Hitachi L22DP03U B User manual

L22DP03U
GB
Instructions for use
22" LCD Colour Television
2
with intergral DVD player

- 1 -
Contents
Digital Teletext ................................................... 22
Over Air Download ........................................... 23
Widescreen ...................................................... 23
IDTV Menu Syste ............................................... 23
Channel List ...................................................... 23
Navigating the Entire Channel List ................ 24
Deleting the Channels in the Channel List .... 24
Rena ing Channels ...................................... 24
Adding Locks to Channels ........................... 24
Setting Favourites ......................................... 25
On Screen Help ............................................ 25
Installation ......................................................... 25
Add New Channels ...................................... 26
Auto atic Search ................................... 26
Manual Search ....................................... 26
Configuration .................................................... 27
Audio Language ........................................... 27
Subtitle .......................................................... 27
Favourite Mode ............................................. 27
EPG Preference ............................................ 27
Receiver Upgrade ......................................... 28
Auto atic Download (Auto atic
Upgrade) ................................................. 28
Search for New Version (Manual
Upgrade) ................................................. 28
Parental Settings ........................................... 28
Ti ers ............................................................... 29
Language .......................................................... 30
TV Setup ........................................................... 30
Co on Interface ............................................. 30
Navigating the Analogue TV Menu Syste .......... 31
Analogue TV Menu Map ....................................... 32
Analogue TV Menu Syste ................................. 33
Sound Menu ...................................................... 33
Volu e .......................................................... 33
Balance ......................................................... 33
Sound Mode .................................................. 33
Effect ............................................................ 33
Equalizer ....................................................... 33
HP Volu e ..................................................... 33
Store .............................................................. 33
Picture Menu ..................................................... 33
Picture Mode ................................................. 33
Brightness/Contrast/Colour/ ......................... 33
Sharpness/Tint ............................................. 33
Colour Te p .................................................. 34
Picture Zoo ................................................. 34
Store .............................................................. 34
Features Menu .................................................. 34
Sleep Ti er ................................................... 34
Language ...................................................... 34
Child Lock ...................................................... 34
Menu Colour .................................................. 34
Favourite Mode ............................................. 34
Install Menu ....................................................... 34
Features ................................................................. 3
Accessories ........................................................... 3
Introduction ............................................................. 4
Preparation ............................................................. 4
Safety Precautions ................................................. 4
Power Source .................................................... 5
Power Cord ........................................................ 5
Moisture and Water ............................................ 5
Cleaning .............................................................. 6
Ventilation ........................................................... 6
Heat and Fla es ................................................. 6
Lightning .............................................................. 6
Replace ent Parts ............................................. 6
Servicing ............................................................. 6
Waste Disposal ................................................... 6
Infor ation for Users in European Union
Countries ............................................................ 6
Disconnecting the Device ................................... 6
Headphone Volu e ............................................ 7
Installation ........................................................... 7
LCD Screen ........................................................ 7
Warning ............................................................... 7
Overview of the Re ote Control ........................... 8
LCD TV and Operating Buttons .............................. 9
Viewing the Connections ..................................... 10
Power Connection ................................................ 12
Aerial Connection ................................................. 12
Connecting the LCD TV to a PC ........................... 13
Connecting an external DVD Player .................... 14
Using Other Connectors ...................................... 15
Connecting Other Equip ent via Scart ................ 16
Inserting Batteries in the Re ote Control
Handset ................................................................ 17
Handling the Re ote Control ............................ 17
Operating Range for the Re ote Control ............. 17
Switching the TV On/Off ..................................... 18
To Switch the TV On ........................................ 18
To Switch the TV Off ....................................... 18
Input Selection ...................................................... 18
Basic Operations .................................................. 19
Operation with the Buttons on the TV ............. 19
Volu e Setting .............................................. 19
Progra e Selection .................................... 19
Entering Main Menu ....................................... 19
AV Mode ....................................................... 19
Operation with the Re ote Control .............. 19
Volu e Setting .............................................. 19
Progra e Selection (Previous or Next
Progra e) ................................................... 19
Progra e Selection (Direct Access) ......... 19
Initial Settings ........................................................ 20
General Operation ................................................ 20
Infor ation Banner on DTV .............................. 20
Electronic Progra e Guide (EPG) .................. 21
Displaying the Subtitles .................................... 22
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:211

- 2 -
Progra ing ................................................. 34
Progra e ............................................. 35
Band ....................................................... 35
Channel ................................................... 35
Standard ................................................. 35
Colour Syste ........................................ 35
Search .................................................... 35
VCR Mode .............................................. 35
Decoder .................................................. 35
Store ....................................................... 35
A.P.S. ............................................................ 35
A.P.S. Country .............................................. 35
Teletext Region ............................................. 36
Install enu in AV odes .............................. 36
Progra ing ........................................... 36
Colour Syste ........................................ 36
Progra Table ............................................... 36
Na e ....................................................... 36
Move ....................................................... 37
Delete ...................................................... 37
APS (Auto Progra ing Syste ) .......... 37
Favourite Mode ....................................... 37
Progra Lock ......................................... 37
Enter PIN ................................................. 37
Change PIN ............................................. 37
PC Mode Menu Syste ......................................... 38
Sound Menu ...................................................... 38
Feature Menu .................................................... 38
PC Picture Menu ................................................ 38
Geo etry Menu ............................................ 38
H. (Horizontal) Position ........................... 38
V. (Vertical) Position ............................... 38
Clock ....................................................... 38
Phase ...................................................... 38
Auto Adjust ent ..................................... 38
Displaying TV Infor ation .................................... 39
Mute Function ....................................................... 39
Personal Preference ............................................ 39
Zoo Modes ......................................................... 39
Auto .............................................................. 39
4:3 ................................................................. 39
16:9 ............................................................... 39
Cine a .......................................................... 39
Subtitle .......................................................... 39
Teletext ................................................................. 40
Tips ....................................................................... 41
Screen Care ..................................................... 41
I age Persistence ............................................ 41
No Power .......................................................... 41
Poor Picture ...................................................... 41
No Picture ......................................................... 41
Sound ................................................................ 41
Re ote Control ................................................. 41
Input Sources ................................................... 41
CI Module .......................................................... 41
Appendix A: PC Input Typical Display Modes ...... 42
Specifications ....................................................... 43
Pin Specifications ................................................. 44
I portant Instruction ............................................. 45
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:212

- 3 -
Features
 Remote controlled colour television.
 Fully integrated digital TV (DVB-T .
 100 programmes from VHF, UHF bands or
cable channels can be preset.
 It can tune cable channels.
 Controlling the TV is very easy by its menu
driven system.

A scart socket for external devices (e.g. video
games, audio set, etc. .
 Stereo sound system (Ger an + Nica Stereo .
 Full function teletext .
 Fastext (10 pages , TOP text.
 Favourite channel.
 Channel lock.
 Headphone connection.
 A.P.S. (Automatic Programming System .
 All programmes can be named.
 Forward or backward automatic tuning.
 Sleep timer.
 Child lock.
Automatic sound mute when no transmission.
 NTSC playback.
 AV in is available.
 It has one HDMI connector for digital video
and audio. This connection is also designed
to accept high definition signals.
 When no valid signal is detected, after 5
minutes the TV switches itself automatically
to standby mode.
 PLL (frequency search .
 PC input.
 Plug & Play for Windows 9X, ME, 2000, XP, Vista.
Accessories
$%&
'()
*+ ,
-./
012
345
67 8
9:;
<=
(;,7
:,'(
3,3
62 85 &( *8,'(
6:$ 3
*+ ,
Remote Controller
RC1165
Batteries
2 X AAA
Instruction Book
Quick Guide
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:213

- 4 -
Introduction
Thank you for choosing this
product. This manual will guide you
in the proper operation of your TV.
Before operating the TV, please
read this manual throughly.
Please do keep this manual in a safe place
for future references.
Preparation
For ventilation, leave a free space of at least
10 cm all around the set. To prevent any fault
and unsafe situations, please do not place
any objects on top of the set.
Use this device in moderate climates.
Safety Precautions
Please read the following recommended
safety precautions carefully for your safety.
SOME DOS AND DON'TS ON THE SAFE
USE OF EQUIPMENT
This equipment has been designed and
manufactured to meet international safety
standards but, like any electrical equipment,
care must be taken if you are to obtain the
best results and safety is to be assured.
**************
DO read the operating instructions before you
attempt to use the equipment.
DO ensure that all electrical connections
(including the mains plug, extension leads
and inter-connections between the pieces of
equipment are properly made and in
accordance with the manufacturer's
instructions. Switch off and withdraw the
mains plug before making or changing
connections.
DO consult your dealer if you are ever in doubt
about the installation, operation or safety of
your equipment.
DO be careful with glass panels or doors on
equipment.
DO route the mains lead so that it is not likely
to be walked on, crushed, chafed, or
subjected to excessive wear and tear or heat.
**************
DON'T remove any fixed cover as this may
expose dangerous voltages.
DON'T obstruct the ventilation openings of the
equipment with items such as newspapers,
tablecloths, curtains, etc. Overheating will
cause damage and shorten the life of the
equipment.
DON'T allow electrical equipment to be
exposed to dripping or splashing, or objects
filled with liquids, such as vases, to be placed
on the equipment.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:214

- 5 -
DON'T place hot objects or naked flame
sources such as lighted candles or nightlights
on, or close to equipment. High temperatures
can melt plastic and lead to fires.
DON'T use makeshift stands and NEVER fix
legs with wood screws - to ensure
complete safety always fit the manufacturer's
approved stand or legs with the fixings
provided according to the instructions.
DON'T use equipment such as personal
stereos or radios so that you are distracted
from
the requirements of traffic safety. It is illegal
to watch television whilst driving.
DON'T listen to headphones at high volume,
as such use can permanently damage your
hearing.
DON'T leave equipment switched on when it
is unattended unless it is specifically stated
that it is designed for unattended operation or
has a stand-by mode. Switch off using the
switch on the equipment and make sure that
your family know how to do this. Special
arrangements may need to be made for infirm
or handicapped people.
DON'T continue to operate the equipment if
you are in any doubt about it working
normally, or if it is damaged in any way - switch
off, withdraw the mains plug and consult
your dealer.
ABOVE ALL
--- NEVER let anyone especially children push
anything into holes, slots or any other opening
in the case - this could result in a fatal electrical
shock;
--- NEVER guess or take chances with
electrical equipment of any kind
--- it is better to be safe than sorry!
*************
Power Source
The TV set should be operated only from a
220-240 V AC, 50 Hz outlet. Ensure that you
select the correct voltage setting for your
convenience.
Power Cord
Do not place any furniture, etc on the power
cord (mains lead that can pinch the Cord.
Handle the power cord by the plug.
Do not unplug the appliance by pulling the
power cord and never touch the power cord
with wet hands as this could cause a short
circuit or electric shock.
Never make a knot in the cord or tie it with
other cords. The power cord should be placed
in such a way that they are not likely to be
stepped on.
A damaged power cord can cause fire or give
you an electric shock.
When it is damaged and needs to be replaced,
it should be done by qualified personnel.
Moisture and Water
Do not use this device in a
humid or damp environment
(avoid the bathroom, the sink
in the kitchen, and near the
washing machine .
Do not expose this device to
rain or water, as this may be dangerous and
do not place objects filled with liquids, such as
flower vases, on top.
Avoid dripping or splashing near the set.
If any solid object or liquid falls into the cabinet
unplug the TV and have it checked by qualified
personnel before operating it any further.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:215

- 6 -
C eaning
Before cleaning, unplug the
TV set from the wall outlet.
Do not use liquid or aerosol
cleaners. Use soft and dry
cloth.
Venti ation
The slots and openings on the TV set are
intended for ventilation and to ensure reliable
operation. To prevent overheating, these
openings must not be blocked or covered in
anyway.
Heat and F ames
The set should not be placed
near to open flames and sources
of intense heat such as an
electric heater. Ensure that no
open flame sources, such as
lighted candles, are placed on top of the TV.
Batteries should not be exposed to excessive
heat such as sunshine, fire or the like.
Lightning
In case of storm and lightning or
when going on holiday,
disconnect the power cord from
the wall outlet.
Rep acement Parts
When replacement parts are required, make
sure that the service technician has used
replacement parts, which are specified by the
manufacturer or have the same specifications
as the original one. Unauthorized
substitutions may result in fire, electrical shock
or other hazards.
Servicing
Please refer all servicing to
qualified personnel. Do not
remove the cover yourself as
this may result in an electric
shock.
Waste Disposa
Instructions for waste disposal:
 Packaging and packaging aids are
recyclable and should principally be recycled.
Packaging materials, such as foil bag, must
be kept away from children.
 Batteries, including those which are heavy
metal-free, should not be disposed of with
household waste. Please dispose of used
battery in an environment friendly manner.
Find out about the legal regulations which
apply in your area.
 Cold cathode fluorescent lamp in LCD
PANEL contains a small amount of mercury;
please follow the local laws or regulations
for disposal.
Information for Users in European
Union Countries
The mark is in compliance
with the Waste Electrical and
Electronic Equipment Directive
2002/96/EC (WEEE .
The mark indicates the
requirement NOT to dispose the equipment
including any spent or discarded batteries as
unsorted municipal waste, but use the return
and collection systems available. If the
batteries or accumulators included with this
equipment, display the chemical symbol Hg,
Cd, or Pb, then it means that the battery has a
heavy metal content of more than 0.0005%
Mercury, or more than 0.002% Cadmium or
more than, 0.004% Lead.
Disconnecting the Device
The mains plug is used to disconnect TV set
from the mains and therefore it must remain
readily accessible.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:216

- 7 -
Headphone Vo ume
Excessive sound pressure from
earphones and headphones can
cause hearing loss.
Insta ation
To prevent injury, this device must be securely
attached to the wall in accordance with the
installation instructions when mounted to the
wall (if the option is available .
LCD Screen
The LCD panel is a very high technology
product with about a million thin film
transistors, giving you fine picture details.
Occasionally, a few non-active pixels may
appear on the screen as a fixed blue, green
or red point. Please note that this does not
affect the performance of your product.
Warning
Do not leave your TV in standby or operating
mode when you leave your house.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:217

- 8 -
Overview of the Remote Control
Standby
Switch to TV
Mono-Stereo/Dual I-II
Direct programme
Double digit
Cursor up
Cursor left
Programme up
Programme down
Previous programme
External source
Time/Sub-page/Subtitle on-off
Teletext
Expand/Image size
Reveal/ Switch to PC
Index page/Electronic
Programme Guide (EPG
Mix
Update
Hold
Personal preference
Tv button(Exit Menu or Teletext
Volume down
Volume up
Cursor down
Cursor right
Okay
Install
Menu
Feature
Picture/Page down

Sound/Page up

Switch to DVD mode
Switch to DTV mode
Mute
Info/Programme Table
$%&
'()
*+,
-./
012
345
678
9:;
<=
(;,7
:,'(
',63/$<
*8, '(
7,0(
*+,
5(7851
68%7,7/(
$8',2
$1*/(
23 (1 &/ 26(
68%7,7/(
7,7/(&
5(3($7
$%
352*5$0 =220
6($5&+02'(
,1)2
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:218

- 9 -
LCD V and Operating Buttons
FRONT VIEW
REAR VIEW
TOP VIEW
3

&
+
0
(
1
8
7
9

$
9
3
R
Z
H
U

R
Q

R
I
I
7
9



$
9
0
(
1
8
3
U
R
J
U
D
P
P
H

8
S



'
R
Z
Q
9
R
O
X
P
H

8
S



'
R
Z
Q
79%87721
'9'%87721
2SHQ&ORVH
6WRS
3OD\3DXVH
6HDUFKEDFN6NLSEDFN
6HDUFKIRUZDUG6NLSQH[W
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:219

- 10 -
Viewing the Connections
HDMI Input are for connecting a device that has an HDMI socket.
Your LCD Television is capable of displaying High Definition pictures from devices such as a
High Definition Satellite Receiver or DVD layer. These devices must be connected via the
HDMI sockets or Component Socket. These sockets can accept either 720p or 1080i signals.
No sound connection is needed for an HDMI to HDMI connection. If you use HDMI to DVI
cable, use C audio in input to enable sound connection.
S/PDIF Out is used for transferring digital audio signals. Use an audio cable to transfer
audio signals to a device that has S/PDIF input.
Note: S/ DIF Out can only provide output from DVD or DTV source.
For instance, if you switch to C mode while in DTV mode, S/ DIF out will not be muted. To
stop this, you should switch to analogue TV mode first. If you enable S/ DIF out on DVD
source, you should stop/pause playing content to stop S/ DIF output before switching the TV
to a new source.
Audio Line Out outputs audio signals to an external device such as an optional sound
system.
To connect the external speakers to your TV, use AUDIO LINE OUT of the TV with an audio
cable.
Headp one jack is used for connecting an external headphone to the system.
Connect to the HEADPHONE jack to listen to the TV from headphones (optional).
REAR VIEW
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2110

- 11 -
Component Video Inputs (YPbPr) are used for connecting component video.
You can connect the component video and audio sockets with a device that has component
output. Connect the component video cables between the COMPONENT VIDEO INPUTS on
on the TV and the component video outputs of your device. While connecting, be sure that the
letters on your TV, Y, Pb, Pr correspond with your devices connectors.
Note that Y input also functions as CVBS Video In jack.This means that you can connect
devices such as a camcorder to your TV by using CVBS Video In jack. Connect the video cable
between the CVBS Video In socket on the TV and the VIDEO OUT jack on your device to make
such a connection.
YPbPr Audio Inputs are used for connecting audio signals of a PC or a device that connects
to the TV via YPbPr sockets.
Connect the audio cable between AUDIO INPUTS on the TV and audio outputs of your device
to enable component audio.
PC Input is for connecting a personal computer to the TV set.
Connect the PC cable between the PC INPUT on the TV and the PC output on your PC.
RF Input connects to an antenna or a cable.
Note: that if you use a decoder or a media recorder, you should connect the aerial cable
through the device to the television with an appropriate antenna cable.
SCART inputs or outputs for external devices.
Connect the SCART cable between SCART sockets on TV and SCART socket on your external
device (such as a decoder, a VCR or a DVD player .
Note: If an external device is connected via the SCART sockets, the TV will automatically
switch to AV mode.
CI Slot is used for inserting a CI card. A CI card allows you to view all the channels that you
subscribe to. For more information, see Common Interface section.
Disc loading slot
Insert a DVD disc into this slot.
NB. press the button on the remote control to select DVD mode.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2111

- 12 -
Power Connection
IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz.
 A ter unpacking, allow the TV set to reach the ambient room temperature be ore you
connect the set to the mains.
 Plug the power cable to the mains socket outlet.
Aerial Connection
 Connect the aerial or cable TV plug to the AERIAL INPUT socket located at the rear of the TV.
REAR VIEW
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2112

- 13 -
Connecting the LCD V to a PC
For displaying your computers screen image on your LCD TV, you can connect your computer
to the TV set.
 Power off both computer and display before making any connections.
 Use 15-pin D-sub display cable to connect a PC to the LCD TV.
 When done, switch to PC source. See, Input selection section.
 Set the resolution that suits your viewing requirements.
REAR VIEW
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2113

- 14 -
Connecting an external DVD Player
If you want to connect a DVD player to your LCD TV, you can use connectors of the TV set. DVD
players may have different connectors. Please refer to your DVD players instruction book for
additional information. Power off both the TV and the device before making any connections.
Note: Cables shown in the illustration are not supplied.
 If your DVD player has an HDMI socket, you can connect via HDMI. When you connect to DVD
player as illustrated below, switch to HDMI source. See, Input selection section.
 Most DVD players are connected through RCA SOCKETS. Use a RCA video cable to connect
video input. For enabling audio, use a component audio cable as illustrated below. When
done, switch to F-AV- source. See, Input selection section.
 You may also connect through the SCART . Use a SCART cable as shown below.
+'0,
,QSXW
6&$57
VRFNHWV
+'0,
FDEOH
6&$57
FDEOH
5&$
FDEOH
REAR VIEW
Note: These three methods of connection perform the same function but in different levels of
quality. It is not necessary to connect by all three methods.
SIDE VIEW
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2114

- 15 -
Using Other Connectors
You can connect a range of optional equipment to your LCD TV. Possible connections are
shown below. Note that cables shown in the illustration are not supplied.
 To connect external speakers; connect the audio output sockets on the TV to an external
amplifier that is connected to a speaker system.
 Turn on the LCD TV and external speaker set after all connections are made. Refer to your
speaker sets manual for further queries.
 To listen the sound from headphones, connect to the HEADPHONE jack of theTV.
SIDE VIEW
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2115

- 16 -
Connecting Other Equipment via Scart
Most devices support SCART connection. You can connect a; DVD recorder, a VCR or a
decoder to your LCD TV by using the SCART sockets. Note that cables shown in the illustration
are not supplied.
 Power off both the TV and the devices before making any connections.
 For more information, refer to your devices own instruction book.
9&5
'9'5HFRUGHU
'HFRGHU
VFDUW
VRFNHW
REAR VIEW
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2116

- 17 -
Inserting Batteries in the
Remote Control Handset
 Remove the battery cover located on the back
of the handset by gently pulling backwards
from the indicated part.
 Insert two AAA/R3 or equivalent type batteries
inside. Place the batteries in the right
directions and replace the battery cover.
Hand ing the Remote Contro
 Improper use could cause corrosion or
battery leakage and may result in physical
injury and/or property damage including fire.
 Never mix used and new batteries in the
device.
 Replace all the batteries in a device at the
same time.
 Remove the batteries if the remote control is
not going to be used for an extended period
of time.
 To avoid possible failure, read the following
instructions and handle the remote control
properly.
 Do not drop or cause impact to the remote
control.
 Do not spill water or any liquid on the remote
control.
 Do not place the remote control on a wet
object.
 Do not place the remote control under the
direct sunlight or near sources of excessive
heat.
Note: Remove the batteries from the remote
control when it is not going to be used
for a long time. Otherwise the batteries
may leak and damage the controller.
Operating Range for the
Remote Control
 Point the top of the remote control toward
the LCD TV's remote sensor LED while
pressing a button.


$%&
'()
*+,
-. /
012
345
678
9:;
<=
(;,7 
:,'(
',63/$<
*8,' (
7,0(
*+,
5( 7 851
68%7,7/(
$8',2
$1*/(
23(1 &/26 (
68% 7,7/(
7,7/(&
5(3($7
$%
352 *5$ 0 =220
6( $5 &+ 0 2' (
,1)2
Remote range is approximately 7m/23ft.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2117

- 18 -
Switching the V On/Off
To Switch the TV On
 Connect the power cord to the 220-240V
AC,50 Hz.
 Press STANDBY button. Then the standby
LED lights up.
 To switch on the TV from standby mode either:
 Press the button, P/CH+ / P/CH- or a
numeric button on the remote control.
 Press the P/CH- or P/CH+ button on the TV.
The TV will then switch on.
Note: If you switch on your TV via
ROGRAMME U /DOWN buttons on the
remote control or on the TV set, the
programme that you were watching last
will be reselected.
To Switch the TV Off
 Press the button on the remote control or
STANDBY button on the TV, so the TV will
switch to standby mode.
 To power down the TV completely, unplug
the power cord from the mains socket.
Input Selection
Once you have connected external systems
to your TV, you can switch to different input
sources.
 Press the AV button on your remote control
until the desired source is highlighted. The
TV will then switch to the selected source
after a short while.
6RXUFH
79
(;7
)$9
'9'
3&
'79
<3%35
+'0,
 Depending on your selection of working
mode, the remote control buttons functions
will change accordingly.
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2118

- 19 -
Basic Operations
You can operate your TV using both the
remote control and onset buttons.
Operation with the Buttons on the TV
Vo ume Setting
 Press - button to decrease volume or + button
to increase volume, so a volume level scale
(slider will be displayed on the screen.
Programme Se ection
 Press +P/CH button to select the next
programme or P/CH- button to select the
previous programme.
Entering Main Menu
 Press the MENU button to enter main menu.
Inthe Main menu select sub-menus using -P/
CH or P/CH+ buttons and enter the sub -
menuusing - or + buttons. To learn the usage
of the menus, refer to the menu system
sections.
AV Mode
 Press the TV/AV button at the control panel
on the TV to switch your TV to AV modes.
Operation with the Remote Contro
 The remote control of your TV is designed to
control all the functions of the model you
selected. The functions will be described in
accordance with the menu system of your TV.
 Functions of the menu system are described
in the following sections.
Vo ume Setting
Press V + button to increase the volume.
Press V - button to decrease the volume. A
volume level scale (slider will be displayed
on the screen.
Programme Se ection (Previous or
Next Programme)
 Press P - button to select the previous
programme.
 Press P + button to select the next
programme.
Programme Se ection (Direct Access)
 Press numeric buttons on the remote control to
select programmes between 0 and 9. The TV
will switch to the selected programme.To select
programmes between 10 - 999 (for IDTV , first
press the -/-- button; then numeric buttons
consecutively (e.g.for programme 27, first press
2 and then 7 within 3 seconds. Longer than this
will result in the TV screen changing to the first
number pressed, (in this example 2 .
ENG-01-TV-22856W-1165UK-MB29-UKIDTV-(1SCRT-AV-YPBPR-HP-SPDIF-STRLOUT-PCIN)-10059170-5013xxxx.p6525.09.2008, 21:2119
