HEC24, HES24, HEH24 & HEH12 SERIES
HEC3-24, HEC3-12, HES3-24 & HES3-12 SERIES
ANSI/UL 1971 and/or ANSI/UL 464 COMPLIANT
WHEC24 & WHES24 SERIES
ANSI/UL 1638 and/or ANSI/UL 464 COMPLIANT
VISIBLE A D/OR AUDIBLE
SIG ALI G APPLIA CES
I. I TRODUCTIO
The ochiki America models EC24, ES24, E 24, E 12, EC3-24, ES3-24, EC3-12, ES3-12, W EC24, W ES24 are high quality audible and/or visible signaling appliances. The
high intensity strobe utilizes a Xenon flash tube that generates a high-intensity flash visible from all angles. This appliance is intended to provide a visible, audible or audible/visible, depending
on the model, notification signal for the purpose of life safety and property protection. The EC3-24, ES3-24, EC3-12, ES3-12 are provided with a slider switch which allows for candela
selection at the installation site; the candela intensities which can be selected are 15Cd, 30Cd, 60Cd, 75Cd, or 110Cd (24VDC only). The EC24 and ES24 are fixed candela units; the
candela intensities which can be ordered, are 177Cd and 15/75Cd. The W EC24 and W ES24 are fixed candela units, available in a 75 candela intensity only. This appliance is ideal for any
occupancy that requires notification appliances per the applicable building or fire code or wherever dependable alarms are required.
The EC24, ES24, EC3-24, ES3-24, EC3-12, ES3-12 strobe is listed in compliance with ANSI/UL 1971, Signaling Appliances for the earing Impaired (The 15/75Cd model on the
EC24 and ES24 is additionally listed in compliance with ANSI/UL1638). The W EC24 and W ES24 strobe is listed in compliance with ANSI/UL 1638, Visual Signaling Appliances - Private
Mode Emergency and General Signaling.
II. LOCATIO
This appliance is intended for use in Fire Alarm Systems and is to be installed in accordance with this manual, the recommendation of the local authorities having jurisdiction, and other NFPA
documents that provide standards on notification appliances for protective signaling systems. The EC24, ES24, E 24, E 12, EC3-24, ES3-24, EC3-12, ES3-12 are intended for
indoor installations only; this appliance is not listed for outdoor or drip proof applications. The W EC24 and W ES24 are intended for indoor or outdoor installations; this appliance is rated for
outdoor or drip proof applications when used in conjunction with the GOE Enclosure.
Wall mounted strobe and horn/strobe appliances shall have their entire lens at heights above the finished floor of not less than 80 in. (2m) and not greater than 96 in. (2.4m)**. Spacing shall be
in accordance with Table A. If a room configuration is not square, the room size that will entirely encompass the room or subdivide the room into multiple squares shall be used. Wall mounted
horn only appliances shall have their tops above the finished floors at heights of not less than 90 in. (2.30m) and below the finished ceilings at heights of not less than 6 in. (152mm). Different
mounting heights shall be permitted by the A J provided the sound pressure level requirements of NFPA 72 are met.
III. MOU TI G, ROUGH-I BOX A D RU WIRI G
This unit is designed for mounting to most single gang boxes, 4" square outlet boxes, 2-gang masonry boxes or non-metallic 2-gang switch boxes. Conduit entrance to boxes should be
selected to insure sufficient wiring clearance.
1. Run a minimum 18 gauge insulated 2 or more conductor cable.
2. Mount a box for each remote signaling appliance. Screw bracket onto box. Insert signal into bracket and slide to the right firmly into the terminal block receptacle. Place housing over
mounted assembly and screw together with single screw at the bottom of the signal. Cover screw with plastic tab.
NOTICE: WIRING S OULD BE CONNECTED TO MOUNTING BRACKET PRIOR TO MOUNTING SIGNAL. INCOMING POSITIVE POWER LEAD MUST BE BROKEN AND EAC LEAD IS
TO BE INSERTED INTO EAC OF T E TOP TWO TERMINALS. IF TWO POWER RUNS ARE MADE TO T E SIGNAL, ONE FOR T E STROBE AND ONE FOR T E ORN, ONLY ONE OF
T E RUNS MUST AVE ITS POSITIVE LEAD BROKEN AND PLACED UNDER T E TWO SEPARATE TOP TERMINALS. A BARRIER IS PROVIDED TO PREVENT BOT LEADS FROM
BEING PLACED UNDER T E SAME TERMINAL.
550-0534
Page 1
Strobe light can not be seen when objects such as doors,
furniture or walls block strobe light.
NOTICE:
T E VISUAL SIGNAL MUST BE IN T E DIRECT VIEWING AREA OF T E
OCCUPANT IN ORDER TO BE SEEN.
VISUAL SIGNALS FOR T E EARING IMPAIRED ARE ONLY ONE MET OD
OF ALERTING T E EARING IMPAIRED. VISUAL SIGNALS MAY NOT BE
T E PREFERRED MET OD FOR NOTIFYING ALL EARING IMPAIRED
INDIVIDUALS.
T E STROBE LIG T MUST BE SEEN BY T E SLEEPING PERSON. IF T E
PERSON AS EAD TURNED OR OT ERWISE UNABLE TO BE ALERTED
BY VISUAL, T E STROBE WILL NOT BE EFFECTIVE.
NA = Not allowable
Table A Room Spacing for Wall-Mounted Visible Appliances per NFPA 72, 2010 Edition
Maximum Room Size Minimum Required Light Output ( Effective Intensity, Cd)
Meters Feet One Light
per Room
Two Lights per
Room (Located on
Opposite Walls)
Four Lights per Room
(One Light per Wall)
6.10 x 6.10 20 x 20 15 NA NA
8.53 x 8.53 28 x 28 30 Unknown NA
9.14 x 9.14 30 x 30 34 15 NA
12.2 x 12.2 40 x 40 60 30 15
13.7 x 13.7 45 x 45 75 Unknown 19
15.2 x 15.2 50 x 50 94 60 30
16.5 x 16.5 54 x 54 110 Unknown 30
16.8 x 16.8 55 x 55 115 Unknown 28
18.3 x 18.3 60 x 60 135 95 30
19.2 x 19.2 63 x 63 150 Unknown 37
20.7 x 20.7 68 x 68 177 Unknown 43
21.3 x 21.3 70 x 70 184 95 60
24.4 x 24.4 80 x 80 240 135 60
27.4 x 27.4 90 x 90 304 185 95
30.5 x 30.5 100 x 100 375 240 95
33.5 x 33.5 110 x 110 455 240 135
36.6 x 36.6 120 x 120 540 305 135
39.6 x 39.6 130 x 130 635 375 185
