HKC APL-3 Series Instruction manual

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 1 / 10 Valve Automation Leader, HKC
APL-3 Series Valve Position Monitor
Installation, Operation & Maintenance Manual
Address : 26, Emtibeui 28-ro, Siheung-si, Gyeonggi-do, 15119, Republic of Korea
Tel : [phone], Home page : www.hkcon.co.kr, email : [email protected]

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 2 / 10 Valve Automation Leader, HKC
Table of Contents
1. General ....................................................................................................................................................................................3
2. Ordering Information ..........................................................................................................................................................3
3. Standard specification .......................................................................................................................................................3
4. Certification ............................................................................................................................................................................3
5. Marking ....................................................................................................................................................................................3
6. Standard Features...............................................................................................................................................................4
7. Initial Inspection ................................................................................................................................................................4
8. Installation ............................................................................................................................................................................5
8.1. Mounting bracket ..................................................................................................................................................5
8.2. Mounting limit switch box .................................................................................................................................5
8.3. Setting cam ...............................................................................................................................................................5
8.4. Wiring ...........................................................................................................................................................................6
8.5. Setting Position Transmitter Unit (APL-3x6) ...............................................................................................8
9. Maintenance .........................................................................................................................................................................9
10. Inspection ..............................................................................................................................................................................9
11. Storage ....................................................................................................................................................................................9
12. Trouble Shooting ...............................................................................................................................................................9
13. Tools..........................................................................................................................................................................................9
14. Installation and Maintenance Tips ..........................................................................................................................9

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 3 / 10 Valve Automation Leader, HKC
1. General
1.1. HKC APL series limit switch box is designed to provide accurate and reliable valve position signaling and
indicating of most valves or actuators manufactured.
1.2. APL limit switch box consists of a visual position indicator, quick-set cam ass’y, terminal strip, switch ass’y
and easy mounting bracket. Quick-set cam allows for a quick and simple hand operation in the setting of
switches.
2. Ordering Information
APL - 3 1 0 N
① ② ③
① Enclosure type
3 : Weather proof
② Switch type
10 : 2-SPDT (Wonwoo : SZM-V16-5FA-61 or Zippy : VA2-16)
11 : 3-SPDT (Wonwoo : SZM-V16-5FA-61 or Zippy : VA2-16)
12 : 4-SPDT (Wonwoo : SZM-V16-5FA-61 or Zippy : VA2-16)
13 : 2-SPST (Wonwoo : SZM-V16-5FA-61 or Zippy : VA2-16)
14 : 2-DPDT (DZ-10GW-1B)
15 : 2-SPDT + Potentiometer (SZM-V16-5FA-61 or VA2-16)
16 : 2-SPDT + Signal Unit(4~20mA) (SZM-V16-5FA-61 or VA2-16)
20 : Proximity Sensor (P&F : NJ2-V3-N)
21 : Proximity Sensor (Autonics : PS17-5DNU)
[22 : Proximity Sensor (P&F : NJ4-12GM-N, -25’C ~ 60’C) --- 18 r0]
23 : Proximity Sensor (P&F : NBB2-V3)
30 : Reed type Proximity Sensor
③ Enclosure Material
N : Aluminum Die-casting
3. Standard specification
Model APL-3..N,
Enclosure Rated Weatherproof IP67
Enclosure High grade aluminum alloy
Ambient Temperature [-20 ℃ ~ + 80 ℃ --- 21 r1]
Cable Entries Standard: Two 1/2" NPT, Option: PT/PF 1/2", PG 13.5, M20
Travel Angle 90 degree +/- 10%
Position Indicator Open : Yellow, Close : Red
Language : English (option : French, German)
Switch Mechanical switch : Wonwoo Starion, Omron, SwitchLab Zippy
Proximity sensor : Autonics, P&F
Reed type proximity sensor
Potentiometer 1kΩ (option : 0~5kΩ , 0~10kΩ)
Current Output Signal Unit 4~20mA, 20~4mA
Terminal Strip 8 point (option : 9~14P)
External Coating Thermally hardened dry powder polyester coating KARUMEL PX8576
4. Certification
CSA Master contract 249581, Certificate 2673306 NEMA type 4X ----- 17 rev1]
S-mark BC-0084 (APL-310), BC-0085(APL-320), BC-0086(APL-330), IP67
5. Marking
 HKC Logo
 Model (APL-3..N)
 Micro switches type
 Manufactured (YY-MM)
 CSA type 4X
 Safety certification by KOSHA

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 4 / 10 Valve Automation Leader, HKC
6. Standard Features
No. Part Name Q’ty Description
1 Window / Indicator 1 PC / ABS
[2 Cover 1 Aluminum die-casting
3 Captive Cover Bolts 4 Stainless steel
4 Name Plate 1 Sticker
5 Shaft 1 Stainless steel
6 Cam 2 PC
7 Switch 2 Mechanical or Proximity type
8 Body 1 Aluminum die-casting
9 Terminal Strip 1 8P (9~14P available) --- 21 r0]
10 Earth Lug 1 Stainless steel
11 Blanking Element 2 Sticker
7. Initial Inspection
7.1. When the user take over the products, please check the condition of the products, and compares the
contents of the order sheet with the name plate to check for any abnormality.
7.2. Carefully remove the packaging wrap or crate and inspect for physical damage that may have occurred
during transportation.
7.3. Check the ordered products and its specification. If the wrong products have been delivered, please notify
our representative immediately.

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 5 / 10 Valve Automation Leader, HKC
8. Installation
8.1. Mounting bracket
Caution ;
Where limit switch box or one of parts are to be moved, installed, disassembled, reassembled by a hand,
care must be taken not to cause injury by the harmful sharp edges of corners or rough surfaces or
residual electricity.
8.1.1. HKC shall supply a NAMUR VDI/VDE standards’ bracket and a fixing stuff for mounting on actuator.
Bracket shall be applicable to any type of valves ; manual valve, linear valve, pneumatic rotary valve.
① Ensure valve actuator alignment (fully open or closed).
② Place the mounting bracket on a horizontal plane of actuator
③ Tighten the bolts enclosed in a box using a proper tool.
8.2. Mounting limit switch box
Caution ;
Do not attempt to work on limit switch box without first shutting off incoming power.
8.2.1. Prior to mounting the limit switch box must be checked for any damage.
8.2.2. Damaged parts must be replaced by original spare parts.
8.2.3. Limit switch boxes are available with a NAMUR shaft that enables direct attachment to actuator pinion
without a coupler. This shaft features a 4mm wide tang that engages the 4mm slot in NAMUR actuators.
① Check to be sure the drive slot on the top of the actuator and the shaft of switch box are the same
direction.
② Insert the shaft of switch box carefully into the mounting bracket.
③ Tighten the bolts enclosed in a box using a proper tool.
④ Check the connection of shaft being assembled correctly.
8.3. Setting cam
Note :
Basically, cams shall be set by manufacturer before shipment.
8.3.1. The color of cams harmonized with position indicator help us to set the
cams easily without wiring diagram. Cams shall be easily set without
tool. APL series cams are splined and can be setting lift up or push
down the cam from gear by hand in a seconds without setting tools.
Self-locking, spring loading make never slip out of adjustment.
8.3.2. Un-tighten the captive cover bolts with an applicable tool. (Spanner.+ Driver recommended)
8.3.3. Remove the cover carefully.
8.3.4. Open cam setting
① Electric power or air supply of valve actuator on to operate the actuator fully open
② Lift the bottom yellow cam (optional green) up and rotate it until the switch is activated.
③ And then release it. Cam shall be back into a stable position by itself.
8.3.5. Close cam setting
① Electric power or air supply of valve actuator off to operate the actuator fully close
② Push the upper red cam down and rotate it until the switch is activated.
③ And then release it. Cam shall be back into a stable position by itself.
Open cam Close cam

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 6 / 10 Valve Automation Leader, HKC
Mechanical switch
Proximity
sensor
Splined cam
8.4. Wiring
Danger ; HAZARDOUS VOLTAGE. No electrical power should be connected until all wiring and limit
switch adjustments have been completely.
8.4.1. Turn off the power before opening the cover.
8.4.2. APL limit switch box enclosure feature prewired switches. All user connections are made at a numbered
terminal strip. A wiring diagram, located inside the cover, indicates which terminal numbers correspond to
switch contacts, such as normally open (NO), normally closed (NC), etc. Follow the wiring diagram and
electrical code to connect the switches to your system.
8.4.3. [The APL-3 limit switch box has two cable entries on the body, and is protected with a sticker to protect it from
moisture and foreign matter penetration. User or installer shall be use cable gland that satisfy the protection
grade and connect them through the cable entries.
8.4.4. If the cable entry remains after wiring, it must be strictly closed using a suitable blanking plug. The cable gland
must be applied by installer or user. --- 20 r0]
① Mechanical switch(2 SPDT)
② Mechanical switch (3 SPDT)

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 7 / 10 Valve Automation Leader, HKC
③ Mechanical Switch (4 SPDT)
④ Mechanical Switch (2 DPDT)
⑤ Mechanical switch (2 SPDT), include Potentiometer

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 8 / 10 Valve Automation Leader, HKC
⑥ Mechanical switch (2 SPDT), include signal unit
Caution ;
Grounding should be connected until all wiring has been completed.
Internal grounding wire square shall be min. 2SQ recommended.
External grounding wire square shall be min. 4SQ recommended .
8.5. Setting Position Transmitter Unit (APL-3x6)
8.5.1. Potentiometer reads the current position of actuator and transfers a resistance value to a current position
transmitter card. Transmitter indicates the actuator position throughout the stroke a 4~20mA output signal.
8.5.2. Technical features
① Power Supply Range 12.5 ~ 37VDC (25V typical)
② Current Signal Output 4~20mA
③ Max. Load Resistance Max. Resistance (ohm) = (Supply voltage – 12.5) / 0.02
④ Potentiometer 0~500 ohm / 10k ohm
⑤ Operation Temperature -20 ~ 60℃
⑥ Dimension 40 * 60 * 15
8.5.3. Calibrating potentiometer
① Apply power or air to the actuator to operate fully closed position
② Connect an ohm meter to P1 and P3 resistance, the value shall be approximately 1kΩ
③ Loosen the shaft gear and connect the ohm meter to P1 and P3 and gently rotate until 80~120 ohm is
achieved (100 ohm preferred). While maintaining the value, tighten a lock screw with a hex wrench.
8.5.4. Zero and Span Calibration
Zero and span setting has been calibrated by manufacturer. However, if re-calibration is required
① Operate an actuator to 50% position and then fully closed position.
② When the actuator is in the fully closed position, adjust the “zero” button on the card until a value of 20
mA is achieved.

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 9 / 10 Valve Automation Leader, HKC
9. Maintenance
Caution :
-Shut off incoming power or air supply on the valve actuator before maintenance limit switch box.
-Be sure that the area is clean before disassemble and maintenance limit switch box. Clean all parts and
housing before re-assemble.
-Refers to the part list when ordering replacement or spare parts.
9.1. Maintenance, under normal conditions at six month intervals or 100,000 cycle operation. But when
conditions are more severe, more frequent inspections may be required.
9.1.1. Ensure valve actuator alignment. [If the alignment is not correct, the shaft may be damaged by metallic
fatigue during operation. --- 20 r0]
9.1.2. Ensure wiring is insulated, connected and terminated properly
9.1.3. Ensure all screws are present and tight
9.1.4. Check the cleanliness of the internal electrical system.
9.1.5. Ensure conduit connections are installed properly and are dry
9.1.6. Check internal devices for condensation
9.1.7. Check enclosure O rings seals and verify that the O ring is not pinched between housing
9.1.8. Visually inspect during open/close cycle
9.1.9. Inspect identification labels for ware and replace if necessary
Warning ;
Before opening, you must ensure that there are no flammable gases and electrical power is off.
Treat cover with care. Gap surface must not be damaged or dirtied in any way
10. Inspection
10.1. Check the item and quantity of products with packing list or related documents.
10.2. Check the limit switch box o-ring. Where a damage on it. It caused the corrosion of internal parts.
10.3. Check the adjustment of cams. Cams shall be released when those have been used for a long period of
operating. If do so, they don’t work correctly with switches.
11. Storage
The products must be stored in a clean, cool and dry area. The unit shall be stored with the cover installed and
the cable entry openings sealed. Storage must be off the floor, covered with a sealed dust protector.
12. Trouble Shooting
The following instructions are offered for the most common difficulties encounter during installation and start-
up.
Signal fails to main control room.
① Check the wiring of limit switch box in accordance with wiring diagram.
② Check whether the cams or switches are damaged or broken.
③ Check the main signal wire from the terminal strip.
④ Re-set the limit switch box
⑤ Check resistance value of the potentiometer.
⑥ Check potentiometer gear jamming
⑦ Check the zero and span calibration
⑧ Check whether the card is damaged or not.
13. Tools
① 1 Set Metric Allen key (Hex Wrench)
② 1 Set Screw driver
③ 1 Set Metric spanner
④ 1 Wire Stripper long nose
⑤ 1 Needle nose pliers
⑥ 1 Multi Meter (AC, DC, Resistance)
⑦ 1 Ohm Meter (0~25mA) : IF APL - . 16 adapted
14. Installation and Maintenance Tips
For any installation and maintenance work, the following should be observed :
Caution :
 A regular inspection and maintenance performed by qualified and trained personnel

APL-3 Series Limit Switch Box
Installation Operation & Maintenance Manual
Doc No. : HumG-APL3-21 Rev1 Page 10 / 10 Valve Automation Leader, HKC
 Work at the open actuator under voltage must only be performed if it is assured that for the duration of the
work there is no danger of explosion.
 Observe additional national regulations.
14.1. Check the limit switch box visually. Ensure that no outside damage or changes are visible.
14.2. The electric connecting cables must be without damage and wired correctly.
14.3. Cable entries, cable glands, plugs etc. have to be checked for correct tightness and sealing.
14.4. Check whether enclosure connections are fastened correctly.
14.5. Take care of possible discolorations of the terminals and wires.
14.6. Check the enclosure gaps whether contaminated dirt and corrosion. Since the dimensions of all enclosure gaps
are strictly defined and inspected, no mechanical work shall be performed on them.
14.7. Ensure that all housing covers are handled carefully and that the seals are checked.
14.8. All cables have to be checked.
14.9. If defects which affect the safety are detected during maintenance, repair measures have to be taken
immediately.
14.10. Any kind of coating for the gap surface shall not be permitted.
14.11. When exchanging parts, seals etc. only original spare parts shall be used.
HKC Co., Ltd. 26, Emtibeui 28-ro, Siheung-si, Gyeonggi-do, 15119, Republic of Korea
Head Office & Plant: Tel) [phone], Fax) [phone]
Fax) Overseas sales office: [phone], Domestic sales office: [phone]
Website www.hkcon.co.kr
