HNK RAX1810 User manual
Figure 1-1
Figure 1-2
1.Appearance
Power LED WPS LED
5G LED
2.4G LED
Internet LED
LAN LED
2.Packing List
HNK wifi router h 1
Power adapter h 1
Ethernet cable h 1
Quick Installation Guide h 1
User manual h 1
Figure 3-1
='4
Modem
Internet
or
Ethernet
3.Connect the Router
1. Before you start, please turn off your modem if any, and remove the backup battery
if it has one.
2. Connect the modem to the routerĆs WAN port with an Ethernet cable.
3. Turn on the modem, and then wait about 2 minutes for it to restart.
4. Connect the power adapter to the router.
5. Verify the power LED on the top panel is solid on (green) .
6. Connect your computer or smartphone to the wifi named HNK-RAX1801 or
HNK-RAX1801-5Ghz.
Note: If your internet connection is through an Ethernet cable directly from the wall
instead of through a DSL / Cable /Satellite modem, connect the Ethernet cable to the
router's WAN port, and then connect the power adapter to the router and turn on the router.
Reset
LAN Ports
WAN Port
WPS Button
DC in
4.Wizard Page
4.1 Wizard Page
Browser Type 192.168.0.1 , automatically jump to the configuration wizard pageδNO
password in defaultε
Figure 4-1
Figure 4-2
4.2 WAN Connection Settings
There are several connection types to choose: Static IP, DHCP and PPPoE. If you are
unsure of your connection method, please contact your Internet Service Provider.
Note: If using the PPPoE option, you will need to remove or disable any PPPoE client
software on your computers.
4.2.1 DHCP Settings
4.2.2 PPPoE Settings
Figure 4-3
Figure 4-4
4.4 Admin Password Settings
After configuring the wifi, click ćNextĈ to set the user (Admin) password, and then
click ćNextĈ to save the configuration.
4.2.3 Static IP Settings
Figure 4-5
Figure 4-6
4.3 Wireless SSID and Password Settings
After configuring the static IP access method, please click ćNextĈ to complete the
wireless SSID configuration and wireless password settings.
Figure 4-7
Figure 4-8
Figure 4-9
5.Web Management Landing Page
5.1 Management Page Login
After completing the configuration wizard, please enter 192.168.0.1 in the browser to
log in to the router management page.
Admin PasswordφThe Device admin Password you set on Wizard Page.
Figure 5-1
6.Home Page
Home page information is displayed.
Figure 6-0
6.1 Internet Information Display Page
Internet connection status and connection information.
Figure 6-1
6.2 WiFi Information Display Page
6.2.1 Router Mode
Home>>RAX1801
Display Extender IPv4 mac address and wireless SSID.
Figure 6-2
6.2.2 Repeater Mode
Display the Extender IPv4 mac address and the uplink routerĆs wireless SSID.
Figure 6-3
6.3 Connected Clients Information Display Page
Connected Clients information display page: It shows Connected Clients information.
Figure 6-4
Click on Settings >> Wireless. Turn off the status button of Smart Connect. Then you can configure
the router 2.4G or 5G WIFI SSID and password.Click on Settings >> Wireless. Turn off the status button
of Smart Connect. Then you can configure the router 2.4G or 5G WIFI SSID and password.
7.Function Configuration
7.1 WIFI Setting
Use this section to configure the wireless settings for your Router. Please note that
settings made in this section may also need to be synchronized on your Wireless Client.
Figure 7-1
7.1.1 WIFI 2.4G Setting and 5G Setting
Configure the router 2.4G or 5G WIFI SSID and password.
Figure 7-2
Complete 2.4G advanced configuration, such as channel, security mode, 802.11
mode.
Figure 7-3
Complete 5G advanced configuration, such as channel, security mode, 802.11
mode.
Figure 7-4
7.1.2 Smart Connect
After the smart connection is closed, the extender 2.4G WIFI and the 5G WIFI can
be searched on the terminal wireless device respectively, and there are two wireless bands
to be displayed on the page.
Figure 7-5
When Smart Connect feature is on, your wireless device can find one wireless SSID,
and it will automatically match the 2.4G or 5G band WIFI according to the connection
signal strength.
Figure 7-6
7.1.3 Guest Zone
This feature lets you enable and configure a Wi-Fi Guest Zone. It allows you to create
a separate network for your guests to secure the main network.
Figure 7-7
7.2 Internet Function Configuration
Use this section to configure your Internet Connection type. There are several connec-
tion types to choose: Static IP, DHCP and PPPoE. If you are unsure of your connection
method, please contact your Internet Service Provider.
Note: If using the PPPoE option, you will need to remove or disable any PPPoE client
software on your computers.
Figure 7-8
7.2.1 IPV4 Settings
Use this section to configure your Internet Connection type. There are several connec-
tion types to choose: Static IP, DHCP, PPPoE. If you are unsure of your connection
method, please contact your Internet service provider.
Note: If using the PPPoE option, you will need to remove or disable any PPPoE client
software on your computers.
Figure 7-9
7.2.2 IPV6 Settings
All of your IPv6 Internet and network connection details are displayed on this page.
Figure 7-10
7.2.3 Host Name
Set Internet connection type as dhcp.
Figure 7-11
Advanced settings.
Figure 7-12
Figure 7-13
Click on Advanced Setting, reset your Host Name (e.g. RAX1801), then click on Save.
7.3 Network Function Configuration
Use this section to configure the network settings for your devices. You can enter a
name for your device in the management link field and use the link to access web UI in a
web browser. Recommend changing the management link if there are more than one
device within the network.
Figure 7-14
7.3.1 Network Settings
Set LAN IP Address, Subnet Mask, Enable DNS Relay.
Figure 7-15
7.3.2 DHCP Server
Settings>>Network>>Advanced Settings>>DHCP Server
Set DHCP Server IP address range, lease duration.
Figure 7-16
Figure 7-17
7.3.3 Network Advanced Settings
Set LAN advanced settings, UPnP function.
7.4 ModeSet Configuration
Settings>>ModeSet
You can set it to be a router or a repeater mode.
Figure 7-18
Figure 7-19
Figure 7-20
Click the scan function after entering the page to scan the uplink router wireless.
Figure 7-21
Select the router 2.4G or 5G WIFI SSID and enter the signal extension password.
Figure 7-22
8.Features Setting
8.1 QOS
Click on Home >> Connected Clients.
Connected clients can be assigned Internet access priority. Create a new QOS rule in
connected clients list.
Figure 8-1
Figure 8-2
Figure 8-3
8.2 Firewall Settings
In this page, you can set the firewall status, remote management, WAN Ping, website
filter, IPv4 Rules and IPv6 Rules.
Figure 8-4
8.2.1 Website Filter
The website filter feature allows you to set rules that you can restrict access to a
specified web address (URL) or block specified keywords in the URL. You can use
Website Filter to restrict access to potentially harmful and inappropriate websites.
Figure 8-5
8.2.2 IPv4 Rules
The IPv4 rule section is an advanced feature used to deny or allow traffic from passing
through the device.
Figure 8-6
After the above setting, click on Features >> QoS Engine.
You can see the connected clients in the QoS rules list.
Create a new rule.
Open Firewall Status>>Save>>IPv4 Rules>> Add Rule
Figure 8-7
8.2.3 IPv6 Rules
The IPv6 will also be supported by your router's built-in firewall. Some applications
or clients may require special adjustments for better performance or extra protection.
Figure 8-8
Create a new rule.
Open Firewall Status>>Save>>IPv6 Rules>> Add Rule
Figure 8-9
8.2.4 Remote Management
HTTP Remote Management
Figure 8-10
Figure 8-11
8.2.5 WAN Ping
8.3 Port Mapping
Figure 8-12
8.3.1 Port Forwarding
Your router helps to share a single IP address assigned by your ISP among several
clients in your home. Port forwarding allows traffic requests from a specified application
to be directed to a specified client inside.
Figure 8-13
Create a new port forwarding rule.
Figure 8-14
8.3.2 DMZ
Your router's high-performance firewall feature continuously monitors Internet traffic,
protecting your network and connected devices from malicious Internet attacks.
Figure 8-15
Figure 8-16
8.3.3 Virtual Server
Your router helps to share a single IP address assigned by your Internet service
provider among several clients in your home. Virtual servers are preset port mappings for
popular services, like a web or e-mail server, that route traffic to a specified client inside.
Figure 8-17
reate a new virtual server rule.
Figure 8-18
Figure 8-19
8.4 DDNS
Dynamic Domain Name Service(DDNS) allows your router to associate an easy-to-re-
member domain name such as [YourDomainName].com with the regularly changing IP
address assigned by your Internet Service provider. This feature is helpful when running a
virtual server.
Figure 8-20
Figure 8-21
9. Management Page
9.1 Time and Schedule
9.1.1 Time
Your router's internal clock is used for data logging and schedules for features. The
date and time can be synchronized with a public time server on the Internet, or set
manually.
Figure 9-1
9.1.2 Schedule
Some features, such as the firewall and website filters, can be turned on or off based
on a schedule. One common use of schedules is to control access to the Internet by a
specified device during specified time periods.
Figure 9-2
Figure 9-3
9.1.3 Led Time
Your router's internal clock is used for data logging and schedules for features. The
date and time can be synchronized with a public time server on the Internet, or set
manually.
Figure 9-4
Figure 9-5
9.2 System Log
On-board diagnostics run continually in the background to monitor the health of your
router. The results are recorded in the system log if it is enabled. This info can be used to
diagnose common problems or help Customer Support resolve issues more quickly.
9.3 Admin Page Settings
To set the administrator password, you need to enter the original password for verifica-
tion; then enter a new administrator password and verify it again.
Figure 9-6
Figure 9-7
Figure 9-8
After modifying the administrator password, the browser will jump to the login page.
Enter the administrator password to login
9.4 System Page Setup
Figure 9-9
9.4.1 Save Settings to Local Hard Drive
Export the configuration file to the local PC for saving, so that you can quickly
restore the configuration information.
Figure 9-10
Figure 9-11
9.4.2 Load Settings from Local Hard Drive
Import the configuration file to the Router to quickly configure the router or restore
configuration information.
9.4.3 Restore to Factory Default Settings
Clear all router configuration and restore the router settings to factory default.
Figure 9-12
9.4.4 Reboot the Device
Reboot the Router.
Figure 9-13
Figure 9-14
9.5 Upgrade Page Settings
9.5.1 Firmware Information Display
Display current firmware version information.
Figure 9-15
