HMS Networks Anybus-E300-DPV1 User manual

Anybus-E300-DPV1 - E300 Communication Module for PROFIBUS
USER MANUAL
SCM-1202-203
Version 1.1
Publicaon date 2022-03-25
ENGLISH

Important User Informaon
Disclaimer
The informaon in this document is for informaonal purposes only. Please inform HMS Networks of any
inaccuracies or omissions found in this document. HMS Networks disclaims any responsibility or liability for any
errors that may appear in this document.
HMS Networks reserves the right to modify its products in line with its policy of connuous product
development. The informaon in this document shall therefore not be construed as a commitment on the
part of HMS Networks and is subject to change without noce. HMS Networks makes no commitment to update
or keep current the informaon in this document.
The data, examples and illustraons found in this document are included for illustrave purposes and are only
intended to help improve understanding of the funconality and handling of the product. In view of the wide
range of possible applicaons of the product, and because of the many variables and requirements associated
with any parcular implementaon, HMS Networks cannot assume responsibility or liability for actual use
based on the data, examples or illustraons included in this document nor for any damages incurred during
installaon of the product. Those responsible for the use of the product must acquire sucient knowledge in
order to ensure that the product is used correctly in their specic applicaon and that the applicaon meets all
performance and safety requirements including any applicable laws, regulaons, codes and standards. Further,
HMS Networks will under no circumstances assume liability or responsibility for any problems that may arise as
a result from the use of undocumented features or funconal side eects found outside the documented scope
of the product. The eects caused by any direct or indirect use of such aspects of the product are undened and
may include e.g. compability issues and stability issues.
Copyright © 2022 HMS Networks
Contact Informaon
Postal address:
Box 4126
300 04 Halmstad, Sweden
E-Mail: inf[email protected]

Table of Contents
1. Preface .................................................................................................................................. 1
1.1. About This Document ........................................................................................................ 1
1.2. Document Convenons ..................................................................................................... 1
1.3. Trademarks ..................................................................................................................... 2
2. Safety .................................................................................................................................... 3
2.1. Intended Use ................................................................................................................... 3
2.2. General Safety ................................................................................................................. 3
3. Preparaon ............................................................................................................................ 4
3.1. Recommended Cables and Connectors ................................................................................. 4
3.2. E300 Communicaon Module Network Informaon ............................................................... 5
3.3. Support and Resources ...................................................................................................... 5
3.4. HMS Soware Applicaons ................................................................................................ 5
3.5. Third-Party Soware Applicaons ........................................................................................ 5
4. Installaon ............................................................................................................................. 6
4.1. E300 Relay Modules .......................................................................................................... 6
4.2. Aach E300 Communicaon Module ................................................................................... 7
4.3. Connect to PROFIBUS Network ........................................................................................... 8
4.4. Connect to Ground ........................................................................................................... 9
4.5. PROFIBUS Address Seng Via Rotary Switches ..................................................................... 10
5. Verify Operaon ..................................................................................................................... 11
5.1. LED Guide ...................................................................................................................... 11
6. Maintenance ......................................................................................................................... 12
6.1. Firmware Update for Host Controller .................................................................................. 12
6.2. Firmware Update for the CompactCom C40 NP40 Chip ........................................................... 14
7. Troubleshoong ..................................................................................................................... 18
7.1. Addional Diagnosc informaon ...................................................................................... 18
7.2. Protecon Trip Status ....................................................................................................... 21
8. Technical Data ........................................................................................................................ 22
8.1. Technical Specicaons .................................................................................................... 22
9. Reference Guides ................................................................................................................... 23
9.1. Cyclic Input Data ............................................................................................................. 23
9.2. Cyclic Output Data ........................................................................................................... 23
9.3. Acyclic Data .................................................................................................................... 24
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1

This page is intenonally le blank.

1. Preface
1.1. About This Document
This manual describes the installaon and conguraon of the E300-DPV1.
For informaon on how to congure the E300 Electronic Overload Relay, refer to the user manual for the E300
Electronic Overload Relay.
For addional documentaon and resources, please visit www.anybus.com/support and
www.rockwellautomaon.com/support.
1.2. Document Convenons
Lists
Numbered lists indicate tasks that should be carried out in sequence:
1. First do this
2. Then do this
Bulleted lists are used for:
• Tasks that can be carried out in any order
• Itemized informaon
User Interacon Elements
User interacon elements (buons etc.) are indicated with bold text.
Program Code and Scripts
Program code and script examples
Cross-References and Links
Cross-reference within this document: Document Convenons (page 1)
External link (URL): www.anybus.com
Preface Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 1 of 28

Safety Symbols
DANGER
Instrucons that must be followed to avoid an imminently hazardous situaon which, if not avoided,
will result in death or serious injury.
WARNING
Instrucons that must be followed to avoid a potenal hazardous situaon that, if not avoided, could
result in death or serious injury.
CAUTION
Instrucon that must be followed to avoid a potenal hazardous situaon that, if not avoided, could
result in minor or moderate injury.
IMPORTANT
Instrucon that must be followed to avoid a risk of reduced funconality and/or damage to the
equipment, or to avoid a network security risk.
Informaon Symbols
NOTE
Addional informaon which may facilitate installaon and/or operaon.
TIP
Helpful advice and suggesons.
1.3. Trademarks
Anybus® is a registered trademark of HMS Networks.
All other trademarks are the property of their respecve holders.
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Trademarks
Page 2 of 28 SCM-1202-203 1.1

2. Safety
2.1. Intended Use
The intended use of this equipment is as a communicaon interface. The communicaon module allows an E300
Relay to be integrated into an automaon system.
The communicaon module has one PROFIBUS-D-SUB connector.
If this equipment is used in a manner not specied by the manufacturer, the protecon provided by the
equipment may be impaired.
2.2. General Safety
WARNING
To prevent electrical shock, disconnect from power source before installing or servicing. Follow NFPA
70E requirements. Install in suitable enclosure. Keep free from contaminants.
WARNING
Installaon, adjustments, pung into service, use, assembly, disassembly, and maintenance shall be
carried out by suitably trained personnel in accordance with applicable code of pracce.
WARNING
In case of malfuncon or damage, no aempts at repair should be made. The product should be
returned to the manufacturer for repair. Do not dismantle the product.
Safety Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 3 of 28

3. Preparaon
3.1. Recommended Cables and Connectors
IMPORTANT
Use only PROFIBUS approved cables and connectors.
Figure 1. Straight, 45° and 90° connectors
Supported versions of PROFIBUS connectors: Straight, 45° and 90°
Maximum supported PROFIBUS connector width: 35 mm.
Table 1. Supported PROFIBUS connectors, examples
Manufacturer Variant Arcle
Siemens 0° 6GK1500-0EA02
Siemens 90° 6ES7972-0BB12-0XA0
Erni 90° 104050
Erni 90° 174048
Phoenix Contact 0° SUBCON-PLUS-PROFIB/AX/SC - 2744380
Phoenix Contact 45° SUBCON-PLUS-PROFIB (2744348)
Phoenix Contact 90° SUBCON-PLUS-PROFIB/90/IDC (2313672)
Maximum cable length depends on the congured Baud rate. For more informaon refer to www.probus.com.
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Preparaon
Page 4 of 28 SCM-1202-203 1.1

3.2. E300 Communicaon Module Network Informaon
Label with Serial Number and Firmware Revision.
3.3. Support and Resources
For addional documentaon and technical support, please visit www.anybus.com/support and
www.rockwellautomaon.com/support.
3.4. HMS Soware Applicaons
The following HMS soware applicaons are needed to update the CompactCom C40 NP40 Chip rmware:
• Anybus Transport Provider
• Anybus Firmware Manager II
Download the installaon les and documentaon from www.anybus.com/support.
3.5. Third-Party Soware Applicaons
The Flash Magic tool is needed to update the E300-DPV1 rmware.
Visit www.ashmagictool.com and download the installaon les for the current version of the Flash Magic tool.
E300 Communicaon Module Network Informaon Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 5 of 28

4. Installaon
4.1. E300 Relay Modules
Three modules comprise the E300 Relay.
All three modules are required to make a funconal overload relay.
Posion Module
A E300-DPV1
B E300 Relay Control Module
C E300 Relay Sensing Module
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Installaon
Page 6 of 28 SCM-1202-203 1.1

4.2. Aach E300 Communicaon Module
Procedure
To aach the E300 Communicaon Module to the E300 Relay Control Module:
1. Pull out the locking tab located on the upper le side of the E300 Relay Control Module.
2. Aach the E300 Communicaon Module to the E300 Relay Control Module.
Aach E300 Communicaon Module Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 7 of 28

3. To lock the modules, push in the locking tab located on the upper le side of the E300 Relay Control Module.
4.3. Connect to PROFIBUS Network
The E300 Communicaon Module has one PROFIBUS D-SUB connector.
IMPORTANT
If a node is the last on a bus segment, use a PROFIBUS connector with built-in and acvated
terminang resistors.
For more informaon about PROFIBUS design and installaon, refer to www.probus.com.
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Connect to PROFIBUS Network
Page 8 of 28 SCM-1202-203 1.1

4.4. Connect to Ground
Connect the Green Wire to Funconal Earth (Ground).
Connect to Ground Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 9 of 28

4.5. PROFIBUS Address Seng Via Rotary Switches
Use the three rotary switches to select the PROFIBUS address.
Rotary Switch Seng Funcon
000 - 125 User congured PROFIBUS address
126 PROFIBUS address congured by PROFIBUS Master (SSA)
600 - 699 NP40-Update-Mode
700 - 799 Host-Update-Mode
NOTE
All other rotary switch sengs are treated as invalid and result in a red TRIP/WARN LED.
A power cycle is required for the changes to take eect.
PROFIBUS address seng example
When the le dial is set to 1, the middle dial is set to 2, and the right dial is set to 3, the resulng PROFIBUS
staon address is: 123.
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS PROFIBUS Address Seng Via Rotary Switches
Page 10 of 28 SCM-1202-203 1.1

5. Verify Operaon
5.1. LED Guide
E300 Communicaon Module LED Indicators
LED A LED C LED D
Indicator State POWER MODE - Network Status STATUS - Module Status
O Device o Not online/No power Not inialized
Green Device Acve (Current Detected)/Run
Mode
Online, data exchange Inialized
Green, ashing Device Ready/ Ready Mode Online, clear Inialized, diagnosc event(s)
present
Red N/A N/A Excepon error
Red, 1 ash N/A Parameterizaon error N/A
Red, 2 ashes N/A PROFIBUS conguraon error N/A
LED B: Indicates status for TRIP/WARN. For more informaon, refer to the E300 Relay Control Module User
Manual.
Verify Operaon Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 11 of 28

6. Maintenance
6.1. Firmware Update for Host Controller
Before You Begin
Download Flash Magic Tool Installaon Files
The Flash Magic tool is needed to update the E300-DPV1 rmware.
Visit www.ashmagictool.com and download the installaon les for the current version of the Flash Magic tool.
E300-DPV1 Firmware Update Files
Download the current E300-DPV1 rmware update les from www.anybus.com/support.
Procedure
Install rmware update for Host Controller
1. Install the Flash Magic tool on your PC.
2. Disconnect the E300-DPV1 from power.
3. Remove the E300-DPV1 from the E300 Relay Control Module.
See Aach E300 Communicaon Module (page 7).
4. Set the E300-DPV1 rotary switches to 700.
See PROFIBUS Address Seng Via Rotary Switches (page 10).
5. To access the TTL pin header connector located on the E300-DPV1 PCB, remove the E300-DPV1 top lid.
Figure 2. TTL pin header connector
6. Connect an TTL-USB cable to the TTL pin header connector and to your PC
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Maintenance
Page 12 of 28 SCM-1202-203 1.1

7. Start the Flash Magic tool and congure the following sengs:
Figure 3. Flash Magic tool rmware update
a. Set Device to UART/LPC1518.
b. Select a Serial Port to connect to on your PC.
c. Keep the default Baud rate seng 57600.
d. In the Firmware secon, browse to and open the rmware HEX le.
e. In the Opons secon, select the Verify aer Programming checkbox.
8. Click Start and wait for the rmware update to complete.
9. Disconnect the TTL-USB cable and close the E300-DPV1 top lid.
10. Aach the E300-DPV1 to the E300 Relay Control Module.
See Aach E300 Communicaon Module (page 7).
11. Set the E300-DPV1 rotary switches to the desired PROFIBUS address.
See PROFIBUS Address Seng Via Rotary Switches (page 10).
12. Reconnect the E300-DPV1 to power.
The rmware update is now complete.
Firmware Update for Host Controller Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 13 of 28

6.2. Firmware Update for the CompactCom C40 NP40 Chip
Before You Begin
Download HMS Soware Applicaons
The following HMS soware applicaons are needed to update the CompactCom C40 NP40 Chip rmware:
• Anybus Transport Provider
• Anybus Firmware Manager II
Download the installaon les and documentaon from www.anybus.com/support.
Download CompactCom C40 NP40 Chip Firmware Update Files
Download the CompactCom C40 NP40 Chip rmware update HIFF les from www.anybus.com/support.
Procedure
Install rmware update for CompactCom C40 NP40 Chip
1. Install the Transport Provider on your PC.
2. Install the Firmware Manager II on your PC.
3. In the Firmware Manager II:
a. Click File > Firmware Archive.
b. Locate the rmware update HIFF le on your PC
c. Drag and drop the rmware HIFF le into the Firmware Archive window.
A new entry appears.
d. Close the Firmware Archive window.
4. Disconnect the E300-DPV1 from power.
5. Remove the E300-DPV1 from the E300 Relay Control Module.
See Aach E300 Communicaon Module (page 7).
6. Set the E300-DPV1 rotary switches to 600.
See PROFIBUS Address Seng Via Rotary Switches (page 10).
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Firmware Update for the CompactCom C40 NP40 Chip
Page 14 of 28 SCM-1202-203 1.1

7. To access the TTL pin header connector located on the E300-DPV1 PCB, remove the E300-DPV1 top lid.
Figure 4. TTL pin header connector
8. Connect a TTL-USB cable to the E300-DPV1 TTL pin header connector.
IMPORTANT
Do not connect the TTL-USB cable to your computer in this step. The E300-DPV1 is powered on
when connected to a computer. If power is turned on too early in the rmware update process,
the rmware update process may me out or fail.
Firmware Update for the CompactCom C40 NP40 Chip Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS
SCM-1202-203 1.1 Page 15 of 28

9. In the Firmware Manager II:
Figure 5. Firmware Manager II Manual Update Wizard
a. Click File > Manual Update Wizard.
b. Select Anybus CompactCom 40 and click Next.
c. Select Transport Provider and click Next.
d. In the new window, click Create.
e. Select COM-Port Transport Provider and click Ok.
f. Connect the TTL-USB cable to your computer.
The E300-DPV1 LED indicators ash green and yellow.
g. Enter a Path name for the new path and click Ok.
IMPORTANT
For the new COM port to appear in the Select Transport Provider Path drop-down list,
ensure that the TTL-USB cable is connected to your computer before you click Ok.
h. Within the next 2 minutes, select a COM-Port from the Select Transport Provider Path drop-down list
and click Ok.
Anybus-E300-DPV1 - E300 Communicaon Module for PROFIBUS Firmware Update for the CompactCom C40 NP40 Chip
Page 16 of 28 SCM-1202-203 1.1
