Hitachi Compute Rack 220S Parts list manual

MK-90CRS003-01
Hitachi Compute Rack 220S
CRU Replacement Guide
F
AST
F
IND
L
INK S
Getting Help
Contents

ii
Hitachi Compute Rack 220S CRU Replacement Guide
© 2012-2014 Hitachi, Ltd. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by
any means, electronic or mechanical, including photocopying and recording, or
stored in a database or retrieval system for any purpose without the express
written permission of Hitachi, Ltd.
Hitachi, Ltd., reserves the right to make changes to this document at any time
without notice and assumes no responsibility for its use. This document contains
the most current information available at the time of publication. When new or
revised information becomes available, this entire document will be updated and
distributed to all registered users.
Some of the features described in this document might not be currently available.
Refer to the most recent product announcement for information about feature
and product availability, or contact Hitachi Data Systems at
https://portal.hds.com.
Notice: Hitachi, Ltd., products and services can be ordered only under the terms
and conditions of the applicable Hitachi Data Systems agreements. The use of
Hitachi, Ltd., products is governed by the terms of your agreements with Hitachi
Data Systems.
Hitachi is a registered trademark of Hitachi, Ltd., in the United States and other
countries. Hitachi Data Systems is a registered trademark and service mark of
Hitachi, Ltd., in the United States and other countries.
Archivas, Essential NAS Platform, HiCommand, Hi-Track, ShadowImage,
Tagmaserve, Tagmasoft, Tagmasolve, Tagmastore, TrueCopy, Universal Star
Network, and Universal Storage Platform are registered trademarks of Hitachi
Data Systems.
AIX, AS/400, DB2, Domino, DS6000, DS8000, Enterprise Storage Server,
ESCON, FICON, FlashCopy, IBM, Lotus, MVS, OS/390, RS6000, S/390, System
z9, System z10, Tivoli, VM/ESA, z/OS, z9, z10, zSeries, z/VM, and z/VSE are
registered trademarks or trademarks of International Business Machines
Corporation.
All other trademarks, service marks, and company names in this document or
website are properties of their respective owners.
Microsoft product screen shots are reprinted with permission from Microsoft
Corporation.

Contents iii
Hitachi Compute Rack 220S CRU Replacement Guide
Contents
Contents.................................................................................................iii
Preface ................................................................................................... v
Intended Audience ..............................................................................................vi
Release Notes .....................................................................................................vi
Referenced Documents........................................................................................vi
Document Conventions....................................................................................... vii
Convention for storage capacity values................................................................ viii
Getting Help ..................................................................................................... viii
Comments ........................................................................................................ viii
Safety guidelines .....................................................................................ix
Safety information................................................................................................x
Common precautions concerning safety ................................................................xi
General safety precautions...................................................................................xi
Precautions against damage to equipment .......................................................... xvi
Safety and warning labels ................................................................................... xx
Introduction......................................................................................... 1-1
User Replacement Guideline...............................................................................1-2
User maintenance tasks.....................................................................................1-2
When a failure occurs ........................................................................................1-3
LED overview....................................................................................................1-4
Replaceable parts ................................................................................. 2-1
Overview ..........................................................................................................2-2
Location ...........................................................................................................2-5
Preparation .......................................................................................... 3-1
Basic Replacement Procedure.............................................................................3-2
Unpack a spare component................................................................................3-4
Powering off system unit ...................................................................................3-4
Sliding out the system unit for maintenance ........................................................3-5
Removing/Installing the cover ............................................................................3-7

iv Contents
Hitachi Compute Rack 220S CRU Replacement Guide
Replacing parts .....................................................................................4-1
Replacing an HDD/SSD ..................................................................................... 4-2
Replacing a power supply.................................................................................. 4-6
Replacing a fan ...............................................................................................4-10
Replacing a DIMM ...........................................................................................4-13
Replacing a PCI card........................................................................................4-19
Setup after maintenance........................................................................5-1
Notice of maintenance by maintenance person ................................................... 5-2
Changing a network adapter's MAC address........................................................ 5-2
Restoring the Web console or Remote Console settings ....................................... 5-3
BIOS resetting.................................................................................................. 5-3
Windows BitLocker recovery password ............................................................... 5-4

Preface v
Hitachi Compute Rack 220S CRU Replacement Guide
Preface
This document describes replacement procedure of the CRU of the Compute Rack
220S (CR 220S).
This preface includes the following information:
Intended Audience
Release Notes
Referenced Documents
Document Conventions
Convention for storage capacity values
Getting Help
Comments
Notice: The use of Compute Rack and all other Hitachi Data Systems products is
governed by the terms of your agreement(s) with Hitachi Data Systems.

vi Preface
Hitachi Compute Rack 220S CRU Replacement Guide
Intended Audience
This document is intended for the personnel who are involved in planning, managing,
and performing the tasks to prepare your site for Compute Rack installation and to
install the same.
This document assumes the following:
The reader has a background in hardware installation of computer systems.
The reader is familiar with the location where the Compute Rack will be installed,
including knowledge of physical characteristics, power systems and specifications,
and environmental specifications.
Release Notes
Read the release notes before installing and using this product. They may
contain requirements or restrictions that are not fully described in this document
or updates or corrections to this document.
Referenced Documents
Compute Rack 220S (CR 220S) documents:
Hitachi Compute Rack 220S Getting Started Giode, MK-90CRS001
Hitachi Compute Rack 220S User's Guide, MK-90CRS002
Hitachi Compute Rack 220S Windows Installation Guide, MK-90CRS005
Hitachi Compute Rack 220S BIOS Guide, MK-90CRS000
Hitachi Compute Rack 220S Remote Management User's Guide,
MK-90CRS004
Hitachi Compute Blade Series / Hitachi Compute Rack Series
OS Installation Guide for Windows Server, MK-99COM076

Preface vii
Hitachi Compute Rack 220S CRU Replacement Guide
Document Conventions
The term “Compute Rack” refers to all Compute Rack models, unless otherwise
noted.
This document uses the following typographic conventions:
Convention Description
Regular text bold In text: keyboard key, parameter name, property name, hardware labels,
hardware button, hardware switch.
In a procedure: user interface item
Italic Variable, emphasis, reference to document title, called-out term
Screen text Command name and option, drive name, file name, folder name, directory
name, code, file content, system and application output, user input
< > (angled brackets) Variable (used when italic is not enough to identify variable).
[ ] (square bracket) Optional values
{ } braces Required or expected value
| vertical bar Choice between two or more options or arguments
_(underline) Default value, for example, [a | b]

viii Preface
Hitachi Compute Rack 220S CRU Replacement Guide
Convention for storage capacity values
Physical storage capacity values (for example, disk drive capacity) are calculated
based on the following values:
Physical capacity unit Value
1 kilobyte (KB) 1,000 (103) bytes
1 megabyte (MB) 1,000 KB or 1,0002bytes
1 gigabyte (GB) 1,000 MB or 1,0003bytes
1 terabyte (TB) 1,000 GB or 1,0004bytes
1 petabyte (PB) 1,000 TB or 1,0005bytes
1 exabyte (EB) 1,000 PB or 1,0006bytes
Logical storage capacity values (for example, logical device capacity) are
calculated based on the following values:
Logical capacity unit Value
1 block 512 bytes
1 KB 1,024 (210) bytes
1 MB 1,024 KB or 1,0242bytes
1 GB 1,024 MB or 1,0243bytes
1 TB 1,024 GB or 1,0244bytes
1 PB 1,024 TB or 1,0245bytes
1 EB 1,024 PB or 1,0246bytes
Getting Help
The Hitachi Data Systems customer support staff is available 24 hours a day,
seven days a week. If you need technical support log on to the Hitachi Data
Systems Portal for contact information: https://portal.hds.com.
Comments
Please send us your comments on this document: [email protected].
Include the document title and number including the revision level (for example,
-07), and refer to specific sections and paragraphs whenever possible. All
comments become the property of Hitachi Data Systems Corporation.
Thank you!

Safety guidelines ix
Hitachi Compute Rack 220S CRU Replacement Guide
Safety guidelines
This section contains warnings and important safety guidelines for using a
Hitachi Compute Rack System. Read and understand the information in this
section before removing, replacing and installing system components.
This section includes the following key topics:
Safety information
Common precautions concerning safety
General safety precautions
Precautions against damage to equipment
Safety and warning labels

xSafety guidelines
Hitachi Compute Rack 220S CRU Replacement Guide
Safety information
This document uses the following symbols to emphasize certain information.
Symbol Label Description
WARNING This indicates the presence of a potential risk that might cause death or
severe injury.
CAUTION This indicates the presence of a potential risk that might cause relatively
mild or moderate injury.
NOTICE NOTICE This indicates the presence of a potential risk that might cause severe
damage to the equipment and/or damage to surrounding properties.
Note This indicates notes not directly related to injury or severe damage to
equipment.
Tip This indicates advice on how to make the best use of the equipment.
Fire Hazard This warns fire hazard. Take appropriate precautions to prevent the risk of
catching a fire.
Electric Shock
Hazard
This warns electric shock hazard. Failure to take appropriate precautions
could result in serious injury or death.
Hot Surface Hot Surface indicates the risk of a serious burn by high temperature.
Laser Hazard This warns laser hazard. Failure to take appropriate precautions could
result in invisible laser radiation.
General
Prohibition
Sign
This indicates the general prohibition.
Disassembly
Prohibition
Sign
This indicates not to allow customer to disassemble component.
General
Mandatory
Sign
This indicates a general action to take. Action by following the instructions
in this guide.
Unplug Power
cord
This indicates unplugging the power cable from the outlet to avoid electric
shock and fire.

Safety guidelines xi
Hitachi Compute Rack 220S CRU Replacement Guide
Common precautions concerning safety
Please carefully read through these safety instructions to follow:
When operating the equipment, follow the instructions and procedures
provided in the manual.
Be sure to follow notes, cautionary statements and advice indicated on the
equipment or in the manual.
Referring to manuals attached to other products which you install in or
connect to the equipment, follow the instructions described in those manuals.
Failure to follow those instructions can cause injury, fire or damage to property
including the equipment.
General safety precautions
Handling of power cables
Always use the power cables shipped with the equipment, and follow the
instructions below: Failure to follow the correct handling practices lead to
damaging the power cables to expose the copper wires and to overheat
due to short-circuiting or partial disconnection, which may cause electric
shock or fire.
Do not place any object on the power cables.
Do not use the power cables near heat-generating appliances.
Do not heat the power cables.
Do not bundle the power cables.
Do not subject the power cables to ultraviolet or strong visible light
continuously.
Keep the power cables from contact with alkali, acid, fat and oil, or
humidity.
Do not use the power cables in a high-temperature environment.
Do not use the power cables above their specified rating.
Do not use the power cables for other devices.
Do not touch the power plug with moistened hands.
Do not place any objects around the electrical outlets in order to allow
users to quickly unplug the power cables.

xii Safety guidelines
Hitachi Compute Rack 220S CRU Replacement Guide
Poor contact and tracking
Comply with the following instructions when handling the power plug.
Otherwise, tracking or poor contact may cause overheating and a fire.
Make sure that the power plug is fully and securely inserted into the
electrical outlet.
Before inserting the power plug, confirm that there is no dust or a water
droplet on the plug. If any dust or water droplet is found, wipe it off with a
dry cloth and then insert it.
Requirements for power outlets
Use a grounding 2-pole plug-in power outlet. Outlets of any other types
would cause an electric shock or fire.
In order to prevent an electric shock, connect the outlet’s grounding
electrode to a grounding terminal installed by a qualified electrician.
Without connection to the grounding terminal, an electric shock can occur
in the event of a failure in power supply.
Plugging and unplugging
When inserting the power plug into the electrical outlet or removing it, be
sure to hold the plug section. Do not pull the cable; it can partially break the
wire, overheat the broken part and lead to a fire.
Power supply
Since the power supply has a high-voltage area in it, do not open the cover.
If you do, it can result in an electric shock or equipment failure.
Installing power supply slot cover
When removing a power supply, do not insert your hand or tool inside the
power slot. After removing a power supply, install a power slot cover. Inside
the power slot, some conductors are exposed. If you touch them with your
hand or tool, it may cause electric shock or equipment failure.

Safety guidelines xiii
Hitachi Compute Rack 220S CRU Replacement Guide
Abnormal heat, smoke, abnormal noise, or abnormal smell
Should you find anything abnormal occurring, turn off the power and unplug
all the power cables of the equipment (maximum of 2) from the electrical
outlets.
Do not repair, remodel or disassemble
Do not attempt to repair, remodel or disassemble the equipment on your
own, except for performing expansion work in accordance with the
instructions in this manual. Work performed by unqualified persons can lead
to an electric shock, fire, or burns. Especially it is hazardous if you touch
areas inside the high-voltage power unit.
Removal of the cover or bracket
Do not remove the cover or bracket. It can result in an electric shock, burns
or equipment failure.
High temperature at a power supply
When a power supply is in operation, the cover and handle get hot. Be careful
when replacing a failed module. You can get burned.
Adding and replacing parts
The cover and internal parts are hot immediately after the power is turned
off. You must wait for about 10 minutes before adding or removing internal
parts unless otherwise specified in this manual. If not, the hot equipment
causes you to get burned.
Installing internal component and connecting peripherals
When you remove a cover for removing and installing components or
connect peripherals, disconnect all the AC cables from electrical outlets
and disconnect all signal cables from the system unit unless otherwise
specified.
Otherwise, you get injury or electric shock. Also malfunction of the system
unit might result.
Use peripherals, internal components, signal cables, and AC cables that
the manual describes as supported.
Otherwise, compatibility issues might occur and malfunction of the
peripherals, internal component, and the system unit. Also burn, smoke,
or fire might occur.

xiv Safety guidelines
Hitachi Compute Rack 220S CRU Replacement Guide
Laser beam
On this product, a Class 1 laser product is installed. Do not look directly at
the laser beam. Do not look at the laser beam using an optical
instrument.
Under the laser module cover, a laser beam is being emitted. Do not
remove the cover of an unused board.
Requirements for the product
Install the product on a fixed rack. Do not lean against the product or stand
on it. Do not install the product in a place with weak floors and walls.
Do not subject the product to excessive vibration. That can drop and fall the
product, leading to failure.
Installing the equipment in a rack
To install or remove the system equipment in or from the rack cabinet,
always get help from at least one other person or use tools. If the system
equipment has to be installed on 31U and above of the rack cabinet or it is
already installed there, call for maintenance personnel instead of attempting
to install or remove it. Defective installation may cause the system
equipment to fall, resulting in injury or equipment failure.
Using a rack cabinet
When using a rack cabinet, do not place anything on the system unit mounted
on the cabinet and do not use the top of the system unit mounted on the
cabinet as a work bench. A heavy object placed on top of the system unit on
the cabinet may fall, resulting in injury.
Locking the rail into place
Be sure to pull out the equipment until it locks into place. If not, the
equipment may move unexpectedly, which causes you to get injured such as
your finger caught in the gap.
Contact with metal edges
When moving the equipment or adding parts, take care not to hurt yourself
on the metal or plastic edges. You can wear cotton gloves to protect your
hands.

Safety guidelines xv
Hitachi Compute Rack 220S CRU Replacement Guide
Improper battery type
CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
Handling of batteries
Since maintenance personnel should change batteries, do not change them
yourself. Follow the instructions described below. Inappropriate handling can
result in injury because the battery can overheat, burst, and catch fire.
Do not put the battery on charge.
Do not short out the battery.
Do not disassemble the battery.
Storing batteries
When storing batteries, apply adhesive tape on the terminals for insulation. If
the batteries are stored without insulation, the terminals can contact each
other to cause a short-circuit and overheat or burst, leading to injury or fire.

xvi Safety guidelines
Hitachi Compute Rack 220S CRU Replacement Guide
Precautions against damage to equipment
Insertion of foreign objects into the equipment
Do not allow clips, pins or any other metal items or flammable items to enter
the equipment through a vent or by any other means. Continuing to operate
the equipment with foreign objects could cause failure.
Impact from falling
Do not fall the equipment or hit it against another object. It can cause internal
deformation and deterioration. Operating the equipment under such
defective conditions can cause failure.
Vent
A vent is used for preventing rise in temperature inside the equipment. Do
not block the vent by placing or leaning an object. If you do, the temperature
rises, which can cause failure. Check and clean ventilation holes periodically
to keep the dust from gathering on them.
Contact with connection terminals
Do not touch connection terminals, such as a connector with your hand or any
metal item. Do not insert any objects such as wire into them. Do not place the
equipment in a place with metal pieces. If you do, a short circuit can be
developed, causing equipment failure.
Moving between two locations with a temperature differential
When you move the equipment from one location to another, a significant
temperature gap between the two locations may cause condensation on the
surface or inside the equipment. Operating the equipment with condensation
inside can cause a failure in equipment. Leave the equipment at the new
location for several hours until the equipment temperature conforms to that
of the new environment before you start using it. When you move the
equipment from an environment with temperature 5 degrees Celsius to that
with 25 degrees Celsius, for example, leave it for about two hours.
Adding and connecting to peripheral devices
Use only peripheral devices which are explicitly listed as supported in the
manual, and always follow the instructions in the manual. Using devices other
than those mentioned above would cause a failure in peripheral devices and
equipment due to the difference in connection specifications.

Safety guidelines xvii
Hitachi Compute Rack 220S CRU Replacement Guide
Radio interference
When you install the equipment next to another electronic device, the radio
waves may interfere with each other. In particular, a television set or a radio
in the vicinity may make a noise.
Magnetism generator
Do not place a device that generates strong magnetism, such as a magnet or
a speaker, near the equipment. Doing so can cause a system unit failure.
Handling HDD/SSD
An HDD/SSD is a precision instrument. Handle it carefully when you use it.
Inappropriate handling could result in HDD/SSD failure.
Failed HDD/SSD
If you attempt to replace failed HDD/SSD using an incorrect procedure or
failed alternative disk, data on the disk array can be corrupted. Back up
the data before replacing the drive.
If you attempt to replace normal HDD/SSD, data on the disk array can be
corrupted. Only replace the failed HDD/SSD.
Replace the failed HDD/SSD with turning on the system unit. Otherwise,
data on the disk array can be corrupted.
Static electricity
Discharge static electricity by touching metal door knob or wear cotton gloves
whenever you handle a component. Otherwise, the device might fail.
Residual electric charge
When you change the configuration of the system unit (DIMM, fan, PCI card,
or peripherals), disconnect all the power plugs and wait 30 seconds and more
before the procedure. Otherwise, residual electric charge might cause
malfunction.

xviii Safety guidelines
Hitachi Compute Rack 220S CRU Replacement Guide
Aluminum electrolytic capacitors
An aluminum electrolytic capacitor has a limited service life. Do not use it
past its service life. Otherwise, leakage or depletion of the electrolyte may
cause smoke or electric shock. To avoid such hazardous situations, replace
limited-life parts once they are past their designated service life.
Distribution board
Install a distribution board close to an entrance/exit to protect the devices in
your computer system and to serve as an emergency power breaker.
Signal cables
Route cables not to trip over them. Tripping over cables could cause
injury or failure of devices connected to the equipment, and also could
cause loss of valuable data.
Do not place heavy items on the cables. Avoid routing cables close to a
thermal appliance. If you do, it could cause damage to cable sheaths,
resulting in failure of the connected devices.
Before turning off the power
Follow the prescribed procedure for power operation. Power input or
output not according to the prescribed procedure may cause problems on
the system equipment.
Before turning off the power, confirm that all devices connected to the
equipment stop. Turning off the power during operation of the equipment
may cause equipment failure or data loss.
When you are using an OS which requires the shut down procedure, be
sure to finish the shut down procedure before turning off the power.
Otherwise, data may be lost.

Safety guidelines xix
Hitachi Compute Rack 220S CRU Replacement Guide
Rack Mount Safety Consideration
Elevated Ambient Temperature
If installed in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than room
ambient. Use care not to exceed the rated maximum ambient
temperature of the unit.
Reduced Air Flow
Installation of the equipment in a rack should be such that the amount of
airflow required for safe operation of the equipment is not compromised.
Mechanical Loading
Mounting of the equipment in the rack should be such that a hazardous
condition is not achieved due to uneven mechanical loading.
Circuit Overloading
Consideration should be given to the connection of the equipment to the
supply circuit and the effect that overloading of the circuits might have
on overcurrent protection and supply wiring. Appropriate consideration
of equipment nameplate ratings should be used when addressing this
concern.
Reliable Earthing
Reliable earthing of rack-mounted equipment should be maintained. Pay
particular attention to supply connections other than direct connections
to the branch circuit (e.g. use of power strips)."

xx Safety guidelines
Hitachi Compute Rack 220S CRU Replacement Guide
Safety and warning labels
The location and content of the warning and safety labels on the CR 220S are shown
here.
