Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

About This Document 3 (12)
1 About This Document
This document describes how to install the Anybus WLAN Access Point IP30
and set up a basic configuration.
For additional documentation and software downloads, FAQs, troubleshooting
guides and technical support, please visit www.anybus.com/support.
Document Conventions
The following formatting conventions are used in this document to indicate safety
information and other content of specific importance:
WARNING
This instruction must be followed to avoid a risk of death or serious injury.
Caution
This instruction must be followed to avoid a risk of personal injury.
This instruction must be followed to avoid a risk of reduced functionality
and/or damage to the equipment, or to avoid a network security risk.
This is additional information which may facilitate installation and/or
operation.
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Installation 4 (12)
2 Installation
Caution
This equipment emits RF energy in the ISM (Industrial, Scientific, Medical)
band. Make sure that all medical devices used in proximity to this device
meet appropriate susceptibility specifications for this type of RF energy.
This product contains parts that can be damaged by electrostatic
discharge (ESD). Use ESD prevention measures to avoid damage.
Make sure that you have all the necessary information about the capabilities and
restrictions of your local network environment before installation.
For optimal reception, wireless devices require a zone between them clear of
objects that could otherwise obstruct or reflect the signal. A minimum distance of
50 cm between the devices should also be observed to avoid interference.
The Anybus WLAN Access Point IP30 can be mounted on a standard DIN rail or
screw-mounted directly onto a flat surface using the included wall mounting kit.
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Installation 5 (12)
2.1 Overview
1Power connector
2, 6 Antenna connectors
3Digital inputs
4Digital outputs
5Console connector (not used)
7Ethernet connectors
8Reset button
9WLAN signal LEDs
10 Status LEDs
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Installation 6 (12)
2.2 Connectors
2.2.1 Power Connector
Connecting power with reverse polarity or using the wrong type of power
supply may damage the equipment. Make sure that the power supply is
connected correctly and of the recommended type.
The power connector consists of a 6-pin terminal block located on the top of the
unit. The unit can be supplied with power from two independent 12–48 VDC
power sources for redundancy using the inputs PWR-1 and PWR-2.
See also Technical Data, p. 10 regarding power supply requirements.
The power connector also includes a relay output, Fault, that can be used for
triggering an alarm in case of power failure (see the User Manual).
V1+ Power Input 1 +
V1- Power Input 1 -
V2+ Power Input 2 +
V2- Power Input 2 -
Fault Relay output, NO, max 1 A @ 24 V
Chassis ground
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Installation 7 (12)
2.2.2 Digital In/Out Connectors
Anybus WLAN Access Point IP30 has 4 digital inputs and 4 digital outputs that
can be used for monitoring and controlling purposes. See the description of the
DIDO settings in the User Manual for more information.
Digital Inputs
Pin Function
DI1 Direct input 1
DI2 Direct input 2
DI3 Direct input 3
DI4 Direct input 4
COM Common signal ground
Digital Outputs
Pin Function
DO1 Direct output 1
DO2 Direct output 2
DO3 Direct output 3
DO4 Direct output 4
GND Common signal ground
2.2.3 Ethernet Connectors
Anybus WLAN Access Point IP30 has two switched Ethernet ports with RJ45
type connectors that are labeled ETH1 and ETH2.
Pin Function
1 TD+
2 TD-
3 RD+
4, 5, 7, 8 (reserved)
6 RD-
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Installation 8 (12)
2.3 LED Indicators
PWR1 Green Power input 1
PWR2 Green Power input 2
FAULT Red General error
WLAN
Off No WLAN link
Green WLAN link established
Green, flashing WLAN traffic
4 LEDs Strong WLAN signal
2–3 LEDs Adequate WLAN signal
1 LED Weak WLAN signal
All unlit No WLAN signal
ETH1/ETH2 LEDs
LNK/ACT
Off No link
Green Link established
Green, flashing Ethernet traffic
Speed
Off No traffic
Orange 10/1000 Mbit/s
Green 100 Mbit/s
2.4 Factory Reset
To restore the factory default settings, press and hold RESET on the front panel
until the power LED indicator(s) starts to flash, then release the button.
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Configuration 9 (12)
3 Configuration
Anybus WLAN Access Point IP30 is configured through a web interface which is
accessed by pointing a web browser to the IP address of the unit. The default IP
address is 192.168.0.2. The computer accessing the web interface must be in
the same IP subnet as the access point.
The web interface is designed for the current stable versions of Internet
Explorer, Chrome, Firefox and Safari. Other browsers may not support the
full functionality of the web interface.
Main Menu
Home Click on Run Wizard for easy configuration.
For manual configuration or to modify the settings applied by
the wizard, use the options in the following menus.
Overview Basic information about the access point and the Ethernet and
wireless networks
Basic Settings Basic settings for the access point and the LAN interface
Wireless Settings Basic settings for the WLAN interface
Advanced
Settings
Advanced settings for the WLAN interface
Event Warning
Settings
Settings for alarm messaging and fault indication
System Status Detailed information about network connections and traffic
Administrator Password settings, configuration backup, unit reset, etc.
Logout Click to log out from the Anybus WLAN Access Point IP30.
See the Anybus WLAN Access Point IP30 User Manual for more information.
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Technical Data 10 (12)
4 Technical Data
4.1 Technical Specifications
Order code EU: AWB4000
US: AWB4001
Wireless antenna External (RP SMA)
Maximum range 400 meters
Wired interface Ethernet
Ethernet port 2 x 10/100/1000Base-T(X) Auto MDI/MDX
RJ45 connectors
Power connector Dual power inputs on 6-pin terminal block
Power supply 2 x 12–48 VDC, reverse polarity protection
Power consumption 7.5 W
Dimensions (WxHxD) 74.3 x 153.6 x 109.2 mm
Weight 1.11 kg
Operating temperature -25 to +70 °C
Storage temperature -40 to +85 °C
Humidity 5 % to 95 % non-condensing
Mounting DIN rail or wall mount
Housing Metal
Protection class IP30
Certifications See datasheet
For more technical details and specifications, visit www.anybus.com/support.
Disposal and recycling
You must dispose of this product properly according to local laws and
regulations. Because this product contains electronic components, it
must be disposed of separately from household waste. When this
product reaches its end of life, contact local authorities to learn about
disposal and recycling options, or simply drop it off at your local HMS
office or return it to HMS.
For more information, see www.hms-networks.com.
Anybus®WLAN Access Point IP30 Startup Guide SP2382 EN 1.1

Technical Data 11 (12)
4.2 Dimensions
All measurements are in mm.
