Hitachi SF-240XWV Product guide

Operating & Installation Instructions
Fully Automatic Washing Machine
Model SF-240XWV / 200XWV / 180XWV
EN
Thank you for purchasing a Hitachi fully automatic washing machine.
■Please read these operating & installation instructions carefully for proper
operation of the machine.
■Please keep these operating & installation instructions for future reference.
Contents
Environmentally Friendly Waste Disposal 2
Hints and Tips for Eco-friendly Washing 2
Safety Instructions 3
Parts and Accessories 5
Control Panel and Display 6
Before You Start Washing 8
How to Use the Washing Machine 9
List of Programs 14
Partial Operations Using the Fuzzy Program 18
In Case of Power Outage 21
Care and Maintenance 21
Troubleshooting 23
Error Codes 24
How to Install the Washing Machine 25
Customer Service 30
Specifications 30

2
Environmentally Friendly Waste Disposal
Disposing of the
packaging
The shipping package has protected your new washing machine on its
way to your home. All materials are ecologically harmless and recyclable.
Please contribute to a better environment by disposing of packaging
materials in an environmentally conscious manner.
Ask your dealer about current means of disposal.
Risk of choking!
Do not let children play with packaging and associated parts.
There is a risk of suffocating on plastic bags and collapsible boxes.
Old appliances are not worthless rubbish. Environment-conscious
recycling can reclaim valuable new materials.
Risk of death!
Unplug the power plug from appliances you are no longer using. Cut off
the power cord and dispose of it with the plug.
If you wish to discard this product, contact your local authorities or dealer
and ask for the correct method of disposal.
Hints and Tips for Eco-friendly Washing
■Keep to the load limit of each program.
■This washing machine features power-saving operations with a built-in
inverter controller which enables the machine to optimize operations
according to the conditions of your clothes.
■Add detergent according to the degree of soiling, laundry size, and
water hardness. Follow the detergent manufacturer's instructions
regarding the amount of detergent to use.
■This washing machine has enhanced water-saving features such as
Spin Shower Rinse and uses less water than former models. If you
want to save more water, select the Water Save program using the
Program button.
Disposing
of your old
appliance

3
General safety
Safety Instructions
This washing machine is designed for home use only.
Before operating the washing machine, please read these safety instructions carefully.
Warning Issues which could cause death or serious injury.
Power source
and cord
Installation
■Do not dismantle, repair or modify the washing machine.
ÆThis could cause malfunction, fire, electric shock or injury.
ÆContact your local service center for repairs.
■Do not put fire sources or anything inflammable in or near the washing
machine (gas, diesel, petroleum, thinner, alcohol, or clothes stained with
these substances).
ÆThis could cause an explosion or fire.
■Do not pour water on the washing machine when it is running.
ÆThis could cause an electric shock.
■Do not climb on the washing machine. Do not place heavy object, drop any
object or apply impact on the lid glass.
ÆThis could cause lid glass breakage. If any scratch or breakage is found
on lid glass, stop using the washing machine and contact your local
service center to request inspection and repair.
■It is a malfunction if the tub is still spinning when the lid lock is released and
you can open the lid. If this happens, do not touch the laundry inside the
tub and stop using the washing machine immediately. Contact your local
service center for repair.
■The washing machine is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge. To use the washing machine safely, supervision and
instruction is necessary.
■Do not install the washing machine in an extremely humid place, such as a
bathroom or a place exposed to rain.
ÆRisk of fire, electric shock, current leakage, corrosion or product damage.
■Do not install the washing machine on a board with castors or on an
unstable surface.
ÆThis may cause injury or malfunction due to abnormal vibration.
■The washing machine must be grounded if you use a two-pin plug adapter
on the three-pin plug.
ÆNot doing so could cause an electric shock.
■Use a new water supply hose to connect the washing machine to the water
tap.
■The opening must not be obstructed by carpeting if the washing machine is
installed on a carpeted floor.
■Do not insert or remove the power plug with wet hands.
ÆThis could cause an electric shock.
■Use the rated voltage. Do not connect other devices to the same outlet.
ÆUsing the washing machine and other electric appliances on the same
outlet may cause the plug to overheat and result in fire.
■Clean off any dust on the power plug.
ÆA dirty or dusty plug may cause a fire.
■Do not use an electric socket or outlet that is damaged or loose.
ÆThis could cause an electric shock, short circuit, or fire.
■Do not damage, cut, modify, bend, or fold the power cord.
ÆThis could damage the power cord and cause a fire or electric shock.
■Do not use an extension cord on the power cord.
ÆThis could cause overheating or fire.
■If the power cord is damaged, it must be replaced by a service agent or
repair shop authorized by the manufacturer to avoid risks.

4
Safety Instructions
■Keep packaging out of reach of children and infants.
ÆDanger of suffocation.
■Do not let children climb onto the washing machine or to get into the tub. Do
not leave boxes or chairs near the washing machine that children could use
to climb onto it.
ÆThis may cause injury.
■Children should be supervised to ensure that they do not play with the
washing machine.
■If there is a water outage or you remove the water supply hose and reattach
it, close the tap and press the Start/Pause button, then wait 40 seconds and
slowly open the tap.
ÆAir pressure from a large amount of air in the water pipes could damage
the washing machine.
■Periodically check that the union nut on the water supply hose is tight.
ÆA loose nut may cause a water leak.
■Remove the power plug from the outlet and close the water tap if you will
not use the washing machine for a long time.
■All packaging materials must be removed before using the washing
machine.
ÆThis could cause malfunction or abnormal vibration.
■Check inside the tub before operating the washing machine.
ÆCheck that no pets or small animals are in the tub.
■Do not wash items, such as raincoats, wet suits, ski suits, sleeping bags,
cushions, pillows, shoes, shower curtain or other things, through which
water does not flow easily.
ÆThe washing machine may not work properly, or it could cause injury or
damage the washing machine.
■
Do not fold and stack large items together, such as blankets, when washing them.
■Do not use a laundry net that is larger than 40 cm on a side.
ÆThe clothes may become off balance and cause abnormal vibration
during the spin cycle.
■Do not load laundry over the lower part of the liquid load
balancer (dotted line).
ÆDoing so could cause laundry to fly out of the tub
during the spin cycle and damage the clothes or the
washing machine, or cause a water leak.
■Always put detergent into the detergent dispenser when
washing laundry.
■Do not use water hotter than 50ºC.
■Do not open the lid without using the Lid Open Button.
ÆThis may cause the damage of lid and lid open button.
■Do not wash items together with coins, pins, or stones.
ÆThis may damage clothes or the washing machine, or cause a water leak.
Check inside pockets before washing.
■Do not press the buttons with sharp pointed objects.
■
Do not put heavy objects, liquid-filled containers or equipment which produces
heat on the washing machine.
ÆThis may damage the washing machine or its top.
■If detergent, fabric softener or bleach spills on the surface of the machine,
clean it up with a damp cloth immediately.
ÆThe plastic or steel parts of the washing machine may be damaged.
■Do not place equipment that produces heat near the washing machine.
ÆThis may cause deformation of the washing machine.
Liquid Load
Balancer
Max
Care and
maintenance
Child safety
General safety
Use
Caution Issues which could cause injury or damage property.

5
Parts and Accessories
Accessories
Water Supply Hose and One-touch Joint
(1 set)
Foot Caps
(2 pieces)
Drain Hose
(1 pieces)
Optional accessories
Laundry Net
Refer to page 12
Part number PTSF-200XWV 014
Drain Hose
Lid Dispenser
(For detergent/
bleach/softener)
Dispenser
Pulsator
Lid Lock
Lid Open Button
Lint Filter
(cassette
type)
Adjustable Foot
Power
Cord
Tub
Control Panel
Liquid Load
Balancer
Powdered Detergent/
Powdered Bleach
Dispenser
Liquid Detergent/
Liquid Bleach
Dispenser
Softener
Dispenser

6
Control Panel and Display
Press this button to switch power on and off. The washing machine
automatically switches off when operations are finished. The washing
machine also turns off automatically if it is not operated or no button is
pressed for 10 minutes after the power has been turned on.
Starts and pauses operation. When the washing machine is paused for
over one hour and no operations are done, it turns off automatically.
Supplies water to the tub when this button is pressed. Amount of water
supplied depends on load amount or program. If you want to cancel water
supply, press this button again.
This function is available during the washing and normal rinsing processes.
This button does not function if the water level has already reached
highest level of each program.
Changes the strength of the water flow. The strength of the water flow
changes each time this button is pressed.
Water flow strength is shown on the Water Level/Timer indicator.
(0: normal, 1: strong, 2: stronger, -1: weak, -2: weaker)
This function is available during the washing and normal rinsing
processes.
Lights in the Delay Timer mode.
Shows a suitable amount of detergent.
Opens the lid. (When opening the lid, please use this button each time.)
Power button
Start/Pause button
Water Power button
Delay Timer indicator
Detergent Amount
indicator
Lid Open button
Shower Plus button
While using the control panel (lid open)
While the washing machine is operating (lid closed)

7
Lid Lock indicator
Selects programs. The program changes each time the button is pressed.
Automatically cleans the outside of the tub and the inside of the outer tub
to keep the washing machine clean. This setting is switched off at the
time of shipment from the factory. Once switched on, the Auto Self Clean
function operates every time you wash your laundry.
Records the selected course, water level, wash time, rinse time and spin
time when it is pressed for 3 seconds. To recall a recorded course, press
this button after the washing machine is turned on.
Switches to the Delay Timer mode, and the time set for the Delay Timer is
shown on 13, the Water Level/Timer indicator. Press it again to return to
the Water Level mode.
Locks the lid during the rinse and spin cycle. The lid cannot be opened
while this indicator is lit. To release the lock, press the Start/Pause button
to pause operation. The lock is automatically released after a short time.
When the lid is opened, it shows the water level. When the lid is closed, it
shows the remaining time.
Adjusts the delay time and water level. The maximum amount of water
that can be set varies according to the program. In the Delay Timer mode,
the delay time can be set between 3 and 12 hours.
Shows the washing time.
Changes the washing time. The washing time can be set between 3 and
24 minutes.
Shows the rinse settings. When EX appears in the indicator, the washing
machine does water-injection rinse.
Changes the rinse time.
Shows the spin time.
Changes the spin time. The spin time can be set between one and 9
minutes.
Control Panel and Display
Program button
Auto Self Clean button
Delay Timer/Water
Level Switching button
Memory button
(Only 240XWV, 200XWV)
Water Level/Timer/
Remaining time
indicator
Delay Timer/Water
Level button
Wash indicator
Wash button
Rinse indicator
Rinse button
Spin indicator
Spin button

8
Before You Start Washing
■Remove any foreign objects (coins, safety pins, etc.).
■Put delicate clothes (knits, lingerie, etc.) in a net.
■Remove large lumps of lint, mud, sand, hair, and pet hair from laundry.
■Tie strings and close fasteners.
■Sort laundry according to the type of fabric and care label symbols
(cottons, blended fabrics, synthetics, wool, hand washable items, etc.).
■Do not wash extremely small loads, such as only a pair of jeans.
ÆThe clothes may become off balance and cause abnormal vibration
during the spin cycle.
■Separate colored and white items.
Risk of injury!
Do not wash the following items, through which water does not flow
easily, because doing so creates abnormal vibration during the spin cycle
and could cause injury or malfunction.
– Waterproof items, such as a wet suit, ski suit, shower curtain, etc.
– Items with non-slip rubber backing, such as door mats.
– Cushions, pillows, shoes, etc.
■Use an appropriate amount of detergent according to the Detergent
indicator on the washing machine.
The type and amount of detergent depend on the type of fabric,
volume, load size, degree of soiling, and hardness of the water used.
Use less detergent if:
– The load is small.
– The laundry is not very dirty.
■Too much detergent can result in excess foam, which reduces rinse
efficiency or may cause a water leak.
■Depending on the detergent brand, detergent may not dissolve
completely in the detergent tray if the water pressure is low or the water
is too cold.
ÆPage 22: Care and Maintenance
■When using softeners or bleaches, follow the instructions on the
package.
Preparation of
the laundry
Sorting the
laundry
Detergents and
additives

9
How to Use the Washing Machine
1 Sort the laundry
2 Press the Power button to turn on the power
3 Select and adjust the program
4 Press the Start/Pause button
■Sort the laundry according to the type of fabric, care label symbol, and degree of soiling.
ÆPage 8: Preparation of the laundry
■Do not exceed the maximum load.
■Laundry shall not exceed this line. Otherwise, laundry may jump out
from the wash tub while spinning and it may cause damage.
Max
■If no program is selected within 10 minutes, the washing machine automatically
switches itself off. Press the Power button again to turn on the power.
■Select a program with the Program button.
ÆPage 14: List of Programs
■You can change the combination or settings of wash, rinse, and spin operations with the
Wash, Rinse, and Spin buttons.
■You can switch on the Auto Self Clean function with the Auto Self Clean button.
ÆPage 11: How to use the Auto Self Clean function
ÆOnce switched on, the Auto Self Clean function operates every time you do your
laundry. Press the Auto Self Clean button again while the power is on to deactivate
the function.
■Before operation starts, the laundry is weighed, and the amount of detergent and water
appear on the display.

10
How to Use the Washing Machine
5 Put detergent into the detergent dispenser and close the lid
■Open the detergent dispenser, add the amount of detergent shown on the display, and
then close the detergent dispenser.
■The amount of detergent is based on a single 35-gram scoop of powder detergent.
Since the required amount of detergent varies depending on the type of detergent,
follow the instructions on the package of detergent.
■For liquid detergent, follow the instructions on the package and add it to the liquid
detergent/liquid bleach dispenser.
■Add softener to the softener dispenser according to the instructions on the package of
softener. The softener is added to the tub automatically before the final rinse.
■For liquid bleach, follow the instructions on the package and add it to the liquid
detergent/liquid bleach dispenser.
■The speed that the lid closes may vary, depending on the temperature, however, this is
not abnormal.
– Pausing a program: Press the Start/Pause button. The washing machine will
switch itself off if it is not restarted within 1 hour.
– Adding clothes partway
through a program:
Press the Start/Pause button to pause operation and
add your clothes. The lid is locked while the tub is
spinning, so wait until the tub stops completely and
the lid lock is automatically released. After adding the
clothes, close the lid and press the Start/Pause button
to restart operation.
* Note: It is not recommended to add a large amount
of clothes as the washing machine first measures the
load size to determine optimum operation.
– Adding water partway
through a program:
Press the Shower Plus button. Adds water when you
press the button. Water stops being added when you
press the button again or the maximum level is reached.
* Note: This function can not operate in the Tub Dry and
Tub Clean Programs.
– Changing strength of
water flow:
Press the Water Power button.
Repeatedly press the button to adjust the strength
through five levels.
* Note: This function operates in the Fuzzy, Smart
Wash, Delicate, Speedy, Soak, Small Load, and
Water Save courses for washing and normal rinsing
programs.
Even if the indicator of strength changes, it may not
change the strength according to the process or the
load amount.
– Terminating a
program:
Press the Start/Pause button, and press the Power
button to turn off the power.

11
6 Program ends
How to Use the Washing Machine
1.Press the Power button to turn on the power.
2.Select a program.
3. Press the Auto Self Clean button, and press the Start/Pause button.
■The setting is switched off at the time of shipment from the factory.
Once switched on, the Auto Self Clean function operates every time
you do your laundry.
■Prior to the final spin cycle, the outside of the tub, the backside of the
pulsator, and the inside of the outer tub are washed to eliminate dirt
and mold.
■To deactivate the Auto Self Clean function, press the Auto Self Clean
button again while the power is on.
●The Auto Self Clean function runs just before the spin cycle begins
in each program.
●The Auto Self Clean function runs even when the washing
machine has started operation from rinsing.
● The Auto Self Clean function cannot be set or cancelled during operation.
●The Auto Self Clean function is automatically cancelled when:
– The spin time is manually set to 1 minute.
– Spin-only operation is set.
– No spinning is set.
●Depending on the type and degree of dirt, some dirt may not be
washed with the Auto Self Clean function.
●If the washing machine is seldom used, some dirt may not be
washed with the Auto Self Clean function.
●To clean the tub more completely, we recommend using the Tub
Clean program along with the Auto Self Clean function.
■The Auto Self Clean function is deactivated when one of the following
programs is selected.
– Blanket
– Tub Dry
– Tub Clean
■When the Auto Self Clean function is running, some water may flow
out from the softener dispenser. This is the normal operation of the
washing machine and does not indicate a malfunction.
How to use
the Auto Self
Clean function
■The alarm sounds when a program ends.
The alarm can be deactivated or the sound can be changed in 5 types if the button of water
level is pressed for at least 3 seconds.
Melody 1
*initial
setting
Melody 2 Melody 3 Mono 1 Mono 2 No alarm
■The washing machine automatically switches off when the operations are finished.

12
How to Use the Washing Machine
How to use
the Blanket
program
1.Prepare the laundry.
■Fold large items, such as quilts or blankets, as follows.
They should not be taller than 30 cm after they are folded.
About 30 cm
30 cm
If it exceeds 30 cm, use a laundry net, which is sold separately.
(Laundry net: Product number PTSF-200XWV 014)
2.Press the Power button to turn on the power.
3.Select the Blanket program.
4.Press the Start/Pause button.
5.Add detergent and close the lid.
Items you can wash with the Blanket program
●Washable quilts
Machine washable quilts with synthetic (polyester) batting.
When not using the optional laundry net:
150 cm x 200 cm or smaller, and less than 1.5 kg
When using the optional laundry net:
174 cm x 225 cm or smaller, and less than 2 kg
(Laundry net: Product number PTSF-200XWV 014)
●Washable blankets
Up to 3 kg of synthetic blankets that are labeled as hand washable.
– For electric blankets, follow the instructions for the electric blanket.
●Washable curtains
Up to 5 kg of curtains that are labeled as hand washable.
– Do not use laundry net for washing curtains.
●Other washable items
Mattress pads labeled as hand washable.
■Do not fold and stack large items together, (such as sheets) when
washing them.
ÆThe clothes may become off balance and cause abnormal vibration
during the spin cycle.

13
How to Use the Washing Machine
■Use this program separately from other washing programs. (Do not put
laundry into the tub.)
1.Press the Power button to turn on the power.
2.Select the Tub Dry program.
3.Close the lid and press the Start/Pause button.
■The tub spins quickly the same as the regular spin cycle to remove the
water from the tub.
■Use this program separately from other washing programs. (Do not put
laundry into the tub.)
1.Press the Power button to turn on the power.
2.Select the Tub Clean program.
■The Tub Clean program can be set to 3 or 11 hours. At first, 3 hours is
set. Press the Program button again to set 11 hours.
3.Press the Start/Pause button. The washing machine starts pouring
water into the tub.
4.Add tub cleaner, according to the package, to the tub. (Liquid
peroxide-based bleach is also effective as a tub cleaner. Since the
required amount of bleach varies depending on the type of bleach,
follow the instructions on the package of bleach.)
5.Close the lid.
■Water is added to the maximum level to wash away dirt you cannot see
on the tub and outer tub. After that, Normal Rinse is performed twice to
flush out any remaining dirt or tub cleaner.
1.Press the Power button to turn on the power.
2.Select a program.
3.Press the Delay Timer/Water Level Switching button and select the
time to finish washing. Each press of the button subtracts an hour
starting from 12 hours to 3 hours later.
4.Press the Start/Pause button.
5.Add detergent and close the lid. The power turns off after a short
time.
6.Operations finish at the set time.
■The Delay Timer is unavailable for the Blanket, Tub Dry, and Tub Clean
programs.
■To change the setting, press the Power button and do the settings
again.
■If there is a power outage while the timer is set, the timer setting is
cancelled. If this happens, press the Power button again and reset the
timer.
■To prevent your laundry from wrinkling, remove it as soon as possible
after washing is done.
How to use
the Delay Timer
How to use
the Tub Clean
program
How to use
the Tub Dry
program

14
List of Programs
Program Fuzzy Smart Wash Delicate
Maximum
load
240XWV 24 kg 8 kg
200XWV 20 kg 8 kg
180XWV 18 kg 8 kg
Amount
of water
240XWV
88 to 150 L (adjusted automatically) 112 L
88 to 150 L 101 to 133 L
200XWV
88 to 148 L (adjusted automatically) 112 L
88 to 148 L 101 to 132 L
180XWV
88 to 147 L (adjusted automatically) 112 L
88 to 147 L 101 to 131 L
Wash
15 min 38 min 6 min
3, 9, 12, 15, 18, 24
min, or none
10, 18, 24, 28, 31, 38
min, or none -
Rinse
Spin Shower Rinse 2 times + Normal Rinse
1 time (In case of laundry exceeds 80%, the
process will be Spin Shower Rinse 1 time and
Normal Rinse 1 time.)
Normal Rinse 1 time
Normal Rinse 2 times, Water-Injection Rinse
2 times, Normal Rinse 3 time, Water-Injection
Rinse 3 time, none, Normal Rinse 1 times, or
Water-Injection Rinse 1 times
Normal Rinse 1 time,
Water-Injection Rinse 1 time,
Normal Rinse 2 times,
Water-Injection Rinse 2 times,
Normal Rinse 3 times,
Water-Injection Rinse 3 times,
or none
Spin Time
6 min 3 min
1, 3, 6, 9 min, or none 1, 3, 6, 9 min, or none
Required
time
(guide)
240XWV 51 to 78 min 56 to 98 min 43 min
200XWV 51 to 77 min 56 to 97 min 43 min
180XWV 51 to 77 min 56 to 97 min 43 min
: Default settings : Changeable settings (via corresponding button)

15
List of Programs
Program Speedy Soak Small Load
0.5 hrs 1 hrs 3 hrs 5 hrs
Maximum
load
240XWV 8 kg 19.2 kg 1 kg
200XWV 8 kg 16.0 kg 1 kg
180XWV 8 kg 14.4 kg 1 kg
Amount
of water
240XWV
106 L 88 to 150 L (adjusted automatically) 50 L
88 to 118 L 88 to 150 L 50 to 101 L
200XWV
106 L 88 to 148 L (adjusted automatically) 50 L
88 to 118 L 88 to 148 L 50 to 101 L
180XWV
106 L 88 to 147 L (adjusted automatically) 50 L
88 to 118 L 88 to 147 L 50 to 101 L
Wash
3 min 30 min 60 min 180 min 300 min 9 min
3, 9, 12, 15, 18, 24 min,
or none ---- -
Rinse
Normal Rinse 1 time Normal Rinse 2 times Normal Rinse
1 time
Normal Rinse 1 time,
Water-Injection Rinse
1 time, Normal Rinse
2 times, Water-Injection
Rinse 2 times, Normal
Rinse 3 times,
Water-Injection Rinse
3 times, or none.
Normal Rinse 2 times,
Water-Injection Rinse 2 times,
Normal Rinse 3 time, Water-Injection
Rinse 3 time, or none, Normal Rinse
1 times, or Water-Injection Rinse
1 times.
-
Spin Time
3 min 6 min 3 min
1, 3, 6, 9 min, or none 1, 3, 6, 9 min, or none -
Required
time
(guide)
240XWV 42 min 90 to
112 min
120 to
142 min
240 to
263 min
360 to
383 min 41 min
200XWV 42 min 90 to
111 min
120 to
141 min
240 to
261 min
360 to
381 min 41 min
180XWV 42 min 90 to
111 min
120 to
141 min
240 to
261 min
360 to
381 min 41 min
: Default settings : Changeable settings (via corresponding button)

16
List of Programs
Program Energy Save Water Save Blanket
Maximum
load
240XWV 24 kg 24 kg 3 kg (follow P.12)
200XWV 20 kg 20 kg 3 kg (follow P.12)
180XWV 18 kg 18 kg 3 kg (follow P.12)
Amount
of water
240XWV
88 to 150 L
(adjusted automatically)
88 to 144 L
(adjusted automatically) 150 L
88 to 150 L 88 to 144 L 133 to 150 L
200XWV
88 to 148 L
(adjusted automatically)
88 to 128 L
(adjusted automatically) 148 L
88 to 148 L 88 to 128 L 132 to 148 L
180XWV
88 to 147 L
(adjusted automatically)
88 to 112 L
(adjusted automatically) 148 L
88 to 147 L 88 to 112 L 131 to 148 L
Wash
48 min 15 min 25 min
-3, 9, 12, 15, 18, 24 min,
or none -
Rinse
Spin Shower Rinse
2 times + Normal Rinse
1 time (In case of
laundry exceeds 80%,
the process will be Spin
Shower Rinse 1 time and
Normal Rinse 1 time.)
Spin Shower Rinse
2 times + Spin Shower
Rinse 2 times
Normal Rinse 2 times
-
Normal Rinse 2 times,
Water-Injection Rinse
2 times, Normal Rinse
3 time, Water-Injection
Rinse 3 time, none,
Normal Rinse 1 times, or
Water-Injection Rinse
1 times.
-
Spin Time
5 min 6 min 9 min
- 1, 3, 6, 9 min, or none 1, 3, 6, 9 min, or none
Required
time
(guide)
240XWV 94 to 100 min 41 to 84 min 103 min
200XWV 94 to 100 min 41 to 83 min 102 min
180XWV 94 to 100 min 41 to 81 min 102 min
: Default settings : Changeable settings (via corresponding button)

17
■The wash time and the spin time may change during the program depending on the weight and type
of laundry being washed.
■The required times are guidelines. More time may be required than is noted here depending on the
water pressure and the type of laundry.
■Programs cannot be changed after they are started. To change them, turn the power off and then on
again, then select a program.
■When the Auto Self Clean function is running, about 10 more minutes and 15 more liters of water are
needed.
■We do not recommend using fabric softener when the Water Save program is selected.
■The Water Save program cycle is the recommended program cycle for a normally soiled load of
laundry at the rated capacity.
■Spin Shower Rinse* is used in the Fuzzy and Energy Save programs to enhance water-saving
performance without compromising the efficiency of rinsing.
* Spin Shower Rinse: A powerful shower and centrifugal force rinse out detergent more effectively.
■The clear part of the lid and control panel may become foggy or may form dew on the edge of lid if
you use hot water to wash your laundry, however, this is not abnormal. Wipe it off after washing your
laundry.
■It has the potential not to be enough for max load according to the kind of clothes.
■Even if you set the delay timer, it may start soon according to the required time of the program.
■Amount of detergent is indicated according to following table as a guide.
List of Programs
* Display of cup mark is based on a single 35-gram scoop of powder detergent.
The amount of detergent is based on a type of 20-gram per 30-liter.
Since the required amount of detergent varies depending on the type of detergent, follow the
instructions on the package of detergent.
Load (guide) Water Level Display of cup mark
(guide) Amount of detergent
16~24 kg 128~150 L
85~100 g
(SF-240XWV)
16~20 kg 128~148 L (SF-200XWV)
16~18 kg 128~147 L (SF-180XWV)
10~16 kg 112~124 L 75~83 g
6~10 kg 101~106 L 67~71 g
~6 kg 88~94 L 59~63 g

18
Partial Operations Using the Fuzzy Program
If you want... To customize
the wash program
To reuse the wash
water and separate
your laundry
To not spin the
laundry because you
are worried about
wrinkles
Operations Wash ⇒Rinse ⇒Spin Wash only Wash ⇒Rinse
Setting method
1. Turn on the power.
2. Select the Fuzzy program.
3.
Set the amount of water.
If you do not set the amount of water, it is set automatically based on the
weight of the laundry.
4. Set the
operations
■Set the wash time
with the Wash button.
■Set the number and
type of rinses with the
Rinse button.
■Set the spin time with
the Spin button.
■Set the wash time
with the Wash button.
■Press Rinse button
repeatedly until rinse
indicator turns off.
■Press Spin button
repeatedly until spin
indicator turns off.
■Set the wash time
with the Wash button.
■Set the number and
type of rinses with the
Rinse button.
■Press Spin button
repeatedly until spin
indicator turns off.
5. Press the Start/Pause button to start.
Remarks
Operates according to
the wash, rinse, and
spin settings.
Stops while the wash
water is still in the tub.
Stops while the rinse
water is still in the tub.

19
Partial Operations Using the Fuzzy Program
If you want... To rinse only To rinse and spin To drain and spin
Operations Rinse only Rinse ⇒Spin Drain ⇒Spin
Setting method
1. Turn on the power.
2. Select the Fuzzy program.
3.
Set the amount of water.
If the amount of water is not set, then maximum
water level is used.
Cannot be used.
4.
■Set the number and
type of rinses with the
Rinse button.
■Press Wash button
repeatedly until wash
indicator turns off.
Press Spin button
repeatedly until spin
indicator turns off.
■Set the number and
type of rinses with the
Rinse button.
■Set the spin time with
the Spin button.
■Press Wash button
repeatedly until wash
indicator turns off.
■Set the spin time with
the Spin button.
■Press Wash button
repeatedly until wash
indicator turns off.
■Press Rinse button
repeatedly until rinse
indicator turns off.
5. Press the Start/Pause button to start.
Remarks
Drains water and spins
before rinsing. Stops
while the rinse water is
still in the tub.
Drains water and spins
before rinsing. Drains water and spins.

20
Partial Operations Using the Fuzzy Program
■Repeatedly press the buttons until the wash, rinse, and spin settings you want are set. If the
indicator is not lit, that operation is not performed.
■You can set the amount of
water each time you press the
Water Level button in a range
from 88 to 150 L.
150 L
144 L
138 L
133 L
128 L
124 L 88 L
94 L
101 L
106 L
112 L
118 L
SF-240XWV
■You can set the amount of
water each time you press the
Water Level button in a range
from 88 to 148 L.
148 L
142 L
136 L
132 L
128 L
124 L 88 L
94 L
101 L
106 L
112 L
118 L
SF-200XWV
■You can set the amount of
water each time you press the
Water Level button in a range
from 88 to 147 L.
147 L
141 L
135 L
131 L
128 L
124 L 88 L
94 L
101 L
106 L
112 L
118 L
SF-180XWV
■You can set the spin time each
time you press the Spin button
in a range of 1 to 9 minutes and
no spinning.
No setup
9 Min
6 Min
3 Min
1 Min
■You can set the wash time each
time you press the Wash button
in a range from 3 to 24 minutes
and no washing.
24 Min
18 Min
15 Min
12 Min
9 Min
3 Min
No washing
■You can set the number and
type of rinses by pressing the
Rinse button. Each time you
press the Rinse button the
setting changes in sequence,
from Water-Injection Rinse 2
times, Normal Rinse 2 times,
Water-Injection Rinse 1 time,
Normal Rinse 1 time, no rinsing,
Water-Injection Rinse 3 times,
Normal Rinse 3 times.
3
Ex 2
Ex 3
1
2
No rinsing
Ex 1
