HODAY VS2201 User manual

VS2201 PLEASE READ THE MANUAL CAREFULLY BEFORE OPERATING
YOUR PRODUCT AND RETAIN IT FOR FUTURE USE

ACTIVATE YOUR 10-YEAR WARRANTY
Register within 2 weeks aer receiving your new product
Visit: www.ihoday.com/warranty
CUSTOMER SERVICE
[e-mail]
FOLLOW ME TO GET MORE INFORMATION
@hoday.co
OFFICIAL WEBSITE
https://ihoday.com
LIVE CHAT SERVICE
Scan QR Code to Start Livechat
m.me/ihoday
SCAN ME
or visit:
CONTENTS
FUNCTIONS ---------------------------------- 03
PRODUCT FEATURES ------------------------- 04
OPERATION MANUAL ------------------------- 05
TIPS ON BAG/ROLL CUTTER ------------------ 06
TROUBLESHOOTING ------------------------- 07
IMPORTANT SAFETY NOTICE&TIPS ---- - ----- 08
HELPFUL HINTS ------------------------------ 09
CLEANING AND MAINTENANCE --------------
STORAGE GUIDE ----------------------------- 11
PACKAGE CONTENTS ------------------------ 12
10
TECHNICAL SPECIFICATION ----------------- 13
USER-GUIDE WARRANTY
- 01 - - 02-

③ VAC& SEAL BUTTON
② SEAL BUTTON
④ STOP BUTTON
① DRY/ MOIST FOOD SETTING BUTTON
INDICATOR LIGHTS
⑤
It will take longer time to seal moist food than dry food.
The indicator light will be illuminated when the corresponding function selected.
Close the cover, press it to vacuum the bag and seal it. (Wait for 60s between
uses to allow appliance to cool down)
During any working status, press STOP button to stop current processing immediately.
The indicator light will be illuminated when VAC/VAC SEAL/SEAL/VAC &
PULSE working.
VAC & PULSE BUTTON
⑥
This button has two uses:
1. Press to vacuum canister/wine stopper with accessory hose.
2. Press and hold it to manually control the vacuum process and then press the
Seal button to seal the bag after vacuuming.
Close the cover, press the SEAL button if you only want to seal the bag. (Wait
for 60s between seals to allow appliance to cool down)
If several lights flasing at the same time after continuous working, overheating protection
activated. Please wait for 5-10 minutes for cooling down and the appliance will be back
in normal mode.
Note:
①DRY/ MOIST FOOD SETTING BUTTON
⑤INDICATOR LIGHTS
⑥VAC & PULSE BUTTON
②SEAL BUTTON ③VAC & SEAL BUTTON
①SILICONE CONTACT BAR
②SEALING FOAM GASKET
③VACUUM NOZZLE
④VACUUM CHAMBER
⑤SEALING STRIP
⑥BUILT-IN CUTTER
⑦TRANSPARENT WINDOW
③ VACUUM NOZZLE
② SEALING FOAM GASKET
④ VACUUM CHAMBER
① SILICONE CONTACT BAR
SEALING STRIP
⑤
Work with silicone sealing gasket to make optimal sealing.
An airtight chamber for vacuuming.
Work with silicone contact bar for sealing function.
⑦
BUILT-IN CUTTER
Close the upper lid cover, pull out the desired bag length, hold the bag with one
hand, and slide the bag cutter across the roll to obtain the desired bag length.
Vacuum view window - Allows the user to see the correct position of the bag in
the vacuum Chamber.
TRANSPARENT WINDOW
⑥
Objective to ensure vacuum chamber is airtight so the bag can be vacuumed properly.
This is used for removing air from bags / canisters / bottles.
Do not block the vacuum nozzle when vacuuming a bag.Accessory hose is
required when vacuuming a canister or bottle.
FUNCTIONS — VS2201 PRODUCT FEATURES — VS2201
④STOP BUTTON
- 03 - - 04 -

OPERATION MANUAL — VS2201 TIPS ON BAG/ROLL CUTTER
TIPS FOR VACUUM BOTTLESTOPPERS/CANISTER
1. Enter the food into the bag, place the opening of the bag on the sealing bar.
Pay attention not to cover the suction air opening.
1
2. Close the lid and press on both end of the lid. You will hear a “clicking” sound
with both release buttons pop up if the lid is properly locked.
3. a. Press VAC SEAL if you want to vacuum & seal the bag.
b. Press SEAL button if you want to seal the bag only.
c. Press VAC / PULSE to vacuum canister/wine stopper with accessory hose.
d. Press and hold VAC/PULSE to manually control the vacuum process and
then press the SEAL button to seal the bag.
4. When SEAL indicator Light turns off, process completed. Press release buttons
at both ends to open the lid and remove the sealed bag.
Close the upper lid cover, pull out the desired bag length, hold the
bag with one hand, and slide the bag cutter across the roll to obtain
the desired bag length.
It can be connected to the vacuum preservation tank, vacuum zipper
bag, and wine stopper via the vacuum tube to keep the food or wine
in the canisters fresh.
3
4
2
- 05 - - 06 -

TROUBLESHOOTING IMPORTANT SAFETY NOTICE&TIPS
④ Air is removed from the bag, but now re-entered.
③ Appliance is plugged in, but cannot vacuum.
① Overheating
② Nothing happens when the power cord is plugged into appliance.
A. Make sure the power cord is not damaged.
B. Make sure the power cord is correctly plugged into the electrical outlet and
appliance.
A. Check if there is a hole or puncture on the bag. It may be punctured by sharp
items. Use a new bag if necessary.
B. Check the sealing seam. Any wrinkle along the sealing seam may cause
air re-entering. If yes, simply cut the sealed edge and re-seal.
C. If there is moisture or liquid at the opening end, cut the bag and wipe it away.
Then choose MOIST FOOD setting and reseal.
D. If the food has been stored for a long time and the bag is full of gases, it may
spoil and suggest to discard.
A. This HODAY vacuum sealer is household use only. 60s cool time is necessary
before next sealing to prevent the overheat of the sealer when continuous work.
B. If the bag melts, the sealing strip maybe overheated, 60s cool time is necessary
before next sealing.
C. Overheating protection is activated when several lights flasing at the same
time after continuous work. Please wait for 5-10 minutes for cooling down
and the appliance will be back in normal mode.
A. Ensure the lid is properly closed.
B. Ensure the opening end of the bag is correctly placed into the vacuum
chamber.
C. Check if the bag is punctured.
D. Check if the foam sealing gasket is deformed or damaged.
Please read the user manual carefully before using and follow the safety
instructions.
1. Check if the Voltage indicated on the appliance is corresponding to the local mains
voltage before you connect the appliance.
2. Do not operate the appliance with a damaged power cord or plug. Do not operate the
appliance if it malfunctions or is in any way damaged. If the cord or the appliance is
damaged, it must be returned to an authorized service center for repairing.
3. To disconnect, unplug the power cord from the electrical outlet. Do not disconnect
by pulling on cord.
4. Do not use an extension cord with the appliance.
5. If the supply cord is damaged, contact the manufacturer, or its service agent or
similarly qualified person to buy it in order to avoid a hazard.
6. When it is not in use or to be cleaned, unplug cord from the power outlet.
7. Do not use the appliance on wet or hot surfaces, or near heat source.
8. Do not immerse any part of the appliance, power cord or plug in water or other liquids.
9. A short power cord is provided to reduce the risks of becoming entangled in a long
cord or tripping over.
10. Use accessories or attachments recommended by the manufacturer only.
11. Use the appliance for its intended use only. Household use only.
12. Closely supervise children when using any electrical appliance. Do not allow the
appliance to be used as a toy.
13. CAUTION: HOT SURFACE. DO NOT TOUCH.
14. Wait for 60 seconds before using it again.
15. To reduce the risk of electric shock, this product has a polarized plug (one blade
is wider than the other). This plug is intended to fit in a polarized outlet only one
way. If the plug does not fit fully in the outlet at the beginning, reserve the plug.
If it still does not fit, contact a qualified electrician to install the proper outlet.
Do not change the plug in any way.
- 07 - - 08 -

HELPFUL HINTS
1. Place the bag correctly, put the bag’s opening edge into the vacuum chamber.
2. If the wet food is sprinkled with soup or water in the vacuum chamber or on the
vacuum foam gasket, please wipe it clean with a towel or paper in time to avoid
any soup or water entering the machine causes any damage.
3. Keep the lip open when not in use to prevent sealing foam gasket from loosening
as prolonged squeezing.
4. Do not overfill the bag. Always leave at least 6-8cm between bag contents and
top of the bag.
5. Make sure the bag is dry. It will be difficult to make a tight seal if the bag is wet.
6. For best results, perishables still need to be frozen or refrigerated after vacuum
sealing process.
7. Clean the opening end of the bag inside and outside. Flattern the bag opening.
8. When vacuum packaging a large item, to prevent wrinkles in the seal, gently stretch
bag flat before placing it into the vacuum chamber.
9. When you are vacuum sealing items with sharp edges (such as dry spaghetti,
silverware, etc.), protect the bag from punctures by wrapping the item in soft
cushioning material, such as a paper towel. You may use a canister instead of
a bag.
10. When using canisters, always leave 2.5 cm / 1 in of space at the top of canister.
11. Allow the appliance to cool for 1 minute between uses to avoid activating
overheating protection.
12. If you are not sure whether your bag was sealed properly, simply reseal the bag.
13. For best results, use bags and canisters produced by the manufacturer.
14. Microwave: Don’t heat sealed food in microwave.
NTC Thermistor-temperature sensor:
Smartly monitor the temperature of the appliance. Protection mode will
be activated automatically when overheat , with lights flash and operation
unavailable. The appliance is back to normal working once cooled and the
lights stop flashing.
CLEANING AND MAINTENANCE
①
Unplug the appliance before cleaning.
Wipe the outer surface with a soft soapy cloth.
Wipe away any food or liquid on the vacuum chamber with paper towel.
Dry the appliance thoroughly before using it again.
Do not immerse the appliance in water or other liquids. Prevent water or
other liquids from entering the AC power port on the appliance.
Do not clean the appliance with abrasive cleaning agent to avoid damaging
the surface.
②
③
④
⑤
⑥
- 09 - - 10-

PACKAGE CONTENTS
NO. Description QtyImage
Vacuum Sealer
Power Cord
AccessoryHose 1
2
Roll
1
1
1
2
3
4
STORAGE GUIDE
Room Temperature (25±2℃)
Bread
Rice/ Flour
Tea Leaves
3-6 Months
1-2 Days
3-5 Months
5-6 Months
＞1 year
6-8 Days
＞1 year
＞1 year
Storage Life with Our
Vacuum Sealing Accessory
In the Freezer (-16~-20℃)
Meats
Seafood and Fish
3-5 Months
3-5 Months
1 Year
1 Year
Storage Life with Our
Vacuum Sealing Accessory
Cooked Meats
In the Refrigerator (5±2℃)
Meats
Seafood and Fish
Vegetables
Eggs
4-6 Days
Normal Storage Life
Normal Storage Life
Normal Storage Life
2-3 Days
1-3 Days
3-5 Days
10-15 Days
10-14 Days
8-9 Days
4-5 Days
7-10 Days
30-50 Days
Storage Life with Our
Vacuum Sealing Accessory
Peanuts/ Beans
- 11 - - 12 -

Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact
your local government for information regarding the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
TECHNICAL SPECIFICATION


-60kPa -80kPa
Description Specification
Item Number VS2201
Rated Voltage �AC100-120V �AC220-240V
Rated Frequency 50Hz - 60Hz
Rated Power
110W
Sealing time 6-12 seconds
Vacuum Level
Dimensions 372*144*72MM (L*W*H)
Net weight 1.20 kg
Gross weight 1.55 kg
- 13 -
