Holland Green Science Hephaestus V900 User manual

User Manual
Version 1.0 1
10310003
Hephaestus V900
Vacuum Oven
User Manual

User Manual
Version 1.0 2
Table of Contents
I. Disclaimer & Warranty .................................................................................................. 3
II. Safety ............................................................................................................................. 7
III. Vacuum Oven –Introduction........................................................................................ 9
IV. Technical Specifications..............................................................................................12
V. Standards and Conformity...........................................................................................13
VI. Inspection.....................................................................................................................14
VII. Operating Instructions.................................................................................................15
VIII. Fault Diagnosis.............................................................................................................21
IX. Maintenance and Cleaning ..........................................................................................23

User Manual
Version 1.0 3
I. Disclaimer & Warranty
•The intellectual property rights for this manual belongs to Holland Green Science
Corporation (hereinafter referred to as “the Company”).
•Products of the company are under the patent protection of China and other
countries and regions (inclusive of obtained patents and patents currently under
application).
•The company reserves the right to change product specifications without notice.
•The contents of the manual are subject to change without notice.
LIMITED WARRANTY & DISCLAIMER
Products sold by the Company are intended solely for the use(s) specified by the manufacturer
and are not to be used for any other purposes including, but not limited to, unauthorized
commercial purposes. Buyer warrants and represents that Buyer will properly test, use, qualify,
and/or validate each Product for intended use, and, to the extent authorized, manufacture and
market any final articles made from the Company’s Products in accordance with the practices of
a reasonable person who is an expert in the field, and in strict compliance with all applicable
national, state and local laws and regulations. Buyer acknowledges and understands that the
purchase of Products only conveys to Buyer the non-transferable right for only the Buyer to use
the Products purchased in compliance with the applicable manufacturer's Published User
Statement, Limited User Statement, or Limited License, if any. While this manual contains certain
representations of the potential dangers from the instrument or equipment, Buyer is solely
responsible for conducting any research necessary to learn the hazards involved for any of its
intended uses of the instrument or equipment purchased from the Company and to properly warn
its customers, employees and other personnel who may be exposed to such instrument or
equipment of any risks involved in using or handling the instrument or equipment.
The Company warrants that this product will operate or perform substantially in conformance with
the Company’s published specifications and be free from defects in material and workmanship,
when subjected to normal, proper and intended storage and usage by properly trained personnel,
for the duration of the manufacturer’s warranty period set forth in this product documentation,
published specifications or package inserts. If a manufacturer’s warranty period is not specified
in the product documentation, published specifications or package inserts, the warranty period
shall be one (1) year from the date of Bill of Sale to Buyer for equipment, and the earlier of any
stated expiration dates or ninety (90) days for all other products (the "Warranty Period"). The
Company agrees during the Warranty Period, to repair or replace, at the Company’s option,
defective Products so as to cause the same to operate in substantial conformance with said
published specifications; provided that Buyer shall (a) promptly notify the Company in writingupon
the discovery of any defect, which notice shall include the product model and serial number (if
applicable) and details of the warranty claim; and (b) after the Company's review, the Company

User Manual
Version 1.0 4
will provide Buyer with service data and/or a Return Material Authorization ("RMA"), which may
include biohazard decontamination procedures and other product-specific handling instructions,
then, if applicable, Buyer may return the defective Products to the Company with all costs prepaid
by Buyer. Replacement parts may be new or refurbished, at the election of the Company. All
replaced parts shall become the property of the Company. Shipment to Buyer of repaired or
replacement Products shall be made in accordance with the Delivery provisions of the Terms &
Conditions agreed to by the purchase of this product. Consumables are expressly excluded from
this warranty.
Notwithstanding the foregoing, Products supplied by the Company but not manufactured by the
Company are not warranted by the Company, and the Company disclaims all warranties
associated with the accuracy of any original manufacturer or third-party supplier Product
information, but the Company agrees to assign to Buyer any warranty rights in such Product that
the Company may have from the original manufacturer or third-party supplier, to the extent such
assignment is allowed by such original manufacturer or third-party supplier.
In no event shall the Company have any obligation to make repairs, replacements or corrections
required, in whole or in part, as the result of (i) normal wear and tear, (ii) accident, disaster or
event of force majeure, (iii) misuse, fault or negligence of or by Buyer, (iv) use of the Product in a
manner for which they were not designed, (v) causes external to the Product such as, but not
limited to, power failure or electrical power surges, (vi) improper storage and handling of the
Product or (vii) use of the Product in combination with equipment or software not supplied by the
Company. If the Company determines that Product for which Buyer has requested warranty
services are not covered by the warranty hereunder, Buyer shall pay or reimburse the Company
for all costs of investigating and responding to such request at the Company's then prevailing time
and materials rates. If the Company provides repair services or replacement parts that are not
covered by this warranty, Buyer shall pay the Company therefor at the Company's then prevailing
time and materials rates.
ANY INSTALLATION, MAINTENANCE, REPAIR, SERVICE, RELOCATION OR ALTERATION
TO OR OF, OR OTHER TAMPERING WITH, THE PRODUCT PERFORMED BY ANY PERSON
OR ENTITY OTHER THAN THE COMPANY WITHOUT THE COMPANY'S PRIOR WRITTEN
APPROVAL, OR ANY USE OF REPLACEMENT PARTS NOT SUPPLIED BY THE COMPANY,
SHALL IMMEDIATELY VOID AND CANCEL ALL WARRANTIES WITH RESPECT TO THE
PRODUCT.
THE OBLIGATIONS CREATED BY THIS WARRANTY STATEMENT TO REPAIR OR REPLACE
A DEFECTIVE PRODUCT SHALL BE THE SOLE REMEDY OF BUYER IN THE EVENT OF A
DEFECTIVE PRODUCT. EXCEPT AS EXPRESSLY PROVIDED IN THIS WARRANTY
STATEMENT, THE COMPANY DISCLAIMS ALL OTHER WARRANTIES, WHETHER EXPRESS

User Manual
Version 1.0 5
OR IMPLIED, ORAL OR WRITTEN, WITH RESPECT TO THE PRODUCTS, INCLUDING
WITHOUT LIMITATION ALL IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE OR USE. THE COMPANY DOES NOT WARRANT THAT
THE PRODUCTS ARE ERROR-FREE OR WILL ACCOMPLISH ANY PARTICULAR RESULT.
NOTHING IN THIS MANUAL OR IN THE TERMS AND AGREEMENT AGREED TO AT THE
TIME OF PURCHASE SHALL BE CONSTRUED TO PROVIDE FOR THE TRANSFER,
ASSIGNMENT OR ALIENATION OF THE LIMITED WARRANTIES PROVIDED BY THE
COMPANY HEREIN TO ANY OTHER PARTY OTHER THAN BUYER, INCLUDING BUT NOT
LIMITED TO, SUCCESSORS, HEIRS, SUBSIDIARIES OR ANY OTHER THIRD PERSON.
THE WARRANTIES IDENTIFIED ABOVE ARE THE SOLE AND EXCLUSIVE WARRANTIES
WITH RESPECT TO THIS PRODUCT AND ARE IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED. ALL OTHER WARRANTIES ARE EXPRESSLY DISCLAIMED,
INCLUDING,WITHOUTLIMITATION, THOSEOF NON-INFRINGEMENT,MERCHANTABILITY,
OR FITNESS FOR A SPECIFIC PURPOSE OR USE (WHETHER ARISING FROM STATUTE,
OR OTHERWISE IN LAW, OR FROM A COURSE OF DEALING, OR USAGE OF TRADE). THIS
WARRANTY IS NOT TRANSFERABLE FROM THE ORIGINAL PURCHASER TO A
SUBSEQUENT OWNER. FURTHER, THE COMPANY IS NOT LIABLE IN CASES OF
DELIBERATE, NEGLIGENT OR ACCIDENTAL MISUSE OF THE PRODUCTS, USE WITH
INAPPROPRIATE REAGENTS OR CONSUMABLES, DAMAGE CAUSED BY DISASTER,
REPAIR OR MODIFICATIONS DONE BY ANYONE OTHER THAN THE COMPANY. THE
COMPANY DOES NOT WARRANT THAT THE PRODUCT WILL NOT INFRINGE THE
INTELLECTUAL PROPERTY RIGHTS OF A THIRD PARTY EITHER ALONE OR IN
COMBINATION WITH OTHER PRODUCTS OR IN THE OPERATION OF ANY PROCESS. THE
COMPANY’S TOTAL LIABILITY FOR BREACH OF THESE WARRANTIES SHALL BE LIMITED
TO THE GROSS PURCHASE PRICE FOR THE PRODUCT AS STATED IN THE RELEVANT
INVOICE OR ORDER UNDER WHICH THE ACTIVITY GIVING RISE TO LIABILITY ARISES.
UNDER NO CIRCUMSTANCES SHALL THE COMPANY BE LIABLE FOR INDIRECT,
INCIDENTAL, CONSEQUENTIAL, SPECIAL OR PUNITIVE DAMAGES (INCLUDING LOSS OF
BUSINESS OR PROFITS) UNDER ANY THEORY OF LIABILITY HEREUNDER.
For claims under the warranty please contact your local supplier. You may also send the
instrument directly to manufacturer, enclosing the invoice copy and by giving reasons for the
claim.
LIMITATION OF LIABILITY
NOTWITHSTANDING ANYTHING TO THE CONTRARY CONTAINED HEREIN, THE LIABILITY
OF THE COMPANY UNDER THESE TERMS AND CONDITIONS (WHETHER BY REASON OF
BREACH OF CONTRACT, TORT, INDEMNIFICATION, OR OTHERWISE, BUT EXCLUDING
LIABILITY OF THE COMPANY FOR BREACH OF WARRANTY (THE SOLE REMEDY FOR

User Manual
Version 1.0 6
WHICH SHALL BE AS PROVIDED UNDER THIS SECTION) SHALL NOT EXCEED AN
AMOUNT EQUAL TO THE LESSER OF (A) THE TOTAL PURCHASE PRICE THERETOFORE
PAID BY BUYER TO THE COMPANY WITH RESPECT TO THE PRODUCT(S) GIVING RISE
TO SUCH LIABILITYOR (B) ONE HUNDRED THOUSAND DOLLARS ($100,000), WHICHEVER
IS LESS.
With respect to any software products incorporated in or forming a part of the Product hereunder
Buyer intends and agrees that such software products are being licensed and not sold, and that
the words "purchase", "sell" or similar or derivative words are understood and agreed to mean
"license", and that the word "Buyer" or similar or derivative words are understood and agreed to
mean "licensee". Notwithstanding anything to the contrary contained herein, The COMPANY or
its licensor, as the case may be, retains all rights and interest in software products provided
hereunder. See the Terms & Conditions of purchase for details regarding such license.

User Manual
Version 1.0 7
II. Safety
IMPORTANT Safety Items to be Observed.
Safety Warnings
! DANGER (may cause serious damage to property and or casualties)
1. The vacuum oven must be grounded reliably and away from any electromagnetic
interference sources (cannot be grounded or neutral).
2. Please confirm that the voltage and frequency of your power supply matches the
specified voltage and frequency advised prior to use.
3. This vacuum oven should be operated on an independent power outlet and always verify
that the plug and socket are well-grounded.
4. Do not allow the vacuum oven to be plugged in or unplugged without firstly ensuring to
turn off the main power switch.
5. It is not permitted to lengthen, reduce or cut the power connection cord to the product.
6. Do not bake or dry any flammable, explosive, volatile, or corrosive substances in this
vacuum oven.
7. When working at temperatures above 80 °C do not touch the door, inspection window, or
surrounding surfaces of the product to prevent burns.
8. Repairs must not be carried out without prior authorization. Repairs should be
commissioned only via repair qualified and accredited professionals.
! WARNING (may cause property damage or personal injury)
9. You must read and understand all the instruction manual details for this product prior to
operation.
10. The 304 stainless steel liner is not acid resistant, please adhere to advised anti-
corrosion measures and never use acidic media within the oven.
11. Use a power outlet with a grounding wire to prevent electric shock. If the power outlet is
not grounded, a ground wire must be installed by a qualified engineering technician.
12. When pulling the power plug out from a power source, do not pull out using the power
cord directly.
13. The power plug of the vacuum oven must be ‘unplugged’ in the following instances:
•Prior to replacing the fuse tube
•In the event of a failure or breakdown an inspection or a repair is required
•When not in use for a long period
•When moving or relocating the vacuum oven

User Manual
Version 1.0 8
14. When the vacuum oven is turned on, the upper deviation alarm function must be
adjusted or confirmed.
! ATTENTION (may affect operational performance or service life)
15. Always place the vacuum oven on a hard, firm, and level surface.
16. Do not allow the door to open or close via gravity only. Always guide the door to avoid
product damage or potential injury.
17. This vacuum oven must be used and operated in accordance with the safety and user
manual conditions outlined.

User Manual
Version 1.0 9
III. Vacuum Oven –Introduction
3.1 Overview
The Hephaestus V900 vacuum oven is designed to efficiently process raw materials in a
temperature controlled vacuum environment. It is ideal for research, pilot process development
and production. This process has the following advantages:
•Lowers the drying temperature due to low pressure.
•Prevents damage caused by dirt.
•The reduced processing temperature minimizes the oxidation rate of the product
ensuring less oxidative damage.
The Hephaestus V900 vacuum oven has an inner chamber, a vacuuming system, and a
temperature-control system.
The inner chamber of the vacuum oven is constructed from high-quality 304 stainless steel and
the exterior surface of the vacuum oven is polymer-coated. The inner chamber uses either a
galvanized or stainless-steel armor plate. Fiberglass insulation is used to thermally insulate the
chamber.
The chamber door has a viewing window that allows visual inspection of the process. The
window is constructed using a double-layered fortified glass design. The door uses a heavy-duty
column door pin. The door frame uses an airproof rubber seal to prevent vacuum leaking when
closed.
Note: The rubber airproof seal is not oil-proof.

User Manual
Version 1.0 10
The power plug for the vacuum oven is shown below. The model of the power plug is L6-30P.

User Manual
Version 1.0 11
3.2 Cautions
•The shell of the vacuum oven inner chamber should be grounded to ensure safety.
•The vacuum oven should be placed in an environment with less than 85% humidity
level. Ensure that there is no strong electromagnetic fields or vibration source nearby.
•The vacuum oven is not explosive proof or corrosion proof. Combustible materials and
corrosive liquids or gases should not be placed in the vicinity of the drying chamber.
•To maximize the lifespan of the vacuum pump, do not use it for a prolonged period.
•When the chamber reaches the required vacuum, switch ‘OFF’ the vacuum pump first
and then switch ‘OFF’ the power of the vacuum pump.
•If the product is excessively damp before drying, add a “precipitation” filter between the
vacuum pump and the cabinet to avoid steam entering the pump.
•If the material for drying is light and/or small in size (e.g. grains) a net should be used
in the mouth of the vacuum pump inside the chamber to prevent any grains from
getting into the pump and causing damage to the electromagnetic valve.
•If the air release rubber stopper becomes difficult to turn, Vaseline may be used to
lubricate the contact area.
•The vacuum chamber should be always clean. The glass on the Inner chamber door
should NOT be cleaned with any chemical solutions and should only be cleaned using
a soft cotton cloth.
•Whenever the vacuum chamber is not used for a prolonged period of time, it is
recommended that all exposed plated parts be cleaned by a nonabrasive lubricant. It is
recommended that a plastic film cover be placed over the cabinets to prevent dust
from accumulating.

User Manual
Version 1.0 12
IV. Technical Specifications
Model
Parameters
10310003
Power Supply
AC 120V 60Hz
Temperature Range
(RT＋10～200) ℃
Temperature Resolution
0.1℃
Fluctuating Degree (℃)
±1℃
Attainable Vacuum Degree
133Pa
Input Power (W)
5800
Shelf (Layer)
5
Bladder Material
Stainless Steel 304 (1Cr～18Ni9Ti)
Bladder Size (mm)
750×1160×1050
Outer Size (mm)
1400×1395×2010
NOTE: “RT” refers to the ambient temperature.

User Manual
Version 1.0 13
V. Standards and Conformity
Construction in Accordance with the
following Safety Standards:
UL 61010-1:2012
CSA C22.2#61010-1-12:2012
UL 61010-2-010:2015
CSA C22.2#61010-2- 010:2015
Construction in Accordance with the
following EMC Standards:
EN 61326-1

User Manual
Version 1.0 14
VI. Inspection
6.1 Packing List
Unpack the equipment carefully and check for any damages which may have arisen during
transport. In the event of identified damage, please contact
[e-mail].
The package includes the following items:
Item Description.
Quantity.
Main Unit
1pcs
Spanner
2pcs (14*17/8*10)
Rubber Tube
1pcs (Φ14mm×0.9m)
Adapting flanges
1pcs (KF25)
Quick setup card
1pcs
Note:
If you find any visible damage on the product, please do not
connect the product to a power supply.

User Manual
Version 1.0 15
VII. Operating Instructions
7.1 Command key instructions
Description of Controller Panel Keys
1) press hold the key for 3s or more to control the run/stop of the program
2) in a mode of setup, click this key to add one number and press hold the key to
increase successively
3) in a mode of setup, click this key to decrease one number and press hold the key
to decrease successively
4) used to return in operating.
5) used to set the target temperature value and enter the internal parameter layers.

User Manual
Version 1.0 16
7.2 Functions
•F1: first layer measurement temperature
•F2: second layer measurement temperature
•F3: third layer measurement temperature
•F4: fourth layer measurement temperature
•“RUN” display of running status.
•“XX: XX” display of controller system.
•“STOP” display of set value.

User Manual
Version 1.0 17
7.3 Temperature Setting
1) When the instrument is switched on, press the button one time, and the set
temperature value will start to blink. Set the desired temperature value (in Celsius
degrees) by pressing keys.
2) The button works for a quick movement between the digits.
3) Confirm the set value with another press of the button.
Note:
Pressing the ‘ or ’ Key only once changes the value by 0.1
Press and Holding either of the keys will change a numerical value rapidly.
7.4 Start / Stop Operation
1) After setting the operating parameters, press button for about 4-5 seconds to start the
heating process. When the word “STOP” disappears on the upper right corner of the
screen, the system is in the stopped state. When the message “RUN” will appear in the
upper right comer, the system is in the running state and the system will display issues
like contemporary, timer, and temperature measured inside the chamber.
2) At any time, you can always manually stop running by pressing the button for 4-5
seconds.

User Manual
Version 1.0 18
7.5 Setting the Deviation Alarm and Timer
•On the controller panel, press and hold the key for 4-5 seconds.
•Press key to confirm, press or key to move, press key to return.
•TIMER WAIT: ON/OFF of waiting temperature. When ‘ON’ the waiting temperature is
available. When ‘OFF’ no waiting temperature is available.
•ALM Temp: Setting of Temperature Deviation Alarm: when the measured temperature >
Set Temperature +ALM TEMP, an audible alarm will sound.
•RH Temp: Setting the upper limit for Temperature Control.
•Timer: Timing Function: when the time is set as 0, the timing function is not available.
When other than 0 is applied the controller is in the ‘Timer’ function.

User Manual
Version 1.0 19
Press the key so, that Timer numerical value is backlit displayed, indicating the timer
can now be set as required, by pressing either the or key.
NOTE: If no operation is performed for a long time, the system automatically returns to the
home screen.
7.6 Setting the Pre-set Start Function
•Press and hold the key and press key, then shift the cursor to ‘START
SETUP’, and press key.
1) START TIMER: Press ‘ON’ to start the Pre-Set timer function settings
2) YEAR, MONTH,DAY,HOUR,MINUTE: Enter timer pre-set required details

User Manual
Version 1.0 20
7.7 Setting the ENGINEER SETUP
•Press and hold the key and press key, then shift the cursor to ‘ENGINEER
SETUP’, and press key, enter the password (The default is”0”), and press to
confirm. Press key to move, press key to confirm, and then press or
key to adjust.
NOTE: The parameters here are factory parameters, do not adjust (except for the system
date and password)
7.8 Unit, SYSTM Timer, and PASSWORD Settings
•Unit:”0” ℃，”1” ℉
•YY: year; MM: month; DD: day; HH: hour; MM: minute; SS: second;
(this is the apparatus system time setting)
•PASSWORD: for direct input and changing of a new password.
0: ℃
1：℉
