SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT.
Plasma Display
November 2005 Digital Media Division
YK No.020E
SERVICE MANUAL 42PD8800TA(PW3)
32LD8800TA(PW3L)
Be sure to read this manual before servicing. To assure safety from fire, electric shock, injury, harmful radia-
tion and materials, various measures are provided in this HITACHI display.
Be sure to read cautionary items described in the manual to maintain safety before servicing.
Caution
1. Features --------------------------------------------------3
2. Specifications--------------------------------------------4
3. Service point ---------------------------------------------5
4. Component names -------------------------------------6
5. New adoption technology-----------------------------7
6. Adjustment --------------------------------------------- 11
7. Troubleshooting--------------------------------------- 38
8. Self-diagnosis function ------------------------------ 53
9. Basic circuit diagram--------------------------------- 55
10.Printed wiring board diagram ---------------------- 82
11.Block diagram ----------------------------------------- 90
12.Connection diagram --------------------------------- 91
13.Wiring diagram ---------------------------------------- 93
14.Disassembly diagram-------------------------------- 97
15.Replacement parts list----------------------------- 101
Contents
1. Since Panel Module and front Filter are made of glass, handling the broken Module and Filter shall be
taken care sufficiently in order not to be injured.
2. Replacing work shall be started after the Panel Module and the AC/DC Power supply become sufficiently
cool.
3. Special care shall be taken to the display area in order not to damage its surface.
4. The Panel Module shall not be touched with bare hand to protect its surface from stains.
5. It is recommended to use clean soft gloves during the replacing work in order to protect not only the dis-
play area of the Panel Module but also a serviceman himself.
6. The Chip Tube of Panel Module (located upper left of the back and surrounded by frame) and flexible
cables connecting Panel glasses to drive circuit PWBs are very weak, so shall be taken care sufficiently
not to break. If you break Chip Tube, the Panel doesn’t display anything forever.
Service Warning
LCD PDP

2
42PD8800/32LD8800
CAUTION FOR SAFETY
Please read this page before repair the monitor.
This page explains to following items for keep the safety of set and prevent to accident during
repair work.
We explain by symbol at happen the damage or injury when took wrong repair.
Warning This symbol means "possible to die or heavy damage"
Caution This symbol means "possible to damage or something will break"
We made the symbol as below, which are kind of following items.
This symbol means "CAUTION"
This symbol means "POSSIBLE to
ELECTRIC SHOCK"
This symbol means "MUST"
This symbol means "DO NOT"
Should be follows to instructions.
We indicates to cabinet, chassis and parts
by label, which are special attention part.
Please follow to note and [Safety Instructions]
of User’s Manual.
Prevent the electric shock.
Please take care during working because
monitor has high voltage part and power
supply part.
Possible to die if you tough to these place
by miss take.
Please disconnect power plug during
overhaul, reassemble or change parts.
You will die or take damage by electric
shock if you touch to live part.
Use recommended components.
Please use to same characteristic compo-
nent, which is same as previous for your
safety and keep reliability especially marked
by in parts list and circuit diagram.
It is reason of electric shock or fire if you
use non-recommended component.
Should be kept same style of wiring or component.
Monitor uses tubes or tapes, which made
by insulator, and some components are
keep distance from surface of PWB for
safety.
Internal leads kept from hot part or high voltage
part by clamper or styling, so please return to
original condition for prevent to electric shock
or fire.
Should be done safety check after finished.
Every part (removed screws, component
and wiring) should be returned to previous
condition.
Check around repair position for make
damage by miss take and measure the
insulated impedance by meg-ohm meter.
Confirm the value of impedance, that
value is more than 4M ohm.
It is reason for electric shock or fire if that
value is less than 4M ohm.
Nobody can check and repair to the code
and combination circuit of HDCP.
Never remove the shield case, which is
assembled to the code and combination
circuit of HDCP.
WARNING

3
42PD8800/32LD8800
PRECAUTIONS
How to clean the plasma screen panel of the monitor
Before cleaning the monitor, turn off the monitor and disconnect the power plug from the power outlet.
To prevent scratching or damaging the plasma screen face, do not knock or rub the surface with sharp or hard
objects. Clean the screen with a soft cloth moistened with warm water and dry with a soft cloth. If it is not
enough, then use a cloth with mild detergent. Do not use harsh or abrasive cleaners.
How to clean the cabinet of the monitor
Use a soft cloth to clean the cabinet and control panel of the monitor. When excessively soiled dilute a neutral
detergent in water, wet and wring out the soft cloth and afterward wipe with a dry soft cloth.
Never use acid/alkaline detergent, alcoholic detergent, abrasive cleaner, powder soap, OA cleaner, car wax,
glass cleaner, etc. especially because they would cause discoloration, scratches or cracks.
1. Features
Large-screen, high-definition plasma display panel
The 42-inch color plasma display panel, with a resolution of 1024 (H) x 1024 (V) pixels, and the 32-inch color LCD
panel with a resolution of 1366(H) x 768(V) pixels, creates a high-definition, large-screen(aspect ratio : 16:9) and low-
profile flat display. Free from electromagnetic interferences from geomagnetic sources and ambient power lines, the
panel produces high-quality display images free from color misconvergence and display distortion.
High Performance Digital Processor
A wide range of input signals can be handed,including composite, component,and HDMI.High Definition Digital Pro-
cessor creates the fine-textured image with dynamic contrast. In addition, it corresponds to a broad array of per-
sonal computer signals, from 640 x 400 and 640 x 480 VGA to 1600 x 1200 UXGA.(RGB Input)
Easy-to-use remote control and on screen display system
The remote control included eases the work of setting display controls. Further, the on-screen display system,
displays the status of signal reception and display control settings in an easy-to-view fashion.
Power saving system
The power saver feature saves power consumption automatically when input signals are not available.
When connected to a VESA DPMS-compliant PC, the monitor cuts its power consumption while it is idle.
Connecting to an Audio Visual Device
• Two composite/S terminal*1,three composite terminal*2, two component terminal*2, two HDMI terminal and
a photo input terminal have been added. A composite video output terminal is also provided as a
monitoring output.
*1 One composite/S terminal are on the side input. Composite terminal and S terminal should not be con-
nected at the same time
*2 Two composite terminal and two component terminal cannot be used at the same time.
• A wide range of devices other than personal computers can also be connected.
Power Swivel Feature
It allows to turn the display left or right within ± 30 degree using the remote control.

4
42PD8800/32LD8800
2. Specifications
Applicable video signals for each input terminal
Terminal RCA D-sub
Signal CVBS S-video Component RGB RGB
AV1,2
AV3
AV4
AV5*
HDMI1,2
( :Available)
HDMI
RGB
Note : CVBS and S-video on AV5 should not be connected
at the same time to prevent interference on the picture
Panel Display dimensions Approx. 32 inches
(698(H) x 392(V)mm, diagonal 801mm)
Approx. 42 inches
(922(H) x 522(V)mm, diagonal 1059mm)
Resolution 1366(H) x 768(V) pixels 1024(H) x 1024(V) pixels
Net dimensions
including Stand :
813(W) x 663(H) x 350(D)mm
excluding Stand :
813(W) x 584(H) x 114(D)mm
including Opional Stand :
1134(W) x 728(H) x 350(D)mm
excluding Optional Stand :
1134(W) x 648(H) x 98(D)mm
Net weight including Stand : 27.6kg
excluding Stand : 21.9kg
including Opional Stand : 43.0kg
excluding Opional Stand : 37.3kg
Ambient
conditions
Temperature Operating : 5°C to 35°C, Storage : 0°C to 40°C
Relative humidity Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply AC100 - 240V, 50/60Hz
Power consumption / at standby 150W / <1W(100 - 220V)
150W / <1.1W(230 - 240V) 370W / <3W
Audio output speaker total 20W speaker total 36W
(VIDEO input)
Input terminals
AV1•2 : composite video input terminal (RCA) or component video input terminal (RCA)
L/R audio input terminal (RCA)
AV3•5 : composite video input terminal (RCA) or S video input terminal.
L/R audio input terminal (RCA)
AV4 : composite video input terminal (RCA)
L/R audio input terminal(RCA)
HDMI1•2 : HDMI input terminal
Audio input terminal (3.5mm Stereo Mini Jack)
Photo Input : Photo Input terminal / SD card slot
Input signals Composite video : PAL, SECAM, NTSC3.58, NTSC4.43, PAL60
Component video : 480i, 576i, 480p, 576p, 720p/50, 720p/60, 1080i/50, 1080i/60
Output Signal
OUTPUT (MONITOR) : composite video monitor-output terminal (RCA)
OUTPUT (MONITOR) : L/R audio monitor-output terminal (RCA)
OUTPUT (HEADPHONE) : L/R audio monitor-output terminal (Mini-pin)
OUTPUT (SUB-WOOFER) : Woofer output terminal
(RF input)
Input terminals ANT : 75Ω Unbalanced
RF Video System
PAL B, G, H / I / D, K
SECAM B, G / D, K / K1
NTSC-M
(RGB input)
Input terminals Analog RGB input terminal (D-sub 15-pin)
Audio unput terminal (3.5mm Stereo Mini Jack)
Input signals 0.7V/1.0Vp-p, analog RGB (Recommended Signal)
Sync signals
H/V separate, TTL level [2KΩ]
H/V composite, TTL level [2KΩ]
Sync on green, 0.3Vp-p [75Ω]
•The monitor takes at least 30 minutes to attain the status of optimal picture quality.

5
42PD8800/32LD8800
3. Service points
Lead free solder
This product uses lead free solder (unleaded) to help preserve the environment. Please read these instructions
before attempting any soldering work.
Caution: Always wear safety glasses to prevent fumes or molten solder from getting into the eyes. Lead free
solder can splatter at high temperatures (600˚C).
Lead free solder indicator
Printed circuit boards using lead free solder are engraved with an "F."
Properties of lead free solder
The melting point of lead free solder is 40-50˚C higher than leaded solder.
Servicing solder
Solder with an alloy composition of Sn-3.0Ag-0.5Cu or Sn-0.7Cu is recommended.
Although servicing with leaded solder is possible, there are a few precautions that have to be taken. (Not taking
these precautions may cause the solder to not harden properly, and lead to consequent malfunctions.)
Precautions when using leaded solder
Remove all lead free solder from soldered joints when replacing components.
If leaded solder should be added to existing lead free joints, mix in the leaded solder thoroughly after the lead
free solder has been completely melted (do not apply the soldering iron without solder).
Servicing soldering iron
A soldering iron with a temperature setting capability (temperature control function) is recommended.
The melting point of lead free solder is higher than leaded solder. Use a soldering iron that maintains a high
stable temperature (large heat capacity), and that allows temperature adjustment according to the part being
serviced, to avoid poor servicing performance.
Recommended soldering iron:
Soldering iron with temperature control function (temperature range: 320-450˚C)
Recommended temperature range per part:
Part Soldering iron temperature
Mounting (chips) on mounted PCB 320˚C±30˚C
Mounting (chips) on empty PCB 380˚C±30˚C
Chassis, metallic shield, etc. 420˚C±30˚C
SUBPOWER PWB (Subpower PWB, Filter PWB, Terminal PWB)
SOUND PWB (Audio PWB, Control PWB, SW PWB)
FC PWB
MAIN PWB (Main PWB, LED PDP PWB, LED LCD PWB, Swivel PWB)
The PWB assembly which has used lead free solder
Readjustment Power supply voltage (PDP only)
When a PANEL or a Power Unit is exchanged, power supply voltage needs to be adjusted. Please adjust to
make the values of Va and Vs of as should on the label currently stuck on the panel back upper parts.Adjust-
ment is performed by VR in the power supply unit. Please refer to the procedures of “Va” and “Vs” adjustments
on 22page.

6
42PD8800/32LD8800
4. Component names
[Main unit]
Control panel
(32")
• The main power switch is located on the lower surface.
Main power switch
(42")
Remote Control
Receiver
Indicating Lamp
SD Memory Card Slot
Sub Power button
Channel UP/▲button
Channel DOWN/▼button
Volume UP /►button
Volume DOWN /◄button
Input Select /OK button
Menu / Return button
OK
P
P
SD MEMORY
CARD
PUSH-EJECT
PH35814
POWER button
INPUT SELECT buttons
MENU button
OK button
SOUND MODE button
VOLUME UP/DOWN button
PROGRAM SELECT buttons
(TV)
FREEZE/MULTI MODE button
RECALL button
FUNCTION SELECT button
DVD CONTROL buttons
RETURN button
SELECT/ADJUST button
PICTURE MODE button
CH I/CH II button (TV)
CHANNEL UP/DOWN button (TV)
MUTE button
MULTI PICTURE button
PHOTO INPUT buttons
SWIVEL button
T/TEXT button
(TV)
CLE-970
[Remote control]

7
42PD8800/32LD8800
5. New adoption technology
[System control micom I001(M30627)]
Pin function table
No. PIN NAME I/O Panel: PDP/ LCD FUNCTION
1VREF (+5.0V) I PDP/ LCD 5V
2+5.0V I PDP/ LCD 5V
3AUDIO_SW1 I/O PDP/ LCD Audio SW1
4OSD_DATA I/O PDP/ LCD OSD DATA
5OSD_CLK I/O PDP/ LCD OSD CLK
6HP_VOL I/O PDP/ LCD Head Phone Volume
7FUNC_1 I/O PDP/ LCD Function1
8 DATA_OUT(FC) I/O PDP/ LCD FC MicroComputer 3 Lines Bus Data Out /Media Data Out
9 DATA_IN(FC) I/O PDP/ LCD FC MicroComputer 3 Lines Bus Data In/ Media Data In
10 CLK(FC) I/O PDP/ LCD FC MicroComputer 3 Lines Bus Clock/ Media Clock
11 BL_INST I/O PDP/ LCD Black Insert On/Off for 32V LCD (37V=Low)
12 BL_BLINK I/O PDP/ LCD Backlight Blink On/Off for 32V LCD (37V=Low)
13 GND I PDP/ LCD GND
14 CNVSS(FLASH) I PDP/ LCD CNVSS(FLASH)
15 DSUB COMP I/O PDP/ LCD Sync Switching
16 RGBSW I/O PDP/ LCD Sync Switching
17 RESET I PDP/ LCD Reset
18 16MHz Oscillation O PDP/ LCD OSC-OUT
19 GND I PDP/ LCD GND
20 16MHz Oscillation I PDP/ LCD OSC-IN
21 +5.0V I PDP/ LCD 5V
22 NMI(+5.0V) I PDP/ LCD 5V PULL UP
23 RMCON I/O PDP/ LCD Receiving Remote Control Signal
24 NC I/O PDP/ LCD NC
25 V.FREQ_3 I/O PDP/ LCD V.Frequency
26 SCV.SYNC I/O PDP/ LCD SUB_Y.SYNC (Composite䋩
27 IRQ䋨PM-IRQ) I/O PDP/ LCD PDP Control
28 MCV.SYNC I/O PDP/ LCD MAIN_Y.SYNC (Composite䋩
29 POWER_LED I/O PDP/ LCD L䋺Lighting (Power Save)
30 FUNC_2 I/O PDP/ LCD Function2
31 CEC_OUT I/O PDP/ LCD CEC OUT(CEC1)
32 H.FREQ_3 I/O PDP/ LCD H.Frequency
33 PDWN I/O PDP/ LCD Panel LVDS
34 RXD2 I/O PDP/ LCD RS-232C Communication
35 TXD2 I/O PDP/ LCD RS-232C Communication
36 TXD1(RS232C/FLASH) I/O PDP/ LCD FLASH for Writing
37 I PDP/ LCD 5V
38 RXD1(RS232C/FLASH) I/O PDP/ LCD FLASH for Writing
39 I PDP/ LCD GND
40 SCLK(FLASH) I/O PDP/ LCD FLASH for Writing
41 BUSY(FLASH) I/O PDP/ LCD FLASH for Writing
42 TXD0(DTT) I/O PDP/ LCD DTT
43 RXD0(DTT) I/O PDP/ LCD DTT
44 SDA4(panel) I/O PDP/ LCD PDP Communication䋨I2C Bus䋩
45 SCL4(panel) I/O PDP/ LCD PDP Communication䋨I2C Bus䋩
46 M_ENABLE I/O PDP/ LCD Media Enable
47 M_SCLK I/O PDP/ LCD Media Clock
48 M_SDA I/O PDP/ LCD Media Data
49 M_WAKEUP I/O PDP/ LCD Media Wakeup
50 PDPGO(PM_ON) I/O PDP/ LCD PDP Control/LCD Panel 12V/WVGA Power

8
42PD8800/32LD8800
No. PIN NAME I/O Panel: PDP/ LCD FUNCTION
51 CPUGO(PM_CPU) I/O PDP/ LCD PDP Control/Inverter Voltage
52 EPM (FLASH) I/O PDP/ LCD FLASH for Writing
53 VIDEO.DET_1 I/O PDP/ LCD VIDEO Board Detection
54 SCL1 I/O PDP/ LCD I2C䋨To the Side of Main Board䋩FE/MSP3455or MSP3415G/SAA5361
55 SDA1 I/O PDP/ LCD I2C䋨To the Side of Main Board䋩FE/MSP3455or MSP3415G/SAA5361
56 HDMI-RESET I/O PDP/ LCD HDMI-Reset
57 HDMI-HPD_RESET I/O PDP/ LCD Hot Plug Detect Reset
58 SEL_0 I/O PDP/ LCD FC Clock/Others SW
59 SEL_1 I/O PDP/ LCD HDMI/DTT SW
60 TUNER.DET_1 I/O PDP/ LCD TUNER Detection
61 CE (FLASH) I/O PDP/ LCD FLASH for Writing
62 STAND.CIR_DET I/O PDP/ LCD Stand Detection
63 SW_L_OUT I/O PDP/ LCD Swivel L Output
64 SW_R_OUT I/O PDP/ LCD Swivel R Output
65 M_SW I/O PDP/ LCD Bridge Media Circuit Connection Judgement Terminal
66 INITIALIZE I/O PDP/ LCD Memory Initial
67 BR_MUTE I/O PDP/ LCD Bridge Media Audio Mute
68 CK_SEL I/O PDP/ LCD Clock Selector
69 SCDT I/O PDP/ LCD HDMI Power Save for Return
70 CK_INV I/O PDP/ LCD Clock Invert
71 DVI-SW I/O PDP/ LCD DVI Control
72 CUR_PRTCT I/O PDP/ LCD Power Swivel Overcurrent Detection
73 SP_MUTE I/O PDP/ LCD SP Relay
74 AUDIO_MUTE I/O PDP/ LCD Audio MUTE
75 ASEL1 I/O PDP/ LCD Audio Switching SW
76 ASEL2 I/O PDP/ LCD Audio Switching SW
77 SDA2 I/O PDP/ LCD I2C(TAS3103/TAS5508)
78 SCL2 I/O PDP/ LCD I2C(TAS3103/TAS5508)
79 D-SUB I/O PDP/ LCD D-SUB COMP for Sync Switching
80 BM_SW I/O BM Switching
81 RGB_BLK_2 I/O NC
82 RGB_BLK_3 I/O NC
83 AUDIO_RESET I/O Audio Circuit Reset
84 PDP_WVGA_LCD_SW_ I/O PDP/42WVGA/LCD Detection
85 +5.0V I
86 EDID_PROTECT_1 I/O PDP/ LCD Memory Protect(Not necessary if power is available to use䋩
87 GND I PDP/ LCD GND
88 WSS_1 I/O PDP/ LCD NC
89 WSS_2 I/O PDP/ LCD NC
90 WSS_3 I/O PDP/ LCD NC
91 TV.AFC(M) I/O PDP/ LCD Main Tuner Control (AFC)
92 TV.AFC(S) I/O PDP/ LCD Sub Tuner Control (AFC)
93 AUDIO_SW2 I/O PDP/ LCD Audio SW2
94 EDID_PROTECT_2 I/O PDP/ LCD Memory Protect(Not necessary if power is available to use䋩
95 HP_DETECT I/O PDP/ LCD HEAD PHONE DETECT
96 PDP_WVGA_LCD_SW_ I/O PDP/ LCD PDP/42WVGA/LCDᬌ಴
97 INT_HDMI I/O PDP/ LCD INT(HDMI)
98 CEC_IN I/O PDP/ LCD CEC IN(CEC2)
99 COMP_SW I/O PDP/ LCD Component SW Main 㹤DSUB
100 DEMP_OUT I/O PDP/ LCD De-emphasis Control Output for HDMI

9
42PD8800/32LD8800
No. PIN NAME I/O Panel: PDP/ LCD FUNCTION
101 NC I/O LCD NC
102 SCL0 I/O PDP/ LCD I2C䋨To the Side of Main Board䋩(TA1391FG/CXA2069/uPD64015/TB1274AF)
103 SDA0 I/O PDP/ LCD I2C䋨To the Side of Main Board䋩(TA1391FG/CXA2069/uPD64015/TB1274AF)
104 SCL3(EEPROM) I/O PDP/ LCD I2C䋨EEPROM䋩
105 SDA3(EEPROM) I/O PDP/ LCD I2C䋨EEPROM䋩
106 EPGGO I/O PDP/ LCD EPGGO
107 EXT_RESET I/O PDP/ LCD EXTERNAL RESET
108 OSD_CS I/O PDP/ LCD OSD CS
109 FC_ENABLE I/O PDP/ LCD FC MicroComputer 3 Lines Enable
110 V_P_DET_1 I/O PDP/ LCD V_DET_1(Power Save Return䋩
111 V_P_DET_2 I/O PDP/ LCD V_DET_2(Power Save Return䋩
112 IRQ_DTT I/O PDP/ LCD DTT IRQ
113 DTT_POWER I/O PDP/ LCD DTT POWER
114 DISPEN I/O PDP/ LCD DISPEN/Backlight on
115 HDMI_A_SW I/O PDP/ LCD HDMI AUDIO SW
116 SCL5 I/O PDP/ LCD I2C䋨Sil9021䋩
117 SDA5 I/O PDP/ LCD I2C䋨Sil9021䋩
118 SCL6 I/O PDP/ LCD I2C䋨To the Side of Sensor Board䋩(AD7414䋩
119 SDA6 I/O PDP/ LCD I2C䋨To the Side of Sensor Board䋩(AD7414䋩
120 COLOR_SYS I/O PDP/ LCD Color System (Pull-in range Switching䋩
121 AD_KEY3 I/O PDP/ LCD AD KEY3**
122 AD_KEY2 I/O PDP/ LCD AD KEY2*
123 AD_KEY1 I/O PDP/ LCD AD KEY1(Power)
124 TV.POWER I/O PDP/ LCD H:PowerON䇮L:(Standby,PowerSave)
125 DIP.DET I/O PDP/ LCD DIP DET
126 POWER_SAVE I/O PDP/ LCD L䋺Lighting(Standby䍂PowerSave), H䋺Lights-out
127 GND I PDP/ LCD GND
128 FAN_ALARM *1 I/O PDP/ LCD FAN ALARM

10
42PD8800/32LD8800
MAIN µ-COMPUTE
R
(M3062
7
)
HP_VOL DA1 P54 VIDEO.DET_1 DSUB COMP P87 P53 SEL_2 RGB SW P86 P52 SEL_1 POWER_SAVE P101 P51 TUNER.DET POWER_LED P76 M_SCK P136 P127 STAND.CIR_DE
T
TV.POWER P103 P126 SW_L_OUT BR_MUTE P45 P125 SW_L_OUT CK_SEL P44 P46 INITIALIZ
E
EEPROM
SCDT
P43
P9
7
AUDIO
_
SW
(CAT24WC64)
CK_IN
V
P42 P47 M_SW
DVI-SW P41 P07 SCL3 BL_BLIN
K
P140 P06 SDA3
EDID
_
PROTECT
_
1
P30
P04
EXT
_
RESET
䇼
A0/A1h
䇽
A
UD RST P121 P115 DISPEN
CUR_PRTC
T
P40 P32
SP_MUTE P37 P33
A
UDIO_MUTE P36 P133
A
SEL1 P35 P132
A
SEL2 P34 P11
PDWN P72 P10 TEMPERATURE V_P_DET_1 P01 VIDEO DECODER SENSOR (0ption
)
TUNER (FE Main)
A
UDIO PROCESSO
R
IRQ(PM
-
IRQ)
P80
P1
7
PDP
_
WVGA
_
LCD
_
SW1
(TB12
7
4)
(AD
7
414
䋩
(ENG39616G
*1/V0
-
A31FTV *2/ENG29
5
**G *3)
(TAS3103)
DA0 P120 PDP_WVGA_LCD_SW2 SCL0 P111 SCL6 SCL1 SCL2
M_SD
A
P135 SDA0 P110 SDA6 SDA1 SDA2
PDPGO(PM_ON) P57 P131 HDMI_RESE
T
*3䇼84/85h䇽
CPUGO(PM
_
CPU)
P
5
6
P130
HDMI
_
HPD
_
RESET
䇼
8E/8Fh
䇽
䇼
3Ah
䇽
䇼
C0h
䇽
䇼
6Ah
䇽
RMCON(AVC
)
P84
CEC_OU
T
TA2OUT FC SUB µ-com AV S
W
SOUND MULTIPLE
X
A
UDIO PROCESSO
R
V
.
FREQ
_
3
INT0
(H8S
_
2239 )
(CXA2069Q)
(MSP341
5
G*
5
䋯
MSP34
55
G *4)
(TAS
55
08
䋩
V_P_DET_2 P00 CLK3 CLOCK SCL0 S-1 SCL1 SCL2 SCV.SYNC TA4IN SOUT3 DATA IN SDA0 S-2 S_DET_AV3 SDA1 SDA2
MCV.SYNC TA3IN SIN3 DATA OUT S-3 COMP_DET_AV2 RESET MSP_RESET
AD
_
KEY3
AN6
P02
ENABLE
S
-
4
COMP
_
DET
_
AV1
䇼
80/81h
䇽
䇼
36h
䇽
A
D_KEY2
A
N5
A
N27 WSS_1 S2-2
A
UDIO_SW2 P22
A
N26 WSS_2 OSD CONTROLER S2-3 FE Sub
EDID
_
PROTECT
_
2
P21
AN2
5
WSS
_
3
(OSDCM201 )
S2
-
3
(ENG39616G)
TV.AFC(S)
A
N23 CLK4 SCLK S2-4 SCL1
TV
.
AFC(M)
AN24
SOUT4
SIN
䇼
90/91h
䇽
SDA1
A
D_KEY1
A
N4 P03 CS
RESET
RESET
3D
L
Y/C
䇼
C6h
䇽
HDMI
_
A
_
SW
P114
P13
7
M
_
ENABLE
(
u
PD6401
5
)
H.FREQ_3 TA1IN M_SCLK SCL0 FUNCTION_
2
P75 M_SD
A
SDA0 TELETEXT TV.SEL_3
FAN
_
ALARM
P100
P134
M
_
WAKEUP
(SAA
5
361
䋩
TV
.
SEL
_
4
WVGA PANEL
SCL6
P111
P124
BM
_
SW
䇼
B8h
䇽
SCL1
TV
.
SEL
_
1
FUNC
_
2
P110
P123
RGB
_
BLK
_
2
SDA1
TV
.
SEL
_
2
SCL4
SCL4
BL_INST P141 P122 RGB_BLK_3 SYNC SEPARATION FE.SW_1 SDA4 SDA4
DIP
_
DET
P102
(TA1391FG)
䇼
60/61h
䇽
FE
.
SW
_
2
DTT
TXD0
RXD2
RS232C
SCL0
AGC
䇼
30/31h
䇽
DTT RXD0 TXD2 RS232C SDA0 Text Ys_SW
D-SUB P31 S_Trap
HP
_
DETECT
AN20
P60
䇼
D8/D9h
䇽
DTT_POWER P116 P61 LCD PANE
L
IRQ
_
DTT
P11
7
P113
HDMI
NC
P12
P112
(Sil9021)
SCL4
DEMP_OU
T
P13 P65 SCLK(FLASH) SCL5 DA
C
SDA4
COMP
_
SW
P14
P64
BUSY(FLASH)
SDA
5
M62342G
TXD1
FLASH
_
TXD
SCL4
INT (HDMI)
P16
RXD1
FLASH
_
RXD
䇼
68/69h
䇽
SDA4
CEC_IN P15 CNVss CE EPM CNVss P56
EPGGO
P0
5
P
5
0
CE
N
orma
l
0V
5
V
0V
COLOR_SYS P107 P55 EPM Flash Writing 5V 0V 5V
WVGA 32LCD 37LCD11
PANEL TYPE
PDP
01 10
䌐120 P17
00
Buffer
Buffer
Level
PDP
Block diagram
