Hohem iSteadyMobile+ User manual

Scan the QR code to
access the tutorial
3-Axis Smartphone Gimbal
User Manual V1.0

01 Product List  01
02 Introduction  02
03 Battery and Charging  03
04 Download the Hohem Joy App 04
05 First Use  05
Horizontal Mode  05
Vertical Mode 06
Ultra-Wide-Angle Shot  08
06 Magnetic Fill Light  08
07 Buttons and Gimbal Modes  09
Buttons and Indicators  09
Gimbal Modes  11
08 Hohem Joy App 12
Bluetooth Connection  12
App Features 12
09 Auto Calibration and Firmware Update  13
Calibration Reasons and How to Calibrate  13
Firmware Update 14
10 FAQs  14
11 Product Speci󽘀cation 16
12 Warning & Disclaimer 17
13 Warranty Terms 18
14 Warranty Card  18
15
Product Hazardous Substances Content Table  19
Contents

01 Product List
Before using this product, please carefully check that all the following items
are included in the product package. In case that any item is found missing,
please contact Hohem customer service or the local distributor.
iSteady Mobile+
Magnetic Fill Light
*Item included only in the kit
Tripod Storage Bag
Type C Charging Cable Warranty Card
Quick Start Guide
01

02
02 Introduction
④
⑤
⑥
⑭
⑮
⑯
⑰
⑱
③②
①
⑧⑪
⑨⑫
⑩
⑬
⑦
① Magnetic Fill Light *Item included only
in the kit
② Magnetic Contact
③ Roll Motor
④ Pan Motor
⑤ 1/4 Inch Extension Screw Hole
⑥ Handle (Battery inside)
⑦ 1/4 Inch Extension Screw Hole
⑧ Mode Indicator
⑨ Zoom/Focus Slider
⑩ Bluetooth Indicator
⑪ Joystick
⑫ Mode Button
⑬ ON/OFF (Shutter button)
⑭ Tilt Motor
⑮ Balancing Knob
⑯ Rotatable Phone Holder
⑰ Trigger
⑱ USB Output
⑲ Type-C Input
⑲

03
03 Battery and Charging
Before use, please ensure that iSteady Mobile+ has su󽘂cient battery power.
Charging Method: To charge the iSteady Mobile+, connect a USB adapter (not
included choose a 5V-2A adapter for better results) into the charging port
with the provided USB-C charging cable.
Battery Display: Tap the power button
to check the battery status.
Flickering: Charging
4 LED lights on: 100%, fully charged
3 LED lights on: 75%
2 LED lights on: 50%
1 LED light on: 25%
Reverse Charging (DC out charging for smartphones)
Android: Charging with the provided USB-C to USB-C cable.
iOS: Charging with USB-C to Lightning cable (Not Included).

04
04 Download the Hohem Joy App
Download on the
Get it on
Scan the QR code or search "Hohem Joy" in App Store or Google Play to
download.
* The app Hohem Joy requires iOS 11.0 or later, Android 6.0 or later.
○ Items marked "*" are optional accessories which are sold
separately.
○ Mount your mobile phone before powering on the
iSteady Mobile+.
○ If no mobile phone is detected or the motor is overloaded
because the phone is not balanced well, the gimbal will
shut down after a warning beeping.
Power Button
Tips：
When the gimbal is powered o󽗿, press the power button once to start reverse
charging your smartphone.

05
05 First Use
*Smartphone screens with 6.7 inches and above, such as
iPhone 15 Pro Max, should be mounted almost at level with the
ground.
*If your phone case is bulky, it's recommended to remove it
before installation.
Horizontal Mode
❶ Pull the phone clamp and
mount the phone.
❷ Push the phone to the right
most to close to the motor.
Left
Right
Small phone
e.g. iPhone 15(6.1 inches)
Large phone
e.g. iPhone 15 Pro Max
(6.7 inches)
❸ Loosen the knob, and slide the arm to balance the gimbal.

06
❹ Tighten the knob. ❺ Long press the power button
to power on.
Vertical Mode
*Do not rotate the phone clamp while the gimbal is powered on.
Left most
❶ Loosen the knob, slide the
arm to the leftmost and tighten
the knob.
❷ Rotate the phone clamp 90
degrees

07
❸ Pull the phone clamp and
mount the phone. Adjust the
phone up or down to roughly
balance the gimbal.
❹ Make the phone roughly
balance, and long press the
power button to power on.
Quick Switch to Portrait Mode
*After you
switch to the
portrait mode,
the joystick
only control
the phone to
rotate left and
right.
The following do not support quick switch:
1. In POV mode
2. When the handle is perpendicular
3. When the app setting of left/right joystick is roll
Scan the QR code to watch the tutorials.

08
Ultra-Wide-Angle Shot
① Ultra-Wide-Angle Shot, switch to this mode by pressing the trigger four
times and the roll motor will be in front of the phone screen for capturing
unobstructed views.
② Default Mode, no obstruction in front of the phone screen.
*Ultra-Wide-Angle Shot is only supported to switch while shooting
horizontally.
❶❷
Magnetic Attachment
Position the 󽘀ll light near the magnetic contact ("hohem" logo upward). The
magnet on the 󽘀ll light will automatically attract and attach to the gimbal.
Magnetic Installation
06 Magnetic Fill Light *Item included only in the kit

09
07 Buttons and Gimbal Modes
Buttons and Indicators
❶
❷
❸
❹
❺
❻❼
Operation
Cold Light / Warm Light / Natural White Light (10-Level Adjustable Brightness)
❹
❸
❷
❺
❶
❶ M Button (Turn on/o󽗿 󽘀ll light)
Press and hold for 3s: Turn on/o󽗿
the 󽘀ll light
Press once: Cold/warm/natural the
white light switch
❷ Plus "+" Button
Single press to increase brightness
in ten levels
❸ Minus "-" Button
Single press to decrease brightness
in ten levels
❹ Fill Light Indicator
("C" is short for cold; "W" is short for
warm.)
C indicator lighting alone: Cold
light in use
W indicator lighting alone: Warm
light in use
C&W indicators both lighting:
Natural white light in use
❺ Power Indicator
Flashing red: Charging
Solid red: Fully Charged

10
❶ Joystick
Push Up/Down: Tilt Control Push Left/Right: Pan Control
❷ Mode Indicator
PF: Pan Follow L: AII Locked
PTF: Pan & Tilt Follow POV: All Follow & Inception
❸ Zoom Slider
(Available in the Hohem Joy / Android 10.0 or later, please ensure the
Bluetooth pairing.)
Push up: Zoom in Push down: Zoom out
❹ Bluetooth Indicator
Soild green: Gimbal is connected with phone
Bluetooth
Soild red: Gimbal abnormality
Flashing red: a.Low battery (auto shutdown)
b.Overload (beep warning)
Blinks yellow and green alternately: Remote*
Pairing
Blinks yellow: Remote control under operation
*Remote control
is non standard
purchase. For remote
control pairing and
instructions please
see the user manual
of remote control or
FAQs.
❺ Mode Button
Single press: Switch between gimbal modes
Triple press: 600° Auto inception (press mode button to stop the rotation)
Press 󽘀ve times: Auto calibration
❻ Power Button/ Shutter Button
Press and hold: Power on/o󽗿
Single press: Take a photo and start/end video(Please ensure Bluetooth is
connected.)
Double press: Switch photo/video modes(Only available in the Hohem Joy /
Android 10.0 or later, please ensure the Bluetooth pairing.)
Triple press: Switch front/rear cameras(Only available in the Hohem Joy /
Android 10.0 or later, please ensure the Bluetooth pairing.)
❼ Trigger Button
Press on: Sport mode
Press once, and then press and hold：L（All locked）
Double press: Recenter the gimbal
Press 4 times: Switch to Ultra-Wide-Angle Shot

11
Gimbal Modes
Tap the button to
switch di󽗿erent
working modes
with light on.
Scan the QR code to
watch the tutorials.
PF (Pan Follow)
Default mode, tilt & roll axis both locked,
camera is able to move to left or right
smoothly.
PTF (Pan & Tilt Follow)
Roll axis locked, camera is able to
move to left/right, and tilt up/down.
L (All Locked)
The camera stays in its current orientation.
POV (AlI Follow & Inception)
All Follow - Tilt axis, roll axis and pan axis all
follow the movement of the gimbal.
Inception - Hold the gimbal horizontally and
push joystick to left or right.

12
08 Hohem Joy App
Bluetooth Connection
1. Power on iSteady Mobile+
2. Turn on Bluetooth on the Mobile Phone
3. Launch the app Hohem Joy and follow the prompts to connect to iSteady
Mobile+.
App Features
3
4
5 6 7
1
2
8910
11
1. Exposure Settings
2. Resolution/Frame Rate
3. Smart Tracking
4. Parameter Setting
5. Home
6. Focus/Zoom
7. Flash
8. Beauty & Filters
9. Gesture Control
10. Front/Rear
11. Moment Templates
* For more details on the
"Hohem Joy" app features,
please visit the o󽘂cial website
of Hohem (www.hohem.com)
and watch iSteady Mobile+ video
tutorials. Scan the QR code to
watch the tutorials.

13
09 Auto Calibration and Firmware Update
Calibration Reasons and How to Calibrate
Auto calibration could reduce drift or slight deviation caused by nearby
magnetic interference or human error.
❶ Place gimbal on a 󽘁at surface
using a tripod.
❷ Double press the trigger button
to recenter the gimbal.
5
❸ Press mode button 󽘀ve times to
start the auto calibration. Please
do not touch the gimbal during
calibration.
❹ Two beeps indicate that the
calibration is completed, the gimbal
will recenter and automatically
return to normal operation.
*If the gimbal is not placed on a 󽘁at surface for calibration (e.g.
hand-held calibration in the car), it may cause calibration failure.
*When the calibration fails, the gimbal will make a beep sound,
all 4 mode lights 󽘁ash and enter the sleep mode. Single press any
button (except the joystick) to wake up the gimbal and follow the
above steps to try again.

14
Firmware Update
You will be prompted in the app Hohem Joy if a new 󽘀rmware update is
available. Follow the on-screen instructions in the app to update the 󽘀rmware.
10 FAQs
① Why does the gimbal automatically power o󽗿?
The gimbal will automatically power o󽗿 if no phone is installed or the phone
is not properly balanced (causing motor overload). You will hear a "beep"
sound as a warning before it shuts down. Make sure to install and balance the
phone correctly before turning on the gimbal (see the First Use section for
details).
② How can I connect my phone's Bluetooth to the
gimbal while the app can't 󽘀nd the device?
Clear the Bluetooth connection and try reconnecting:
Push the zoom lever upwards and simultaneously long-press the M button
for 5s. When the Bluetooth indicator 󽘁ashes green 󽘀ve times, it means the
Bluetooth connection has been cleared. You can then follow the Bluetooth
connection steps to connect again.

15
③ How do I connect the remote controller?
*The remote controller is an optional accessory and needs to be purchased
separately.
Switch the remote to "OFF". Press the M button seven times to enter the
remote controller pairing mode (at this point, the Bluetooth indicator will
alternate between yellow and green). Switch the remote to "ON," and it will
automatically connect to the gimbal. When you press buttons on the remote
controller, and the gimbal's Bluetooth indicator 󽘁ashes yellow, it indicates a
successful pairing.
7
Exit the remote controller pairing: Press the mode button once.
Clear the remote controller pairing: Double-press the M button while in the
remote controller pairing.

16
Weight 474g include battery
Folded Size 294*120*47mm
Main Material High performance composite
Payload 280g
Mobile Width
Supported 58mm~89mm
Power Rating 1.0W
Battery Capacity 18650li-ion 7.4V/1800mAh/13.32Wh
Battery Life Up to 13 hours (Under ideal conditions with the
gimbal fully balanced）
Charging Time 2 hours (5V 2A)
Mechanical Range Panning：600° Rolling：320° Tilting：320°
Working
Temperature -10~45° C
Motors Protection Gimbal will be powered o󽗿 automatically due to
improper operation of motors
Gimbal
Weight 16g
Battery Capacity 3.7V / 300mAh
Power Rating 1W
Battery Life 1 Hour
Lights
Cold Light (6500k)
Warm Light (3000k)
Natural White Light (5500k)
Fill Light *Item included only in the kit
11 Product Speci󽘀cation

17
Thank you for purchasing Hohem iSteady Mobile+. By using this product,
you hereby signify that you have read this disclaimer and warning carefully.
In addition, you understand and agree to abide by the terms and conditions
herein. You acknowledge that you are solely responsible for your own
conduct while interacting with this product, and for any consequences
thereof. You agree to use this product only for purposes that are proper and
in accordance with all applicable laws, rules, and regulations, and all terms,
precautions, practices, policies and guidelines Hohem has made and may
make available. Hohem accepts no liability for damage, injury, or any legal
responsibility incurred directly or indirectly from the use of this product. The
user shall observe safe and lawful practices including, but not limited to,
those set forth in this document.
This document and all other collateral documents are subject to change at
the sole discretion of Hohem. For up-to-date product information, visit www.
hohem.com and click on the product page for this product.
12 Warning & Disclaimer
Email: [email protected]
Website: www.hohem.com
Manufacturer: Hohem Technology Co., Ltd
Hohem Technology Co., Ltd
Connect us at Facebook
CALL CENTER -Toll Free
UNITED STATES: [phone] Mon-Fri: 9:00AM-5:00PM(EST)
UNITED KINGDOM: [phone] Mon-Fri: 2:00PM-10:00PM(GMT +0)
CANADA: [phone] Mon-Fri: 9:00AM-5:00PM(EST)
BRAZIL: [phone] Mon-Fri: 10:00AM-6:00PM(GMT -3)

18
13 Warranty Terms
14 Warranty Card
① Customers are entitled to replacement service in case of quality de󽘀cits
or functional disorders found in the product within seven (7) calendar
days of receiving a product. But ensure the commodity and package with
no damage, and we will o󽗿er a brand new replacement after con󽘀rming
the product's problem is not related to arti󽘀cial damage.
② The warranty service is subject to normal use.
③ The valid warranty period is 12 months counting from the date of selling
under normal use. Accessories are excluded from the warranty service.
④ This warranty service DOES NOT cover accidental or arti󽘀cial damages
(including but not limited to) caused by unauthorized modi󽘀cation,
disassembly, incorrect use and operation.
⑤ Please keep and o󽗿er the warranty card for claiming the warranty service.
User Name：
Contact No.：
Address：
Purchase Date：
Prod. Serial No.：
Failure Cause：
Service Record：
