Hitachi EH 5000AC-3 User manual

INTRODUCTION
Read this manual carefully to learn how to operate and
service your machine correctly. Failure to do so could
result in personal injury and/or machine damage.
This standard specification machine can be operated
under the following conditions without being modified.
Atmospheric Temperature: -20 to 50 °C (-4 to 122 °F)
Altitude: 0 m to 2000 m (0 ft to 6600 ft)
In case the machine is used under conditions other than
described above, consult your nearest Hitachi dealer.
This manual should be considered a permanent part of
your machine and should remain with the machine when
you sell it.
This machine is of metric design. Measurements in this
manual are metric. Use only metric hardware and tools as
specified.
• SI Units (International System of Units) are used in
this manual.
For reference MKS system units and English units are
also indicated in parentheses after the SI units.
Example : 24.5 MPa (250 kgf/cm, 3550 psi)
Right-hand and left-hand sides are determined by
facing in the direction of forward travel.
Write product identification numbers in the Machine
Numbers section. Accurately record all the numbers
to help in tracing the machine should it be stolen.
Your dealer also needs these numbers when you order
parts. If this manual is kept on the machine, also file the
identification numbers in a secure place off the machine.
Use only diesel fuel with quality specified in JIS K-2204,
EN-590 or ASTM D-975 which contents 15 ppm or lower
sulfur.
Also use fuel that complies with solid contamination level
of class 18/16/13 of ISO4406-1999 (solid contamination
includes dust). If the fuel specified above is not used,
exhaust gas that exceeds the regulation values may be
discharged, causing serious problem on the engine.
Consult your nearest Hitachi dealer.
Warranty is provided as a part of Hitachi’s support
program for customers who operate and maintain their
equipment as described in this manual. The warranty is
explained on the warranty certificate which you should
have received from your dealer.
This warranty provides you the assurance that Hitachi will
back its products when defects occur within the warranty
period. In some circumstances, Hitachi also provides field
improvements, often without charge to the customer,
even if the product is out of warranty.
Should the equipment be abused or modified to
change its performance beyond the original factory
specifications, the warranty will become void and field
improvements may be denied.
Setting fuel delivery above specifications or otherwise
overpowering machines will result in such action.
Moreover, when replacement parts are required, be sure
to use genuine Hitachi parts. Failure to do so may result in
voiding the warranty and/or denial of field improvements.
The Yellow Pages in this operator’s manual contain
IMPORTANT SAFETY INFORMATION.
Read these pages thoroughly and familiarize yourself
with the safety standards and recommendations set
forth in these yellow pages of the manual.
Follow all safety instructions prior to and while
operating this dump truck.
Only qualified, experienced operators officially licensed
(according to local law) should be allowed to operate the
machine.
Moreover, only officially licensed personnel should be
allowed to inspect and service the machine.
Prior to operating this machine, including
communication satellite system, in a country other
than a country of its intended use, it may be necessary
to make modifications to it so that it complies with
the local regulatory standards (including safety
standards) and legal requirements of that particular
country.
Please do not export or operate this machine
outside of the country of its intended use until such
compliance has been confirmed. Please contact
Hitachi Construction Machinery Co., Ltd. or any of
our authorized distributors or dealers if you have any
questions concerning compliance.
All information, illustrations and specifications in this manual are based on the latest product information available at the
time of publication. The right is reserved to make changes at any time without notice.
©2012 Hitachi Construction Machinery Co., Ltd.
All rights reserved.
Find manuals at https://best-manuals.com

INDEX
MACHINE NUMBERS
SAFETY
SAFETY SIGNS
COMPONENTS NAME
GETTING ON/OFF MACHINE
EMERGENCY EXIT
OPERATOR’S STATION
BREAK-IN
OPERATING ENGINE
DRIVING MACHINE
OPERATING MACHINE
MAINTENANCE
MAINTENANCE UNDER SPECIAL ENVIRONMENTAL CONDITIONS
STORAGE
TROUBLESHOOTING
SPECIFICATIONS
INDEX
Find manuals at https://best-manuals.com

CONTENTS
MACHINE NUMBERS
SAFETY
Recognize Safety Information ....................................................S-1
Understand Signal Words.............................................................S-1
Follow Safety Instructions............................................................S-2
Prepare for Emergencies...............................................................S-2
Wear Protective Clothing..............................................................S-3
Protect Against Noise ....................................................................S-3
Inspect Machine ..............................................................................S-3
General Precautions for Cab........................................................S-4
Use Handholds and Steps ............................................................S-4
Operator’s Visibility.........................................................................S-5
Adjust Operator’s Seat...................................................................S-6
Fasten Your Seat Belt......................................................................S-6
Move and Operate Machine Safely...........................................S-7
Handle Starting Aids Safely .........................................................S-7
Operate Only from Operator’s Seat ..........................................S-8
Jump Starting ...................................................................................S-8
Avoid Injury Caused by High Tension Electric Shock .........S-9
Investigate Job Site Beforehand................................................S-9
Provide Signals for Jobs Involving Multiple Machines.......S-9
Drive Machine Safely...................................................................S-10
Wheel Maintenance.....................................................................S-11
Drive on Snow Safely .................................................................. S-12
Avoid Injury from Rollaway Accidents..................................S-12
Avoid Injury from Back-Over Accidents ...............................S-13
Keep Person Clear from Working Area..................................S-13
Avoid Tipping.................................................................................S-14
Protect Against Falling Stones and Debris.......................... S-15
Operate with Caution .................................................................S-15
Avoid Power Lines........................................................................S-15
Precautions for Lightning.......................................................... S-16
Avoid Overloading ......................................................................S-16
Protect Against Flying Debris .................................................. S-17
Park Machine Safely..................................................................... S-17
Prevent Unintended Machine Movement........................... S-18
Handle Fluids Safely - Avoid Fires...........................................S-18
Practice Safe Maintenance........................................................S-19
Warn Others of Service Work ...................................................S-20
Support Machine Properly........................................................ S-20
Stay Clear of Moving Parts ........................................................S-20
Prevent Parts from Flying.......................................................... S-21
Prevent Burns................................................................................. S-21
Replace Rubber Hoses Periodically........................................ S-22
Avoid High-Pressure Fluids.......................................................S-22
Prevent Fires...................................................................................S-23
Evacuating in Case of Fire..........................................................S-24
Beware of Exhaust Fumes..........................................................S-24
Precautions for Welding and Grinding.................................S-25
Avoid Heating Near Pressurized Fluid Lines....................... S-25
Avoid Applying Heat to Lines Containing Flammable
Fluids ...........................................................................................S-25
Precautions for Handling Accumulator and Gas
Cylinder ......................................................................................S-26
Remove Paint Before Welding or Heating........................... S-26
Beware of Asbestos and Silicon Dust and Other
Contamination.........................................................................S-26
Prevent Battery Explosions ....................................................... S-27
Service Air Conditioning System Safely ...............................S-27
Handle Chemical Products Safely........................................... S-28
Dispose of Waste Properly.........................................................S-28
Precautions for Communication Terminal........................... S-28
SAFETY SIGNS..............................................................................S-29
COMPONENTS NAME ..................................................................1-1
GETTING ON/OFF MACHINE.....................................................1-2
EMERGENCY EXIT
Emergency Exit ................................................................................1-3
Evacuating in Case of Fire.............................................................1-4
OPERATOR’S STATION
Cab Features......................................................................................1-6
Monitor Display................................................................................1-7
How to Use Screens........................................................................1-7
How to Use Key Pad........................................................................1-9
Basic Screen....................................................................................1-10
Engine Related Warning Indicators........................................1-14
Driving Related Warning Indicators.......................................1-17
Hydraulic Related Warning Indicators .................................. 1-21
Light Indicators .............................................................................1-24
Miscellaneous Indicators...........................................................1-25
Alarm Occurrence Screen..........................................................1-27
Clock Setting..................................................................................1-28
Head Lights/Front Combination Lights/Horns..................1-30
Side Lights.......................................................................................1-31
Rear Lights ......................................................................................1-32
Maintenance Lights.....................................................................1-33
Steering Wheel..............................................................................1-34
Horn Switch....................................................................................1-34
Turn Signal/High Beam Lever Switch.................................... 1-34
Hazard Warning Lamp Switch..................................................1-35
Tilt/Telescope Steering Wheel .................................................1-35
Accelerator Pedal..........................................................................1-35
Service Brake Pedal......................................................................1-36
Electric Brake Pedal......................................................................1-37
Parking Brake.................................................................................1-37
Center Console..............................................................................1-38
Hoist Lever......................................................................................1-40
Console Panel ................................................................................1-42
Rear Console ..................................................................................1-49
Dome Light Switch ......................................................................1-50
Sun Visor..........................................................................................1-50
Air Conditioner..............................................................................1-51
Designations and Functions of the Control Panel............1-52
Cooling............................................................................................. 1-53
Heating.............................................................................................1-54
Dehumidifying and Heating.....................................................1-54
Defrosting .......................................................................................1-54
Blower Operation Without Cooling or Heating.................1-55
Ventilation of the Cab.................................................................1-55
Find manuals at https://best-manuals.com

CONTENTS
AM/FM Radio Operation............................................................ 1-56
Digital Clock Setting Procedure..............................................1-57
Camera Monitor............................................................................1-58
Adjusting Operator’s Seat .........................................................1-59
Adjusting Trainer’s Seat..............................................................1-62
Seat Belt...........................................................................................1-63
Cab Door Lock...............................................................................1-64
Opening/Closing Cab Left Door .............................................1-64
Electrical Equipment Box (Behind Cab)................................1-65
Relay Box .........................................................................................1-67
BREAK-IN
Observe Machine Closely.............................................................2-1
Every 10 Hours or Each Shift .......................................................2-1
After the First 50 Hours .................................................................2-1
OPERATING ENGINE
Inspect Machine Daily Before Starting....................................3-1
Before Starting Engine ..................................................................3-2
System Check....................................................................................3-3
Starting Engine in Normal Temperature.................................3-4
Starting Engine in Cold Weather................................................3-5
Check Instruments After Starting..............................................3-6
Using Booster Batteries.................................................................3-7
Stopping Engine..............................................................................3-9
DRIVING MACHINE
Drive Machine Carefully................................................................4-1
Starting ...............................................................................................4-2
Propel Change..................................................................................4-3
Acceleration ......................................................................................4-3
Cruise Control...................................................................................4-4
Deceleration......................................................................................4-6
Electric Brake.....................................................................................4-6
Auto Retard........................................................................................4-7
Steering...............................................................................................4-9
Stopping Machine........................................................................4-10
Parking Machine...........................................................................4-11
Towing.............................................................................................. 4-12
OPERATING MACHINE
Loading...............................................................................................5-1
Load Weighing System..................................................................5-2
Hauling................................................................................................5-3
Dumping ............................................................................................5-4
Speed Limitation Function While
Dump Body is Raised................................................................5-7
Deactivation of Speed Limitation Function
in an Emergency.........................................................................5-7
MAINTENANCE
Correct Maintenance and Inspection Procedures...............7-1
Check Hour Meter Regularly .......................................................7-2
Use Correct Fuels and Lubricants..............................................7-2
Prepare Machine for Maintenance............................................7-3
Installing Dump Body Prop Cable.............................................7-5
Removal and Storage of Dump Body Prop Cable................7-6
Installing Dump Body Prop Pins ................................................7-7
Removal and Storage of Dump Body Prop Pins...................7-8
Inspection/Maintenance Lights.................................................7-9
Main Part/Component Location Diagram...........................7-11
Periodic Replacement of Parts.................................................7-12
Hydraulic System..........................................................................7-13
Maintenance Guide .....................................................................7-15
A. Greasing......................................................................................7-20
B. Engine.......................................................................................... 7-23
Check Engine Oil Level.......................................................... 7-24
Change Engine Oil..................................................................7-25
Replace Engine Oil Filters.....................................................7-25
C. Travel Reduction Gear............................................................7-27
Check Gear Oil Level.............................................................. 7-28
Change Gear Oil ......................................................................7-29
Replace Gear Oil Filter........................................................... 7-29
Clean and Replace Air Breather.........................................7-30
Clean Oil Cooler Core ............................................................7-30
D. Hydraulic System.....................................................................7-31
Inspection and Maintenance of Hydraulic
Equipment ...........................................................................7-32
Check Hydraulic Oil Level ....................................................7-34
Drain Hydraulic Oil Tank Sump .......................................... 7-35
Replace Full-Flow Filter Element .......................................7-36
Replace Line Filter Element.................................................7-37
Change Hydraulic Oil.............................................................7-38
Replace Suction Filter............................................................7-38
Check Hoses and Lines .........................................................7-41
Service Recommendations for Hydraulic Fittings.......7-44
Replace Hydraulic Oil Tank Breather................................7-47
E. Fuel System................................................................................7-48
Drain Fuel Tank Sump............................................................7-50
Drain Fuel Filter........................................................................7-50
Replace Fuel Filter Element................................................. 7-51
Replace Fuel Filter...................................................................7-52
Check Fuel Hoses .................................................................... 7-53
Clean and Replace Fuel Tank Breather ............................7-54
F. Air Cleaner...................................................................................7-55
Clean Air Cleaner Outer Element ......................................7-55
Replace Air Cleaner Outer and Inner Elements............7-55
Clean Air Cleaner Dust Cups............................................... 7-57
Check Vacuator Valve.............................................................7-58
G. Cooling System........................................................................7-59
Check Coolant Level .............................................................. 7-60
Check DCA4 Concentration in Coolant...........................7-61
Replace Coolant Filter ...........................................................7-69
Change Coolant.......................................................................7-70
Clean Radiator, After Cooler Interior................................7-70
Clean Radiator, After Cooler Core .....................................7-71
Check Fan Belt for Wear........................................................7-71
H. Air Conditioner.........................................................................7-72
Clean and Replace Recirculation Air Filter..................... 7-72
Clean and Replace Ventilation Air Filter..........................7-73
Check Refrigerant Quantity.................................................7-74
Check Compressor Belt Tension ........................................7-75
Clean Condenser Core ..........................................................7-76
Check Tightening Torque.....................................................7-77
Find manuals at https://best-manuals.com

CONTENTS
Seasonal Maintenance..........................................................7-78
I. Electrical System........................................................................ 7-79
Batteries .....................................................................................7-80
Replacing Fuses.......................................................................7-85
Check Fusible Link..................................................................7-87
Check Electrical Cables and Wire Harnesses.................7-88
Check Emergency Engine Stop Switch...........................7-90
Check Lights .............................................................................7-91
Check Horn and Backup Alarm Buzzer............................7-91
Check Suspension Pressure Sensor..................................7-92
J. Brakes & Steering System ......................................................7-94
Check Brake Operation.........................................................7-94
Check Service Brake...............................................................7-95
Check Parking Brake ..............................................................7-96
Check Accumulator................................................................ 7-97
Check Front Brake Lining .....................................................7-99
Check Front Brake Disk .........................................................7-99
Check Rear Brake Cooling Oil Level................................7-100
Drain Rear Brake Cooling Oil Tank Sump......................7-101
Change Rear Brake Cooling Oil........................................7-102
Replace Suction Filter..........................................................7-102
Replace Line Filter Element...............................................7-104
Clean Brake Cooling Oil Cooler........................................7-105
K. Suspension, Wheels & Tires................................................7-106
Check Suspension.................................................................7-107
Check Wheels .........................................................................7-108
Check Front Axle ...................................................................7-109
Check Front Wheel Lubricant ...........................................7-109
Change Front Wheel Lubricant........................................7-109
Check Tire Inflation Pressure.............................................7-110
Check Tire Condition ...........................................................7-111
Check Wheel Alignment.....................................................7-111
L. Miscellaneous..........................................................................7-112
Check, Clean and Replace Alternator
Carbon Brush ....................................................................7-112
Check and Change Coolant
in the Control Cabinet ...................................................7-115
Clean and Replace Pressurized
Control Cabinet Filter.....................................................7-116
Clean Rear Axle Inside.........................................................7-117
Check and Replace Seat Belt.............................................7-117
Check Windshield Washer Tank .......................................7-117
Check Play Amount in Steering Wheel Stroke............7-118
Check Auto-Lubrication System......................................7-119
Check Tightening Torque of Bolts and Nuts................7-121
Check Dump Body Prop Cable.........................................7-132
MAINTENANCE UNDER SPECIAL
ENVIRONMENTAL CONDITIONS.............................................9-1
STORAGE
Storing Machine............................................................................10-1
Removing Machine from Storage ..........................................10-2
TROUBLESHOOTING
Cummins Fault Code Lamps and
Diagnostic Switches...............................................................11-1
Engine...............................................................................................11-2
Electrical System...........................................................................11-6
Hydraulic System..........................................................................11-9
Hydraulic Hoist System ............................................................11-11
Hydraulic Steering System......................................................11-11
Steering Pump.............................................................................11-12
Steering Control Valve..............................................................11-13
Front Axle......................................................................................11-14
Rear Axle........................................................................................11-15
Hoist Pump Driveline................................................................11-15
Rear Axle Planetary....................................................................11-16
Parking Brake...............................................................................11-16
Alternator......................................................................................11-17
Wheel Motor ................................................................................11-17
Blower Motor ...............................................................................11-18
SPECIFICATIONS
Specifications.................................................................................12-1
Hitachi Loading Policy................................................................12-2
INDEX...............................................................................................14-1
Find manuals at https://best-manuals.com

CONTENTS
MEMO
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
..................................................................................................................................................................................................
Find manuals at https://best-manuals.com

The manufacturing Nos. explained in this group is the
individual number (serial No.) given to each machine and main
components. These numbers are requested when inquiring
any information on the machine and/or components. Fill these
serial Nos. in the blank spaces in this group to immediately
make them available upon request.
Machine
MODEL/TYPE:
PRODUCT
IDENTIFICATION
NUMBER:
fNOTE:
*HCMQHA00A00010001*
Marks to indicate the start
and end of the PIN
PRODUCT IDENTIFICATION
NUMBER (PIN)
M8R7-03-001
MACHINE NUMBERS
Machine ROPS Cab
View A
Rollover Protective Structure Cab Name Plate
MODEL/TYPE:
ROPS
MODEL
NUMBER:
MAX
MACHINE
MASS, M-kg:
A
Find manuals at https://best-manuals.com

MACHINE NUMBERS
Control Cabinet
TYPE:
MFG. NO.:
Hydraulic Pump
TYPE:
MFG. NO.:
Control Valve
TYPE:
MFG. NO.:
MQHA-00-003
MQHA-00-004
MQHA-00-005

MACHINE NUMBERS
Travel Reduction Gear
TYPE:
MFG. NO.(LEFT):
MFG. NO.(RIGHT):
M8R7-00-003

Recognize Safety Information
•These are the SAFETY ALERT SYMBOLS.
• When you see these symbols on your machine or in this
manual, be alert to the potential for personal injury.
• Follow recommended precautions and safe operating
practices.
Understand Signal Words
•On machine safety signs, signal words designating the
degree or level of hazard - DANGER, WARNING, or CAUTION
- are used with the safety alert symbol.
• DANGER indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
• WARNING indicates a potentially hazardous situation
which, if not avoided, could result in death or serious
injury.
• CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate
injury.
• DANGER or WARNING safety signs are located near
specific hazards. General precautions are listed on
CAUTION safety signs.
• Some safety signs do not use any of the designated signal
words above after the safety alert symbol are occasionally
used on this machine.
•To avoid confusing machine protection with personal safety
messages, a signal word IMPORTANT indicates a situation
which, if not avoided, could result in damage to the
machine.
•
fNOTE indicates an additional explanation for an
element of information.
S-1
SAFETY
SA-688
SA-1223

Follow Safety Instructions
•Carefully read and follow all safety signs on the machine
and all safety messages in this manual.
•Safety signs should be installed, maintained and replaced
when necessary.
• If a safety sign or this manual is damaged or missing,
order a replacement from your authorized dealer in the
same way you order other replacement parts (be sure to
state machine model and serial number when ordering).
•Learn how to operate the machine and its controls correctly
and safely.
•Allow only trained, qualified, authorized personnel to
operate the machine.
•Keep your machine in proper working condition.
• Unauthorized modifications of the machine may impair
its function and/or safety and affect machine life.
•The safety messages in this SAFETY chapter are intended
to illustrate basic safety procedures of machines. However
it is impossible for these safety messages to cover every
hazardous situation you may encounter. If you have any
questions, you should first consult your supervisor and/or
your authorized dealer before operating or performing
maintenance work on the machine.
Prepare for Emergencies
•Be prepared if a fire starts or if an accident occurs.
• Keep a first aid kit and fire extinguisher on hand.
• Thoroughly read and understand the label attached on
the fire extinguisher to use it properly.
• To ensure that a fire-extinguisher can be always used
when necessary, check and service the fire-extinguisher
at the recommended intervals as specified in the fire-
extinguisher manual.
• Establish emergency procedure guidelines to cope with
fires and accidents.
• Keep emergency numbers for doctors, ambulance
service, hospital, and fire department posted near your
telephone.
SAFETY
S-2
SA-437
SA-003

Wear Protective Clothing
•Wear close fitting clothing and safety equipment
appropriate to the job.
You may need:
A hard hat
Safety shoes
Safety glasses, goggles, or face shield
Heavy gloves
Hearing protection
Reflective clothing
Wet weather gear
Respirator or filter mask.
Be sure to wear the correct equipment and clothing for the
job. Do not take any chances.
• Avoid wearing loose clothing, jewelry, or other items that
can catch on control levers or other parts of the machine.
•Operating equipment safely requires the full attention of
the operator. Do not wear radio or music headphones while
operating the machine.
Protect Against Noise
•Prolonged exposure to loud noise can cause impairment or
loss of hearing.
• Wear a suitable hearing protective device such as
earmuffs or earplugs to protect against objectionable or
uncomfortably loud noises.
Inspect Machine
•Inspect your machine carefully each day or shift by walking
around it before you start it to avoid personal injury.
• In the walk-around inspection, be sure to cover all points
described in the“INSPECT MACHINE DAILY BEFORE
STARTING” chapter in the operator’s manual.
SAFETY
S-3
SA-438
SA-434
SA-435

General Precautions for Cab
•Before entering the cab, thoroughly remove all dirt and/or
oil such as mud, grease, soil or stones that may mess up the
cab from the soles of your work boots. If any controls such
as a pedal is operated while with dirt and/or oil on the soles
of the operator’s work boots, the operator’s foot may slip off
the pedal, possibly resulting in a personal accident.
• Do not mess up around the operator’s seat with parts,
tools, soil, stones, obstacles that may fold up or turn
over, cans or lunch box. The pedals become inoperable if
obstacle jams in operation stroke of the accelerator pedal,
electric brake pedal or service brake pedal, which may
result in serious injury or death.
• Do not leave parts and/or tools lying around the
operator’s seat. Store them in their specified locations.
• Avoid storing transparent bottles in the cab. Do not
attach any transparent type window decorations on
the windowpanes as they may focus sunlight, possibly
starting a fire.
• Refrain from listening to the radio, or using music
headphones or mobile telephones in the cab while
operating the machine.
• Keep all flammable objects and/or explosives away from
the machine.
• After using the ashtray, always cover it to extinguish the
match and/or tobacco.
• Do not leave cigarette lighters in the cab. When the
temperature in the cab increases, the lighter may
explode.
• Use proper floor mat dedicated to the machine. If another
floor mat is used, it may be displaced and contact with
the accelerator pedal, electric brake pedal or service
brake pedal during operation, resulting in serious injury
or death.
•When operator drives the machine with decreased
attentiveness, resulting in serious injury or death.
• Never operate the machine in the state with drinking
alcohol or drug.
Use Handholds and Steps
•Falling is one of the major causes of personal injury.
• When you get on and off the machine, always face the
machine and maintain a three-point contact with the
steps and handrails.
• Do not use any controls as handholds.
• Never jump on or off the machine. Never mount or
dismount a moving machine.
• Be careful of slippery conditions on platforms, steps, and
handrails when leaving the machine.
• Do not step or climb on surfaces, which are not intended
for walking. Step only on the areas provided with the slip
resistant surfaces.
SAFETY
S-4
SA-439

Operator’s Visibility
•This machine is equipped with mirrors and cameras to
see around the machine. Adjust the view mirrors and
cameras position so that the best visibility is obtained from
the operator’s seat. If the mirrors and cameras are dirty,
immediately clean them. Also see carefully around the
machine while moving your viewpoint as need arises.
• The view mirrors and cameras position should be
adjusted whenever changing the operator for the
machine. Always take extra attention for surrounded area
during operating.
• When the machine is modified or fitted with equipment
that influences visibility, it is necessary to check again the
operator’s visibility according to the ISO 5006. Contact
your authorized dealer before modifying the machine.
•This machine has the blind area created because of parts of
the base machine and/or its equipment from the operator’s
seat by direct.
•Operate the machine safely with sufficient recognition this
machine has blind area from the operator’s seat by direct.
•The operator’s visibility according to the ISO 5006 of this
machine with standard mirrors and cameras is as follows.
Operator’s visibility on a rectangular 1 m boundary close
around the machine
Operator can see the entire circumference of the height
1.5 m located at 1 m distance from the outside rectangular
boundary of the machine as illustrated.
Operator’s visibility on a 12 m visibility test circle
Operator can see the entire circumference located the circle
with 12 m radius located on the ground reference plane
with its center vertically below the operator’s eye point as
illustrated.
TM: test machine
RB: rectangular 1 m boundary
VTC: visibility test circle with 12 m radius
OEP: operator’s eye point
SAFETY
S-5
VTC
ΤΜ
OEP
12 m
1 m
TM
OEP
1 m
RB
SS-3231
SS-3232

Adjust Operator’s Seat
•A poorly adjusted seat for either the operator or the
work at hand may quickly fatigue the operator leading to
misoperations.
• The seat should be adjusted whenever changing the
operator for the machine.
• The operator should be able to fully depress the pedals
and to correctly operate the steering wheel with his back
against the seat back.
• If not, move the seat forward or backward, and check
again.
• Adjust the mirror position so that the best rear visibility is
obtained from the operator’s seat. If the mirror is broken,
immediately replace it with a new one.
Fasten Your Seat Belt
•If the machine should overturn, the operator may become
injured and/or thrown from the cab. Additionally the
operator may be crushed by the overturning machine,
resulting in serious injury or death.
• Prior to operating the machine, thoroughly examine
webbing, buckle and attaching hardware. If any item is
damaged or worn, replace the seat belt or component
before operating the machine.
• Be sure to remain seated with the seat belt securely
fastened at all times when the machine is in operation to
minimize the chance of injury from an accident.
• We recommend that the seat belts are replaced every
three years regardless of its apparent condition.
SAFETY
S-6
SA-462
SA-237

Move and Operate Machine Safely
•Bystanders can be run over.
• Take extra care not to run over bystanders. Confirm the
location of bystanders before moving, or operating the
machine.
• Always keep the travel alarm and horn in working
condition (if equipped). It warns people when the
machine starts to move.
• Use a signal person when moving, or operating the
machine in congested areas. Coordinate hand signals
before starting the machine.
• Use appropriate illumination. Check that all lights are
operable before operating the machine. If any faulty
illumination is present, immediately repair it.
• Always keep the cab door closed while operating the
machine.
• Check the mirrors and the monitors in the CAB for
problems. If there are problems, replace the problem
parts or clean the mirrors, cameras and monitors.
Refer to Camera Monitor section on the cleaning of the
camera and monitor.
Handle Starting Aids Safely
Starting fluid:
•Starting fluid is highly flammable.
• Keep all sparks and flame away when using it.
• Keep starting fluid well away from batteries and cables.
• Remove container from machine if engine does not need
starting fluid.
• To prevent accidental discharge when storing a
pressurized container, keep the cap on the container, and
store it in a cool, well-protected location.
• Do not incinerate or puncture a starting fluid container.
SAFETY
S-7
SA-1598
SA-293

Operate Only from Operator’s Seat
•Inappropriate engine starting procedures may cause the
machine to runaway, possibly resulting in serious injury or
death.
• Start the engine only when seated in the operator’s seat.
• NEVER start the engine while standing on the platform.
• Do not start engine by shorting across starter terminals.
• Check that the parking brake switch is turned ON.
• Before starting the engine, confirm that shift lever is in
the NEUTRAL position.
• Before starting the engine, confirm the safety around the
machine and sound the horn to alert bystanders.
Jump Starting
•Battery gas can explode, resulting in serious injury.
• If the engine must be jump started, be sure to follow the
instructions shown in the “OPERATING ENGINE”chapter.
• The operator must be in the operator’s seat so that the
machine will be under control when the engine starts.
Jump starting is a two-person operation.
• Never use a frozen battery.
• Failure to follow correct jump starting procedures could
result in a battery explosion or a runaway machine.
SAFETY
S-8
SA-1599
SA-032
Other manuals for EH 5000AC-3
2
Table of contents
Other Hitachi Utility Vehicle manuals
Popular Utility Vehicle manuals by other brands

FERPINTA
FERPINTA Herculano HPG 8 instruction manual

Demco
Demco Kar-Kaddy SS KK460SS Operator's manual

Hammerhead
Hammerhead UM250IIR 2005 Owner's manual and parts manual

TrailMaster
TrailMaster MINI XRS Setup instructions

ABI Attachments
ABI Attachments Workman XL owner's manual

Anderson
Anderson RBMPRO 2000 Operator's manual

Ingersoll-Rand
Ingersoll-Rand VR518 Operation and maintenance manual

Baja motorsports
Baja motorsports BLASTER 65 owner's manual

MULTIQUIP
MULTIQUIP WT5HPSG Operation manual

Toro
Toro 07280TC Operator's manual

Toro
Toro Groundsmaster 7200 Series Operator's manual

Chironex
Chironex SPARTAN XT 600 EFI owner's manual
