TECHNICAL DATA
AND
SERVICE MANUAL
CIRCULAR SAWS
C 9SA2
C 9BA2
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT
LIST Nos. C 9SA2: E516
C 9BA2: E517
Nov. 2006
C
MODELS
C 9SA2
C 9BA2
Hitachi 
Power Tools

REMARK:
Throughout this TECHNICAL DATA AND SERVICE MANUAL, a symbol(s)
is(are) used in the place of company name(s) and model name(s) of our
competitor(s). The symbol(s) utilized here is(are) as follows:
Symbol Utilized
Competitor
Company Name Model Name
BBOSCH GKS85S
CMAKITA 5900B
C 9SA2, C 9BA2

Page
CONTENTS
1. PRODUCT NAME ...........................................................................................................................1
2. MARKETING OBJECTIVE .............................................................................................................1
3. APPLICATIONS ..............................................................................................................................1
4. SELLING POINTS ..........................................................................................................................2
4-1. Selling Point Descriptions .............................................................................................................. 3
5. SPECIFICATIONS ..........................................................................................................................5
6. COMPARISONS WITH SIMILAR PRODUCTS .............................................................................. 6
7. PRECAUTIONS IN SALES PROMOTION .....................................................................................7
7-1. Handling Instructions ..................................................................................................................... 7
7-2. Caution on Name Plate .................................................................................................................. 7
8. PRECAUTIONS IN DISASSEMBLY AND REASSEMBLY ............................................................8
8-1. Disassembly .................................................................................................................................. 8
8-2. Reassembly ................................................................................................................................... 9
8-3. Insulation Tests ............................................................................................................................ 12
8-4. Cleaning the Cover ...................................................................................................................... 12
9. STANDARD REPAIR TIME (UNIT) SCHEDULES .......................................................................13
Assembly Diagram for C 9SA2
Assembly Diagram for C 9BA2

--- 1 ---
1. PRODUCT NAME
Hitachi Circular Saws, Models C 9SA2/C 9BA2 [235 mm (9-1/4")]
2. MARKETING OBJECTIVE
Fifteen years have passed since the sales start of the Model C 9. Although this model has been well reputed in
the market thanks to the ease of operation, compact and lightweight body until now, it is upgraded to the new
Models C 9SA2 and C 9BA2. With these new models, we aim to expand our market share. The key features of
the new models are as follows:
(1) Compact and lightweight
(2) Unique design
(3) Low noise and vibration
(4) Electric brake (Model C 9BA2 only)
(5) PTFE coating base for smooth sliding of workpieces (Model C 9BA2 only)
3. APPLICATIONS
Cutting of various wood materials

--- 2 ---
4. SELLING POINTS
Large knob for easy
cutting depth adjustment
Low noise and vibration
(Noise level during no-load operation:
3 dB lower than the conventional
model)
Main handle
Blower function to
blow out cutting dust
on the ink line
Precise and heavy-duty
aluminum die-cast base
and lower guard
Comfortable and nonskid
soft-touch handle
Main handle
Adjustable steel guide piece
Powerful motor
Unique design Electric brake
(Model C 9BA2 only)
Most lightweight in the class
thanks to the gear cover made
of die-cast magnesium alloy
PTFE coating base for
smooth sliding of workpieces
(Model C 9BA2 only)
Compact and lightweight
(Weight: 6.8 kg)

--- 3 ---
4-1. Selling Point Descriptions
(1) Compact and lightweight
Catalog
weight
Maker
Model
* Measured
weight
kg
kg
HITACHI
C 9SA2 B
HITACHI
C 9BA2 C
6.8
6.8
6.9
7.3
6.8
6.8
7.0
7.0
The Models C 9SA2 and C 9BA2 are most lightweight in each category as shown in Table 1.
(2) Unique design
Ease of operation is sufficiently considered in designing the Models C 9SA2 and C 9BA2 including the handle
location and shape. These models are uniquely designed through the richly used elastomer. The elastomer
used at the handle makes each model easier to operate.
(3) Low noise and vibration
In the Models C 9SA2 and C 9BA2, the ball bearings at the front and the back of the motor are supported by
rubber parts and a highly efficient, low-noise and small-diameter fan is adopted. The noise level and the
vibration level at start-up and no-load operation are reduced thanks to the above.
(4) Electric brake (Model C 9BA2 only)
The Model C 9BA2 is equipped with the electric brake function that is well-reputed in the conventional model.
The rotation of the motor is braked upon turning off the switch and stopped in a shorter time than the case of a
circular saw without braking function. Thus the Model C 9BA2 can quickly start the next work.
(5) PTFE coating base for smooth sliding of workpieces (Model C 9BA2 only)
When the operator pushes the circular saw forward during cutting, the pushing force is partially compensated
by friction with the workpiece. The PTFE coating base can reduce such a compensated force because the
frictional resistance is low. As a result, workpieces can be cut smoothly.
(6) Powerful motor
Table 2. Comparison of power input/measured weight ratio when using 9" dia. saw blade
Table 1. 9" circular saw weight comparisons (* Measured weight excludes cord, guide and saw blade)
Power
input
* Measured
weight
W
kg
HITACHI
C 9SA2 BHITACHI C 9BA2 C
2000
6.8
1700
7.3
2000
6.8
2000
7.0
Input/
weight W/kg 299 233 299 286
The Models C 9SA2 and C 9BA2 are superior to competitors concerning power input values in each category
as shown in Table 2. The power input/measured weight ratio obtained by dividing the power input by the
measured weight is also superior to competitors. The Models C 9SA2 and C 9BA2 are well-balanced circular
saws.
Maker
Model

--- 4 ---
(7) Comfortable and nonskid soft-touch handle
The handle is entirely covered with elastomer. The main handle and the sub handle are nonskid and fit in
hands for comfortable cutting operation.
(8) Adjustable steel guide piece
If the center of the saw blade is deviated from the notch of the guide piece due to continuous operation or
replacement of the saw blade, the position of the guide piece can be adjusted finely for more accurate cutting
operation. It is also convenient for cutting with respect to either side of the blade. The guide piece is made of
steel for higher strength.
(9) Blower function to blow out cutting dust on the ink line
The conventional models discharge almost all the cooling air forward as a blower function. However,
discharge of cooling air increases the operating noise. To cope with this, the Models C 9SA2 and C 9BA2 are
equipped with the improved cooling air path to reduce the operating noise while maintaining the blower
function.
(10) Precise and heavy-duty aluminum die-cast base and lower guard
The base and the lower guard are made of heavy-duty aluminum die-cast material. The Models C 9SA2 and
C 9BA2 can accurately cut workpieces for a long time because the base and the lower guard are highly
durable and resistant to warping.
(11) Large knob for easy cutting depth adjustment
The large knob is easy to adjust cutting depth speedily and reliably.
(12) Gear cover made of die-cast magnesium alloy
The Models C 9SA2 and C 9BA2 are most lightweight in the class thanks to the gear cover made of die-cast
magnesium alloy.

--- 5 ---
* Be sure to check the name plate on product as it is subject to change by areas.
** Measured weight excludes cord, guide and saw blade.
Housing
Handle cover
Gear cover
Saw cover
Lower guard
Base
Polycarbonate resin, elastomer
Polycarbonate resin, elastomer
Die-cast magnesium alloy
Polycarbonate resin, elastomer
Die-cast aluminum alloy
Die-cast aluminum alloy
Standard accessories
Tungsten carbide tipped (TCT) saw blade •••••••••••••••••••••••••••••••••••••••••••• 1
Hex. bar wrench ....................................................................................... 1
Guide .........................................................................................................1
Wing bolt .................................................................................................... 1
Type of motor
Enclosure
Weight
AC single phase
Cutting depth
at 90û
Power source
* Power input
at 45û
Voltage (V)
* Current (A)
Rotation speed
Cord
No-load
Gross (with case)
** Net
Full-load
Type
Overall length
1,570 W
2,600 min-1
2.5 m (8.2 ft.)
5. SPECIFICATIONS
235 mm (9-1/4")
Two-core cabtire cable
Model
Saw blade diameter
C 9SA2
0 to 86 mm (0 to 3-3/8")
AC single phase commutator motor
Packing Corrugated cardboard box/Plastic case and corrugated cardboard sleeve
Max. 65 mm (2-9/16")
Type of switch Trigger switch
6.8 kg (15.0 lbs)
11.5 kg (25.4 lbs)
110
15
5,000 min-1
3,200 min-1
C 9BA2
Gross 9.0 kg (19.8 lbs)
Long guide .................................................................................................1
Dust collector ............................................................................................ 1
Lever (Short type) ......................................................................................1
Optional accessories
220
9.6
2,000 W
230
9.2
2,000 W
240
8.8
2,000 W
3,360 min-1

--- 6 ---
Maker
Model
Power input
No-load rotation speed
Overall length
Weight
No-load rotation speed
Full-load rotation speed
Full-load output
Max. output
No-load noise
Max. cutting
depth
90
45
mm (in.)
mm (in.)
mm (in.)
W
min
-1
mm
kg (lbs.)
min
-1
min
-1
W
W
dB
Saw blade diameter
Catalog specifications
Characteristics
Structure
HITACHI HITACHI
BC
C 9BA2
C 9SA2 C 9
235 (9-1/4")
86 (3-3/8")
65 (2-9/16")
2000
5000
397
6.8 (15.0)
5040
3360
1260
3220
86
235 (9-1/4")
86 (3-3/8")
65 (2-9/16")
1750
4900
376
7.1 (15.7)
4630
3220
1160
2900
90
230 (9-3/64")
85 (3-11/32")
60 (1-23/64")
1700
4000
395
6.9 (15.2)
4700
3180
1370
3020
92
235 (9-1/4")
86 (3-3/8")
65 (2-9/16")
2000
5000
397
6.8 (15.0)
5190
3252
1300
2960
86
235 (9-1/4")
85 (3-11/32")
64 (2-33/64")
2000
4500
400
7.0 (15.4)
4720
3800
980
3930
91
L
H
W
mm
mm
mm
Nickel plated
aluminum
Aluminum
Provided
Provided
397
291
272
Material of lower guard
Soft-touch handle
Blower function
Material of base Nickel plated
aluminum
Aluminum
None
None
376
288
257
Steel
Aluminum
None
None
395
315
377
PTFE plated
aluminum
Aluminum
Provided
Provided
397
291
272
Aluminum
Aluminum
None
None
400
276
271
6. COMPARISONS WITH SIMILAR PRODUCTS

--- 7 ---
7. PRECAUTIONS IN SALES PROMOTION
In the interest of promoting the safest and most efficient use of the Models C 9SA2 and C 9BA2 Circular Saws by
all of our customers, it is very important that at the time of sale the salesperson carefully ensures that the buyer
seriously recognizes the importance of the contents of the Handling Instructions.
7-1. Handling Instructions
Although every effort is made in each step of design, manufacture, and inspection to provide protection against
safety hazards, the dangers inherent in the use of any electric tool cannot be completely eliminated. Accordingly,
general precautions and suggestions for the use of electric power tools, and specific precautions and suggestions
for the use of the circular saw are listed in the Handling Instructions to enhance the safe and efficient use of the
tool by the customer. Salespersons must be thoroughly familiar with the contents of the Handling Instructions to
be able to offer appropriate guidance to the customer during sales promotion.
7-2. Caution on Name Plate
Each tool is provided with a Name Plate which contains the following basic safety precautions in the use of the
tool.
(1) For New Zealand and Australia
CAUTION
Read thoroughly HANDLING INSTRUCTIONS before use.

--- 8 ---
8. PRECAUTIONS IN DISASSEMBLY AND REASSEMBLY
The disassembly and reassembly procedures for the Models C 9SA2 and C 9BA2 are essentially the same. The
[Bold] numbers in the descriptions below correspond to the item numbers in the parts list and exploded assembly
diagram for the Model C 9SA2. During disassembly and reassembly, and at all other times as well, sufficient care
must be exercised in handling to ensure that there is no deviation in the flatness of the bottom surface of the base
and in its perpendicularity with relation to the saw blade.
8-1. Disassembly
(1) Prior to attempting further disassembly, ensure without fail that the TCT Saw Blade 235MM [12] is removed to
prevent damage to its cutting edge, and to avoid possible serious accident.
(2) Removal of the Safety Cover [7]
First, disconnect the Return Spring [8] from the Safety Cover [7]. Then, loosen the two Seal Lock Flat Hd.
Screws M5 x 14 [10] and take off the Bearing Cover [9]. The Safety Cover [7] can then be removed.
Fig. 1
(5) Removal of the Armature [24]
First, remove the Brush Caps [58] and take out the Carbon Brushes (1 Pair) [57]. Then, loosen the Machine
Screws (W/Washers) M5 x 40 (Black) [59] and separate the Housing Ass'y [62] from the Gear Cover [27].
If the Armature [24] is remained in the Housing Ass'y [62], gently tap the Housing Ass'y [62] on the edge of the
surface where the Gear Cover [27] is mounted with a wooden or plastic hammer and remove the Armature
[24]. At this time, be very careful not to hit the fan on the Armature [24]. If the Bearing Bushing [31] is
remained in the Housing Ass'y [62], remove it in the same manner as the case of the Armature [24]. If the
Rubber Bushing [30] is remained in the Housing Ass'y [62], remove it with tweezers being very careful not to
scratch it.
(6) Removal of the Base Ass'y [45]
Extract the Roll Pin D8 x 50 [26] and disassemble the Base Ass'y [45] from the Gear Cover [27].
(3) Removal of the Bearing Holder [3] together with the Spindle and
Gear Set [2]
After removing the Safety Cover [7] as described above, loosen the
two Seal Lock Flat Hd. Screws M6 x 14 [4].
(4) Separation of the Spindle and Gear Set [2] from the Bearing Holder [3]
As illustrated in Fig. 1, support the Bearing Holder [3] with an
appropriate tubular jig, and push down on the end of the spindle to
separate the Spindle and Gear Set [2] from the Bearing Holder [3].
Jig
Push
56 mm
(2-13/64")
60 mm
(2-23/64")

--- 9 ---
Fig. 2
(2) Reassembling the Stator Ass'y [22]
To align each screw hole of the Stator Ass'y [22] and the
Housing Ass'y [62] accurately, insert the guide bar (J-132
stator press pins [special repair tool, code no. 970911]
are recommended) to press-fit the Stator Ass'y [22] to the
Housing Ass'y [62] as shown in Fig. 2. After press-fitting,
hook the Brush Terminal [21] on the Brush Holder [56].
Be careful not to pinch the internal wire of the Stator
Ass'y [22] between the Stator Ass'y [22] and the seat for
the Hex. Hd. Tapping Screw D5 x 65 [33] in the Housing
Ass'y [62]. Secure the Stator Ass'y [22] to the Housing
Ass'y [62] with the two Hex. Hd. Tapping Screws D5 x 65
[33].
(3) Reassembly of the Armature [24]
Prior to assembling the Armature [24], ensure that the
Rubber Ring [35] is properly inserted into the groove of
the bearing case within the Gear Cover [27]. At this time,
be very careful not to damage the Rubber Ring [35]. Be
sure to mount the Bearing Bushing [31] and the Rubber
Bushing [30] to the Armature [24] before reassembly.
Do not perform reassembly with the Bearing Bushing [31]
and the Rubber Bushing [30] remained in the Housing
Ass'y [62].
[22]
[55]
[21]
8-2. Reassembly
Reassembly can be accomplished by following the disassembly procedures in reverse. However, particular
attention should be given to the following items.
(1) Tightening torques for fastening screws and bolts
Machine Screws M4 [17] [20] [46] ........................................... 1.8 0.4 N•m {18 4 kgf•cm}
Special Bolt [15] ....................................................................... 1.8 0.4 N•m {18 4 kgf•cm}
Machine Screws M5 [59] .......................................................... 3.4 0.7 N•m {35 7 kgf•cm}
Seal Lock Flat Hd. Screw M6 x 14 [4] ...................................... 4.9 1.0 N•m {50 10 kgf•cm}
Hex. Socket Hd. Bolt M8 x 15.5 [19] ........................................ 14.7 1.0 N•m {150 10 kgf•cm}
Tapping Screws (W/Flange) D4 [60] [66] [73] .......................... 2.0 0.5 N•m {20 5 kgf•cm}
Hex. Hd. Tapping Screw D5 x 65 [33] ...................................... 2.9 0.5 N•m {30 5 kgf•cm}
Screw of switches ..................................................................... 0.8 0.2 N•m {8 2 kgf•cm}
Screw of pillar terminal ............................................................. 0.35 0.1 N•m {3.5 1 kgf•cm}
Guide bar
(J-132 stator press pins)
Name plate side
[21]

--- 10 ---
(5) Lubrication
Literally apply the designated lubricants as follows:
Within the Gear Cover [27]................................................. Grease (SEP-3A) Code No. 930035
9 g
Apply the above grease to the pinion teeth of the Armature [24] entirely.
(6) Internal wire arrangement
Connect internal wire as illustrated in Fig. 4 to Fig. 5. At this time, ensure that none of the wires are pinched
between components during assembly.
(4) Reassembly of the Lock Lever [25] (See Fig. 3.)
A. Position the Lock Lever [25] between the fan and the
Ball Bearing 6202VVCMPS2L [34] of the Armature [24],
and carefully assemble it together with the Armature
[24] into the Gear Cover [27].
B. Ensure that both ends of the spring on the Lock Lever
[25] are properly supported inside the ribs of the Gear
Cover [27].
C. When assembly of the Lock Lever [25] is completed
(when the Gear Cover [27] has been assembled to the
Housing Ass'y [62] and fastening with the Machine
Screws (W/Washers) M5 x 40 (Black) [59]), push the
Lock Lever [25] by hand and ensure that it returns to its
original position when released.
Fig. 3
[27]
[27]
[25]
Spring
Rib

--- 11 ---
Fig. 4
Fig. 5
A. Model C 9SA2
Safety lock button
(Only for New Zealand and Australia)
B. Model C 9BA2
Noise suppressor
(Only for
New Zealand,
Australia, Korea
and Taiwan)
Blue or white lead wires
Pillar terminal
Blue or white
Brown
White
Blue
Pillar terminal
Term inal
White
Cord
Noise
suppressor Armature
Stator coil
Stator coil
Switch
Stator
Switch
Safety lock button
(Only for Australia)
Noise suppressor
(Only for Australia
and Taiwan)
Blue, black and
yellow lead wires
Pillar
terminal
Black
Brown
White
Blue
Pillar terminal
Ter m inal
White
Cord
Noise
suppressor
Stator coil
Brake coil
Switch
Armature
Switch
Blue
Yellow
Blue or white

--- 12 ---
8-3. Insulation Tests
On completion of disassembly and repair, measure the insulation resistance and conduct dielectric strength test.
Insulation resistance: 7 M Ωor more with DC 500 V megohm tester
Dielectric strength: AC 4000 V/1 minute, with no abnormalities
8-4. Cleaning the Cover
Clean the exterior of the tool with a soft cloth moistened with soapy water, and dry thoroughly. Chloric solvent,
gasoline, and thinner will cause plastic components to dissolve.

--- 13 ---
9. STANDARD REPAIR TIME (UNIT) SCHEDULES
MODEL 10 20 30 40
Fixed
Variable
Work Flow
Switch
Cord
Cord Armor
Armature Ass'y
Ball Bearing
(6202VV)
Ball Bearing
(6000VV)
Bearing Bushing
Protective
Cover
Return Spring
Saw Cover
60 min.
50
Housing Ass'y
Stator Ass'y
Spindle and
Gear Set
Bearing Holder
Ball Bearing
(6203VV)
Gear Cover
Base Ass'y
General Assembly
C 9SA2
Handle Cover
C 9BA2

ELECTRIC TOOL PARTS LIST
LIST NO. E516
CIRCULAR SAW
Model C 9SA2
2006
•
11
•
16
(E1)
Hitachi Power Tools
A
A
B
B
1
2
3
4
5
6
7
8
9
10
11
19
23
15
63
64
39
13
14
12
16
17
18
20
21
22
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
59
60
56
57
58
61
65
66
67
68
62
70
71
72
73
69
74
75
76
505
501 502
503 504

*ALTERNATIVE PARTS--- 2 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
11 -- 06
C 9SA2
1673-002 NEEDLE BEARING (HK1212) 1
2303-789 SPINDLE AND GEAR SET 1
3303-790 BEARING HOLDER 1
4303-797 SEAL LOCK FLAT HD. SCREW M6X14 2
5998-887 LINER 1
6620-3VV BALL BEARING 6203VVCMPS2L 1
7326-803 SAFETY COVER 1
8303-906 RETURN SPRING 1
9303-804 BEARING COVER 1
10 992-013 SEAL LOCK FLAT HD. SCREW M5X14 2
*11 326-802 WASHER (A) 1
*11 303-365 WASHER (A) 1 FOR AUS, NZL
*12 326-830
TCT SAW BLADE 235MM-D25.4 HOLE-NT40 1
*12 326-829 TCT SAW BLADE 235MM-D25 HOLE-NT40 1 FOR AUS, NZL
13 325-354 SAW COVER 1
14 HITACHI LABEL 1
15 324-139 SPECIAL BOLT 1
16 302-464 KNOB 1
17 304-043
MACHINE SCREW (W/WASHERS) M4X10 (BLACK) 1
18 302-423 WASHER (B) 1
19 324-662 HEX. SOCKET HD. BOLT M8X15.5 1
20 305-691
MACHINE SCREW (W/WASHERS) M4X14 (BLACK) 4
21 937-623 BRUSH TERMINAL 2
*22 340-691C STATOR ASS’Y 110V 1 INCLUD. 21
*22 340-660P STATOR ASS’Y 110V 1 INCLUD. 21 FOR TPE
*22 340-691E STATOR ASS’Y 220V-230V 1 INCLUD. 21
*22 340-660Q STATOR ASS’Y 220V-230V 1 INCLUD. 21 FOR NZL, KOR
*22 340-691F STATOR ASS’Y 240V 1 INCLUD. 21
*22 340-660R STATOR ASS’Y 240V 1 INCLUD. 21 FOR AUS
23 325-352 FAN GUIDE 1
*24 360-759C ARMATURE 110V 1
*24 360-759E ARMATURE 220V-230V 1
*24 360-759F ARMATURE 240V 1
25 303-793 LOCK LEVER 1
26 949-884 ROLL PIN D8X50 (10 PCS.) 1
27 325-350 GEAR COVER 1 INCLUD. 1, 28, 29, 35
28 961-729 CUSHION 1
29 949-794 FLAT HD. SCREW M6X20 (10 PCS.) 1
30 325-356 RUBBER BUSHING 1
31 325-355 BEARING BUSHING 1
32 600-0VV BALL BEARING 6000VVCMPS2L 1
33 960-251 HEX. HD. TAPPING SCREW D5X65 2
34 620-2VV BALL BEARING 6202VVCMPS2L 1
35 303-792 RUBBER RING 1
36 324-660 KNOB 1
37 676-531 O-RING (P-7) 1
38 303-801 SLEEVE 1
39 961-436 WASHER (B) 1
40 324-658 WING NUT M8 1
41 949-433 BOLT WASHER M8 (10 PCS.) 1
42 301-806 WING BOLT M6X15 1

*ALTERNATIVE PARTS --- 3 ---
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
PARTS
11 -- 06
C 9SA2
43 947-859 LOCK SPRING 1
44 302-469 SLOTTED HD. SET SCREW (SEAL LOCK) M6X6 1
45 326-804 BASE ASS’Y 1 INCLUD. 40, 41, 46-51, 53, 54
46 317-333 MACHINE SCREW (W/SP. WASHER) M4X6 1
47 324-659 GUIDE PIECE 1
48 302-457 BOLT (SQUARE) M8X30 1
49 308-481 BEVEL PLATE 1
50 308-482 RIVET D6X24 1
51 308-480 RIVET D6X17 1
52 303-800 DIAGONAL BOLT M8 1
53 949-425 WASHER M6 (10 PCS.) 1
54 302-438 WING BOLT (A) M6X20 1
55 938-477 HEX. SOCKET SET SCREW M5X8 2
56 983-362 BRUSH HOLDER 2
57 999-038 CARBON BRUSH (1 PAIR) 2
58 961-781 BRUSH CAP 2
59 303-796
MACHINE SCREW (W/WASHERS) M5X40 (BLACK) 3
60 301-653 TAPPING SCREW (W/FLANGE) D4X20 (BLACK) 5
61 NAME PLATE 1
*62 325-363 HOUSING ASS’Y 1 INCLUD. 55, 56
*62 325-362 HOUSING ASS’Y 1 INCLUD. 55, 56 FOR AUS, NZL
*63 325-358 SAFETY LOCK BUTTON 1 FOR AUS, NZL
*64 325-359 SPRING 1 FOR AUS, NZL
65 325-357 SWITCH (1P SCREW TYPE) 1
66 305-720 TAPPING SCREW (W/FLANGE) D4X12 1
67 946-362 BEARING LOCK 1
68 325-351 HANDLE COVER 1
*69 980-063 TERMINAL 1 FOR AUS, NZL, TPE, KOR
70 938-307 PILLAR TERMINAL 1
*71 980-063 TERMINAL 1 FOR CORD
*71 930-804 TERMINAL M4.0 (10 PCS.) 1 FOR CORD FOR TPE
72 937-631 CORD CLIP 1
73 984-750 TAPPING SCREW (W/FLANGE) D4X16 2
*74 930-039 NOISE SUPPRESSOR 1 FOR AUS, NZL, TPE, KOR
*75 958-049 CORD ARMOR D8.2 1
*75 940-778 CORD ARMOR D10.7 1
*76 500-234Z CORD 1 (CORD ARMOR D8.2)
*76 500-423Z CORD 1 (CORD ARMOR D8.2) FOR SIN, KUW
*76 500-439Z CORD 1 (CORD ARMOR D8.2) FOR AUS, NZL
*76 500-447Z CORD 1 (CORD ARMOR D8.2) FOR SYR
*76 500-435Z CORD 1 (CORD ARMOR D8.2) FOR HKG
*76 500-474Z CORD 1 (CORD ARMOR D10.7) FOR TPE
*76 500-455Z CORD 1 (CORD ARMOR D8.2) FOR THA
*76 500-214Z CORD 1 (CORD ARMOR D10.7) FOR VEN

*ALTERNATIVE PARTS
--- 4 --- 11 -- 06
OPTIONAL ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
STANDARD ACCESSORIES
ITEM
NO. CODE NO. DESCRIPTION REMARKS
NO.
USED
C 9SA2
Printed in Japan
(061116N)
501 303-888 GUIDE 1
502 872-422 HEX. BAR WRENCH 6MM 1
503 303-811 SIDE HANDLE 1
504 949-340 FLAT HD. SCREW M6X16 (10 PCS.) 2
*505 325-364 CASE 1 FOR AUS, NZL
601 325-365 LONG GUIDE 1
602 324-669 DUST COLLECTOR 1
603 303-338 KNOB 1
