HMS Networks Ewon FLX3101 User manual
Single Ethernet Ext. Card FLX3101
INSTALLATION GUIDE
IG-0017-00 1.5 en-US ENGLISH
Important User Information
Disclaimer
The information in this document is for informational purposes only. Please inform HMS Industrial Networks of any
inaccuracies or omissions found in this document. HMS Industrial Networks disclaims any responsibility or liability
for any errors that may appear in this document.
HMS Industrial Networks reserves the right to modify its products in line with its policy of continuous product
development. The information in this document shall therefore not be construed as a commitment on the part of
HMS Industrial Networks and is subject to change without notice. HMS Industrial Networks makes no commitment
to update or keep current the information in this document.
The data, examples and illustrations found in this document are included for illustrative purposes and are only
intended to help improve understanding of the functionality and handling of the product. In view of the wide range
of possible applications of the product, and because of the many variables and requirements associated with any
particular implementation, HMS Industrial Networks cannot assume responsibility or liability for actual use based on
the data, examples or illustrations included in this document nor for any damages incurred during installation of the
product. Those responsible for the use of the product must acquire sufficient knowledge in order to ensure that the
product is used correctly in their specific application and that the application meets all performance and safety
requirements including any applicable laws, regulations, codes and standards. Further, HMS Industrial Networks will
under no circumstances assume liability or responsibility for any problems that may arise as a result from the use of
undocumented features or functional side effects found outside the documented scope of the product. The effects
caused by any direct or indirect use of such aspects of the product are undefined and may include e.g. compatibility
issues and stability issues.
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Table of Contents Page
1 Preface ................................................................................................................................. 3
1.1 About This Document .......................................................................................................3
1.2 Document History ............................................................................................................3
1.3 Related Documents ..........................................................................................................3
1.4 Trademark Information.....................................................................................................3
2 Product Summary................................................................................................................ 4
3 Safety, Environmental & Regulatory Information ............................................................. 5
3.1 Scope.............................................................................................................................5
3.2 ESD Damage Prevention....................................................................................................5
3.3 Applicable Directives, Standards and Compliances .................................................................5
4 Hardware Description ......................................................................................................... 7
4.1 Mechanical Layout and Interfaces .......................................................................................7
4.2 Extension Card Label ........................................................................................................7
4.3 Front Panel LEDs..............................................................................................................8
4.4 Ewon Flexy Extension Cards Environmental Conditions ........................................................... 9
4.5 Ethernet Port Specifications...............................................................................................9
4.6 Plug the FLX 3101 into the Base Unit ...................................................................................9
4.7 Power Requirements ...................................................................................................... 13
5 Powering on the Base Unit with its Extension Cards ...................................................... 15
6 Check Card Detection on the Embedded Web Page ....................................................... 16
6.1 Connecting to the Embedded Web Server .......................................................................... 16
6.2 Detected Cards Displayed in the System Page ..................................................................... 16
This page intentionally left blank
Preface 3 (18)
1 Preface
1.1 About This Document
This document describes the hardware of the FLX 3101 – single Ethernet port extension card
which belongs to the Ewon Flexy family
The Ewon Flexy family is a range of modular industrial gateway/router and as its name Ewon
Flexy suggests, it has been designed to enable numerous different combinations of base units
with extension cards.
For additional related documentation and file downloads, please visit www.ewon.biz/support.
1.2 Document History
Version Date Description
1.0 2016-07-05 First release
1.1 2015-11-21 Official product release
1.2 2015-11-18 New template release
1.3 2016-07-27 Update of legal references
1.4 2018-08-03 New template release
1.5 2019-09-03 Changed: Safety, Environmental & Regulatory Information, p. 5
Changed: Ewon Flexy Extension Cards Environmental Conditions, p. 9
1.3 Related Documents
Document Author Document ID
Ewon Flexy HMS IG-0014-00
EwonFlexy 205 HMS IG-0028-00
1.4 Trademark Information
Ewon®is a registered trademark of HMS Industrial Networks SA. All other trademarks mentioned
in this document are the property of their respective holders.
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Product Summary 4 (18)
2 Product Summary
The present Installation Guide is focusing on the FLX 3101 – single Ethernet port extension card
which, as such, needs to be inserted in one of the Flexy base units to work.
The base units have their own Installation Guide which can be found in the Related Documents, p.
3.
This guide also addresses shortly how the extension cards integrate the base units as well as
some recommendations on how to mount them. See Base Unit Slot Compatibility, p. 9 for more
details.
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Safety, Environmental & Regulatory Information 5 (18)
3 Safety, Environmental & Regulatory Information
3.1 Scope
The present heading addresses Safety, Environmental & Regulatory Information about the FLX
3101 – single Ethernet port extension card.
This extension card is belonging to the same compliance frame than the base units. In the
present case of a telecommunication extension card, additional directives, standards and
instructions apply.
3.2 ESD Damage Prevention
Always use ESD precautions when handling extension cards and / or opened base unit as
they contain parts and assemblies susceptible to be damaged by electrostatic discharge
(ESD).
The extension card described in this document is a module exposing both sides of an electronic
printed circuit board. Therefore, it is packed in an antistatic ESD bag. In order to avoid ESD
damage, the product must be handled with the necessary precaution including:
• Grounded ESD protective work surface
• Personnel grounding
3.3 Applicable Directives, Standards and Compliances
TheFLX 3101 inserted in a base unit belongs to class A Information Technology Equipment (ITE).
In a domestic environment, this product may cause radio interference in which case the user
may be required to take appropriate measures.
3.3.1 Applicable European Directives
The FLX 3101 is in conformity with the following EC directives:
• RoHS Directive 2011/65/EU
• RE Directive 2014/53/EU
3.3.2 Applicable Safety Standards
The FLX 3101 is in conformity with the following safety standards:
• IEC / EN 60950-1
• UL 60950-1
• CSA-C22.2 No 60950-1-07
• EN/IEC 62368-1
• UL 62368-1
• CAN 62368-1
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Safety, Environmental & Regulatory Information 6 (18)
3.3.3 FCC Compliance
The FLX 3101 complies with Part 15 of the FCC Rules. Operating is subject to the following two
conditions:
• This product may not cause harmful interference
• This product must accept any interference received, including interference that may cause
undesired operation.
3.3.4 Certifications
The FLX 3101 has been certified by authorized bodies:
• UL Certificate of Compliance (COC) # 20190529_E350576
• CB certificate # DK-84039-UL
These certificates can be downloaded as PDF files on the Ewon support web site: www.ewon.biz/
support
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Hardware Description 7 (18)
4 Hardware Description
4.1 Mechanical Layout and Interfaces
Fig. 1 Mechanical layout and interfaces
1Ethernet Port Connector RJ45 - 10/100 Base-T
2Back-plane connector
4.2 Extension Card Label
4.2.1 Label Location and Included Information
The identification label of the extension cards is placed on the solder side of the PCB.
The different parts of the label are described below:
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Hardware Description 8 (18)
Fig. 2 FLX 3101 label
Label Description
PN Part Number (see syntax table below)
SN Serial Number in the form: MMMM-YYWW-SSSS-
PP
• MMMM : MTID (product related)
• YYWW : Year and week
• SSSS : Sequential manufacturing order
• PP : Product type
MIN. FW Minimum firmware version required in the Ewon
device
Marks CE, UL... certification number and logos if
applicable
4.2.2 Part Number Structure for Extension Cards
FLYXXXX_00/S
FL FL is the prefix for the extensions of the Ewon Flexy family Only FL (constant)
Y1 alphabetic sign (CAP)
Defines the slots of the base module in which the extension
card can be inserted.
A2 first slots
only
●●○○
B2 last slots
only
○○●●
XAny slots ●●●●
CAny slots.
Available for
Flexy 205 only.
○○○○
XXXX_00 The extension card type. The suffix _00 is used for software options.
/S The suffix might have an optional “/” character
It might also be blank or include “S” character => Indicates compliance with the UL/IEC/EN 60950
standard.
4.3 Front Panel LEDs
Fig. 3 Front panel LEDs
Item Mark Function
1 LNK ON
Link ETH 10/100 present
Speed indication:
Green = 100 Mbps
Amber = 10 Mbps
2 ACT Flashing Green
Packets transfer activity
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Hardware Description 9 (18)
4.4 Ewon Flexy Extension Cards Environmental Conditions
Characteristic Value
Operating temperature -25 to +60 °C
Storage temperature -40 to +70 °C
Relative humidity 10 to 95% non-condensing
Operating altitude Up to maximum 2000m
Storage altitude Up to maximum 3000m
4.5 Ethernet Port Specifications
Characteristic Value
Ethernet Port 10/100Mbps
Default IP mode Static
Default IP address (WAN) 10.1.0.53
Default Subnet Mask 255.255.255.0
4.6 Plug the FLX 3101 into the Base Unit
4.6.1 Base Unit Slot Compatibility
The FLX 3101 must be inserted in one of the “Type X” slots of the base unit.
The reference code of the extension cards includes a letter defining their compatibility:
• FLXxxxx: designate cards that fit into “Type X” slots.
In addition to the card reference, each type of extension card bears a visual compatibility symbol
on its front panel:
Design Slot Type Flexy 205 Location Flexy 10x & 20x
●●●● Type X Any slot Any slot
Ewon Flexy 205
As the Flexy 205 has room for 2 slots, the type slot compatibility rule doesn’t apply. The FLX 3101
can be inserted in both slots.
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Hardware Description 11 (18)
Fig. 5 Position of the “Type X” Slots on a Flexy 10x & 20x.
4.6.2 How to Insert into the Flexy Base Unit
Wait 30 seconds after turning off the equipment before inserting (or removing) an extension
card to avoid possible damage to the base unit and the extension cards.
Remove the slot filler of the location the new card will be inserted. To do so, press on both ends
of the cover, note that the hooks are off-centered.
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Hardware Description 12 (18)
Fig. 6 Remove the slot fillers
1Hooks to be pressed are off-centered. Press while pulling upwards
2This metal tag soldered on the PCB acts as mistake-proof security (mating stop in housing).
Doesn’t apply on Flexy 205.
Insert the extension card carefully and slide it down until the hook clicks. Make sure the card is
completely inserted.
DO NOT insist if a resistance is felt when trying to insert the card. This can occur if the extension
card is inserted in a wrong slot type. In such case, check slot compatibility of the relevant
extension card.
Boot the unit for the inserted extension cards to be detected. The web interface of the Flexy
base unit has a diagnostic page showing the extension cards in their order of detection (from left
to right).
If an extension card is inadvertently forced in a wrong slot, the base unit will detect the
misplaced card and will not complete its boot process. Therefore, the unit will not be
accessible through its LAN interface. The slot error is returned by the USR LED. (red ON 1
sec, OFF 0.5 sec).
4.6.3 Insertion of Multiple FLX 3101
Detection Order
The boot sequence of the base unit includes an automated detection of the inserted extension
cards. This detection is done sequentially, slot per slot starting from left to right (when holding
the base unit with its logo on the right side).
Software Compatibility
The base unit allows the insertion of multiple extension cards, sometimes of the same type.
Some configurations including multiple extension cards, even if mechanically acceptable, are not
supported by the embedded software. Cards in excess are ignored during the automated
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Hardware Description 13 (18)
detection process which means that the base unit and its running extension cards will operate
normally.
The Flexy firmware currently supports up to 1FLX 3101.
The ignored card(s) will appear in the Diagnostic >Status >System Info >System but they will
not be functional.
Fig. 7 Order of the Extension Cards
The picture above shows an example of a configuration that would be OK mechanically and
power wise but would not be supported by the firmware.
During the boot process, the first 2 serial port extension cards are detected and both can be used.
In case of 2 single Ethernet cards, these 2 cards are also detected but the second Ethernet card is
not supported by the firmware and cannot be used. The presence of this “ignored” card in the
base unit does not alter the operation of the base unit itself nor does it alter its “accepted”
extension cards.
4.7 Power Requirements
The “Power Requirements” concept doesn’t apply to Flexy 205 and its inserted extension
cards.
The internal power converter of the Flexy base units has been dimensioned to cover a broad
range of different combinations of extension cards. Users should make sure the total power
demand of the extension cards does not exceed the capabilities of the base unit. That is why the
notion of “Energy Points” has been introduced.
The Installation Guide “eWON Flexy - Base Units” includes a section giving the Available Energy
Points of each type of base unit.
The power requirements of each extension card is expressed in Energy Demand Points. This
number is meant to check whether the balance with the Available Energy Points of a given base
unit with extension cards is OK or not.
The Energy Demand Points of the FLX 3101 is 1
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Powering on the Base Unit with its Extension Cards 15 (18)
5 Powering on the Base Unit with its Extension Cards
When the base unit is powered on, it takes approximately 25 seconds for the unit to go through
its self-test procedure. The slots in which the extension cards have been inserted and their type
are detected during this process.
If the boot process completes normally, the following LED status should be observed:
• Base unit : USR LED flashing green slowly
• Extension card : None
If the USR LED of the base unit is flashing red, it might be because the extension card was
improperly inserted (for example in a wrong slot).
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
Check Card Detection on the Embedded Web Page 16 (18)
6 Check Card Detection on the Embedded Web Page
The Flexy extension cards require no software configuration. They are automatically detected by
the base unit when the device boots.
6.1 Connecting to the Embedded Web Server
Configure the network parameters to set the computer being used to reach the web interface on
the same IP range than the LAN of the Ewon device.
Once both devices are in the same IP range, connect the PC to one of the LAN port of the Ewon
device.
Open an Internet browser and access the homepage of the Ewon device by typing the LAN IP
address in the URL field (the default address is http://10.0.0.53).
A dialog box will pop-up asking for credentials. Default ones are:
• login: adm
• password: adm
For security reasons, changing the default password adm is an absolute requirement. To
change it, from the menu bar, click on Setup > Users and double click on the adm entry to
edit and save its password.
6.2 Detected Cards Displayed in the System Page
Once connected to the embedded web pages of the Ewon device, the homepage displays the
system status including detected extension cards.
To access in details the system status summary, click on Diagnostic > Status > System Info >
System.
Single Ethernet Ext. Card FLX3101 Installation Guide IG-0017-00 1.5 en-US
This page intentionally left blank
last page
© 2019 HMS Industrial Networks
Box 4126
300 04 Halmstad, Sweden
Table of contents
Other HMS Networks Network Card manuals
