Hitachi C 10FCD Operator's manual

MODELCOMPOUNDSAW
MODELESCIE AONGLETINCLINABLE
MODELOSIERRACOMPUESTA
C10FCD
INSTRUCTIONMANUALANDSAFETYINSTRUCTIONS
WARNING
Improper and unsafe use of this power toolcan result in death or serious bodily injury!
This manualcontains importantinformation aboutproduct safety.Please read and
understand this manualbefore operating the power tool.Please keep this manual
available for others before they use the power tool.
MODED’EMPLOIETINSTRUCTIONSDESECURITE
AVERTISSEMENT
Une utilisation incorrecte etdangereuse de cetoutil motorisé peutentraîner la mort
ou de sérieuses blessures corporelles!
Ce mode d’emploicontientd’importantes informations à propos de la sécurité de
ce produit.Prière de lire etd’assimiler ce mode d’emploiavantd’utiliser l’outil
motorisé.Garder ce mode d’emploià la disponibilité des autres utilisateurs avant
qu’ils utilisentl’outil motorisé.
MANUALDEINSTRUCCIONESEINSTRUCCIONESDESEGURIDAD
ADVERTENCIA
¡La utilización inapropiada e insegura de esta herramienta eléctrica puede resultar
en lesiones serias o en la muerte!
Este manualcontiene información importante sobre la seguridad delproducto.Lea y
comprenda este manualantes de utilizar la herramienta eléctrica.Guarde este manual
para que puedan leerlo otras personas antes de que utilicen la herramienta eléctrica.
DO UBLE INSULATION
DO UBLE ISOLATION
AISLAMIENTO DOBLE

English
Page
IMPO R TANT INFO R MATION ..................................... 3
MEANINGS OFSIGNA L WO R DS ............................... 3
SAFETY
IMPO R TANT SAFETYINST R UCTIONS
FO R USING A LL POWE R TOO L S............................ 3
R EP L ACEMENT PA R TS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
USE P R OPE R EXTENSION CO R D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
DOUB L EINSU L ATION FO R
SAFE R OPE R ATION .................................................. 7
OPERATIONANDMAINTENANCE
NAME OFPA R TS.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SPECIFICATIONS ......................................................... 9
ACCESSO R IES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
STANDA R DACCESSO R IES .................................... 9
Page
OPTIONA L ACCESSO R IES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
APP L ICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
P R EPA R ATION BEFO R EOPE R ATION . . . . . . . . . . . . . . . . . . . . . 10
BEFO R EUSING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
BEFO R ECUTTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
P R ACTICA L APP L ICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SAW B L ADE MOUNTING
AND DISMOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
OVE R L OAD P R OTECTIVE DEVICE FO R
PO L Y-V-BE L T.......................................................... 21
MAINTENANCE AND INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . 21
SE R VICE AND R EPAI R S. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . 22
PA R TS L IST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
CONTENTS
Français
Page
INFO R MATIONS IMPO R TANTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SIGNIFICATION DES MOTS D’AVE R TISSEMENT . . . . . 23
SECURITE
CONSIGNES DE SÉCU R ITÉ R E L ATIVES AUX
OUTI L SÉ L ECT R IQUES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
PIECES DE R ECHANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
UTI L ISATION D’UN CO R DON DE R A LL ONGE . . . . . . . . 27
DOUB L EISO L ATION POU R UN
FONCTIONNEMENT P L US SU R . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
UTILISATIONETENTRETIEN
NOM DES PIÈCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
SPÉCIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Page
ACCESSOI R ES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . 29
ACCESSOI R ES STANDA R D. . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 29
ACCESSOI R ES EN OPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
APP L ICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
P R ÉPA R ATION AVANT L ’UTI L ISATION ................. 30
AVANT L ’UTI L ISATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
AVANT L ACOUPE . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
APP L ICATIONS P R ATIQUES .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
INSTA LL ATION ET R ET R AIT DE L A L AME . . . . . . . . . . . . 40
DISPOSITIFDE P R OTECTION ANTI-SU R CHA R GE
DE L APO L Y-COU RR OIE EN V.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
ENT R ETIEN ET INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
SE R VICE AP R ÈS-VENTE ET R ÉPA R ATIONS . . . . . . . . . . 42
TABLEDES MATIERES
Página
ACCESO R IOS ESTÁNDA R . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . 49
ACCESO R IOS OPCIONA L ES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
AP L ICACIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
P R EPA R ATIVOS P R EVIOS A L AOPE R ACIÓN . . . . . . . . 50
ANTES DE L AUTI L IZACIÓN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
ANTES DE L CO R TE..................................................... 53
AP L ICACIONES P R ÁCTICAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
MONTAJE YDESMONTAJE DE L AHOJA DE
SIE RR A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
DISPOSITIVO P R OTECTO R CONT R ASOB R ECA R GA
PA R A L ACO RR EA EN VDE PO L IVINI L O.....................
61
MANTENIMIENTO EINSPECCIÓN .. . . . . . . . . . . . . . . . . . . . . . . 61
SE R VICIO Y R EPA R ACIONES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
ÍNDICE
Español
Página
INFO R MACIÓN IMPO R TANTE ................................. 43
SIGNIFICADO DE L AS PA L AB R AS C L AVE . . . . . . . . . . . . 43
SEGURIDAD
NO R MAS DE SEGU R IDAD PA R A L AS
HE RR AMIENTAS E L ÉCT R ICAS
................................... 43
PIEZAS DE R EEMP L AZO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
UTI L IZACIÓN DE UN CAB L EP R O L ONGADO R . . . . . . 47
AIS L AMIENTO DOB L EPA R AOF R ECE R UNA
OPE R ACIÓN MÁS SEGU R A. . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . 47
OPERACIÓNYMANTENIMIENTO
NOMENC L ATU R ADE PA R TES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
ESPECIFICACIONES.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
ACCESO R IOS .............................................................. 49

3
English
IMPORTANT INFORMATION
Read and understand all of the operating instructions,safety precautions and warnings in the Manualbefore
operating or maintaining this power tool.
Mostaccidents thatresult from tooloperation and maintenance are caused by the failure to observe basic
safety rules or precautions.An accidentcan often be avoided by recognizing a potentially hazardous situation
before it occurs and by observing appropriate safety procedures.
Basic safety precautions are outlined in the SAFETY section of this manualand in the sections which contain
the operation and maintenance instructions.
Hazards thatmustbe avoided to preventbodily injury or machine damage are identified by WARNIN GS on
the tooland in this Manual.
Never use this toolin a manner thathas notbeen specifically recommended by HITACHI,unless you first
confirm thatthe planned use will be safe for you and others.
MEANINGS OFSIGNAL WORDS
WARNING:indicates apotentiallyhazardous situation which,if ignored,couldresultinserious personal
injury.
CAUTION:indicates ahazardous situation which,if ignored,couldresultinamoderatepersonal
injury,or couldcausemachinedamage.
NOTE emphasizes essentialinformation.
SAFETY
INPORTANT SAFETY INSTRUCTIONS FORUSING ALL POWERTOOLS
READ ALL OFTHE WARNINGS AND OPERATING INSTRUCTIONS INTHISMANUAL BE-
FOREOPERATING ORMAINTAINING THISTOOL:
WARNING:Whenusing this electrictool,take all necessary precautions to minimizetheriskofelectric
shockor otherpersonalinjury.
Inparticular,always complywith thefollowing safety rules:
1.ALWAYS KEEP GUARDS INPLACE and in working order.
2.ALWAYS REMOVE ADJUSTING KEYS AND WRENCHES BEFORESTARTING TOOL.
Always confirm thatall keys and adjusting wrenches have been removed from the toolbefore it is turned on.
3.ALWAYS KEEP WORK AREA CLEAN. Avoid injuries by notcluttering the workareas and work
benches.
4.NEVERUSE TOOL INHAZARDOUS ENVIRONMENTS.Never use the power toolin damp or
wetplaces and never expose it to rain.Always keep the workarea well lighted.
5.NEVERPERMITCHILDREN OROTHERSTO LOITERNEARTHE WORK AREA.Keep all
people (especially children) away from the workarea.Always unplug unattended tools and keep the
workplace tamper-proof by installing locks on the doors and on the master switches.
6.NEVERFORCE THE TOOL.It will do the job better and more safely if it is operated atthe rate for
which it was designed.
7.ALWAYS USE THE RIGHT TOOLS.Never force a toolor an attachmentto do a job for which it
was notdesigned.
8.ALWAYS WEARPROPERAPPAREL WHEN WORKING WITH THE TOOL. Never wear loose
clothing,gloves,neckties,rings,bracelets or other jewelry which may getcaughtin the moving parts.
Always wear non-slip footwear,preferably with steeltoes.Wear protective hair covering to contain long
hair.
9.ALWAYS USE EYE PROTECTION WHEN WORKING WITH THE TOOL TO PREVENT
EYE INJURY.Ordinary eyeglasses do notprovide adequate protection because they have only impact
resistantlenses,they are N OT safety glasses.Also,use a face maskfor additionalsafety and wear a
dustmaskif the cutting operation produces dust.

4
English
10.ALWAYS SECURETHE WORKPIECE TO THE FENCE ORTHE TABLE. Use clamps or a vise
to hold the workpiece in place.It is safer than using your hand and it frees both hands to operate the tool.
11.NEVEROVERREACH.Always keep proper footing and balance when working with the tool.
12.ALWAYS MAINTAINTOOLSWITH CARE.Always keep tools sharp and clean for the bestand
safestperformance.Always follow instructions for lubricating the tooland for changing accessories.
13.ALWAYS DISCONNECT THE TOOL before servicing and before changing blades or other accessories.
14.NEVERRISKUNINTENTIONAL STARTING WHEN PLUGGING INTHE TOOL.Always
confirm thatthe switch is in the OFF position before inserting the power plug into the receptacle.
15.ALWAYS USE RECOMMENDED ACCESSORIES ONLYWHEN OPERATING THISTOOL.
Consult this instruction manualfor descriptions of recom mended accessories.To avoid personalinjuries,
use only recommended accessories in conjunction with this tool.
16.NEVERSTAND ON THE TOOL.Serious injury could occur if the toolis tipped or if unintentional
contact with the saw blade is made.
17.ALWAYS CHECKFORDAMAGED PARTS BEFOREUSING THE TOOL.Always check the
guard and all other components for damage before using the toolto assure thatthey will function
properly.Check all moving parts for proper alignment,freedom from binding and other conditions that
mightaffect proper operation.Always repair or replace any damaged guards or other damaged
components before using the tool.
18.ALWAYS CONFIRMTHE ROTATION DIRECTION OFTHE BLADE BEFOREUSING THE
TOOL.Always feed workinto the toolagainstthe rotation direction of the blade in order to prevent
possible injury.
19.NEVERLEAVE THE TOOL RUNNING WHILEUNATTENDED.TURNPOWEROFF.Do not
leave tooluntil it comes to a complete stop.Always turn the power off when the toolis notin use.
Always unplug the power cord when the toolis notin use.
20.This toolwas notdesigned to be used for mass-production applications and should notbe used in
mass-production environments.
21.When servicing this tool,use only authorized replacementparts.
22.Apply 115 volts AC only to this tool.Applying the wrong voltage or applying DC power can cause the
PO WER TO OL to operate improperly and cause serious personalinjury or damage to the tool.
23.Never raise the saw blade from the workpiece until it has firstcome to a complete stop.
24.Always use outboard stands to provide supportfor long workpieces thatoverhang the table of the
compound saw.
25.POLARIZED PLUGS To reduce the riskof electric shock,this equipmenthas a polarized plug (one
blade is wider than the other).This plug will fit in a polarized outletonly one way.If the plug does notfit
fully in the outlet,reverse the plug.If it still does notfit,contact a qualified electrician to install the
proper outlet.Do notchange the plug in any way.
SpecificSafety Rules for Useofthis PowerTool
WARNING:Thefollowing specificoperating instructions mustbeobservedwhenusing this POWER
TOOL inorderto avoidinjury:
DO’s
ALWAYS OBSERVE THE FOLLOWING RULES TO ASSURESAFEUSE OFTHISTOOL:
1. Review this Manualand familiarize yourself with the safety rules and operating instructions for this
PO WER TOOL before attempting to use it.
2. Always confirm thatthe POWER TO OL is clean before using it.
3. Always wear snug-fitting clothing,non-skid footwear (preferably with steeltoes) and eye protection
when operating the POWER TOOL.
4. Always handle the PO WER TO OL carefully.If the POWER TOOL falls or strikes againsta hard object,it
mightbecome deformed or cracked or sustain other damage.
5. Always cease operating the saw atonce,if you notice any abnormality whatsoever.
6. Always confirm thatall components are mounted properly and securely before using the tool.

5
English
7. When replacing the saw blade,always confirm thatthe rpm rating of the new blade is correct for use
on this tool.
8. Always shutoff the power and wait for the saw blade to completely stop rotating before doing any
maintenance or adjustments.
9. Always clamp or otherwise secure the workpiece to the fence;otherwise the workpiece mightbe thrust
from the table and cause bodily harm.
10. During miter or bevelcutting,always wait for the rotation of the blade to stop completely before lifting
the saw blade.
11. Always make a trialrun firstbefore attempting any new use of the saw.
12. Always handle the saw blade with care when dismounting and mounting it.
13. Always confirm thatthe workpiece is free of nails or other foreign objects before beginning a cut.
14. Always keep your hands outof the path of the saw blade.
15. Always confirm thatthe safety cover is in the proper place before using the saw.
16. Inspect the toolpower cords periodically.
17. Always confirm thatthe proper lengths and types of extension cords are being utilized,if necessary,
before starting the tool.
18. Always confirm thatthe motor air vents are fully open before using the tool.
19. Always wait until the motor has reached full speed before starting a cut.
20. Always keep the handles dry,clean and free of oil and grease.Hold the toolfirmly when in use.
21. Always use outboard stands to provide supportfor long workpieces thatoverhang the table of the
compound saw.
22. Always operate the toolafter ensuring the workpiece is fixed properly with a vise assembly.
23. The operating instructions provided with the toolshall direct the user to secure the toolto supporting
structure if,during normaloperation,there is a tendency for the toolto tip over,slide,or walk on the
supporting surface.
DON’Ts
NEVERVIOLATE THE FOLLOWING RULES TO ASSURESAFEUSE OFTHISTOOL:
1. Never operate the POWER TO OL unless you fully understand the operating instructions contained in
this Manual.
2. Never leave the PO WER TOOL unattended withoutfirstunplugging the power cord.
3. Never operate the POWER TO OL when you are tired,after you have taken any medications,or have
consumed any alcoholic beverages.
4. Never use the PO WER TOOL for applications notspecified in the instruction manual.
5. Never operate the toolwhile wearing loose clothing,a necktie or jewelry,or while your hair is uncovered,
to protect againstgetting caughtin the moving machinery.
6. Never reach around the saw blade.
7. Never touch any moving parts,including the blade,while the saw is in use.
8. Never remove any safety devices or blade guards;use of the toolwithoutthem would be hazardous.
9. Never lock the safety cover;always confirm thatit slides smoothly before using the tool.
10. Never damage the power cord of the tool.
11. Never attemptto move a plugged-in PO WER TOOL while your finger is on the starting switch.
12. Never use the PO WER TOOL if the starting switch does notturn on and off properly.
13. Never use the PO WER TOOL if the plastic housing or the handle is cracked or deformed.
14. Never use the POWER TOOL near flammable liquids or gases because sparking can cause an explosion.
15. Never clean plastic components with solvents because the plastic may dissolve.
16. Never operate the saw unless all the blade guards are in place.

6
English
17. Never raise the saw blade from the workpiece until it has firstcome to a complete stop.
18. Never place your limbs inside of the line nextto warning sign “ ” while the toolis being operated.
This may cause hazardous conditions.
19. Never use abrasive type blades on this saw.
20. Never expose to rain or use in damp locations.
21. Never cutferrous metals or masonry.
WARNING
FORYOUROWN SAFETY READ THISINSTRUCTION MANUAL BEFOREOPERATING THE
COMPOUND SAW
1. Always wear eye protection when using the compound saw.
2. Always keep hands outof the path of the saw blade.
3. Never operate the saw withoutthe guards in place.
4. Never perform any freehand operation with the compound saw.
5. Never reach around the saw blade.
6. Always turn off tooland wait for saw blade to stop before moving workpiece or changing settings.
7. Always disconnect power before changing blade or servicing.
8. Saw blade diameter is 10" (255mm).
9. No load speed is 3800rpm.
REPLACEMENT PARTS
When servicing use only identicalreplacementparts.
Repairs should be conducted only by a Hitachiauthorized service center.
USE PROPEREXTENSION CORD
Make sure your extension cord is in good condition.When using an extension cord,be sure to use one
heavy enough to carry the currentyour product will draw.An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating.Table shows the correct size to use depending on cord
length and nameplate ampere rating.If in doubt,use the nextheavier gage.The smaller the gage number,
the heavier the cord.
MINIMU M GA GE FOR CORD SETS
TotalLength of Cord in Feet(Meter)
0 –25 26 –50 51 –100 101 –150
(0 –7.6) (7.9 –15.2) (15.5 –30.5) (30.8 –45.7)
Ampere Rating AW G
More NotMore
Than Than
0 –6 18 16 16 14
6 –10 18 16 14 12
10 –12 16 16 14 12
12 –16 14 12 NotRecom mended
WARNING:Avoidelectricalshockhazard.Neverusethis toolwith adamagedor frayedelectricalcord
or extension cord.
Inspectall electricalcords regularly.Neveruseinor nearwateror inany environment
whereelectricshockis possible.

7
English
DOUBLEINSULATION FORSAFEROPERATION
To ensure safer operation of this power tool,HITACHIhas adopted a double insulation design.“Double
insulation ”means thattwo physically separated insulation systems have been used to insulate the electrically
conductive materials connected to the power supply from the outer frame handled by the operator.Therefore,
either the sy mbol“”or the words and “Double insulation”appear on the pow er toolor on the nam eplate.
Although this system has no externalgrounding,you m uststill follow the normalelectricalsafety precautions
given in this Instruction Manual,including notusing the pow er toolin wetenviron ments.
To keep the double insulation system effective,follo w these precautions:
* Only HITACHIA UTH ORIZED SERVICE CE NTER should disasse mble or asse m ble this po wer tool,and only
genuine HITACHIreplacementparts should be installed.
* Clean the exterior of the po w er toolonly with a softcloth moistened with soapy water and dry thoroughly.
* Never use solvents,gasoline or thinners on plastic co mponents;otherwise the plastic may dissolve.
SAVE THESE INSTRUCTIONS
AND
MAKETHEM AVAILABLETO
OTHERUSERSOFTHISTOOL!

8
English
OPERATION AND MAINTENANCE
NOTE:Theinformation containedinthis Instruction Manualis designedto assistyou inthesafeoperation
and maintenanceofthepowertool.Someillustrations inthis Instruction Manualmayshow details
or attachments thatdifferfrom thoseon your own powertool.
NAME OFPARTS
Fig.1
Fig.2
Spring Plate
Table InsertTable
Base
Extension Wing
(O ptionalAccessory)
Fe nce
Vise Assem bly
Angle Regulator
DustBag
Lever
Motor
Blade G uard
(M etal)
Head
Na meplate
Clam p Lever
Extension Stay
5 m m M achine Screw
Plunger Handle
Switch Lock
Ha n dle
Trigger S w itch
Blade
Blade G uard (Plastic)
Stock Stop
(O ptionalAccessory)
Chip Deflector
Indicator
Miter A ngle Scale
Miter Handle

9
English
SPECIFICATIONS
Item M odelC 10FCD
Motor Type Series co m mutator m otor
Po w er source Single-phase A C 60Hz
Voltage (Volts) 115
Full-load current(A m p) 13
Applicable Outside Dia.10" (255 m m)
sa w blade Hole Dia.5/8" (15.9 m m)
No load speed 3800rpm
Miter 0°Max.Height2-23/32" (69 m m) *M ax.Height3-1/2" (89 m m)
Bevel0°M ax.Width 5-5/8" (143 m m)
(
*M ax.Width 3-5/8" (92 m m)
)
Miter 45°Max.Height2-23/32" (69 m m)
Max.Width 3-7/8" (98 m m)
Miter 0°Max.Height1-25/32" (45 m m)
Max.sawing LeftM ax.Width 5-5/8" (143 m m)
dimensions Bevel45°Miter 45°Max.Height1-25/32" (45 m m)
Max.Width 3-7/8" (98 m m)
Miter 0°Max.Height15/16" (24 m m)
RightM ax.Width 4-3/4" (120 m m)
Bevel45°Miter 45°M ax.Height15/16" (24 m m)
Max.Width 3-11/32" (85 m m)
Miter sa wing range Left0°–45°,Right0°–45°
Bevelsa wing range Left0°–45°,Right0°–45°
Co m pound sawing range Left(Bevel) 0°–45°,Leftand Right(Miter) 0°–45°
Right(Bevel) 0°–45°,Leftand Right(Miter) 0°–45°
Netw eight28.7 lbs.(13 kg)
Cord 2 Conductor type cabtire cable 6.6 ft(2 m)
*N ote:11/16" (17 m m) thick spacer board is required to be attached to the fence.
ACCESSORIES
WARNING:Accessories for this powertoolarementionedinthis Instruction Manual.
Theuseofany otherattachment or accessory canbedangerous and couldcauseinjury or
mechanicaldamage.
STANDARDACCESSORIES
Fig.3
eVise Assem bly (1 piece)
For ho w to use,refer to
pag e 15.
tWrench (1 piece)
q10 " (255 m m) TC T Sa w
blade (1 piece)
wDustBag (1 piece)
For ho w to use,refer to
pag e 19.
rExtension Stay (1 piece)
5 m m M achine Scre w (2
pieces)
For ho w to use,refer to
pag e 11.
(N o.of teeth 24 Code N o.
790004)

10
English
OPTIONAL ACCESSORIES...sold separately
qHolder Asse mbly (Fig.1) (Code No.317542)
wVise Asse m bly (Code No.317541)
eSa w blade 10" (255 m m) TCT Sa w blade for fine surface cut(Totalteeth:60) (Code No.976472)
rSa w blade 10" (255 m m) TCT Sa w blade for normalcut(Totalteeth:70) (Code No.976473)
WARNING:Using attachments or accessories not recommendedinthis manualcanbedangerous
and causepersonalinjury or mechanicaldamageto thesaw.
APPLICATIONS
Wood,plyw ood,color board,softfabric board,hard board similar m aterials and alu minu m sash.
PREPARATION BEFOREOPERATION
Make the follo wing preparations before operating the po w er tool:
1.Installation
Fig.4
Attach the power toolto a level,horizontalworkbench in accordance with Fig.4.
Select 5/16" (8 m m) diameter bolts suitable in length for the thickness of the workbench.
Bolt length should be atleast2" (50 m m) plus the thickness of the w orkbench.
For exa mple,use 5/16" (8 m m) ×3" (75 m m) bolts fota 1" (25 m m) thick w orkbench.
The extension stay attached to the rear of the base (see Fig.2) helps stabilize the power tool.
19-1/16 " (484 m m)
11-1/2"(292m m)
3/8" (10 m m),4 Holes
16-27/32" (428 m m )
5/16 " (8 m m) Bo lt
WorkBench5/16" (8 m m) N ut
Base

11
English
2.Releasing the plunger handle
Fig.5-a Fig.5-b
When the po wer toolis prepared for shipping,its main parts are secured by a plunger handle.M ove the
handle slightly so thatthe plunger handle can be disengaged and adjusted as indicated in Fig.5-b.
NOTE:Lowering thehandlesloghtlywill enableyou to disengagetheplungerhandlemoreeasily
and safely.
Thelockposition oftheplungerhandleis for carrying and storageonly.
For transportation purpose,grasp the handle (see Fig.1) with one hand and hold the base atthe leftend
grip section with the other hand to carry.
3.Installing the dustbag,miter handle,extension wing,stock stop and vises.
(The extension wing and stock stop are optionalaccessories).
Attach the dustbag,miter handle,extension wing,stock stop and vise assembly as indicated in Fig.1
and Fig.2.
(1) Asse m bly of cla mp lever
qInsertspring and scre w into the hole of the cla m p lever
as sho w n in Fig.6.
wAsse mble the cla m p lever to the handle collar,then
tighten the scre w as shown in Fig.7.
4.Installing the extension stay
(1) Insertthe extension stay into the hole of the base.
(2) Fasten the tw o 5 m m m achine screws and fix an extension stay as indicated in Fig.2.
Plunger Handle
Plunger Handle
Clock wise
Pull outto disengage.
Rotate th e kn o b 1/4 turn
and fit the pin stoppers
into the shallow slot.
Fig.6
During transport,fit the
plunger handle into the
deep slot.
N O TE:This position is notbe
used for any cuttin g
operation.
During operatio n fit the
plunger handle stoppers
into the shallow slot.
Fig.7
Clam p Lever
5 m m H ex.soc.hd.cap bolt (C)
(Stopper for 0°)
Scre w
Ha n dle
Collar
Clam p
Lever
Scre w S pring

12
English
Fig.8
BEFOREUSING
1.Make sure the power source is appropriate for the tool.
WARNING:Neverconnectthepowertoolunless theavailableAC powersourceis ofthesame
voltageas thatspecifiedon thenameplateofthetool.
Neverconnectthis powertoolto aDC powersource.
2.Make sure the trigger switch is turned OFF.
WARNING:Ifthepowercord is connectedto thepowersourcewith thetriggerswitchturned
ON thepowertoolwill start suddenlyand cancauseaserious accident.
3.Check the saw blade for visible defects.
Confirm thatthe sa w blade is free of cracks or other visible dam age.
4.Confirm thatthe saw blade is attached securely to the po wer tool.
Using the supplied wrench,tighten the bolt on the arbor shaftto secure the saw blade.For details,see Fig.
36-a,Fig.36-b and Fig.36-cin the section on “SAW BLADE M O U NTING AND DISMO U NTING ”.
5.Check the blade guards for proper operation.
Blade guards are designed to protect the operator from coming
into contact with the sa w blade during operation of the tool.
Always check thatthe blade guard (plastic) moves smoothly and
covers the saw blade properly.
WARNING:Neveroperatethepowertoolif thebladeguard (plastic)does not function smoothly.
6.Confirm the position of the spindle lock before using the tool.
After installing the saw blade,confirm thatthe spindle lock has been returned to the retract position
before using the po w er tool(see Fig.36-a).
7.Check the lower limit position of the Saw Blade.
Although it w as adjusted before ship ment,carefully check the heightof the saw blade.Confirm thatthe
saw blade can be lowered 1-1/32" to 1-3/32" (26 m m to 28 m m) below the table insert.For details,see
the section on “Checking the sa w blade lower limit position ”.
8.Check the Power Receptacle.
To preventoverheating,accidentalstopping or intermittentoperation,confirm thatthe pow er cord
plug fits properly in the electricalreceptacle and does notfall outafter it is inserted.Repair or replace
the receptacle if it is faulty.
9.Confirm the tool’s power cord is notdamaged.
Repair or replace the po w er cord if an inspection indicates thatit is damaged.
AFTERCONNECTING THE POWERPLUG TO AN APPROPRIATE AC POWERSOURCE,
CHECKTHE OPERATION OFTHE TOOL AS FOLLOWS:
10.TrialRun
After confirming thatno one is standing behind,the po wer toolstartand confirm thatno operating
abnormalities existbefore atte m pting a cutting operation.
11.Inspect the rotating stability of the saw blade.
For precise cutting,rotate the saw blade and check for deflection to confirm thatthe blade is notnoticeably
unstable;otherwise vibrations mightoccur and cause an accident.
Blade G uard
(M etal)
Blade G uard
(Plastic)

13
English
Fig.9
Fig.10
Fig.12
BEFORECUTTING
1.Cutting a groove on the table insert.
A groove has to be cutin the table insert,before starting
operation.Secure a piece of wood about5-1/8" (130 m m)
wide to the table with the vise asse m bly,to preventthe
breakage of the table insert.
After the switch has been turned on and the saw blade has
reached m axim u m speed,slo wly lower the handle to cuta
groove on the table insert.
CAUTION:D o n o t cu t t hegro o vetoo quickly;
otherwisethetableinsert might become
damaged.
2.Checking the saw blade lo wer limit position
WARNING:To prevent anaccident or personalinjury,always turn off thetriggerswitchand
disconnectthepowerplug from thereceptaclebeforeadjustment.
Check thatthe sa w blade can be lowered 1-1/32" to 1-3/32" (26 m m to
28 m m) b elow the table insert.
If necessary,adjustas follows:
(1) Loosen the 6 m m lock nuton the 6 m m depth adjustm entscrew.
(2) Turn th e 6 m m d epth adjustmentscrew as necessary to setthe lower
li mit p ositio n.T he sa w blad e g oe s u p w h e n the 6 m m d epth
adjustmentscrew is turned clockwise and do w n w hen it is turned
counterclockwise.
(3) Once the adjustmentis co mplete,fully tighten the 6 m m lock nut.
NOTE:Beforetightening the6 mm locknut,confirm thatthesaw
bladeis adjustedsothatitwill not cut into thetable.
3.Oblique angle
Before the po wer toolis shipped fro m the factory,it is adjusted for 0°,rightangle,left45°bevelcutting
angle and right45°bevelcutting angle with the 6 m m b olt (A),6 m m bolt (B) and the 5 m m hex.soc.hd.cap
bolt (C) (see Fig.7).
When changing the adjustment,change the heightof the 6 m m bolt (A),6 m m b olt (B) or the 5 m m hex.soc.
hd.cap bolt (C) (see Fig.7) by turning the m.
(Maximu m bevelcutting angle is 45°).
When changing the bevelangle to the right45°,pull up the locating bar on the direction shown in Fig.12
and incline the m otor head to the right.
When adjusting the m otor head to 0°,always return the locating bar to its initialposition.
Table Insert
Table
d
6 m m D epth
Adjustment
Scre w
6 m m Lock
Nut
Fig.11
6 m m B olt (A)
(Stopper for right45°be velangle)
Locating
Bar
Clam p Lever
Indicator
Be velAngle
Scale
6 m m B olt (B)
(Stopper for left45°
bev elangle)
5 m m H ex.soc.hd.cap bolt (C)
(Stopper for 0°)
Locating
Bar
Pull
Up
Clam p
Lever

14
English
Line Line
Warning Sign
Fig.14
Fig.15
4.Securing the w orkpiece
WARNING:Always clamp or viseto securetheworkpieceto thefence;otherwisetheworkpiece
might bethrustfrom thetableand causebodilyharm.
5.Installing the extension wings (O ptionalaccessory)
The extension wings help keep longer workpieces stable and in
place during the cutting operation.
(1) Insertthe 8 m m scre w into the hole located on the base.
(2) Setthe lock supportrod under the side of the base.
(3) Then with the 8 m m screw for the lock supportrod temporary
stop.
(4) Insertan extension wing into the tw o holes of the lock support
rod.
(5) Push an extension wing until it contact with the base.
(6) Fasten the 8 m m scre w and fix an extension wing.
CAUTION:Whentransporting or carrying thetool,do not
grasptheextension wing.
Thereis thedangeroftheextension wing slipping
out ofthebase.Graspthehandle(see Fig.1)
insteadoftheextension wing.
6.Stock stop for precision cutting (Stock stop is optionalaccessory)
The stock stop facilitates continuous precision cutting
in lengths of 10" to 16-21/32" (253 m m to 423 m m).To
install the stock stop,attach it to the extension wing with
the 6 m m wing bolt as shown in Fig.15.
PRACTICAL APPLICATIONS
WARNING:* To avoidpersonalinjury,neverremoveor placeaworkpieceon thetablewhilethetool
is being operated.
* Neverplaceyour limbs insideofthelinenext to warning sign whilethetoolis being
operated.This maycausehazardous conditions (see Fig.16).
Fig.16
Extension
Wing
Fig.13
Lock Support
Rod
Extension
Wing
Base
8 m m
Scre w
Extension Wing
6 m m W ing Bolt
Stock Stop
Warning Sig n

15
English
Fig.17
1.Switch operation
The switch lock is designed to preventinadvertentoperation of the
po wer tool.
To operate the power tool,it is necessary to firstpush up the switch
lock as sho wn in Fig.17.
The trigger switch will notoperate unless the switch lock has been
pushed up.W hen the trigger switch is released,the power goes off
and the switch lock auto matically returns to its initialposition,
locking the trigger switch.
WARNING:This will ensurethatthepowertoolcannot beturnedon accidentallyor by someone
(especiallyachild)who is not qualifiedto usethepowertool.
To prevent unauthorizedoperation ofthis tool,insert apadlockthrough theholein
theswitchtrigger.
2.Using the vise assem bly (Standard accessory)
(1) The vise asse m bly can be mounted on either the leftside
base or the rightside base,and can be raised or lo w ered
according to the heightof the workpiece.
qInsertsupportof vise asse m bly into the hole located on
either the leftside base or the rightside base.
wThen tighten 5 m m clam p bolt as sho wn in Fig.18.
NOTE:Thesupport has two locking grooves into which
thetipofthe5 mm clamp boltis designedto fit,to
locktheviseassemblyinthedesiredposition.
(2) The vise asse m bly can be mounted on either the leftside
fence or the rightside fence,and can be raised or lo wered
according to the heightof the workpiece.
qInsertsupportof vise asse m bly into the hole located on
either the leftside fence or the rightside fence.
wThen tighten 5 m m clam p bolt as sho wn in Fig.19.
CAUTION:Always confirm thatthemotor head(see Fig.1)does not contacttheviseassembly
whenitis loweredfor cutting.Ifthereis any dangerthatitmaydo so,loosenthe5
mm clamp boltslightlyand movetheviseassemblyto aposition whereitwill not
contactthesawblade.
Switch
Lock
Hole
Trigger
Switch
Base 5 m m
Clam p Bolt
Vise
Assem bly
Support
Fig.18
5 m m
Clam p Bolt
Fe nce
Support
Vise
Assem bly
Fig.19

16
English
3.Using the vise assem bly (O ptionalaccessory)
(1) The vise assem bly can be mounted on either the
leftside base or the rightside base,and can be
moved back and forth according to the width of the
workpiece.
Insertsupportof vise assem bly into the hole located
on either the leftside base or the rightside of the
base as show n in Fig.20.
4.Cutting Operation
(1) As sho wn in Fig.21 the width of the sa w blade is the
width of the cut.Therefore,slide the w orkpiece to the
right(vie w e d fro m the o perator’s positio n) w h en
length bis desired,or to the leftw hen length ais
desired.
(2) Once the sa w blade reaches maximum speed,push
th e h a n d le d o w n car ef ul l y u n ti l th e s a w b la d e
approaches the workpiece.
(3) Once the sa w blade contacts the workpiece,push the
handle down gradually to cutinto the w orkpiece.
(4) After cutting the workpiece to the desired depth,turn
th e p o w e r to olO F F a n d letth e s a w b la d e s to p
co m pletely b e fo r e r a isin g th e h a n d le fro m th e
workpiece to return it to the full retract position.
CAUTION:*Increasedpressureon thehandlewill not increasethecutting speed.
On thecontrary,too muchpressuremayresultinoverloadofthemotor and / or
decreasedcutting efficiency.
*Ifthehandleis presseddown with excessiveor lateralforce,thesawblademay
vibrateduring thecutting operation and causeunwantedcutting marks on the
workpiece,thus reducing thequality ofthecut.Accordingly,press thehandledown
gentlyand carefully.
WARNING:* Confirm thatthetriggerswitchis turnedOFF and thepowerplug has beenremoved
from thereceptaclewheneverthetoolis not inuse.
5.Miter cutting procedures
(1) Loosen the miter handle and push the spring plate.
(2) A djustth e table u ntil the in dicator aligns w ith the
desired setting on the miter angle scale as shown in
Fig.22.
(3) Re-tighten the miter handle to secure the table in the
desired position.
NOTE:*Positivestops areprovidedattheright and leftofthe0°centersetting,at15°,22.5°,31.6°,and
45°settings.
Checkthatthemiteranglescaleand thetipoftheindicator areproperlyaligned.
* Operation ofthepowertoolwith themiteranglescaleand indicator out ofalignment,or with
themiterhandlenot properlytightened,will resultinpoor cutting precision.
Fig.20
Vise
Assem blyBase
(Fro ntView)
Adjusting Line
ab
Marking
(pre-marked)
Marking
(pre-marked)
ab
ab
Table Insert
Fig.21
Workpiece
Fig.22
Miter A ngle
Scale
Indicator
Spring
Plate
Tighten
Turn the
Table
Loosen
Miter Handle

17
English
Fig.23
6.Bevelcutting procedures
(1) Loosen the cla mp lever and bevelthe saw blade to the
leftor to the right.
When tilting the motor head to the right,pull up the
locating bar as indicated in Fig.23.
(2) A djustthe bevelan gle to the desired settin g w h ile
w atching the bev ela n gle scale and in dicator,then
secure the clam p lever.
WARNING:Whentheworkpieceis securedon theleftor right sideoftheblade,theshort cut-off
portion will cometo reston theright or leftsideofthesawblade.Always turn the
poweroff and letthesawbladestop completelybeforeraising thehandlefrom the
workpiece.
Ifthehandleis raisedwhilethesawbladeis still rotating,thecut-off piecemay
becomejammedagainstthesawbladecausing fragments to scatterabout
dangerously.
7.Compound cutting procedures
For co mpound cutting,follo w the instructions in paragraphs 5 and 6 above.
For m axim um dim ensions for co m pound cutting,refer to “SPECIFICATIO N S ”table on page 9.
CAUTION:Always securetheworkpiecewith theright or lefthand sidefor compound cutting.
Neverrotatethetableto theright for compound cutting (leftbevel),becausethe
sawblademight thencontacttheclamp or visethatsecures theworkpiece,and
causepersonalinjury or damage.
Neverrotatethetableto theleftfor compound cutting (right bevel),becausethe
sawblademight thencontacttheclamp or visethatsecures theworkpiece,and
causepersonalinjury or damage.
8.Cro wn molding cutting procedures
Fig.24 shows tw o co m mon cro w n molding types having angles of (θ) 38°and 45°.
For the typicalcro w n molding fittings,see Fig.25.
Fig.24 Fig.25
The table belo w shows the miter angle and the bevelangle settings thatare idealfor the two cro wn
molding types.
NOTE:For convenience,positivestops areprovidedfor themitersetting (leftand right 31.6°)positions.
For miter cutsetting
If the table has been setto either of the angles described,m ove the table adjusting miter handle a little
to the rightand leftto stabilize the position and to properly align the miter angle scale and the tip of the
indicator before the operation starts.
For bevelcutsetting
Move handle on bevelsection to the rightand leftand check thatthe position is stable and thatthe
bevelangle scale and the tip of the indicator are properly aligned.Then tighten the cla m p lever.
Loosen
Clam p
Lever
Pull
Up
Locating Bar
Indicator
Be velAngle
Scale
Tighten
Ceiling
Wall
qw er
Wall
Aupper surface
Ceiling
Blow er surface
θ°

18
English
Type of To process cro wn m olding at To process crown m olding at
Crown M olding positions 1and 4in Fig.25. positions 2and 3in Fig.25.
Miter Angle BevelAngle Miter A ngle BevelAngle
Setting Setting Setting Setting
45°Type right35.3°left30°right30°left35.3°left30°right30°
38°Type right31.6°left33.9°right33.9°left31.6°left33.9°right33.9°
( mark) ( mark) ( mark) ( mark)
(1) Setting to cutcrown m oldings atpositions qand rin Fig.25 (see Fig.26):
qTurn the table to the rightand setthe Miter Angle as follows:
* For 45°type cro wn m oldings:35.3°
* For 38°type cro wn m oldings:31.6°
wTilt the head to the leftand setthe BevelA ngle as follows:
* For 45°type cro wn m oldings:30°
* For 38°type cro wn m oldings:33.9°( m ark)
ePosition the crown m olding so thatthe upper surface (Ain Fig.24) contacts the fence as indicated
in Fig.27.
(2) Setting to cutcrown m oldings atpositions wand ein Fig.25 (see Fig.28):
qTurn the table to the leftand setthe Miter Angle as follows:
* For 45°type cro wn m oldings:35.3°
* For 38°type cro wn m oldings:31.6°
wTilt the head to the leftand setthe BevelA ngle as follows:
* For 45°type cro wn m oldings:30°
* For 38°type cro wn m oldings:33.9°( m ark)
ePosition the cro wn molding so thatthe lo wer surface (Bin Fig.24) contacts the fence as in Fig.
29.
Fig.26 Fig.28
Fig.27 Fig.29
(3) Setting to cutcrown m oldings atpositions qand rin Fig.25 (see Fig.30):
qTurn the table to the rightand setthe Miter Angle as follows:
* For 45°type cro wn m oldings:35.3°
* For 38°type cro wn m oldings:31.6°
wTilt the head to the rightand setthe BevelA ngle as follows:
* For 45°type cro wn m oldings:30°
* For 38°type cro wn m oldings:33.9°( m ark)
ePosition the crown m olding so thatthe upper surface (Bin Fig.24) contacts the fence as indicated
in Fig.31.
q
Be vel
Angle Scale
r
Fe nce
Base
Miter A ngle Scale
Table
Head
Miter A ngle Scale
Be vel
Angle Scale
e
Base Table
Head
Fe nce
w
Table on Base
Fe nce
AB
Fe nce
Table on Base
BA

19
English
Fe nce
A
Table on Base
B
(4) Setting to cutcrown m oldings atpositions wand ein Fig.25 (see Fig.32):
qTurn the table to the leftand setthe Miter Angle as follows:
* For 45°type cro wn m oldings:35.3°
* For 38°type cro wn m oldings:31.6°
wTilt the head to the rightand setthe BevelA ngle as follows:
* For 45°type cro wn m oldings:30°
* For 38°type cro wn m oldings:33.9°( m ark)
ePosition the cro wn molding so thatthe lo wer surface (Ain Fig.24) contacts the fence as in Fig.
33.
Fig.30 Fig.32
Fig.31 Fig.33
9.Cutting easily-deformed materials,such as alu minu m sash
M aterials such as alu m in u m sas h ca n e asil y d e f or m w h e n
tightened too much in a vise assembly.This will cause inefficient
cutting and possible overload of the motor.
When cutting such materials,use a wood plate to protect the
workpiece as shown in Fig.34.
When cutting alu minu m materials,coatthe saw blade with cutting
oil (non-com bustible) to achieve sm ooth cutting and a fine finish.
10.Ho w to use the dustbag (Standard accessory)
(1) W hen the dustbag has beco me full of sawdust,dustwill be
blown outof the dustbag when the sa w blade rotates.
Check the dustbag periodically and empty it before it beco mes
full.
(2) During beveland com pound cutting,attach the dustbag ata
rightangle to the base surface as shown in Fig.35.
CAUTION:Empty thedustbagfrequentlyto prevent the
ductand thebladeguard (metal) from becoming
clogged.
Sawdustwill accumulatemorequicklythan
normalduring bevelcutting.
Fig.34
q
Be velAngle
Scale
r
Fe nce
BaseMiter A ngle Scale
Table
Head
Miter A ngle Scale
Be velAngle
Scale
e
Base Table
Head
Fe nce
w
Wood Plate
Vise
Assem bly
Wood Plate
5 m m
Clam p Bolt Aluminu m
Sash
Base Surface
Right
Angle
Blade G uard
(M etal)
DustBag
Fe nce
B
Table on Base
A
Fig.35

20
English
SAW BLADE MOUNTING AND DISMOUNTING
WARNING:To prevent anaccident or personalinjury,always turn off thetriggerswitchand disconnect
thepowerplug from thereceptaclebeforeremoving or installing asawblade.
1.Mounting the saw blade
(1) Rotate blade guard (plastic),to top position.
(2) Loosen 5 m m screw to free cutter shaftguard.
And rotate cutter shaftguard to the up position as shown in Fig.36-b.
Atthattime,the blade guard (plastic) m ove together.
(3) Press in spindle lock and loosen bolt with wrench.
Since the bolt is left-hand threaded,loosen by turning it to the rightas shown in Fig.36-b.
NOTE:Ifthespindlelockcannot beeasilypressedinto lockthearbor shaft,turn theboltwith
wrenchwhileapplying pressureon thespindlelock.
Thearbor shaftis lockedwhenthespindlelockis pressedinward.
(4) Rem ove the bolt and arbor collar.
(5) Mountthe saw blade.
WARNING:Whenmounting thesawblade,confirm thattherotation indicator markon thesaw
bladeand therotation direction ofthebladeguard (metal) areproperlymatched.
(6) Thoroughly clean collar,arbor collar,blade washer (confirm mounting direction) and the bolt,and
install them onto the arbor shaftas shown in Fig.36-c.
(7) Press in the spindle lock and tighten the bolt by turning it to the leftby wrench as indicated in Fig.
36-b.
CAUTION:* Confirm thatthespindlelockhas returnedto theretractposition afterinstalling or
removing thesawblade.
* Tightentheboltsoitdoes not comelooseduring operation.
Confirm thebolthas beenproperlytightenedbeforethepowertoolis started.
(8) Rotate the cutter shaftguard to the initialposition and tighten 5 m m screw.
(9) Place blade guard (plastic) in the do wn position.
Fig.36-a
Fig.36-c
Fig.36-b
Spindle
Lock
Wrench
Bolt
Saw Blade
Loosen
Tighten
Up
Blade G uard
(Plastic)
Cutter Shaft
Guard
5 m m Scre w
Arbor Collar
Bolt
Saw Blade
Blade Washer
5/8"(15.9m m)
Collar
Arbor
Collar
Arbor S h aft
SpotFacing
