unit
TV Operation
Advanced Features
Other Information
IMPORTANT SAFETY INSTRUCTIONS
CHILD SAFETY NOTICE
SAFETY PRECAUTIONS
Installing the Tabletop Stand
Features
Power source
Contents
Location of controls
Remote control
Antenna connections
Cable TV connections
8
9
10
11
12
12
13
14
14
16
16
17
8
32
32
33
33
33
34
35
36
38
39
41
42
43
32

Power indicator3D emitter
3D emitter Sends signals to 3D glasses during playback of 3D movies and TV shows.
Adjusts TV volume and used as Cursor Left and Right keys to navigate OSD menus.
Selects input source to TV and used like remote control's ENTER key when
choosing an item in OSD menus.
Selects a TV channel and used as Cursor Up and Down keys to navigate OSD menus.
Do not put anything near the sensor,
as its function may be affected.
red
0(18
,1387
&+
92/
32:(5
Illuminates white when the TV is in on mode.
3( )
10

1
2
4
6
7
9
11
13
14
19
20
23
24
3
8
10
12
15
18
21
22
25
26
5
28
16
17
27
1. Slide open the battery cover on the back of the remote control.
2. Install two AAA size(1.5V) batteries. Match the “+” and “-”
signs on the batteries to the signs on the battery compartment.
3. Close the battery cover.
123


11
16. MUTE Button – To turn off the sound, press this button
once. The LCD TV will be silenced and the mute icon will
appear on the screen. The muting feature can be released by
pressing the MUTE button again or by pressing either of the
VOL(VOLUME) button.
17. Direct Input Key Buttons – Press to go Vudu/Netflix/DMP
18. Transport Keys – Use them with DMP/Vudu/ Netflix/HDMI
CEC features.
19. S.MODE – Press to select Sound mode.
20. P.MODE – Press to select Picture mode.
21. C.C.Button – Used to turn on/off the Closed Captions.
22. ASPECT Button – Press to change the picture size.
23. MTS/SAP Button – Press to change the audio language.
24. 3D Button – Press to open the 3D Menu.
25. SLEEP Button – To set the LCD TV to turn off after a
preset amount of time, use the SLEEP button on the remote
control.
26. TIME Button – Press to display the time.
27. – Button – This button is the “-”button, used when
selecting digital channels.
28. Button – Press to display the application menu.
1. POWER Button – Press to turn the LCD TV’s power on/off.
2. Direct Input Key Buttons – Press to go to the
AV/COMP/RGB/HDMI.
3. INPUT Button – Press to change the TV’s input
4. Direct Channel Selection Button (0-9) – Allow direct
access to any channel of the LCD TV.
5. LAST CH Button – Pressing this button allows you to go
back to the previous channel selected. Press this button again
to return to the channel you were watching.
6. Color keys – Used for network features like VUDU.
7. MENU Button – Press to display the On-Screen menu.
8. EXIT Button – Press to exit the On-Screen menu.
9. CURSOR Buttons –Use to navigate and select
menu functions of the LCD TV.
10. ENTER Button – Press to enter or select functions for the
On-Screen menu.
11. RETURN Button – Return to the previous menu.
12. INFO Button – When you press this button, the current
information will the displayed on the screen.
13. FAV CH Button – Press to display favorite channels.
14. VOL(VOLUME) Buttons – Press the button to
increase, or the button to decrease the sound level.
15. CH(CHANNEL) Buttons – Press to change the
channels of the TV.
ENTER

12
Antenna connections
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you
are using a Cable TV service, see Cable TV connections.
Combination VHF/UHF Antenna (Single 75 ohm cable)
Cable TV connections
For basic Cable TV service not requiring a Converter/Descrambler box, connect the
75 ohm Coaxial Cable directly to the Antenna Jack on the back of the TV.
For subscribers to scrambled Cable TV service
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial
Cable to the Converter/Descrambler box.Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler
box to the Antenna Jack on the TV. Follow the connections shown below. Set the TV to the output channel of the Converter/
Descrambler box (usually channel 3 or 4) and use the Converter/Descrambler box to select channels.
For subscribers to unscrambled Cable TV service with scrambled premium channels
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require the use of a
Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available from the Cable TV company
or an electronics supply store). Follow the connections shown below. With the switch in the “B” position, you can directly tune any
nonscrambled channels on your TV. With the switch in the “A” position, tune your TV to the output of the Converter/Descrambler box
(usually channel 3 or 4) and use the Converter/Descrambler box to tune scrambled channels.
This TV has an extended tuning range and can tune free access cable channels without using a Cable TV Converter box. Most
cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal
viewing requires the use of a descrambler device which is generally provided by the Cable TV company.
For subscribers to basic Cable TV service
Incoming 75 ohm Cable TV Cable 75 ohm Cable to TV
Antenna
Jack
Converter/
Descrambler
Splitter B
A
Incoming
75 ohm
Cable TV
Cable A/B Switch 75 ohm Cable to TV
Converter/
Descrambler Antenna
Jack
75 ohm
Coaxial
Cable
Antenna
Jack
75 ohm
Coaxial Cable
Antenna
Jack

Starting setup
will assist you to specify the Air/Cable setting and program
your channels automatically.
IMPORTANT: Make sure that the antenna or cable TV system
connection is made.
1
To turn on the TV, press POWER (POWER indicator LED on the
confirm. This product qualifies for ENERGY STAR in Home mode
on remote control
default setting.
Retail mode is not an energy saving mode.
front of the unit changes to white. It may take approx. 10 seconds
for a picture to appear on screen.). The
Setup Wizard function
begins.
2Press ▲or ▼to select “Source”, then press or to select
“Cable” or “Air”.
3Press ▲or ▼to select “Scan”, then press or ENTER.
4
s
NOTE
s
TV operation
TO SELECT DIGITAL CHANNELS
– button followed by
the remaining number.
Example, to select channel 15-1, press 1,5,–, 1, then press
ENTER.
sIf a channel is selected with only audio content, “Audio
only” will be displayed on the screen.
sIf a channel is selected with a weak digital signal, “Searching
for Signal....” will be displayed on the screen.
sThe same program may be available on either an analog
channel or a digital channel. You may choose to watch
either format.
sIf a channel is selected to which you have not subscribed,
“Scrambled Video” will be displayed on the screen.
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13
VHF
2-13
UHF
14-69
NOTES
sIf a channel with no broadcast is selected, the sound will
automatically be muted.
sIt may take a few seconds for a digital channel picture to
appear on screen after being selected.
To select the video input source
▲▼
CH /
Press and release CH / . The channel automatically stops at
the next channel set into memory.
For proper operation, before selecting channels, they should be
set into the memory. Refer to the Channels Menu on page 14.
Please select your tuner mode:
Cable
Move Select ExitReturn
Air
If you press EXIT in the process of “Setup Wizard”, the Setup
Wizard stops and changes to the normal screen. When you
make a menu selection, your changes occur
immediately. You
do not have to press EXIT to see your changes.
Depending on the reception condition, it may take up to 25
minutes or more to complete memorizing digital cable
channels. Please allow the process to complete without
interruption.
“Setup Wizard” will begin. After the Setup Wizard is
completed, the TV channel appears on the screen.
CATV
Digital Terrestrial Broadcast(8VSB):2-69
Digital cable(64/256 QAM):1-135
1-125
Air
INPUT
Air/Cable
Component
RGB
USB
AV
HDMI 1
HDMI 2
HDMI 3
HDMI 4
Select
Exit
Move
13
▲
▼
▲
▲
To view a signal from another device connected to
your LCD TV, such as a VCR player, press INPUT,
then press or ,then press ENTER. You can
select Air/Cable, HDMI1, HDMI2, HDMI3, HDMI4,
Component, AV, RGB or USB depending on which
input jacks you used to connect your devices.
1To turn on the TV, press POWER .
(POWER indicator LED on the front of the unit changes to white.
It may take approx. 10 seconds for a picture to appear on
screen.)
2Adjust the volume level by pressing VOL or . The
volume level will be indicated on the screen by a volume bar.
3Set the Source option to the appropriate position.
4Press the Direct Channel Selection (0-9, –) buttons to
select the channel.
(If you press only the channel number, channel selection will
be delayed for a few seconds.)
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to select channel
2, press 2, then press ENTER.
10-99: Press the 2 digits in order. Example, to select
channel 12, press 1, 2, then press ENTER.
100-135: Press the 3 digits in order. Example, to select
channel 120, press 1, 2, 0, then press ENTER.
Move
▲
▼
Select
▲
Retail mode is intended for in-store display and resets video
settings at Power On.
▲
▼

Set Move Return
Select ExitMove
Select ExitMove
Lock Setting On
Reset
3D
10
Return
Auto Scan
Status: Scanning... Cable
Analog Channels: 7
Digital Channels: 0
16%
MENU MENU
EXIT
EXIT
EXIT
EXIT
Digital Channels. Digital Channels
Analog Channels. Analog Channels
Auto Movie, Noise Reduction, MPEG NR, Dynamic Gamma,
Backlight, Aspect Ratio, Color Temperature, White Balance,
Blue Only Mode , and Overscan.
Audio Language
Audio Language
/Standard/Movie/Pro-Day/Pro-night/Game/Custom.
When 3D video is watched under the fluorescent lamp
(50~60 Hz) or tri-band fluorescent tube, there may be
slight flicker, so please adjust the illumination downward
or switch off the light.
Certain functions, such as change aspect ratio, are not
available when watching 3D movies and TV shows.
Other brands of 3D glasses may not be supported.
Sit upright and facing the TV when watching 3D movies and
TV shows.
This TV supports automatic identification of common
3D formats when connected to HDMI V1.4 compatible
sources. Other 3D sources require manual setup.
Audio Language
NOTES
Set to the "warmness" or "coolness" of the
white areaa for picture.
Before using 3D function
14
▲
▼
▲
▲
▼
▲
▼
ENTER
ENTER
ENTER
ENTER

3D WARNING!
1. Some viewers may experience various types of discomfort during or
after viewing 3D visual images, including symptoms like dizziness,
disorientation, eye strain/fatigue, blurry vision, headaches and/or
nausea. If a viewer notices any of these or any other symptoms of
discomfort while using the TV to view 3D visual images, the affected
viewer should immediately stop watching the TV until such symptoms
have disappeared for at least 30 minutes. If any such symptoms are
particularly severe or persist for hours or days after using the TV to view
3D visual images, the affected viewer should consult a qualified
physician.
2. It is strongly recommended that individuals with epilepsy, people with
any history (or family history) of seizures, individuals with heart disease,
pregnant women, and anyone who becomes nauseated easily should
refrain from using the TV to view 3D visual images unless they have
first consulted a qualified physician.
3. Children’s and teenagers’ use of the TV to view 3D visual images
should be carefully supervised. Because the visual development of
children 6 years and younger may be incomplete and could be
adversely affected by exposure to 3D visual images, it is not
recommended that they use the TV to view 3D visual images unless
their parent or guardian has first consulted a qualified physician.
4. Using the TV to view 3D visual images for extended periods of time
is not recommended, even if none of the above symptoms have been
experienced, and all viewers should take regular breaks from such
viewing.
15
ReturnMove
Auto Movie Auto
MPEG NR High
Dynamic Gamma Dynamic1
Backlight 100
Aspect Ratio 16 9
Color Temperature Standard
White Balance
Blue Only Mode Off
When 3D signal format is Frame Packing, the image will be displayed
according to the resolution of the incoming signal.
For example: when the input signal is 1280×720, a 720p image will be
displayed. A 1920×1080 input signal will be displayed in 1080p.
When 3D signal format is Side-by-Side, Top-and-Bottom, the image is
displayed full screen in half resolution (960× 1080 or 1920×540
respectively).
3D Mode: Format may be set to: Off, 2D-to-3D, Side-by-Side or
Top-and-Bottom. (3D image is not displayed in Game mode.)
L-R Switch: Flips the left and right frames in Side-by-Side format.
Depth of Field: Adjusts the range of distance (focus) that appears
acceptably sharp in a 3D image.
3D-to-2D: Disables automatic identification of 3D format during playback;
forces 2D playback using only the Left or Right frame.
3D: Enables playback of 3D movies and TV shows (requires compatible
3D glasses).
Noise Reduction: The Noise Reduction function automatically
reduces conspicuous noise in the picture without degrading picture
quality. Set Noise Reduction to OFF if you see individual blocks in the
picture.
MPEG NR: The MPEG NR (Noise Reduction) function automatically
reduces block noise in the picture without degrading picture quality.
Aspect Ratio : Use the arrow button to choose the screen aspect ration
from 16:9, 4:3, Zoom, Cinema, Dot-to-Dot.
Dynamic Gamma: The Dynamic Gamma feature allows you to set
among three settings (Off, Dynamic 1, and Dynamic 2) to produce
greater picture detail in dark or bright scene area.
As the theatrical movies are shot on film at 24 frames of still pictures per
second, instead of 30 frames or 60 fields like video. When the film is
transferred to video for television viewing, the disparity between the two
frame rates must be reconciled. This involves a process known as 3:2
pull down.
When the Auto Movie is set to Auto, your Hitachi LCD TV will activate
the circuitry for this special feature to improve video performance when
watching interlaced format film based sources. Set to Off will deactivate
this feature.
▲
▼
Color Temperature: Set to Warm for cooler color with more
blue, set to Cool for a more natural color or set to Standard for
accurate color.
Backlight: Adjust to increase or decrease the brightness of
backlight.
Auto Movie: This feature sets the 3:2 pull down detection feature to
Auto or Off.

CONEQ Wall Mount
Bass
Treble
50
50
Reset
Move
MENU
Lock Setting: Select on to lock your favorite settings.
This function is available only for Pro-Day and Pro-Night modes.
White Balance: Use this function to adjust the dark end (Cut off)
and bright end (Drive) of the White background.
Blue Only Mode: This function removes the red and green
signal from the video signal and displays the blue signal only.
This lets you accurately adjust the color and tint settings.
EXIT
EXIT
Mode
Bass: This function controls the low frequency audio to the
speakers.
Treble: This function controls the high frequency audio to the
speakers.
CONEQ: Delivers clear crisp sound and high fidelity music
playback. Use the CURSOR PAD to select the preferred setting.
Table Top: Use this setting for improved sound quality with table
top stands.
Wall Mount- Select this setting for improved sound quality when
wall mounting.
Hearing Aid- This special mode is for users that want to maintain
clear sound after removing their conventional hearing aid. Note
that this feature emphasizes higher frequencies.
Select from Standard, Movie, News or Custom
sound modes.
Select Return
Menu Settings
HDMI CEC
RGB
PC Standby On
Power LED On
Home/Retail Home
Closed Captions
MENU
EXIT
EXIT
Demo mode: Turn the demo mode On or Off.
Menu Settings:
duration
16
▲
▼
Overscan: When you select on, the border of the image extends
past the video signal isn't seen.
ReturnMove
Select ReturnMove
Time Zone
Daylight Savings on
Time
Sleep Timer off
Day/Night Timer
Day/Night Timer : Select this feature to activate and set your
TV’s Day/Night picture mode Timers. There are three available
Timers for your convenience.
Select Return
Move
▲
▼
Move
▲
▼
▲
▼
ENTER
ENTER
ENTER
ENTER

HDMI CEC: Set to On and this feature will enable the
HDMI-CEC signal bus to allow your Hitachi LCD TV to
discover and communicate automatically with other compatible
HDMI-interfaced Audio/Video device. The CEC signal bus
makes global controls possible, based on “plug & play”
automation, to minimize the number of IR remotes and
key-presses required for basic operation of your AV device.
Select Off to disable this option.
Power LED: Select this feature to turn Off or On the Power
LED indicator on the front panel on your TV.
RGB
Home/Retail: You can change the initial setting to either Home
or Retail mode quickly through this menu option, without
running the TV Setup Wizard again.
Retail mode is intended for showroom use only. Any menu
or control changes in this mode will not be saved when
the TV is turned off.
A TV feature introduction will be popped up at the bottom of the
screen.
Return
Password
7
8
9
10
Set ReturnMove
17
ReturnMove
Caption Control,
four
On/Off/With Mute.
ReturnMove
Caption Style As Broadcaster
Font Size Large
Font Style Style1
Font Color White
Font Opacity Solid
Background Color Black
Background Opacity Solid
Window Color Black
Window Opacity Transparent
by
▲
▼
▼
▲
Channel Block
Rating
Input Block
Change Password
Factory Reset
▲
▼
Set ReturnMove
▲
▼
ENTER
ENTER
EXIT
EXIT
Reset AV & Setup - returns TV to factory default settings.
Version Info -
You can adjust:
H.Position - Move the image right or left.
V.Position - Move the image up or down.
Phase - Adjust the focus of stable images.
Clock - Adjust the sample frequency.
Auto Adjust - Detects input signal clock, phase and position and
adjusts TV display accordingly.

ReturnMove
Rating Enable off
U.S. TV Rating
U.S. Movie Rating
Canadian Ratings(Eng)
Canadian Ratings(Frn)
Region 5
Block Unrated TV off
HDMI3
HDMI4
7
8
Set ReturnMove
Air/Cable
AV
Region 5: I
Block Unrated TV:
U.S.Movie Rating: Follow Step B
18
▲
▼
▲
▼
ENTER

19

20
