Hitachi C 12RSH2 User manual

DOUBLE INSULATION
DOUBLE ISOLATION
AISLAMIENTO DOBLE
Model
Modèle
Modelo C 12RSH2
(Laser Marker Equipment)
(Outil avec marqueur à laser)
(Equipo marcador láser)
Slide Compound Miter Saw
Scie a coupe d’onglet radiale
Tronzadora radial abatible
SAFETY INSTRUCTIONS AND INSTRUCTION MANUAL
WARNING
IMPROPER OR UNSAFE use of this power tool can result in death or serious bodily injury!
This manual contains important information about product safety. Please read and understand
this manual before operating the power tool. Please keep this manual available for other users
and owners before they use the power tool.This manual should be stored in safe place.
INSTRUCTIONS DE SECURITE ET MODE D’EMPLOI
AVERTISSEMENT
Une utilisation INCORRECTE OU DANGEREUSE de cet outil motorisé peut entraîner la mort
ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de ce produit.
Prière de lire et de comprendre ce mode d’emploi AVANT d’utiliser l’outil motorisé. Garder ce
mode d’emploi à la disponibilité des autres utilisateurs et propriétaires avant qu’ils utilisent
l’outil motorisé. Ce mode d’emploi doit être conservé dans un endroit sûr.
INSTRUCCIONES DE SEGURIDAD Y MANUAL DE INSTRUCCIONES
ADVERTENCIA
¡La utilización INAPROPIADA O PELIGROSA de esta herramienta eléctrica puede resultar
en lesiones de gravedad o la muerte!
Este manual contiene información importante sobre la seguridad del producto. Lea y
comprenda este manual ANTES de utilizar la herramienta eléctrica. Guarde este manual para
que puedan leerlo otras personas antes de utilizar la herramienta eléctrica. Este manual debe
ser guardado en un lugar seguro.
0000BookC12RSH2.indb10000BookC12RSH2.indb1 2016/03/0118:07:282016/03/0118:07:28

2
CONTENTS
TABLE DES MATIERES
ÍNDICE
English
Français
Español
Page
I MPORTANT SAFETY INFORMATION .....................3
MEANINGS OF SIGNAL WORDS ............................3
SAFETY.......................................................................4
IMPORTANT SAFETY INSTRUCTIONS FOR
USING ALL POWER TOOLS .................................4
REPLACEMENT PARTS...........................................8
USE PROPER EXTENSION CORD..........................8
DOUBLE INSULATION FOR SAFER OPERATION ..9
OPERATION AND MAINTENANCE .........................10
NAME OF PARTS ...................................................10
SPECIFICATIONS...................................................12
ACCESSORIES ......................................................13
APPLICATIONS ......................................................14
PREPARATION BEFORE OPERATION ..................14
BEFORE USING.....................................................15
Page
INFORMATIONS IMPORTANTES DE
SÉCURITÉ...........................................................42
SIGNIFICATION DES MOTS
D’AVERTISSEMENT............................................42
SECURITE ................................................................43
CONSIGNES DE SECURITE RELATIVES AUX
OUTILS ÉLECTRIQUES ......................................43
PIECES DE RECHANGE........................................47
UTILISER LE CORDON DE RALLONGE
APPROPRIÉ ........................................................48
DOUBLE ISOLATION POUR UN
FONCTIONNEMENT PLUS SUR ........................48
UTILISATION ET ENTRETIEN .................................50
NOM DES PIÈCES .................................................50
SPÉCIFICATIONS...................................................52
ACCESSOIRES ......................................................53
Página
INFORMACIÓN IMPORTANTE SOBRE
SEGURIDAD........................................................83
SIGNIFICADO DE LAS PALABRAS DE
SEÑALIZACIÓN...................................................83
SEGURIDAD .............................................................84
NORMAS DE SEGURIDAD PARA LAS
HERRAMIENTAS ELÉCTRICAS..........................84
PIEZAS DE REEMPLAZO ......................................88
UTILICE EL CABLE PROLONGADOR
ADECUADO.........................................................89
AISLAMIENTO DOBLE PARA OFRECER UNA
OPERACIÓN MÁS SEGURA...............................89
OPERACIÓN Y MANTENIMIENTO...........................91
NOMENCLATURA DE PARTES .............................91
ESPECIFICACIONES .............................................93
ACCESORIOS........................................................94
APLICACIONES......................................................95
Page
BEFORE CUTTING ................................................17
PRACTICAL APPLICATIONS..................................23
SAW BLADE MOUNTING AND
DISMOUNTING ...................................................37
MAINTENANCE AND INSPECTION.......................38
SERVICE AND REPAIRS........................................41
PARTS LIST ...........................................................125
Page
APPLICATIONS ......................................................54
PRÉPARATION AVANT L’UTILISATION..................54
AVANT L’UTILISATION............................................55
AVANT LA COUPE..................................................57
APPLICATIONS PRATIQUES .................................64
INSTALLATION ET RETRAIT DE LA LAME............78
ENTRETIEN ET INSPECTION................................80
SERVICE APRÈS-VENTE ET RÉPARATIONS........82
LISTE DES PIECES ...............................................125
Página
PREPARATIVOS PREVIOS A LA
OPERACIÓN........................................................95
ANTES DE LA UTILIZACIÓN..................................96
ANTES DEL CORTE...............................................98
APLICACIONES PRÁCTICAS ..............................105
MONTAJE Y DESMONTAJE DE LA
HOJA DE SIERRA .............................................119
MANTENIMIENTO E INSPECCIÓN......................121
SERVICIO Y REPARACIONES .............................124
LISTA DE PIEZAS ..................................................125
0000BookC12RSH2.indb20000BookC12RSH2.indb2 2016/03/0118:07:292016/03/0118:07:29

3
English
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in the
Instruction Manual before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure
to observe basic safety rules or precautions. An accident can often be avoided by recognizing a
potentially hazardous situation before it occurs, and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in
the sections which contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by
WARNINGS on the power tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by
HITACHI.
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death
or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in
minor or moderate injury, or may cause machine damage.
NOTE emphasizes essential information.
0000BookC12RSH2.indb30000BookC12RSH2.indb3 2016/03/0118:07:292016/03/0118:07:29

4
English
SAFETY
IMPORTANT SAFETY INSTRUCTIONS
FOR USING ALL POWER TOOLS
READ ALL OF THE WARNINGS AND OPERATING INSTRUCTIONS IN THIS
MANUAL BEFORE OPERATING OR MAINTAINING THIS TOOL:
WARNING: When using this electric tool, take all necessary precautions to minimize
the risk of electric shock or other personal injury.
In particular, always comply with the following safety rules:
1. ALWAYS KEEP GUARDS IN PLACE and in working order.
2. ALWAYS REMOVE ADJUSTING KEYS AND WRENCHES BEFORE STARTING TOOL.
Always confirm that all keys and adjusting wrenches have been removed from the tool
before it is turned on.
3. ALWAYS KEEP WORK AREA CLEAN. Avoid injuries by not cluttering the work areas and
work benches.
4. NEVER USE TOOL IN HAZARDOUS ENVIRONMENTS. Never use the power tool in damp
or wet places and never expose it to rain. Always keep the work area well lighted.
5. NEVER PERMIT CHILDREN OR OTHERS TO LOITER NEAR THE WORK AREA. Keep
all people (especially children) away from the work area. Always unplug unattended tools
and keep the work place tamper-proof by installing locks on the doors and on the master
switches. Always remove the lock-offbutton from the tool and store it in a secure place,
when the tool is not in use.
6. NEVER FORCE THE TOOL. It will do the job better and more safely if it is operated at the
rate for which it was designed.
7. ALWAYS USE THE RIGHT TOOLS. Never force a tool or an attachment to do a job for
which it was not designed.
8. ALWAYS WEAR PROPER APPAREL WHEN WORKING WITH THE TOOL. Never wear
loose clothing, gloves, neckties, rings, bracelets or other jewelry which may get caught in
the moving parts. Always wear non-slip footwear, preferably with steel toes. Wear protective
hair covering to contain long hair.
9. ALWAYS WEAR EYE PROTECTION WITH SIDE SHIELDS THAT MEETS THE
REQUIREMENTS OF ANSI STANDARD Z87.1 WHEN WORKING WITH THE TOOL TO
PREVENT EYE INJURY. Ordinary eyeglasses do not provide adequate protection because
they do not contain impact resistant safety glass. Also, use a face mask for additional safety
and wear a dust mask if the cutting operation produces dust.
10. ALWAYS SECURE THE WORKPIECE TO THE FENCE OR THE TABLE. Use clamps or a
vise to hold the workpiece in place. It is safer than using your hand and it frees both hands
to operate the tool.
0000BookC12RSH2.indb40000BookC12RSH2.indb4 2016/03/0118:07:292016/03/0118:07:29

5
English
11. NEVER OVERREACH. Always keep proper footing and balance when working with the
tool.
12. ALWAYS MAINTAIN TOOLS WITH CARE. Always keep tools sharp and clean for the best
and safest performance. Always follow instructions for lubricating the tool and for changing
accessories.
13. ALWAYS DISCONNECT THE TOOL before servicing and before changing blades or other
accessories.
14. NEVER RISK UNINTENTIONAL STARTING WHEN PLUGGING IN THE TOOL. Always
confirm that the switch is in the OFF position before inserting the power plug into the
receptacle.
15. ALWAYS USE RECOMMENDED ACCESSORIES ONLY WHEN OPERATING THIS TOOL.
Consult this instruction manual for descriptions of recommended accessories. To avoid
personal injuries, use only recommended accessories in conjunction with this tool.
16. NEVER STAND ON THE TOOL. Prevent serious injury by not tipping the tool and by not
risking unintentional contact with the saw blade.
17. ALWAYS CHECK FOR DAMAGED PARTS BEFORE USING THE TOOL. Always check
the guard and all other components for damage before using the tool to assure that they will
function properly. Check all moving parts for proper alignment, freedom from binding and
other conditions that might affect proper operation. Always repair or replace any damaged
guards or other damaged components before using the tool.
18. ALWAYS CONFIRM THE ROTATION DIRECTION OF THE BLADE BEFORE USING THE
TOOL. Always feed work into the tool against the rotation direction of the blade in order to
prevent possible injury.
19. NEVER LEAVE THE TOOL RUNNING WHILE UNATTENDED. TURN POWER OFF. Do
not leave tool until it comes to a complete stop. Always turn the power offwhen the tool is
not in use. Always unplug the power cord when the tool is not in use.
20. This tool was not designed to be used for mass-production applications and should not be
used in mass-production environments.
21. When servicing this tool, use only authorized replacement parts.
22. Apply 120 volts AC only to this tool. Applying the wrong voltage or applying DC power
can cause the POWER TOOL to operate improperly and cause serious personal injury or
damage to the tool.
23. Never raise the saw blade from the workpiece until it has first come to a complete stop.
24. Always use outboard stands to provide support for long workpieces that overhang the table
of the slide compound miter saw.
25. Always return the carriage to the full rear position after each crosscut operation in order to
reduce the risk of injury.
26. POLARIZED PLUGS To reduce the risk of electric shock, this equipment has a polarized
plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician to install the proper outlet. Do not change the plug in any way.
Specific Safety Rules for Use of this Power Tool
WARNING: The following specific operating instructions must be observed when
using this POWER TOOL in order to avoid injury:
0000BookC12RSH2.indb50000BookC12RSH2.indb5 2016/03/0118:07:292016/03/0118:07:29

6
English
DO’s
ALWAYS OBSERVE THE FOLLOWING RULES TO ASSURE SAFE USE OF THIS TOOL:
1. Review this Manual and familiarize yourself with the safety rules and operating instructions
for this POWER TOOL before attempting to use it.
2. Remove all packing materials attached or connected to the tool before attempting to operate
it.
3. Always confirm that the POWER TOOL is clean before using it.
4. Always wear snug-fitting clothing, non-skid footwear (preferably with steel toes) and eye
protection when operating the POWER TOOL.
5. Always handle the POWER TOOL carefully. If the POWER TOOL falls or strikes against a
hard object, it might become deformed or cracked or sustain other damage.
6. Always cease operating the saw at once, if you notice any abnormality whatsoever.
7. Always confirm that all components are mounted properly and securely before using the
tool.
8. When replacing the saw blade, always confirm that the rpm rating of the new blade is correct
for use on this tool.
9. Always shut offthe power and wait for the saw blade to completely stop rotating before
doing any maintenance or adjustments.
10. During slide cutting, always push the saw blade away from the operator.
11. Always clamp or otherwise secure the workpiece to the fence; otherwise the workpiece
might be thrust form the table and cause bodily harm.
12. During miter or bevel cutting, always wait for the rotation of the blade to stop completely
before lifting the saw blade.
13. Always make a trial run first before attempting any new use of the saw.
14. Always handle the saw blade with care when dismounting and mounting it.
15. Always confirm that the workpiece is free of nails or other foreign objects before beginning
a cut.
16. Always keep your hands out of the path of the saw blade.
17. Always confirm that the lower guard is in the proper place before using the saw.
18. Always confirm that the lower guard does not obstruct the sliding motion of the saw before
attempting slide cutting.
19. Inspect the tool power cords periodically.
20. Always confirm that the proper lengths and types of extension cords are being utilized, if
necessary, before starting the tool.
21. Always confirm that the motor air vents are fully open before using the tool.
22. Always wait until the motor has reached full speed before starting a cut.
23. Always keep the handles dry, clean and free of oil and grease. Hold the tool firmly when in
use.
24. Always use outboard stands to provide support for long workpieces that overhang the table
of the slide compound miter saw.
25. Always operate the tool after ensuring the workpiece is fixed properly with a vise assembly.
26. The operating instructions provided with the tool shall direct the user to secure the tool to
supporting structure if, during normal operation, there is a tendency for the tool to tip over,
slide, or walk on the supporting surface.
0000BookC12RSH2.indb60000BookC12RSH2.indb6 2016/03/0118:07:292016/03/0118:07:29

7
English
DON’Ts
NEVER VIOLATE THE FOLLOWING RULES TO ASSURE SAFE USE OF THIS TOOL:
1. Never operate the POWER TOOL unless you fully understand the operating instructions
contained in this Manual.
2. Never leave the POWER TOOL unattended without first unplugging the power cord.
3. Never operate the POWER TOOL when you are tired, after you have taken any medications,
or have consumed any alcoholic beverages.
4. Never use the POWER TOOL for applications not specified in the instruction manual.
5. Never operate the tool while wearing loose clothing, a necktie or jewelry, or while your hair
is uncovered, to protect against getting caught in the moving machinery.
6. Never reach around the saw blade.
7. Never touch any moving parts, including the blade, while the saw is in use.
8. Never remove any safety devices or blade guards; use of the tool without them would be
hazardous.
9. Never lock the lower guard; always confirm that it slides smoothly before using the tool.
10. Never damage the power cord of the tool.
11. Never attempt to move a plugged-in POWER TOOL while your finger is on the starting
switch.
12. Never use the POWER TOOL if the starting switch does not turn on and offproperly.
13. Never use the POWER TOOL if the plastic housing or the handle is cracked or deformed.
14. Never use the POWER TOOL near flammable liquids or gases because sparking can cause
an explosion.
15. Never clean plastic components with solvents because the plastic may dissolve.
16. Never operate the saw unless all the blade guards are in place.
17. Never raise the saw blade from the workpiece until it has first come to a complete stop.
18. When slide cutting, never pull the handle toward the operator, since this could cause the
saw blade to kick up from the workpiece. Always push the handle away from the operator in
a single, smooth motion.
19. Never place your limbs inside of the line next to warning sign “ ” while the tool is being
operated. This may cause hazardous conditions.
20. Never use abrasive type blades on this saw.
21. Never expose to rain or use in damp locations.
22. Never cut ferrous metals or masonry.
WARNING
FORYOUR OWN SAFETY READTHIS INSTRUCTION MANUAL BEFORE OPERATING
THE SLIDE COMPOUND MITER SAW
1. Always wear eye protection when using the slide compound miter saw.
2. Always keep hands out of the path of the saw blade.
3. Never operate the saw without the guards in place.
4. Never perform any freehand operation with the slide compound miter saw.
5. Never reach around the saw blade.
0000BookC12RSH2.indb70000BookC12RSH2.indb7 2016/03/0118:07:292016/03/0118:07:29

8
English
6. Always turn offtool and wait for saw blade to stop before moving workpiece or changing
settings.
7. Always disconnect power before changing blade or servicing.
8. Saw blade diameter is 12" (305 mm).
9. No load speed is 4,000/min.
10. To reduce the risk of injury, return carriage to the full rear position after each crosscut
operation.
REPLACEMENT PARTS
When servicing use only identical replacement parts.
Repairs should be conducted only by a Hitachi authorized service center.
USE PROPER EXTENSION CORD
Make sure your extension cord is in good condition. When using an extension cord, be sure to
use one heavy enough to carry the current your product will draw. An undersized cord will cause
a drop in line voltage resulting in loss of power and overheating. Table shows the correct size to
use depending on cord length and nameplate ampere rating. If in doubt, use the next heavier
gage. The smaller the gage number, the heavier the cord.
MINIMUM GAGE FOR CORD SETS
Total Length of Cord in Feet (Meter)
0 – 25
(0 – 7.6)
26 – 50
(7.9 – 15.2)
51 – 100
(15.5 – 30.5)
101 – 150
(30.8 – 45.7)
Ampere Rating AWG
More
Than
Not More
Than
0 – 6 18 16 16 14
6 – 10 18 16 14 12
10 – 12 16 16 14 12
12 – 16 14 12
Not Recommended
WARNING: Avoid electrical shock hazard. Never use this tool with a damaged or
frayed electrical cord or extension cord.
Inspect all electrical cords regularly. Never use in or near water or in
any environment where electric shock is possible.
0000BookC12RSH2.indb80000BookC12RSH2.indb8 2016/03/0118:07:292016/03/0118:07:29

9
English
DOUBLE INSULATION FOR SAFER OPERATION
To ensure safer operation of this power tool, HITACHI has adopted a double insulation design.
“Double insulation” means that two physically separated insulation systems have been used to
insulate the electrically conductive materials connected to the power supply from the outer frame
handled by the operator. Therefore, either the symbol “ ” or the words and “Double insulation”
appear on the power tool or on the nameplate.
Although this system has no external grounding, you must still follow the normal electrical
safety precautions given in this Instruction Manual, including not using the power tool in wet
environments.
To keep the double insulation system effective, follow these precautions:
* Only HITACHI AUTHORIZED SERVICE CENTER should disassemble or assemble this power
tool, and only genuine HITACHI replacement parts should be installed.
* Clean the exterior of the power tool only with a soft cloth moistened with soapy water and dry
thoroughly.
* Never use solvents, gasoline or thinners on plastic components; otherwise the plastic may
dissolve.
SAVE THESE INSTRUCTIONS
AND
MAKE THEM AVAILABLE TO
OTHER USERS
AND
OWNERS OF THIS TOOL!
0000BookC12RSH2.indb90000BookC12RSH2.indb9 2016/03/0118:07:292016/03/0118:07:29

10
English
OPERATION AND MAINTENANCE
NOTE: The information contained in this Instruction Manual is designed to assist you
in the safe operation and maintenance of the power tool. Some illustrations in
this Instruction Manual may show details or attachments that differ from those
on your own power tool.
NAME OF PARTS
MODEL C12RSH2
Hinge
Clamp lever
Sub fence (B)
Nameplate
Side handle
Lever
Dust bag
Locking pin
Holder (A)
Laser marker
Set pin (A)
Vise assembly
Fence (B)
Base
Motor
Gear case
Handle
Spindle cover
Lower guard
Saw blade
Sub fence (A)
Fence (A)
5 mm machine
screw
Table insert
Turntable
Indicator
(For miter scale)
Rotation
direction
Indicator
(For right bevel scale)
Motor head
Fig. 1
0000BookC12RSH2.indb100000BookC12RSH2.indb10 2016/03/0118:07:292016/03/0118:07:29

11
English
Lever
Guard
Trigger switch
Spindle lock
Adjuster (For laser marker)
Indicator (For left bevel scale)
Slide securing knob
Holder
Base
Clamp lever
Holder (A)
Laser marker switch
Side handle
Fig. 2
0000BookC12RSH2.indb110000BookC12RSH2.indb11 2016/03/0118:07:302016/03/0118:07:30

12
English
SPECIFICATIONS
Item Model C 12RSH2
Motor Type Series commutator motor
Power source Single-phase AC 60Hz
Voltage (Volts) 120
Full-load current (Amp) 15
Laser Marker Maximum output <1mW CLASS Laser Product
Wave length 400 – 700 nm
Laser medium Laser Diode
Applicable saw
blade Outside Dia. 12" (305 mm) Hole Dia. 1" (25.4 mm)
No load speed 4,000/min
Max.
sawing
dimension
Head Turntable Max. sawing dimension
Miter 0 0
*
Max. Height
Max. Width
or
Max. Height
Max. Width
4-3/16" (107 mm)
12-1/4" (312 mm)
4-11/16" (120 mm)
10-3/16" (260 mm)
With aux. board 1" (25 mm)
0 Left 45°
or
Right 45° *
Max. Height
Max. Width
or
Max. Height
Max. Width
4-3/16" (107 mm)
8-5/8" (220 mm)
4-11/16" (120 mm)
7-1/16" (180 mm)
With aux. board 1" (25 mm)
0Right57°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
4-3/16" (107 mm)
6-11/16" (170 mm)
4-3/4" (120 mm)
5-1/8" (130 mm)
With aux. board 1" (25 mm)
Bevel Left 45° 0
*
Max. Height
Max. Width
or
Max. Height
Max. Width
2-3/4" (70 mm)
12-1/4" (312 mm)
2-15/16" (75 mm)
10-3/16" (260 mm)
With aux. board 1" (25 mm)
Right 45° 0
*
Max. Height
Max. Width
or
Max. Height
Max. Width
1-3/4" (45 mm)
12-1/4" (312 mm)
1-15/16" (50 mm)
10-3/16" (260 mm)
With aux. board 1" (25 mm)
Compound Left 45° Left 45°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
2-3/4" (70 mm)
8-5/8" (220 mm)
2-15/16" (75 mm)
7-1/16" (180 mm)
With aux. board 1" (25 mm)
Left 45° Right 31°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
2-3/4" (70 mm)
10-7/16" (265 mm)
2-15/16" (75 mm)
8-11/16" (220 mm)
With aux. board 1" (25 mm)
Right 45° Right 45°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
1-3/4" (45 mm)
8-5/8" (220 mm)
1-15/16" (50 mm)
7-1/16" (180 mm)
With aux. board 1" (25 mm)
Right 45° Left 31°
*
Max. Height
Max. Width
or
Max. Height
Max. Width
1-3/4" (45 mm)
10-7/16" (265 mm)
1-15/16" (50 mm)
8-5/8" (220 mm)
With aux. board 1" (25 mm)
Miter sawing range Left 0° – 45° Right 0° – 57°
Bevel sawing range Left 0° – 45° Right 0° – 45°
Compound sawing range Left (Bevel) 0° – 45°, Left (Miter) 0° – 45°, Right (Miter) 0° – 31°
Right (Bevel) 0° – 45°, Right (Miter) 0° – 45°, Left (Miter) 0° – 31°
Net weight 59.5 lbs. (27 kg)
Cord 2 Conductor type cable 6ft. (1.8 m)
0000BookC12RSH2.indb120000BookC12RSH2.indb12 2016/03/0118:07:302016/03/0118:07:30

13
English
When cutting the workpiece which has the dimension of “*” there might be some possibility of
the lower end of the circular saw to touch with the workpiece, even if the motor head is located
at the lower limit position. Pay attention when cutting the workpiece. For further details, refer
to “PRACTICAL APPLICATIONS” on page 23. Mount the auxiliary board on the fence surface
(Refer ( ) the thickness of auxiliary board). Refer to "5. Cutting large workpieces" on page 27
(Fig. 26).
ACCESSORIES
WARNING: Accessories for this power tool are mentioned in this Instruction
Manual.
The use of any other attachment or accessory can be dangerous and
could cause injury or mechanical damage.
STANDARD ACCESSORIES
2Dust bag (1 piece)
112" (305 mm) TCT Saw blade
(1 piece) (For wood)
For how to use, refer to page 36.
417 mm Wrench (1 piece)
3Vise Assembly w/knob bolt
(1 piece)
For how to use, refer to page 25.
5Holder (1 piece)
For how to use, refer to page 14.
Fig. 3
OPTIONAL ACCESSORIES...sold separately
1Extension Holder and Stopper (Code No. 324369)
2Crown molding Vise Ass’y (Code No. 321434) (Include Crown molding Stopper (L))
3Crown molding Stopper (L) (Code No. 321374)
4 Crown molding Stopper (R) (Code No. 321373)
NOTE: Accessories are subject to change without any obligation on the part of the
HITACHI.
0000BookC12RSH2.indb130000BookC12RSH2.indb13 2016/03/0118:07:302016/03/0118:07:30

14
English
APPLICATIONS
Wood and aluminum sash.
PREPARATION BEFORE OPERATION
Make the following preparations before operating the power tool:
1. Remove all packing materials attached or connected to the tool before attempting to operate
it.
2. Installation
11-1/18"
(282 mm)
11/32" (9 mm)
4 holes
10-1/16" (255.5 mm)
12-7/8"
(327 mm)
1" (25 mm) thick bench
Work bench 5/16" (8 mm) nut
5/16" (8mm) boltBase
Fig. 4
Attach the power tool to a level, horizontal work bench in accordance with Fig. 4.
Select 5/16" (8 mm) diameter bolts suitable in length for the thickness of the work bench.
Bolt length should be at least 1-9/16" (40 mm) plus the thickness of the work bench.
For example, use 2-9/16" (65 mm) or larger bolts for a 1" (25 mm) thick work bench.
The holder attached to the rear of the base helps stabilize the power tool.
Holder adjustment:
Loosen the 6 mm bolt with the 10 mm box
wrench.
Adjust the holder until its bottom surface
contacts the work bench surface.
After adjustment, firmly tighten the 6 mm
bolt.
6 mm
Bolt
Move
Adjust the holder until its bottom surface contacts the
work bench surface.
Fig. 5
Holder
0000BookC12RSH2.indb140000BookC12RSH2.indb14 2016/03/0118:07:302016/03/0118:07:30

15
English
3. Releasing the locking pin
When the power tool is prepared for
shipping, its main parts are secured by a
locking pin.
Move the handle slightly so that the locking
pin can be disengaged.
NOTE: Lowering the handle slightly
will enable you to disengage
the locking pin more easily and
safely.
The lock position of the locking
pin is for carrying and storage
only.
4. Installing the dust bag, holder, stopper and vises
(The holder and stopper are optional accessories.)
Attach the dust bag and vise assembly as indicated in Fig. 1 and Fig. 2.
BEFORE USING
1. Make sure the power source is appropriate for the tool.
WARNING: Never connect the power tool unless the available AC power
source is of the same voltage as that specified on the nameplate
of the tool.
Never connect this power tool to a DC power source.
2. Make sure the trigger switch is turned OFF.
WARNING: If the power cord is connected to the power source with the
trigger switch turned ON the power tool will start suddenly and
can cause a serious accident.
3. Check the saw blade for visible defects.
Confirm that the saw blade is free of cracks or other visible damage.
4. Confirm that the saw blade is attached securely to the power tool.
Using the supplied 17 mm wrench, tighten the 10 mm bolt on the saw blade spindle to
secure the saw blade.
For details, see Fig. 50-a, Fig. 50-b, Fig. 50-c and Fig. 50-d in the section on “SAW BLADE
MOUNTING AND DISMOUNTING”.
Pull
Locking pin
Handle
Fig. 6
0000BookC12RSH2.indb150000BookC12RSH2.indb15 2016/03/0118:07:302016/03/0118:07:30

16
English
5. Check the lower guard for proper operation.
Lower guard is designed to protect the operator from
coming into contact with the saw blade during operation
of the tool.
Always check that the lower guard moves smoothly and
covers the saw blade properly.
WARNING: NEVER OPERATE THE POWER TOOL if the lower guard does not
function smoothly.
6. Confirm the position of the spindle lock before using the tool.
After installing the saw blade, confirm that the spindle lock has been returned to the retract
position before using the power tool (see Fig. 2).
7. Check the lower limit position of the Saw Blade.
Although it was adjusted before shipment, carefully check the height of the saw blade.
Confirm that the saw blade can be lowered 23/64" to 7/16" (9 mm to 11 mm) below the table
insert. For details, see the section on “Checking the saw blade lower limit position”.
8. Check the Power Receptacle.
To prevent overheating, accidental stopping or intermittent operation, confirm that the
power cord plug fits properly in the electrical receptacle and does not fall out after it is
inserted. Repair or replace the receptacle if it is faulty.
9. Confirm the tool’s power cord is not damaged.
Repair or replace the power cord if an inspection indicates that it is damaged
10. Eye protection
Always wear eye protection with side shields that meets the requirements of ANSI Standard
Z87.1. Ordinary eyeglasses do not provide adequate protection because they do not contain
impact resistant safety glass.
WARNING: Operating the tool without wearing proper eye protection may
result in serious injury.
11. Electric brake
This tool is equipped with an electric brake which will typically stop the blade within 5
seconds after the trigger switch is released.
Occasionally, there will be a delay in the brake engaging which will result in a longer blade
stopping time. On rare occasions, the brake may not engage at all and the saw blade will
coast to a stop.
If the brake fails to engage frequently, depress and release the trigger switch to turn the tool
on and off4 or 5 times. If the brake still does not engage, have the tool serviced at a Hitachi
authorized service center.
Lower guard
Fig. 7
0000BookC12RSH2.indb160000BookC12RSH2.indb16 2016/03/0118:07:312016/03/0118:07:31

17
English
Always confirm that the saw blade has completely stopped before raising it from the
workpiece.
The brake is not a substitute for a properly functioning lower guard. Check the function of
the lower guard before each use. Serious personal injury may occur if the lower guard does
not move smoothly and cover the blade properly.
WARNING: Please be aware of the reaction of the Motor Head (Fig.1) when
the brake is activated. Braking causes the Motor Head to jerk
downward and the user should be prepared for this reaction,
especially when the trigger switch is released before the blade is
completely down. Failure to be familiar with, and prepared for, the
operational characteristics of the tool may cause serious injury.
AFTER CONNECTING THE POWER PLUG TO AN APPROPRIATE AC
POWER SOURCE, CHECK THE OPERATION OF THE TOOL AS FOLLOWS:
12. Trial Run
After confirming that no one is standing behind, the power tool start and confirm that no
operating abnormalities exist before attempting a cutting operation.
13. Inspect the rotating stability of the saw blade.
For precise cutting, rotate the saw blade and check for deflection to confirm that the blade
is not noticeably unstable; otherwise vibrations might occur and cause an accident.
BEFORE CUTTING
1. Positioning the table insert
Table insert Table insert
Saw blade
Table insert
Saw blade
Saw blade
5 mm
machine
screw
5 mm
machine
screw
[Right angle cutting]
Fig. 8-a
[Left bevel angle cutting]
Fig. 8-b
[Right bevel angle cutting]
Fig. 8-c
5 mm
machine
screw
Table inserts are installed on the turntable. When shipping the tool from the factory, the
table inserts are so fixed that the saw blade does not contact them. The burr of the bottom
surface of the workpiece is remarkably reduced, if the table insert is fixed so that the gap
between the side surface of the table insert and the saw blade will be minimum. Before
using the tool, eliminate this gap in accordance with the following procedure.
0000BookC12RSH2.indb170000BookC12RSH2.indb17 2016/03/0118:07:312016/03/0118:07:31

18
English
(1) Right angle cutting
Loosen the three 5 mm machine screws, then secure the left side table insert and
temporarily tighten the 5 mm machine screws of both ends. Then fix a workpiece
(about 7-7/8" (200 mm) wide) with the vise assembly and cut it off. After aligning the
cutting surface with the edge of the table insert, securely tighten the 5 mm machine
screws of both ends. Remove the workpiece and securely tighten the 5 mm center
machine screw. Adjust the right hand table insert in the same way.
(2) Left and right bevel angle cutting
Adjust the table insert in the manner shown in Fig. 8-b and Fig. 8-c following the same
procedure for right angle cutting.
CAUTION: After adjusting the table insert for right angle cutting, the
table insert will be cut to some extent if it is used for bevel
angle cutting.
When bevel cutting operation is required, adjust the table
insert for bevel angle cutting.
2. Checking the saw blade lower limit position
Check that the saw blade can be lowered 23/64" to 7/16" (9 mm to 11 mm) below the table
insert as shown in Fig. 9-a.
When you replace a saw blade with a new one, adjust the lower limit position so that the saw
blade will not cut the turntable or complete cutting cannot be done.
To adjust the lower limit position of the saw blade, follow the procedure (1) indicated below.
(Fig. 9-b)
Furthermore, when changing the position of a 8 mm depth adjustment bolt that serves as a
lower limit position stopper of the saw blade.
(1) Turn the 8 mm depth adjustment bolt,
change the height where the bolt head and
the hinge contacts, and adjust the lower
limit position of the saw blade.
NOTE: Confirm that the saw blade is
adjusted so that it will not cut into
the turntable.
Gear case
8 mm depth
adjustment
bolt
Saw blade
Turntable
Fig. 9-a
Hinge
Fig. 9-b
8 mm depth
adjustment bolt
Turn
Hinge
Gear case
0000BookC12RSH2.indb180000BookC12RSH2.indb18 2016/03/0118:07:312016/03/0118:07:31

19
English
3. Lower limit position of saw blade when cutting a large workpiece
NOTE: When cutting a workpiece exceeding 4-7/32" (107 mm) in height in right-
angle cutting or 2-3/4"(70 mm) in left bevel angle cutting or 1-3/4" (45 mm)
in right bevel angle cutting, adjust the lower limit position so that the base
of the motor head (see Fig. 9-a) will not come in contact with the workpiece.
To adjust the lower limit position of the saw blade, follow the procedure (1) shown in Fig. 9-a.
○Lower the motor head, and turn the 8 mm depth adjustment bolt and make adjustments
so that there can be a clearance of 5/64" to 1/8" (2 mm to 3 mm) between the lower limit
position of the motor head and the top of the workpiece at the saw blade’s lower limit
position where the head of the 8 mm depth adjustment bolt contacts the hinge.
4. Confirmation for use of sub fence (A)
WARNING: When right angle cutting, loosen the 6 mm wing bolt, then slide
the sub fence (A) outward and remove it.
Failure to do so may result in the main body or saw blade coming
into contact with the sub fence (A) and causing injury.
This power tool is equipped with a sub fence
(A).
In the case of direct angle cutting and left bevel
angle cutting, use the sub fence (A). Then, you
can realize stable cutting of the material with a
wide back face.
When right angle cutting, loosen the 6 mm
wing bolt, then slide the sub fence (A) outward
and remove it, as shown in Fig. 10.
5. Confirmation for use of sub fence (B)
WARNING: When left angle cutting, loosen the 6 mm wing bolt, then slide the
sub fence (B) outward.
Failure to do so may result in the main body or saw blade coming
into contact with the sub fence (B) and causing injury.
This power tool is equipped with a sub fence
(B). In the case of direct angle cutting and
right bevel angle cutting, use the sub fence
(B). Then, you can realize stable cutting of the
material with a wide back face. When left angle
cutting, loosen the 6 mm wing bolt, then slide
the sub fence (B) outward, as shown in Fig. 11.
Fig. 10
Fence (A)
6 mm wing bolt
Sub fence (A)
6 mm wing bolt
Sub fence (B)
Fence (B)
Fig. 11
0000BookC12RSH2.indb190000BookC12RSH2.indb19 2016/03/0118:07:322016/03/0118:07:32

20
English
6. Oblique angle
Before the power tool is shipped from the factory, it is adjusted for 0°, right angle, left 45°
bevel cutting angle and right 45° bevel cutting angle with the 8 mm set screw, 8 mm bolt (A)
and 8 mm bolt (B).
When changing the adjustment, change the height of the 8 mm set screw, 8 mm bolt (A), or
8 mm bolt (B) by turning them.
When changing the bevel angle to the right 45°, pull the set pin (A) on the direction shown in
Fig. 12-b and incline the motor head to the right.
When adjusting the motor head to 0°, always return the set pin (A) to its initial position as
shown in Fig. 12-b.
Fig. 12-a
8 mm bolt (A)
(Stopper for left 45° bevel angle)
Indicator
(For left bevel scale)
Fig. 12-b
Pull
Set pin (A)
8 mm bolt (B)
(Stopper for right 45° bevel angle)
8 mm set screw
(Stopper for 0° not shown)
Indicator
(For right bevel scale)
7. Securing the workpiece
WARNING: Always clamp or vise to secure the workpiece to the fence;
otherwise the workpiece might be thrust from the table and cause
bodily harm.
8. Installing the holders ... (Optional accessory)
The holders help keep longer workpieces
stable and in place during the cutting operation.
(1) As indicated in Fig. 13, use a steel square
for aligning the upper edge of the holders
with the base surface.
Loosen the 6 mm wing nut. Turn a height
adjustment bolt 6 mm, and adjust the
height of the holder.
(2) After adjustment, firmly tighten the 6 mm
wing nut and fasten the holder with the
6 mm knob bolt (optional accessory). If the
length of Height Adjustment Bolt 6 mm is
insufficient, spread a thin plate beneath.
Make sure the end of Height Adjustment
Bolt 6 mm does not protrude from the
holder.
6 mm knob bolt
(Optional accessory)
Holder
(Optional
accessory)
Steel
square
Base surface
6 mm wing nut
(Optional
accessory)
Height adjustment bolt 6 mm
(Optional accessory)
Fig. 13
0000BookC12RSH2.indb200000BookC12RSH2.indb20 2016/03/0118:07:322016/03/0118:07:32
