Hitron HT-DW1 Instructions for use

HT-DW1
0440010170N0(1A)
Hitron's HT-DW1 is a micro door / window sensor,
uses a magnetic reed switch to detect when a
door, window, cabinet, garage door or any other
object is opened.
Quick Install Guide / Manual
1. Activate Battery
Slide open the sensor’s housing and
pull the tab to activate it for pairing.
2. Join the Network
Follow the instructions on your iControl
touchscreen to add a new HT-DW1.
During the joining needs to be lower
case, the LED on the HT-DW1 will blink
while it’s searching for the network.
More information about this process can be
found at: http://www.hitron-americas.com
Unobtrusive Compact Design
3+ Year Coin Cell Battery Life
Easy Installation with Tape or
Screws
Tamper Switch for Extra Security
100m Free Field, 60m+ Inside
Range
Key Features Contents
HT-DW1
1 CR-2032 Battery
Screws and Tape (4 each)
LED Indicators/ Troubleshooting
Status/Action Description
The LED will light green) for 2 seconds when the
battery is inserted.
(
The LED will flash (green) 3 times each time. It will
quit flashing when it finds a network.
Holding the tamper switch, inserting the battery,
and releasing it while the LED is green (within 2
seconds of inserting the battery).
Pressing and releasing the tamper switch 5 times
within 5 seconds.
Start using your HT-DW1
HT-DW1 is ON
Search for network
Factory reset
Forced rejoin
Battery
LED
Sensor’s
housing Tab
Tamper
switch
Magnet

Screw
Orientation
Dimple
3. Install the sensor and magnet in a proper orientation
4.Close sensor’s housing
0.75"(1.9cm) Mounting plate
Tape
Screw holes
Where not to place
(1) Metal can reduce transmission range
(2) Damp or very humid area
Test the Sensor from desired location before permanent
installation. Position the sensor’s mounting plate beside
the door or window frame on the wall and the magnet on
the door or window itself by using either double sided tape
or screws. They can be a maximum of 0.75” (1.9 cm) apart.
If aligned properly, you will be able to hear a 'click' when
they approach. When the door/window is opened, contact
is broken and the sensor sends a signal to activate the receiver(s).
Once you have confirmed the Sensor is
communicating, install it in its mounting
plate on the door or window frame.
